Abstract
The management of black water depends primarily on the knowledge of the dynamics of organic matter (OM), iron (Fe), sulfide (S), and manganese (Mn), at the water-sediment boundary (WSB). However, the mechanistic path of these substances leading to black water remains unsettled. In this study, a 35-day field study was conducted using the thin-film diffusion gradient technology (DGT) and the planar optrode to address the unknown combined effects of Fe, Mn, OM, S, and tannins from Eucalyptus species on Tianbao reservoir.
Our results indicated that the hypolimnion was hypoxic due to thermal stratification, which caused the reduction of insoluble Fe and Mn from sediments to bottom water. Correlation analysis (Fe:S (r:0.5–0.9); Mn:S (r:0.2–0.8)) and elevated fluxes (Fe2+, Mn2+, S2−) connoted that these parameters interacted chemically to give black matter. The content of OM, Fe2+, and tannic acid in the benthic region diminished remarkably (p < 0.05) from day 1 (strong stratification) to day 35 (weak stratification), connoting that these parameters also interacted chemically to give black matter. The turbidity (clarity of the water) increased from day 1 to 35 with a significant difference (p < 0.05) recorded on day 14 confirming that black water was formed on this day when the thermal structure of the reservoir was annihilated. Correlation analysis supported the assertion that the variability in oxygen and redox conditions caused changes in Fe, Mn, and OM content at the WSB.
The finding from the field research provides useful information to stakeholders on how to improve the quality of freshwater management designs.
Similar content being viewed by others
Data availability
All data generated or analyzed during this study are included in this published article (and its supplementary information files).
References
Akoto O, Gyimah E, Zhan Z et al (2019) Evaluation of health risks associated with trace metal exposure in water from the Barekese reservoir in Kumasi, Ghana. Hum Ecol Risk Assess 7039. https://doi.org/10.1080/10807039.2018.1559033
Bisutti I, Hilke I, Raessler M (2004) Determination of total organic carbon - an overview of current methods. TrAC Trends Anal Chem 23:716–726. https://doi.org/10.1016/j.trac.2004.09.003
Calviño-Cancela M, van Etten EJB (2018) Invasive potential of Eucalyptus globulus and Pinus radiata into native eucalypt forests in Western Australia. For Ecol Manag 424:246–258. https://doi.org/10.1016/j.foreco.2018.05.001
Cao J, Sun Q, Zhao D, Xu M, Shen Q, Wang D, Wang Y, Ding S (2019) A critical review of the appearance of black-odorous waterbodies in China and treatment methods. J Hazard Mater 121511. https://doi.org/10.1016/j.jhazmat.2019.121511
Chen Q, Chen J, Wang J, Guo J, Jin Z, Yu P, Ma Z (2019) In situ, high-resolution evidence of phosphorus release from sediments controlled by the reductive dissolution of iron-bound phosphorus in a deep reservoir, southwestern China. Sci Total Environ 666:39–45. https://doi.org/10.1016/j.scitotenv.2019.02.194
Davison W, Zhang H (1994) In situ speciation measurements of trace components in natural waters using thin-film gels. Nature 367:546–548. https://doi.org/10.1038/367546a0
Ding S, Sun Q, Xu D, Jia F, He X, Zhang C (2012) High-resolution simultaneous measurements of dissolved reactive phosphorus and dissolved sulfide: the first observation of their simultaneous release in sediments. Environ Sci Technol 46:8297–8304. https://doi.org/10.1021/es301134h
Engler B, Becker G, Hoffmann S (2016) Process mechanization models for improved Eucalyptus plantation management in Southern China based on the analysis of currently applied semi-mechanized harvesting operations. Biomass and Bioenergy 87:96–106. https://doi.org/10.1016/j.biombioe.2016.02.021
Ferraz Filho AC, Scolforo JRS, Mola-Yudego B (2014) The coppice-with-standards silvicultural system as applied to Eucalyptus plantations - a review. J For Res 25:237–248. https://doi.org/10.1007/s11676-014-0455-0
Gimpel J, Zhang H, Hutchinson W, Davison W (2001) Effect of solution composition, flow and deployment time on the measurement of trace metals by the diffusive gradient in thin films technique. Anal Chim Acta 448:93–103. https://doi.org/10.1016/S0003-2670(01)01323-X
Glud RN, Ramsing NB, Gundersen JK, Klimant I (1996) Planar optrodes: a new tool for fine scale measurements of two- dimensional O2 distribution in benthic communities. Mar Ecol Prog Ser 140:217–226. https://doi.org/10.3354/meps140217
Han C, Ding S, Yao L, Shen Q, Zhu C, Wang Y, Xu D (2015) Dynamics of phosphorus-iron-sulfur at the sediment-water interface influenced by algae blooms decomposition. J Hazard Mater 300:329–337. https://doi.org/10.1016/j.jhazmat.2015.07.009
Huang H, Lv Y, Sun X, Fu S, Lou X, Liu Z (2018) Rapid determination of tannin in Danshen and Guanxinning injections using UV spectrophotometry for quality control. J Innov Opt Health Sci 11:1850034. https://doi.org/10.1142/S1793545818500347
Huang J, Norgbey E, Li G, Wang J, Rainizafy M, Nkrumah PN, Takyi-Annan GE (2019) Unraveling the feeding dynamics of Chinese mitten crab-based ecosystems using carbon and nitrogen stable isotope techniques. J Consum Prot Food Saf 0123456789. https://doi.org/10.1007/s00003-019-01220-w
Huang Y, Li Y, Ji D, Nwankwegu AS, Lai Q, Yang Z, Wang K, Wei J, Norgbey E (2020) Study on nutrient limitation of phytoplankton growth in Xiangxi Bay of the Three Gorges Reservoir, China. Sci Total Environ 723:138062. https://doi.org/10.1016/j.scitotenv.2020.138062
Jiang D, Chen L, Xia N, et al (2020) Elevated atmospheric CO 2 impact on carbon and nitrogen transformations and microbial community in replicated wetland
Krueger KM, Vavrus CE, Lofton ME, McClure RP, Gantzer P, Carey CC, Schreiber ME (2020) Iron and manganese fluxes across the sediment-water interface in a drinking water reservoir. Water Res 116003:116003. https://doi.org/10.1016/j.watres.2020.116003
Li, Ding S, Yang L, Zhu Q et al (2019a) Planar optode: a two-dimensional imaging technique for studying spatial-temporal dynamics of solutes in sediment and soil. Earth-Science Rev 197:102916. https://doi.org/10.1016/j.earscirev.2019.102916
Li R, Wu Z, Li L et al (2019b) Simulation of fish migration at different water depths based on backpropagation neural network. Appl Ecol Environ Res 17:437–449
Li HT, Mao X et al (2019c) Controlling reduced iron and manganese in a drinking water reservoir by hypolimnetic aeration and artificial destratification. Sci Total Environ 685:497–507. https://doi.org/10.1016/j.scitotenv.2019.05.445
Li B, Feng M, Chen X, Wang Y, Shen Y, Wu QL (2020a) Abundant sediment organic matter potentially facilitates chemical iron reduction and surface water blackness in a Chinese deep lake. Environ Pollut 116002:116002. https://doi.org/10.1016/j.envpol.2020.116002
Li P, Yuan D, Lin K (2020b) Determination of nanomolar dissolved sulfides in water by coupling the classical methylene blue method with surface-enhanced Raman scattering detection. Spectrochim Acta Part A Mol Biomol Spectrosc 119162. https://doi.org/10.1016/j.saa.2020.119162
Liang Z, Fang W, Luo Y, Lu Q, Juneau P, He Z, Wang S (2020) Mechanistic insights into organic carbon-driven water blackening and odorization of urban rivers. J Hazard Mater 405:124663. https://doi.org/10.1016/j.jhazmat.2020.124663
Liu MM, Zhang YY, Shi K, Zhu G, Wu Z, Liu M, Zhang Y (2019) Thermal stratification dynamics in a large and deep subtropical reservoir revealed by high-frequency buoy data. Sci Total Environ 651:614–624. https://doi.org/10.1016/j.scitotenv.2018.09.215
Luo F, Li Y, Norgbey E, Li R, Ya Z, Nwankwegu AS, Lie H, Sarpong L (2020) A study on the occurrence of black water in reservoirs in Eucalyptus Plantation region. Environ Sci Pollut Res 27:34927–34940. https://doi.org/10.1007/s11356-020-09613-3
Ma WW, Zhu MX, Yang GP, Li T (2017) In situ, high-resolution DGT measurements of dissolved sulfide, iron and phosphorus in sediments of the East China Sea: Insights into phosphorus mobilization and microbial iron reduction. Mar Pollut Bull 124:400–410. https://doi.org/10.1016/j.marpolbul.2017.07.056
Menegário AA, Yabuki LNM, Luko KS, Williams PN, Blackburn DM (2017) Use of diffusive gradient in thin films for in situ measurements: A review on the progress in chemical fractionation, speciation and bioavailability of metals in waters. Anal Chim Acta 983:54–66. https://doi.org/10.1016/j.aca.2017.06.041
Norgbey E, Huang J, Hirsch V, Liu WJ, Wang M, Ripke O, Li Y, Takyi Annan GE, Ewusi-Mensah D, Wang X, Treib G, Rink A, Nwankwegu AS, Opoku PA, Nkrumah PN (2020a) Unravelling the efficient use of waste lignin as a bitumen modifier for sustainable roads. Constr Build Mater 230:116957. https://doi.org/10.1016/j.conbuildmat.2019.116957
Norgbey E, Li Y, Ya Z, Li R, Nwankwegu AS, Takyi-Annan GE, Luo F, Jin W, Huang Y, Sarpong L (2020b) High resolution evidence of iron-phosphorus-sulfur mobility at hypoxic sediment water interface: an insight to phosphorus remobilization using DGT-induced fluxes in sediments model. Sci Total Environ 724:138204. https://doi.org/10.1016/j.scitotenv.2020.138204
Qi H, Wang L, Huang Q, Hung YC (2020) Effect of organic load on the efficacy of activated persulfate in inactivating Escherichia coli O157:H7 and the production of halogenated by-products. Food Control 114:107218. https://doi.org/10.1016/j.foodcont.2020.107218
Shen Q, Liu C, Zhou Q, Shang J, Zhang L, Fan CX (2013) Effects of physical and chemical characteristics of surface sediments in the formation of shallow lake algae-induced black bloom. J Environ Sci (China) 25:2353–2360. https://doi.org/10.1016/S1001-0742(12)60325-8
Yang X, Li D, McGrouther K, Long W, Li Y, Chen Y, Lv X, Niazi NK, Song Z, Wang H (2017) Effect of Eucalyptus forests on understory vegetation and soil quality. J Soils Sediments 17:2383–2389. https://doi.org/10.1007/s11368-016-1431-4
Yang G, Wen M, Deng Y, Su X, Jiang D, Wang G, Chen Y, Chen G, Yu S (2019) Occurrence patterns of black water and its impact on fish in cutover areas of Eucalyptus plantations. Sci Total Environ 693:133393. https://doi.org/10.1016/j.scitotenv.2019.07.199
Yiping L, Fan L, Jinchuan G et al (2018) Mechanism of “black-water” occurrence in the reservoirs with Eucalyptus plantation, southern China. J Lake Sci 30:15–24. https://doi.org/10.18307/2018.0102
Acknowledgements
We are grateful to the local authorities at Tianbao reservoir for the provision of resources to conduct the experiment.
Funding
The research was supported by the National Key Research and Development Program of China (2017YFC0405203, 2016YFC0401703) and the Chinese National Science Foundation (51779072, 51809102). Further support came from the Major Science and Technology Program for Water Pollution Control and Treatment (2017ZX07204003) and Fundamental Research Funds for the Central Universities(B200204014).
Author information
Authors and Affiliations
Contributions
Conceptualization: EN, LY; methodology: EN, ZY; formal analysis and investigation: EN, AN; writing–original draft preparation: EN, GETA; writing–review and editing: LN, PB; funding acquisition: LY, EN; resources: PY, YH; supervision: RB, DA
Corresponding author
Ethics declarations
Ethics approval and consent to participate
Not applicable
Consent for publication
Not applicable
Conflict of interest
The authors declare no competing interests.
Additional information
Responsible Editor: Philippe Garrigues
Publisher’s note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Rights and permissions
About this article
Cite this article
Li, Y., Norgbey, E., Zhu, Y. et al. Iron, thermal stratification, Eucalyptus sp., and hypoxia: drivers to water blackening in southern China reservoirs. Environ Sci Pollut Res 28, 26717–26731 (2021). https://doi.org/10.1007/s11356-021-12500-0
Received:
Accepted:
Published:
Issue Date:
DOI: https://doi.org/10.1007/s11356-021-12500-0
