Neuropathological criteria of anti-IgLON5-related tauopathy


We recently reported a novel neurological syndrome characterized by a unique NREM and REM parasomnia with sleep apnea and stridor, accompanied by bulbar dysfunction and specific association with antibodies against the neuronal cell-adhesion protein IgLON5. All patients had the HLA-DRB1*1001 and HLA-DQB1*0501 alleles. Neuropathological findings in two patients revealed a novel tauopathy restricted to neurons and predominantly involving the hypothalamus and tegmentum of the brainstem. The aim of the current study is to describe the neuropathological features of the anti-IgLON5 syndrome and to provide diagnostic levels of certainty based on the presence of associated clinical and immunological data. The brains of six patients were examined and the features required for the neuropathological diagnosis were established by consensus. Additional clinical and immunological criteria were used to define “definite”, “probable” and “possible” diagnostic categories. The brains of all patients showed remarkably similar features consistent with a neurodegenerative disease with neuronal loss and gliosis and absence of inflammatory infiltrates. The most relevant finding was the neuronal accumulation of hyperphosphorylated tau composed of both three-repeat (3R) and four-repeat (4R) tau isoforms, preferentially involving the hypothalamus, and more severely the tegmental nuclei of the brainstem with a cranio-caudal gradient of severity until the upper cervical cord. A “definite” diagnosis of anti-IgLON5-related tauopathy is established when these neuropathological features are present along with the detection of serum or CSF IgLON5 antibodies. When the antibody status is unknown, a “probable” diagnosis requires neuropathological findings along with a compatible clinical history or confirmation of possession of HLA-DRB1*1001 and HLA-DQB1*0501 alleles. A “possible” diagnosis should be considered in cases with compatible neuropathology but without information about a relevant clinical presentation and immunological status. These criteria should help to identify undiagnosed cases among archival tissue, and will assist future clinicopathological studies of this novel disorder.


An intriguing progressive neurological disorder at the crossroads of autoimmunity and neurodegeneration was recently described in eight patients affected by a previously unknown disorder characterized by non-REM sleep (NREM) parasomnias, sleep apnea, and stridor [16]. All patients had serum and CSF antibodies, mainly of the IgG4 subclass, against IgLON5, a neuronal cell-adhesion molecule with unknown function. In addition, all patients had the same HLA-DRB1*1001 and HLA-DQB1*0501 haplotype, which is very rare in the normal population [16]. Although these findings suggested an autoimmune disease, the symptoms did not respond to immunotherapy. Moreover, post-mortem findings in two patients suggested a novel tauopathy restricted to neurons and predominantly involving the hypothalamus and tegmentum of the brainstem without evidence of inflammation [16]. Since then, eight additional cases have been identified (four of them reported) based on the combined recognition of the characteristic sleep disorder, presence of IgLON5 autoantibodies and, when available, demonstration of the same haplotypes described above [2, 7, 14, 17].

While these clinical, immunological, and genetic features were being established, results of the post-mortem neuropathological examination of a third patient became available confirming the initial findings of a possible novel tauopathy. Therefore, a Task Force was organized to describe in detail the neuropathological features of the disorder with the aim of developing neuropathological diagnostic criteria which should also help to identify this disease in retrospective studies of archival tissue from patients whose diagnosis was not obtained during life.

Materials and methods

The present study includes the neuropathological study of the brain of six patients. It comprises three previously reported cases, two of them from the archives of the IDIBAPS Neurological Tissue Bank, Barcelona, Spain [16] and one who had been identified and followed at the Department of Neurology, Medical University of Innsbruck, and underwent post-mortem examination at the Institute of Neurology, University of Vienna, Austria [7]. These three initial cases were comprehensively reviewed and a consensus regarding a preliminary set of neuropathological criteria was established. Based on these criteria two additional patients from Queen Square Brain Bank and the Division of Neuropathology, UCL Institute of Neurology, University College London, UK and a third one from the Institute of Pathology of the University of Ljubljana, Slovenia, were identified. Clinicopathological data of two of these patients who had died several years before the discovery of the anti-IgLON5 syndrome, were described as single case reports [13, 15].

In order to establish the neuropathological diagnostic criteria a meeting was held by four neuropathologists (EG, RH, GGK, TR), who were familiar with all of the six cases. Using a multi-header microscope the cases were re-evaluated and the histological features required for the neuropathological diagnosis of this novel tauopathy were agreed on by consensus. Subsequently, these neuropathological criteria along with clinical, immunological, and HLA haplotype findings were used by all the investigators [neuropathologists and clinicians (JD, FG, JS, BH)] to define three diagnostic levels of disease: “possible”, “probable”, and “definite”.

All six brains were processed according to standard neuropathological procedures. Formalin-fixed and paraffin-embedded tissue blocks representing frontal, temporal, parietal and occipital cortices, caudate, lenticular nucleus, hypothalamus, thalamus, hippocampus, parahippocampal gyrus, amygdala, midbrain, pons, medulla oblongata, spinal cord, and cerebellum were retrieved from the archives of the four centers and were cut as 5 μm thick sections. Sections were stained with haematoxylin and eosin method and in selected cases and areas tissue sections were also stained with Bielschowsky’s or Gallyas silver impregnation and Luxol-fast-blue/cresyl violet method. For immunohistochemistry a panel of primary antibodies was used in each laboratory (Table 1). Cases 1 and 2 were processed in Barcelona, case 3 in Vienna, case 4 originally in Ljubljana and later in Vienna, and cases 5 and 6 in Preston and London.

Table 1 Antibodies used for neuropathological characterization


The main clinical and immunological characteristics of the six patients are summarized in Table 2. Three patients were male and the median age at the onset of symptoms was 53 years (range 48–77 years). The three patients diagnosed in life with positive IgLON5 antibodies were studied with video-polysomnography and presented a unique temporal sequence of sleep stages and behaviors, from very abnormal at the beginning of the night to close to normal by the end. The initiation and re-entering of sleep after awakening were characterized by undifferentiated non-rapid eye movement (NREM) sleep with frequent vocalizations, stereotyped movements, and finalistic behaviors (parasomnias). The REM sleep was present but only in the form of REM sleep behavior disorder. In addition, most patients had a sleep breathing disorder characterized by stridor and obstructive sleep apnea.

Table 2 Clinical features of the six patients

The clinical history of the three patients in whom IgLON5 antibodies were not tested was dominated by bulbar dysfunction and repetitive episodes of respiratory insufficiency that required tracheostomy or multiple admissions to ICU. Other symptoms included gait instability, frequent falls, dysphagia, gaze palsies, central hypoventilation, dysautonomia, and chorea. These symptoms can suggest other diagnoses such as progressive supranuclear palsy or multiple system atrophy, although no parkinsonian signs were present. In none of these patients was the sleep formally studied, but in two of the cases symptoms of excessive daytime sleepiness, stridor, sleep apnea or parasomnia were documented (Table 2).

Table 3 summarizes the neuropathological features of the six cases. The detailed neuropathological reports of the two cases not previously reported and the re-evaluation of the previously published UK case [13] are presented below.

Table 3 Neuropathological characteristics including topographical distribution of hyperphosphorylated tau pathology

Case 3 (Vienna–Innsbruck, Austria)

Detailed clinical information of the disease course has been previously reported [7] and is summarized in Table 2. Post-mortem examination of the cerebrum was performed after obtaining informed consent from the next of kin. Gross examination showed mild atrophy of superior cerebellar peduncles and brainstem tegmentum. Histology revealed a prominent tauopathy, characterized by numerous Gallyas-positive neurofibrillary tangles (NFT), diffuse granular cytoplasmic phospho-tau (pTau) immunoreacitivity (pretangles), and neuropil threads involving predominantly the hypothalamus, zona incerta, hippocampus, tegmentum of brainstem (mesencephalon, pons and medulla), and cervical spinal cord (Table 3; Fig. 1) in a symmetrical fashion. The hippocampus showed a high density of NFT and pretangles in the pyramidal cell layer (Fig. 2a), accentuated in the CA2 and CA4 sectors, and moderate amounts of pretangles in the dentate gyrus. Only occasional ghost tangles were detected. The pathology in the midbrain, pons, and medulla oblongata was mainly restricted to the tegmentum including periaqueductal gray matter, laterodorsal tegmental nucleus, pedunculopontine nuclei, median raphe nuclei, dorsal motor nucleus of the vagus nerve, nucleus ambiguus and neurons of the magnocellular nucleus (Fig. 2c). Substantia nigra was only mildly affected, and the subthalamic nucleus and basis pontis showed isolated threads and pretangles (Fig. 2d). The inferior olivary nucleus was well preserved but had frequent clusters of fine threads surrounding individual neurons (Fig. 2e). The cerebellar cortex was globally well preserved, but showed a fine granular synaptic-like pTau immunoreactivity pattern involving the glomerula of the granular cell layer of the vermis (Fig. 2f). In addition, a few Purkinje cells showed diffuse cytoplasmic pTau positivity. There was a prominent involvement of the cervical spinal cord with marked pTau pathology in the dorsal horns and lesser involvement of the anterior horns (Fig. 1j), with decreasing intensity further caudally in the lumbar spinal cord, where pathology became less evident but was still visible in the dorsal horn. pTau immunoreactivity was almost entirely confined to neurons and the tau-positive structures were also labeled with both, the 3R-tau (Fig. 2h) and 4R-tau (Fig. 2i) antibodies. All these areas showed moderate microglial activation. Neuronal loss correlated with the presence of NFT. The cranial nerves were not affected. Only very occasional coiled bodies and tau-positive granular fuzzy astrocytes were visible in the hypothalamus, substantia nigra, and anterior horn of the spinal cord. Other morphological alterations included a few ballooned neurons in the amygdala. Anti-LCA revealed only a few meningeal and perivascular leukocytes mainly composed of CD3 and CD8 positive T cells and a few CD20 and CD79A B cells in the hypothalamus, brainstem, and cerebellum without any parenchymal involvement that could suggest an inflammatory process. No obvious IgG4 deposits were detected, except for a faint staining of the cerebellar glomerula of the vermis (data not shown). Complement deposits were not visible.

Fig. 1
figure 1

Distribution of tau related pathology in case 3. Coronal sections through the substantia innominata and hypothalamus (a), thalamus with nucleus ruber and substantia nigra (b), cerebellum with pons (c), higher magnification of hippocampus (d, e), pons (f), medulla oblongata at the level of olivary nucleus (g, h), cerebellar cortex (i), and cervical spinal cord (j, k). The tau pathology predominantly affects the hypothalamus, substantia innominata (a), zona incerta, hippocampus (b), and the tegmentum of the brain stem (c); Tangles and threads are abundantly present in the pyramidal layer with the highest density in the CA2 sector (d). Pretangles are also present in the dentate gyrus (rectangle in d enlarged in e). High densities of tangles and threads are present in the tegmentum of pons (f) and medulla oblongata (g). Bush-like delicate processes accumulating around neurons are visible in the olivary nucleus (rectangle in g enlarged in h). Grain-like processes are mainly found in the vermis of the cerebellar cortex, occasionally, a few Purkinje cells show a cytoplasmic tau immunoreactivity (rectangle in c enlarged in i). Moderate tau pathology is apparent mainly in the dorsal horn of the spinal cord (j, enlarged in k)

Fig. 2
figure 2

Morphology of tau related pathology in case 3. pTau related pathologies include NFT and pretangles (a CA2 sector of the hippocampus; b substantia innominata), diffuse fine granular cytoplasmic immunoreactivity (c gigantocellular nucleus of reticular formation), and numerous somato-synaptic immunoreactivity in the brain stem nuclei (d hypoglossal nucleus), bush-like delicate processes accumulating around neurons (e olivary nucleus), fine granular synaptic-like-deposits (f cerebellar cortex) and long coarse and fine threads (g substantia innominata). These immunomorphologies stain positive for three-repeat- (h) and four-repeat (i) tau isoforms. ag: AT8 ×400; h: 3RT ×400; i: 4RT ×400

Case 5 (London, UK)

A 48-year-old man developed recurrent vertigo and marked involuntary fidgety movements. At the age of 53 he developed breathing and swallowing difficulties. Multiple episodes of aspiration pneumonia and respiratory arrests warranted four admissions to the intensive care unit and, on two occasions, intubation for ventilator support was required. Due to recurrent aspiration, a gastrostomy tube was inserted for feeding. One year later, he developed progressive difficulties with his balance and intermittent diplopia. He had lateral and upgaze nystagmus with limitation of vertical and abduction eye movements. There was cerebellar dysarthria, finger-nose dysmetria, and he was unable to tandem walk. Choreiform movements were present in all limbs. Deterioration in excessive daytime somnolence caused him to fall asleep even when he was standing. His wife reported that his breathing pattern changed as soon as he was asleep but no abnormal movements were noted. During a hospital admission to investigate his sleep attacks, he had a respiratory arrest and died at the age of 60.

Neuropathological examination was performed after appropriate written informed consent from the next of kin had been obtained. Consent for the use of this case for research purposes was also given. The brain was macroscopically unremarkable. Microscopic studies showed an increase in number of reactive astrocytes in the striatum and globus pallidus. There was some loss of neurons with accompanying astrogliosis in the dorsolateral aspect of the subthalamic nucleus while the substantia nigra was well populated with pigmented and non-pigmented neurons. There was some reduction of the height of the pontine tegmentum, which was marked in the medulla oblongata. Tau immunohistochemistry using the AT8 antibody demonstrated only occasional NFT and pretangles in neocortical areas. All hippocampal subregions were affected by neuronal tau pathology; there were moderate numbers of pretangles and NFT in the CA1 hippocampal subregion, which were sparse in the CA3 and CA4 subregions. There were frequent pretangles in CA2 and also in the granule cells of the dentate gyrus, which were ubiquitin and p62-negative. Fine neuropil threads were present in all hippocampal subregions. The tau pathology was similar, but mild in the subiculum while moderate numbers of Gallyas-positive NFT and neuropil threads were seen in the entorhinal cortex. There were scattered tau-positive neuropil threads, pretangles and occasional NFT in the striatum. Similar, but slightly more severe pTau pathology was seen in the globus pallidus. The subthalamic nucleus contained moderate numbers of pretangles, NFT and neuropil threads. A conspicuous feature was the severe tau deposition in the posterior hypothalamus and brainstem structures. In the midbrain a significant proportion of the substantia nigra pars compacta neurons showed granular or dot-like tau positivity, which was also seen in neuronal processes. Similar tau pathology was seen in the midbrain tegmentum, periaqueductal gray matter and tectum. The majority of the neurons of the otherwise well-populated locus coeruleus contained similar neuronal tau-positive inclusions and the pontine tegmentum and base were also extensively affected by similar tau pathology. The tau deposition was particularly severe in the tegmentum of the medulla including the dorsal motor nucleus of the vagus nerve, nucleus tractus solitarius, nucleus ambiguus and neurons of the magnocellular nucleus were severely affected. In the inferior olive neurons were often surrounded by a meshwork of fine tau-positive processes and dot-like tau positivity. There were scattered pretangles and NFT, neuropil threads and clusters of fine tau-positive dots in the cerebellar dentate nucleus. There was rather widespread granular tau positivity in the cerebellar cortex and an occasional Purkinje cell showed fine, dot-like tau positivity. Differential tau immunohistochemistry confirmed that the pTau deposits were composed of both 3R-tau and 4R-tau isoforms.

Case 6 (London, UK)

For clinical history and the distribution of the NFT pathology see Lidov et al. [13]. Tau immunohistochemistry with the AT8 antibody was carried out using tissue sections of paraffin blocks available in the archives of the Division of Neuropathology, UCL Institute of Neurology. The distribution of the pTau pathology, including involvement of the hippocampus was rather similar to that described in case 5. However, there were some differences, which included that in this case the striatum was virtually devoid of tau pathology and the involvement of the globus pallidus and subthalamic nucleus was considerably milder than that observed in case 5. The brainstem tegmentum showed severe deposition of disease-associated tau in a distribution as described above, but the substantia nigra and pontine base showed only sparse tau-positive pretangles, NFT and neuropil threads. There was tau pathology of moderate degree in the posterior horns of the cervical and thoracic cord (these were the levels that were available for review) and sparse neuropil threads and occasional NFT were also seen in the anterior horns. Occasional tau-positive granular deposits were found in the cerebellar cortex. The tau inclusions were both 3R-tau and 4R-tau immunoreactive.

Summary of neuropathological features and suggested neuropathological criteria

The neuropathological findings in the six patients showed remarkable similarity consistent with a neurodegenerative disease with neuronal loss and gliosis, without the presence of inflammatory infiltrates. The most relevant finding was a prominent neuronal accumulation of pTau, comprising both 3R-tau and 4R-tau isoforms, involving the hypothalamus and more severely the tegmental brainstem nuclei, with a cranio-caudal gradient of severity, reaching the upper cervical cord. The cerebral cortex, basal ganglia, thalamus and subthalamic nucleus were mostly unaffected or mildly affected. In five cases the entorhinal cortex and hippocampus were also affected including dentate gyrus and CA4 to CA1 sectors, with variable involvement of transentorhinal region. Interestingly, CA2 sector was consistently involved. There was a lack of glial tau pathology except for the presence of isolated coiled bodies and granular fuzzy astrocytes in the hypothalamus and amygdala in cases 3 and 4. A detailed semiquantitative assessment of pTau pathology in different brain areas of all cases is represented in Table 3 and Fig. 3 shows a schematic heat-map representation of the distribution and severity of pTau pathology throughout the brain for all cases.

Fig. 3
figure 3

Schematic distribution of tau pathology in anti-IgLON5 related tauopathy. Coronal sections through the amygdala and the lateral geniculate body (a), midbrain (b), pons (c), medulla oblongata [level of olivary nucleus (d) and decussation of pyramids (e)], and cervical spinal cord (f). Scoring of the frequency of tau pathology in sections stained with tau AT8 is based on the number of tangles and threads: red many; orange moderate; orange dots moderate/few; green dots few; and blue dots isolated. A nucleus ambiguus, AC anterior commissure, Amy amygdala, CA anterior horn, CC crus cerebri, CI inferior colliculus, CN cuneate nucleus, CP posterior horn, ER entorhinal cortex, F fornix, GP pallidum, GN gracile nucleus, HC hippocampus, Hyp hypothalamus, LC locus coeruleus, LTN laterodorsal tegmental nucleus, NPB parabrachial nuclei, NS solitary nucleus, ON olivary nucleus, P putamen, PAG periaquaeductal gray, PI pars intermedia, PPN pedunculopontine nucleus, RU nucleus ruber, R raphe nucleus, RF reticular formation, RF(Gi) gigantocellular reticular nucleus, SG substantia gelatinosa, SI substantia innominata, SN substantia nigra, SNT nucleus of spinal tract of trigeminal nerve, STN subthalamic nucleus, TS solitary tract, V trigeminal nucleus, VIII inf inferior vestibularis nucleus, VIII med medial vestibularis nucleus, X dorsal nucleus vagal nerve, XI spinalis spinal accessory nucleus, XII hypoglossal nucleus, ZI zona incerta

There were no other abnormal deposits of proteins, or if present these were mild and localized in a few areas suggesting the co-existence of other neurodegenerative or age-related pathologies. Case 2 showed isolated Bunina bodies and TDP43 protein aggregates in few brainstem and motor neurons in the spinal cord. A few neuritic plaques were observed in cases 2, 4, and 6, along with cerebral amyloid angiopathy in cases 2 and 4. Case 4 additionally showed scattered alpha-synuclein positive Lewy bodies and Lewy neurites in the substantia nigra and dorsal nucleus of the vagus nerve and argyrophilic grain pathology, and case 5 showed sparse neuronal cytoplasmic TDP43 protein inclusions in the granule cells of the dentate gyrus.

Based on the similarities of these cases we propose research criteria for the neuropathological diagnosis of the tauopathy underlying the anti-IgLON5 syndrome (Table 4) and recommend a protocol of tissue sampling (Table 5). When a neuropathologist is confronted with a case with such a neuropathological phenotype in conjunction with positive IgLON5 antibodies in CSF or serum, the diagnosis of “definite anti-IgLON5-related tauopathy” should be considered. In contrast, when the information of the anti-IgLON5 antibodies status is missing but the clinical history is compatible or the patient harbored the HLA-DRB1*1001 and HLA-DQB1*0501 alleles, then the diagnostic category of “probable anti-IgLON5-related tauopathy” should be applied. The category of “possible anti-IgLON5-related tauopathy” should be reserved for those cases where clinical data are not available (e.g. due to the retrospective identification of archival cases or other reasons) and ancillary tests (anti-IgLON5 antibodies and/or HLA-DRB1*1001 and HLA-DQB1*0501 alleles) could not be performed. Note that both the HLA genotyping and the anti-IgLON5 antibody assay could be done post-mortem from DNA samples and serum or ventricular CSF, respectively. No exclusion criteria have been proposed as the whole spectrum of pathological changes and possible concomitant pathologies are yet unknown.

Table 4 Proposed neuropathological criteria to define the tauopathy underlying the anti-IgLON5 syndrome
Table 5 Recommended minimal sampling protocol for the diagnosis of anti-IgLON5 related tauopathy


We report here the main neuropathological features underlying the anti-IgLON5 syndrome that are different from those of other tauopathies [4, 11]. The three main findings are (1) the subcortical topographical distribution of the tau pathology with predominant involvement of the hypothalamus and brainstem tegmentum, with a rostro-caudal gradient of severity to include the upper cervical cord, (2) the nearly exclusive neuronal tau pathology with little or no involvement of glia and the white matter, and (3) composition of disease-associated tau of both 3R-tau and 4R-tau isoforms.

We propose that the tauopathy underlying the anti-IgLON5 syndrome can be diagnosed with three levels of probability: definite, probable, and possible. Accordingly, for example the previously reported case by Kaphan et al. [10] would fulfill criteria of “probable” anti-IgLON5-related tauopathy as the neuropathological findings and clinical features are supportive of the diagnosis. We believe that these neuropathological features present in our six cases make this entity unique and the tau pathology seen did not meet the diagnostic criteria of any of the known primary tauopathies. In our cases the neuronal tau pathology showed a characteristic distribution with preferential involvement of the hypothalamus, tegmentum of the midbrain, pons, and medulla oblongata, which affected the periaqueductal gray matter, laterodorsal tegmental nucleus, pedunculopontine nucleus, median raphe nucleus, dorsal motor nucleus of the vagus, nucleus ambiguus, and the magnocellular nuclei of reticular formation with only mild or no involvement of substantia nigra and inferior olivary nucleus. These areas have been implicated in sleep regulation and correlate well with clinical symptoms of the patients [5]. There is additional involvement of the spinal cord with neuronal accumulation of pTau in the dorsal horns, and to a lesser extent, in the anterior horns. The tau pathology also shows a cranio-caudal gradient in that the cervical spinal cord is more severely affected than the lumbar cord. Discrete fine granular tau immunoreactivity is also observed in glomerula of the granular cell layer of the cerebellar cortex in the vermis. In addition, a few Purkinje cells may show diffuse cytoplasmic pTau positivity.

This condition has distinct microscopic appearances allowing its differentiation from other ‘primary’ tauopathies, although the topographical distribution of the tau pathology is, to some extent, reminiscent of that seen in progressive supranuclear palsy (PSP). Indeed, one post-mortem case has been previously reported as “early” PSP [10] and another case clinically mimicking PSP and with serum—but not CSF—IgLON5 antibodies has been described [2]. However, the anti-IgLON5-related tauopathy can clearly be differentiated from PSP, even from its variants with more restricted tau pathology [4, 18] or other 4R tauopathies such as corticobasal degeneration (CBD) [4], globular glial tauopathies (GGT) or argyrophilic grain disease (AgD) by the morphological patterns of the tau pathology, including the absence of glial pathology (tufted astrocytes or coiled bodies), and sparse supratentorial and basal ganglia involvement [11]. A severe brainstem involvement clinically causing REM sleep behavior disorder, stridor, respiratory insufficiency and death during sleep, cerebellar dysfunction including nystagmus and limb/gait ataxia, and autonomic dysfunction is also seen in multiple system atrophy, which is associated with alpha-synuclein accumulation in glial cytoplasmic inclusions and less frequently neuronal cytoplasmic and nuclear inclusions [8].

As in Alzheimer’s disease, the tau filaments seen in the anti-IgLON5 syndrome ultrastructurally appear as paired helical filaments [13] and the differential tau immunohistochemistry confirms that they are composed of both 3R-tau and 4R-tau isoforms. In addition to Alzheimer’s disease, tau inclusions composed of both 3R-tau and 4R-tau isoforms occur also in several other disorders such as postencephalitic parkinsonism, chronic traumatic encephalopathy, Parkinson-dementia complex of Guam, and FTDP-17 due to MAPT mutations. However, these disorders frequently have glial involvement, show different topographical distribution of abnormalities, and present with different clinical syndromes [11].

In addition to the prominent brainstem involvement, five of the six patients had neuronal tau pathology in the hippocampus with frequent pretangles in CA4 and CA2 sector, and NFT in CA1 sector and entorhinal cortex, with variable involvement of transentorhinal region, and ring-shaped pretangles in the granule cells of the dentate gyrus. Selective involvement of CA2 sector has been reported to occur more frequently in 4R-tauopathies [9]. The tau distribution was however more similar to that described in primary age-related tauopathy (PART) [3] which is considered a common pathology associated with human aging. More neuropathological studies are needed to clarify whether the hippocampal involvement in our patients indicates the presence of an associated PART as an accelerated aging or is part of the neuropathological signature of anti-IgLON5-related tauopathy. The prominence of hippocampal pTau pathology and its extension beyond the boundaries of the medial temporal lobe in relatively young patients (mean age 68.2) argues for the latter possibility. The mild to moderate involvement of the locus coeruleus might also reflect an age-related process, since this has been reported as another site of early tau hyperphosphorylation and accumulation (pretangle stage) even before puberty or in early young adulthood [1]. Similarly, occasional coiled bodies and tau-positive fuzzy astrocytes observed in one case suggest the presence of a mild aging-related tau astrogliopathy (ARTAG) [12].

The most intriguing aspect of the disease is the association of neuropathological findings suggesting a non-inflammatory degenerative process with the presence of highly specific antibodies against IgLON5 (a neuronal cell-adhesion molecule) and a strong association with the HLA system. A possible mechanism that could explain tau hyperphosphorylation and accumulation in neurons might relate to one of the functions of IgLON family as glucosyl-phosphatidyl-inositol anchored proteins and its role in membrane stabilization [6]. An antibody-induced dysfunction of IgLON5 may disrupt the interaction of this protein with the internal cytoskeletal network, de-stabilize the neuronal microtubular system and induce hyperphosphorylation and accumulation of the microtubule-associated protein tau, leading to neuronal dysfunction and ultimately to neurodegeneration. The distribution of pTau pathology could raise the possibility of a trans-synaptic spread of tau from selectively vulnerable neuronal populations by neuronal connectivity, i.e. from several brainstem nuclei (e.g. dorsal raphe, reticular formation, locus coeruleus), caudally to posterior and intermediate spinal cord gray matter and rostrally to hypothalamic nuclei, although no overt involvement of other interconnected areas has been observed (e.g. amygdala, striatum, thalamus, neocortex) (supplementary Fig. 1).

However, the intriguing coexistence of neuropathological and immunological findings and the precise mechanism of the cross-talk between these two potential pathogenic mechanisms need to be elucidated.

In summary, since the publication of two cases of a novel, brainstem accentuated neuronal 3R and 4R tauopathy associated with IgLON5 autoantibodies in patients with apnea and NREM parasomnia, a new case has been confirmed in Austria and three additional cases, one from Slovenia and two from the UK have been retrospectively identified on the basis of their nearly identical neuropathological phenotype. We suggest including these cases under the umbrella term of a single clinicopathological entity termed “anti-IgLON5-related tauopathy”. To facilitate communication with clinicians and researchers and to provide a framework for future clinicopathological and research studies we propose here research criteria for the neuropathological diagnosis of this unique tauopathy and recommend a protocol for tissue sampling. This information could also be of value in the re-evaluation of archival cases. Clearly, the recognition of more cases will be of utmost importance to identify the entire spectrum of the clinicopathological presentation and to elucidate the role of IgLON5 antibodies in initiating a cellular cascade finally resulting in abnormal hyperphosphorylation, aggregation and accumulation of tau. Only a better understanding of this interplay can result in the design of appropriate treatment strategies that can modify disease progression and consequently mitigate the risk of sudden death during sleep.


  1. Braak H, Thal DR, Ghebremedhin E, Del Tredici K (2011) Stages of the pathologic process in Alzheimer disease: age categories from 1 to 100 years. J Neuropathol Exp Neurol 70:960–969

    CAS  Article  PubMed  Google Scholar

  2. Brüggemann N, Wandinger KP, Gaig C, Stöcker W, Junghanns K, Helmchen C et al (2016) Dystonia, lower limb stiffness and upward gaze palsy in a patient with IgLON5 antibodies. Mov Disord 31:762–764

    Article  PubMed  Google Scholar

  3. Crary JF, Trojanowski JQ, Schneider JA, Abisambra JF, Abner EL, Alafuzoff I et al (2014) Primary age-related tauopathy (PART): a common pathology associated with human aging. Acta Neuropathol 128:755–766

    CAS  Article  PubMed  PubMed Central  Google Scholar

  4. Dickson DW, Hauw JJ, Agid Y, Litvan I (2011) Progressive supranuclear palsy and corticobasal degeneration. In: Dickson DW, Weller RO (eds) Neurodegeneration: the molecular pathology of dementia and movement disorders, 2nd edn. Wiley–Blackwell Publishers, New York, pp 135–155

    Chapter  Google Scholar

  5. Dutschmann M, Menuet C, Stettner GM, Gestreau C, Borghgraef P, Devijver H et al (2010) Upper airway dysfunction of Tau-P301L mice correlates with tauopathy in midbrain and ponto-medullary brainstem nuclei. J Neurosci 30:1810–1821

    CAS  Article  PubMed  Google Scholar

  6. Hashimoto T, Yamada M, Maekawa S, Nakashima T, Miyata S (2008) IgLON cell adhesion molecule Kilon is a crucial modulator for synapse number in hippocampal neurons. Brain Res 1224:1–11

    CAS  Article  PubMed  Google Scholar

  7. Högl B, Heidbreder A, Santamaria J, Graus F, Poewe W (2015) IgLON5 autoimmunity and abnormal behaviours during sleep. Lancet 385:1590

    Article  PubMed  Google Scholar

  8. Holton JL, Lees AJ, Revesz T (2011) Multiple system atrophy. In: Dickson DW, Weller RO (eds) Neurodegeneration: the molecular pathology of dementia and movement disorders, 2nd edn. Wiley–Blackwell Publishers, New York, pp 242–252

    Chapter  Google Scholar

  9. Ishizawa T, Ko LW, Cookson N, Davias P, Espinoza M, Dickson DW (2002) Selective neurofibrillary degeneration of the hippocampal CA2 sector is associated with four-repeat tauopathies. Neuropathol Exp Neurol 61:1040–1047

    CAS  Article  Google Scholar

  10. Kaphan E, Pellissier JF, Rey M, Robert D, Auphan M, Ali Chérif A (2008) Esophageal achalasia, sleep disorders and chorea in a tauopathy without ophthalmoplegia, parkinsonian syndrome, nor dementia (progressive supranuclear palsy?): clinicopathological study. Rev Neurol (Paris) 164:377–383

    CAS  Article  Google Scholar

  11. Kovacs GG (2015) Neuropathology of tauopathies: principles and practice. Neuropathol Appl Neurobiol 41:3–23

    CAS  Article  PubMed  Google Scholar

  12. Kovacs GG, Ferrer I, Grinberg LT, Alafuzoff I, Attems J, Budka H et al (2016) Aging-related tau astrogliopathy (ARTAG): harmonized evaluation strategy. Acta Neuropathol 131:87–102

    CAS  Article  PubMed  Google Scholar

  13. Lidov HG, Duchen LW, Thomas PK, Thrush DC (1989) Progressive medullary failure associated with neurofibrillary degeneration. J Neurol Neurosurg Psychiatry 52:643–647

    CAS  Article  PubMed  PubMed Central  Google Scholar

  14. Montojo MT, Piren V, Benkhadra F, Codreanu A, Wirtz G, Kerschen P et al (2015) Mimicking progressive supranuclear palsy and causing Tako-Tsubo syndrome: a case report on IgLON5 encephalopathy [abstract]. Mov Disord 30(Suppl 1):710

    Google Scholar

  15. Pretnar-Oblak J, Zaletel M, Hajnsek TM, Meglic B, Hocevar-Boltezar I, Popovic M (2010) Isolated bulbar paralysis in a patient with medullar tau pathology: a case report. J Neurol Neurosurg Psychiatry 81:847–849

    CAS  Article  PubMed  Google Scholar

  16. Sabater L, Gaig C, Gelpi E, Bataller L, Lewerenz J, Torres-Vega E et al (2014) A novel non-rapid-eye movement and rapid-eye-movement parasomnia with sleep breathing disorder associated with antibodies to IgLON5: a case series, characterisation of the antigen, and post-mortem study. Lancet Neurol 13:575–586

    CAS  Article  PubMed  PubMed Central  Google Scholar

  17. Simabukuro MM, Sabater L, Adoni T, Cury RG, Haddad MS, Moreira CH et al (2015) Sleep disorder, chorea, and dementia associated with IgLON5 antibodies. Neurol Neuroimmunol Neuroinflamm 2:e136

    Article  PubMed  PubMed Central  Google Scholar

  18. Williams DR, Holton JL, Strand C, Pittman A, de Silva R, Lees AJ et al (2007) Pathological tau burden and distribution distinguishes progressive supranuclear palsy-parkinsonism from Richardson’s syndrome. Brain 130:1566–1576

    Article  PubMed  Google Scholar

Download references


We thank brain donors and their families for generous brain donation for research. We are indebted to the Neurological Tissue Bank of the IDIBAPS Biobank, Institute of Neurology of the Medical University of Vienna Neurobiobank, Lubljana Pathology Department and Queen Square Brain Bank for data and sample procurement. We are grateful to Nora Löwy and Valerie Pichler (Institute of Neurology,Vienna), Marija Zupančič and Dane Velkavrh in Lubljana, Sara Charif and Veronica Santiago (IDIBAPS Barcelona Biobank) for excellent technical support. Queen Square Brain Bank is supported by Reta Lila Weston Institute for Neurological Studies and the Medical Research Council UK. This research was supported by the National Institute for Health Research University College London Hospitals Biomedical Research Centre. This research was also partly supported by the National Institute for Health Research (NIHR) Queen Square Biomedical Research Unit in Dementia based at University College London Hospitals, University College London. The views expressed are those of the author(s) and not necessarily those of the NHS, the NIHR or the Department of Health. TR is also supported by a grant from CBD Solutions.

Author information

Authors and Affiliations


Corresponding author

Correspondence to Tamas Revesz.

Ethics declarations


This study was partly supported by grants from Fundació Marató de TV3 to EG (grant no. 20141610), Fondo de Investigaciones Sanitarias, FEDER, (FIS 15/00377, FG), (FIS 14/00203, JD) and CIBERER (JD), Madrid, Spain, Fundació CELLEX (JD), and NIH RO1NS077851 (JD).


JD receives royalties from licensing fees to Athena diagnostics for a patent for the use of Ma2 and autoantibody test, and from licensing fees to Euroimmun for patents for the use of NMDAR and GABAbR as autoantibody tests, and licensing fees for the use of DPPX, GABAaR, and IgLON5 antibodies as diagnostic tests. JD has received a research grant from Euroimmun. FG receives royalties from licensing fees to Euroimmun for the use of IgLON5 as a diagnostic test.

Conflict of interest

EG, RH, HL, JH, TD, MP, JP, BH, GR, JS, HB, TR, GK declare that they have no conflict of interest.

Additional information

E. Gelpi and R. Höftberger contributed equally.

Electronic supplementary material

Below is the link to the electronic supplementary material.


Supplementary Figure 1: Simplified schematic representation of neuroanatomical pathways connecting different brainstem nuclei upwards and downwards by which a trans-synaptic propagation of IgLON5-related pathology could be postulated. Gray shaded boxes indicate nearly non-affected areas. (TIFF 23576 kb)
