Abstract
Groundwater economic models have refined optimal extraction rules while lagging behind in the study of optimal spatial policies. This paper develops a theoretical model to estimate welfare gains from optimal groundwater management when the choice variable set is expanded to include well location decisions as well as optimal groundwater extraction paths. Our theoretical results show that if there is spatial heterogeneity in groundwater, the welfare gains from optimal location of wells are substantial even if extraction rates are unregulated. Furthermore, second-best economically defined spacing regulations may possibly have better efficiency results (and lower implementation costs) than first-best uniform taxes or quotas. An application of the model to a real-world aquifer shows the importance of including well location decisions in spatially differentiated groundwater models and the need for (1) robust estimates of the gains from optimal management and; (2) spatially explicit regulations.
Similar content being viewed by others
Notes
The location of a well affects the feasible capacities and locations for the rest of wells. Even if Ω is a convex set, once any well is located, the remaining feasible set is non-convex. The non-convex nature of the problem prevents us from solving it by conventional optimization methods. In order to surpass the non-convexity of the problem and attain an analytical solution, we set the feasible region Ω to be a convex set and allow wells to be, in principle, arbitrarily close to one another. Although, in a more realistic setting well location decisions would be limited by land ownership, we exclude this type of spatial restrictions from the present study to keep the model tractable.
We also assumed that net benefits decrease at least linearly with head loss and falling extraction rates,.
The calculation can be simplified when: (i) the objective functional and state dynamics are linear in the state; (ii) they are no cross-terms involving control and state variables; and (iii) a small and fixed number of users is considered.
The model was calibrated with regional hydrogeological studies and a trial-and-error method that compared observed and simulated water drawdown at several spatial points. A sensitivity analysis was conducted on the value of regional hydraulic conductivity. A 100 % increase in the value assumed did not result in significant changes on water table levels throughout the region (Charlesworth et al. 2008).
References
Andre FJ (2009) Intertemporal and spatial location of disposal facilities. Span Econ Rev 11(1):23–49
Athanassoglou S, Sheriff G, Siegfried T, Huh W (2011) Optimal mechanisms for heterogeneous multi-cell aquifers. Environ Resour Econ. doi:10.1007/s10640-011-9528-0
Barbazza C (2006) Acuifero Guarani. Analisis economico del reuso del agua termal en actividades productivas: Salto -Uruguay (Guarani Aquifer. Economic analysis of thermal water reuse in productive activities: Salto-Uruguay), Project for the environmental protection and sustainable development of the Guarani Aquifer System. The World Bank, Montevideo
Bockstael NE (1996) Modeling economics and ecology: the importance of a spatial perspective. Am J Agr Econ 78(5):1168–1180
Bredehoeft JD, Young RA (1970) The temporal allocation of groundwater: a simulation approach. Water Resour Res 6(1):3–21
Brill TC, Burness HS (1994) Planning versus competitive rates of groundwater pumping. Water Resour Res 30(6):1873–1880
Brouwer R, Hofkes M (2008) Integrated hydroeconomic modeling: approaches, key issues and future research directions. Ecol Econ 66:16–22
Brown G, Deacon R (1972) Economic optimization of a single-cell aquifer. Water Resour Res 8(3):557–564
Brozovic N, Sunding DL, Zilberman D (2006) Optimal management of groundwater over space and time. In: Goetz RU, Berga D (eds) Frontiers in Water Resource Economics. Springer, New York, pp 109–136
Brozovic N, Sunding DL, Zilberman D (2010) On the spatial nature of the groundwater pumping externality. Resour Energy Econ 32(2):154–164
Burchi S (1999) National regulations for groundwater: options, issues and best practices. In: Salman SMA (ed) Groundwater: legal and policy perspectives. Proceedings of a World Bank seminar. The World Bank, Washington D.C., pp 55–67
Burt OR (1967) Temporal allocation of groundwater. Water Resour Res 3(1):45–56
Burt OR (1970) Groundwater storage control under institutional restrictions. Water Resour Res 6(6):1540–1548
Castagnino G (2008) ESE- Reuso efluente termal. Proyecto Piloto Salto-Concordia (ESE – Reuse of thermal discharges. Pilot Project Concordia-Salto), Project for the environmental protection and sustainable development of the Guarani Aquifer System. The World Bank, Montevideo
Chakraborty U, Hochman E, Zilberman D (1995) A spatial model of optimal water conveyance. J Environ Econ Manag 29(1):25–41
Charlesworth D, Sangam H, Assadi A (2008) Modelo numerico hidrogeologico area piloto Concordia-Salto (Hydrogeologic numerical model for the Concordia-Salto pilot area). Project for the environmental protection and sustainable development of the Guarani Aquifer System. The World Bank, Montevideo
Dixon LS (1989) Models of groundwater extraction with an examination of agricultural water use in Kern County, California. PhD Dissertation, University of California, Berkeley.
Gaudet G, Moreaux M, Salant SW (2001) Intertemporal depletion of resource sites by spatially distributed users. Am Econ Rev 91(4):1149–1159
Gisser M (1983) Groundwater: focusing on the real issue. J Polit Econ 91(6):1001–1027
Goetz RU, Zilberman D (2000) The dynamics of spatial pollution: the case of phosphorus runoff from agricultural land. J Econ Dyn Control 24(1):143–163
Haab TC, Hicks RL (1997) Accounting for choice set endogeneity in random utility models of recreation demand. J Environ Econ Manag 34(2):127–147
Hauber AB, Parsons GR (2000) The effect of nesting structure specification on welfare estimation in a random utility model of recreation demand: an application to the demand for recreational fishing. Am J Agr Econ 82(3):501–514
Heinz I, Pulido-Velazquez M, Lund JR, Andreu J (2007) Hydro-economic modeling in river basin management: implications and applications for the European water framework directive. Water Resour Manag 21:1103–1125. doi:10.1007/s11269-006-9101-8
Hsiao C, Chang L (2002) Dynamic optimal groundwater management with inclusion of fixed costs. J Water Resour Pl 128(1):57–65
Kaoru Y, Smith VK, Long Liu J (1995) Using random utility models to estimate the recreational value of estuarine resources. Am J Agr Econ 77(1):141–151
Katic P, Grafton RQ (2011) Optimal groundwater extraction under uncertainty: resilience versus economic payoffs. J Hydrol 406:215–224. doi:10.1016/j.jhydrol.2011.06.016
Katic P, Grafton RQ (2012) Economic and spatial modelling of groundwater extraction. Hydrogeol J 20(5):831–834. doi:10.1007/s10040-011-0817-z
Knapp KC, Schwabe KC (2008) Spatial dynamics of water and nitrogen management in irrigated agriculture. Am J Agr Econ 90(2):524–539
Kolstad C (1994) Hotelling rents in hotelling space: product differentiation in exhaustible resource markets. J Environ Econ Manag 26(2):163–180
Koundouri P (2004) Potential for groundwater management: Gisser-Sanchez effect reconsidered. Water Resour Res. doi:10.1029/2003WR002164
McKinney DC, Lin M (1994) Genetic algorithm solution of groundwater management models. Water Resour Res 30(6):1897–1906
Morel-Seytoux HJ, Daly CJ (1975) A discrete kernel generator for stream-aquifer studies. Water Resour Res 11(2):253–260
Negri DH (1989) The common property aquifer as a differential game. Water Resour Res 25:9–15
Nel J, Xu Y, Batelaan O, Brendonck L (2009) Benefit and implementation of groundwater protection zoning in South Africa. Water Resour Manag 23:2895–2911. doi:10.1007/s11269-009-9415-4
Parker DC (2007) Revealing “space” in spatial externalities: edge-effect externalities and spatial incentives. J Environ Econ Manag 54(1):84–99
Provencher B, Burt OR (1993) The externalities associated with the common property exploitation of groundwater. J Environ Econ Manag 24:139–158
Qureshi ME, Qureshi SE, Bajrcharya K, Kirby M (2008) Integrated biophysical and economic modelling framework to assess impacts of alternative groundwater management options. Water Resour Manag 22:321–341. doi:10.1007/s11269-007-9164-1
Rubio S, Casino B (2003) Strategic behavior and efficiency in the common property extraction of groundwater. Environ Resour Econ 26(1):73–87
Saak AE, Peterson JM (2007) Groundwater use under incomplete information. J Environ Econ Manag 54(2):214–228
Scrogin D, Boyle K, Parsons G, Plantinga AJ (2004) Effects of regulations on expected catch, expected harvest, and site choice of recreational anglers. Am J Agr Econ 86(4):963–974
Smith MD (2005) State dependence and heterogeneity in fishing location choice. J Environ Econ Manag 50(2):319–340
Smith MD, Sanchirico JN, Wilen JE (2009) The economics of spatial-dynamic processes: applications to renewable resources. J Environ Econ Manag 57(1):104–121
Steward DR, Peterson JM, Yang X, Bulatewicz T, Herrera-Rodriguez M, Mao D, Hendricks N (2009) Groundwater economics: an object-oriented foundation for integrated studies of irrigated agricultural systems. Water Resour Res 45:W05430. doi:10.1029/2008WR007149
Terrell BL, Johnson PN, Segarra E (2002) Ogallala aquifer depletion: economic impact on the Texas High Plains. Water Policy 4(1):33–46
The World Bank (2010) Deep wells and prudence: towards pragmatic action for addressing groundwater overexploitation in India. The World Bank, Washington D.C.
Theis CV (1935) The relation between the lowering of the piezometric surface and the rate and duration of discharge of a well using groundwater storage. Trans Am Geophys Union 2(5):519–524
Tsur Y, Graham-Tomasi T (1991) The buffer value of groundwater with stochastic surface water supplies. J Environ Econ Manag 21(3):201–224
Wang M, Zheng C (1998) Groundwater management optimisation using genetic algorithms and simulated annealing: formulation and comparison. J Am Water Resour As 34(3):519–530
Zektser IS, Everett LG (2004) Groundwater resources of the world and their use. IHP-VI Series on Groundwater No. 6. UNESCO, Paris
The World Bank (2006) The Guarani Aquifer Initiative for Transboundary Groundwater Management. The GW MATE Case Profile Collection no. 9. The World Bank, Washington D.C.
Acknowledgments
I am grateful to the Environmental Protection and Sustainable Development of the Guarani Aquifer System Project for the hydrological and economic data provided on the Concordia-Salto pilot project and to attendees at the Spanish-Portuguese Association of Natural Resources and Environmental Economics and the Sustainable Resource Use and Economic Dynamics conferences for their feedback.
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Katic, P.G. Groundwater Spatial Dynamics and Endogenous Well Location. Water Resour Manage 29, 181–196 (2015). https://doi.org/10.1007/s11269-014-0834-5
