Currently the criteria as defined by Nugent et al. [1] are considered as the standard procedure to score vaginal smears by Gram stain [2]. This method scores the smears in a standardized manner by quantification of some of the cell types present – designated as Lactobacillus, Gardnerella vaginalis, Bacteroides and Mobiluncus 'morphotypes'. However, the Nugent scoring system conflates women with potentially very different vaginal microflora in a single category [3]. Since the method requires considerable time and skill, simpler versions have been described which assess the categories in a more qualitative manner [46]. Recent developments in our knowledge of the vaginal microflora – including the observation of different Lactobacillus species producing different amounts of hydrogen peroxide [79] with a potential effect on pregnancy outcome [10, 11] urge to refine the Gram stain criteria in an effort to increase the agreement between Gram stain and the true composition of the vaginal microflora. In addition, a strong association of the metronidazole resistant fastidious anaerobic coccobacillus Atopobium vaginae with bacterial vaginosis [1214] might have important implications in the pathophysiology of bacterial vaginosis related preterm labour and birth. The more accurate allocation of subjects according to vaginal microflora status, as assessed by Gram stain, may enhance the validity of studies on the etiology of bacterial vaginosis, and help to better understand response to treatment and recurrence in some women, as well as its relation to preterm birth.

Here we report our findings obtained by studying a total of 515 vaginal samples by Gram stain, by DNA-based techniques – like cloning and sequencing of amplified 16S rRNA-genes [1315] and species specific PCR [12, 1518] – which make it possible to detect fastidious bacteria like A. vaginae [13, 16, 17] and by culture in combination with tDNA-PCR [20, 21], which allows the rapid identification of large numbers of cultured isolates, including isolates from different Lactobacillus species [22]. Based on these findings, we propose refined criteria to categorize the status of the microflora of vaginal smears.


We studied the composition of the vaginal microflora of 515 vaginal swabs from a prospective cohort of 197 unselected pregnant women at three time points during pregnancy using i) Gram stain based grading according to modified Ison & Hay criteria [6] – which will be further denoted here as the criteria of Claeys, ii) culture in combination with molecular identification of cultured organisms by tDNA-PCR and iii) species specific PCR for G. vaginalis and A. vaginae.

Detailed observation of the Gram stained vaginal smears in combination with specific PCR and tDNA-PCR based identification of cultured isolates led to subdivision of grade I samples and the recognition of a separate category, designated grade I-like: Grade I specimens were characterized as grade Ia when only Lactobacillus crispatus cell types (plump, mostly short rods) were present (Figure 1a – 1b), as grade Ib when only other Lactobacillus cell types were present (smaller or more elongated and less stained than in Ia smears)(Figure 1c – 1d) and as grade Iab when both L. crispatus and other lactobacilli were present (Figure 1e – 1f). Furthermore a number of samples were designated as grade I-like because of the presence of Gram positive rods, either quite small and short or otherwise irregularly shaped with clubbing, curved edges and irregular staining and often arranged like Chinese letters ('diphtheroid cell types') (Figure 1g – 1h). To corroborate that grade I-like samples indeed represent a separate class, cloning was carried out for two samples that had been categorized as grade I-like. For completeness, figures 1i – 1j represent grade II vaginal smears and figures 1k – 1l represent grade III vaginal smears.

Figure 1
figure 1

Microscopic image (100 ×) of Gram-stained vaginal smears illustrating the different categories of vaginal microflora described:. a, b: grade Ia, i.e. mainly Lactobacillus crispatus cell types, plump quite homogeneous lactobacilli. c, d: grade Ib, i.e. non-L. crispatus cell types, long or short, thin lactobacilli. e, f: grade Iab, i.e. containing mixtures of L. crispatus and non-L. crispatus cell types. g, h: grade I-like, i.e. irregular-shaped Gram positive rods. i, j: grade II, i.e. mixture of Lactobacillus cell types and bacterial vaginosis-associated bacteria (Gardnerella, Bacteroides-Prevotella and Mobiluncus cell types). k, l: grade III, i.e. bacterial vaginosis.

Comparison between Gram stain and culture

Using the criteria of Claeys, 162 vaginal smears were scored as grade Ia, 181 as grade Ib, 60 as grade Iab, 36 as grade I-like, 46 as grade II, 22 as grade III and eight as grade IV (Table 1).

Table 1 Detailed composition of the vaginal microflora of 515 vaginal swab samples, as determined by culture and tDNA-PCR based identification

We cultured 1108 isolates anaerobically out of the 515 vaginal swabs and identified these with tDNA-PCR. A total of 136 isolates remained unidentified, since no corresponding tDNA-PCR fingerprint could be found in the database or because no amplification was obtained. A total of 72 species were identified, of which 17 belonged to the genus Lactobacillus and six to the genus Bifidobacterium (Table 1). The most common species recovered from grade Ia, Ib and Iab specimens were lactobacilli. L. crispatus (87.0%) and L. jensenii (22.2%) were the most abundant bacteria in grade Ia samples, whereas L. gasseri (32.0%) and L. iners (39.8%) were the most frequently present species in grade Ib specimens. Grade I-like specimens were found to contain mostly bifidobacteria (54.9%) and L. gasseri (52.8), while L. crispatus was almost absent (2.8%). In 19.8% of grade I-like specimens bifidobacteria were present while lactobacilli were absent. Bifidobacteria were more frequent in grade I-like samples than in other samples (χ2 = 120.6, p < 0.001, Table 2).

Table 2 Presence of Bifidobacterium spp. in grade I like samples versus other samples.

L. crispatus was present in 87.0% of grade Ia, 76.7% of grade Iab and 37.5% of grade IV samples but in less than 13.3% in all other grades. L. crispatus was the only Lactobacillus species that was linked to a single grade, namely grade Ia (χ2 = 186.3, p < 0.001), while the other lactobacilli were more evenly distributed over all samples (Table 3, 4, 5, 6). L. jensenii was the second most abundant species in grade Ia (22.2%), but was also frequent in most other grades, for example in 47.8% of grade II. L. vaginalis, the third most abundant species in grade Ia (9.3%) was absent from grade III and present in less than 20% of all other grades. L. gasseri and L. iners were more abundant in grade Ib (32.0 and 39.8%), grade I-like (52.8 and 19.4%), grade II (54.3 and 26.1%) and grade III (9.1 and 31.8%) than in grade Ia (6.8 and 3.7%).

Table 3 The presence of Lactobacillus species in grade Ia and grade Ib samples.
Table 4 Presence of L. gasseri or L. iners in grade II and grade III samples versus presence in other samples.
Table 5 Number of samples with lactobacilli in grade Ia versus the other grades.
Table 6 Number of samples with lactobacilli in grade I versus the other grades.

The most characteristic cultured organisms in grade II and grade III specimens were G. vaginalis (respectively 21.7% and 72.7%) (χ2 = 120.6, p < 0.001, Table 7), Actinomyces neuii (respectively 6.5% and 9.1%), Aerococcus christensenii (respectively 4.3% and 22.7%), A. vaginae (respectively 4.3% and 13.6%), Finegoldia magna (respectively 2.2% and 9.1%) and Varibaculum cambriense (respectively 2.2% and 13.6%). These were virtually absent from grade I and grade IV, although G. vaginalis was present in approximately 2.0% of grade I samples. L. jensenii (47.8%) and L. gasseri (54.3%) were the most common lactobacilli in grade II specimens. Furthermore, whereas L. crispatus and L. vaginalis were never cultured from grade III specimens, L. iners (31.8%) was the lactobacillus mostly present in grade III. Mobiluncus curtisii and Peptostreptococcus sp. were cultured from grade III specimens only (both 4.5%). Dialister sp. (22.7%) and Prevotella spp. (22.6%) were frequently cultured from grade III specimens and only sporadically from other specimens.

Table 7 Presence of G. vaginalis in grade II and grade III samples versus presence in other samples.

The average number of species cultured per sample ranged from 1.5 for grade Ia specimens to 3.6 for grade III specimens (Table 8). Overall, the species diversity of the grade I-like category was higher (0.83) than that of the grade I subcategories (0.17, 0.21 and 0.30 for grades Ia, Ib, and Iab respectively) and comparable to that of the grade II category (0.76). The grade III category had the highest species diversity (1.50) (Table 8).

Table 8 Numbers of species cultured per patient and species diversity indices

Comparison between Gram stain and species specific PCR for Gardnerella vaginalis and Atopobium vaginae

The series of 515 vaginal samples were analyzed by PCR with 16S rRNA gene based primers specific for A. vaginae and 16S–3S spacer primers specific for G. vaginalis.

After amplification with the ato167f A. vaginae primer set, respectively 14.7% of grade I, 8.3% of grade I-like, 28.3% of grade II, 86.4% of grade III and 12.5% of grade IV samples showed an amplicon. The percentage of positive samples for G. vaginalis specific PCR was respectively 28.9%, 19.4%, 47.8%, 86.4% and 12.5%.

The simultaneous presence of A. vaginae and G. vaginalis in a vaginal swab specimen had an accuracy of 90% [95% CI: 86–92%], a sensitivity of 82% [95% CI: 59–94%], a specificity of 90% [95% CI: 87–92%], a positive predictive value of 26% [95% CI: 17–39%] and a negative predictive value of 99% [95% CI: 98–100%] in assessing bacterial vaginosis (defined as a grade III smear).

Comparison between culture and cloning of grade I-like samples

Cloning of two grade I-like samples from trimesters 1 and 2 of the same patient, revealed the presence of Bifidobacterium breve (respectively 33.1 and 53.5%), Lactobacillus delbrueckii (64.8 and 13.3%) and L. gasseri (2.1 and 33.1%) clones. This was in agreement with the culture results which revealed the presence of B. breve in both trimesters, L. delbrueckii only in the first and L. gasseri only in the second.

In general, grade I-like samples were found by culture to contain more frequently Bifidobacterium (19/36 samples) and more different Bifidobacterium species (6) than samples from all other categories. Of the Bifidobacterium species, B. breve was most clearly associated with grade I-like, grade II and grade III.


The importance of correct diagnosis of bacterial vaginosis and of more detailed characterization of the vaginal microflora

Although not causing a vaginal inflammatory response, bacterial vaginosis is considered to be the most common cause of vaginitis in pregnant and non-pregnant women and prevalences between 4.9% and 36.0% have been reported from European and American studies [23]. Several studies suggest the possibility that bacterial vaginosis increases the risk of acquiring HIV [24, 25] and that the bacterial flora associated with bacterial vaginosis increases genital-tract HIV shedding [26]. A recent meta-analysis by Leitich et al. [27] established an odds ratio of 8 for preterm birth in association with bacterial vaginosis during early pregnancy. Spontaneous preterm birth occurs in 7–11% of pregnancies but accounts for three quarters of perinatal morbidity and mortality and for half of long term neurological impairment in children [28, 29].

Bacterial vaginosis is characterized by the replacement of the normal vaginal microflora of lactobacilli by Gardnerella vaginalis and anaerobic organisms. Recently, different groups showed that the strict anaerobe Atopobium vaginae is another organism that is strongly associated with bacterial vaginosis [12, 13, 16, 17]. The association between A. vaginae and bacterial vaginosis might help explain why some women suffer from recurrent bacterial vaginosis. For example, a recent study pointed to great in vitro efficacy of metronidazole, since this antibiotic inhibited growth of 99% of the vaginal isolates from bacterial vaginosis samples [30], but most likely overlooked the fastidious metronidazole resistant A. vaginae, shown in this study to be present in 86.4% of bacterial vaginosis samples when detected with species specific PCR.

Given the possibility that certain not yet characterized subgroups within the presumably heterogenic clinical entity of women with bacterial vaginosis could identify a group at higher risk for preterm birth than women with bacterial vaginosis as a whole and that adequate treatment of women from this higher risk group may allow for more targeted preterm birth prevention, better understanding of the composition and dynamics of the vaginal microflora and accurate diagnosis of bacterial vaginosis are warranted. Also, our data indicate that refined characterization of vaginal microflora may be necessary for more accurate interpretation of the results of clinical studies. For example, thus far Atopobium vaginae has been overlooked in clinical studies and furthermore, the fact that different Lactobacillus species may confer different strengths of colonisation resistance [10, 11] has not been taken into account, partly because most laboratories lack the access to rapid and accurate methods for the identification of lactobacilli to the species level. In other words, several studies concerning the relation between the status of the vaginal microflora and different gynecologic and obstetric diseases and their treatments thus far may have reached biased conclusions due to insufficiently precise characterization of the microflora.

Criteria for microbiological categorization of vaginal microflora status

Spiegel et al. [31] defined a scoring system based on some of the bacterial cell types that can be seen in Gram stained smears of vaginal secretion. This was later refined by Nugent et al. [1], who provided a scoring system that evaluates the changes in vaginal microflora, from the normal condition to bacterial vaginosis status, as a continuum. Although the Nugent criteria have gained wide acceptance for the evaluation of the condition of the vaginal microflora [2, 32], further refinement is warranted for several reasons. First, no definite criteria have been described to distinguish the Lactobacillus cell types from the Gardnerella and Bacteroides-Prevotella cell types. In practice and in our experience, 'morphotypes' are often difficult to assign to one of these groups. Also, some genera and species that are clearly associated with bacterial vaginosis, like Peptostreptococcus spp. [32] and A. vaginae [12, 17, 13] are not included in the Nugent score. Furthermore, Forsum et al. [2] found major discrepancies in scoring when the lactobacillary cell types were few in number and Larsson et al. [33] reported several problems in the interpretation of smears. For example, using the Nugent criteria, the presence of different Lactobacillus cell types in smears from patients with bacterial vaginosis can lead to assignation to grade II, whereas patients without bacterial vaginosis but with smears with more than 300–500 pleomorphic Lactobacillus cells may be regarded as containing G. vaginalis, also because some of these cells are very small. Additionally, the Nugent scoring system conflates women with potentially very different vaginal microflora in a single category [3].

In this study, the clinical microbiologist (GC) could not grade some of the smears due to the presence of cell types not scored in the system developed by Nugent [1] and classified these samples as grade I-like. Further detailed observation lead to the splitting up of grade I samples into subcategories designated grade Ia, grade Ib and grade Iab. After blind grading of the vaginal smears into grades Ia, Ib, Iab, I-like, II, III and IV, this classification was compared with the culture results and with species specific PCRs.

Grade Ia and Iab: Agreement with the presence of L. crispatus

From this comparison it became obvious that it is possible to recognize the presence of L. crispatus by means of Gram stain, since this species was cultured in 81.9% of the grade Ia samples and 76.7% of the grade Iab samples. Nevertheless, L. crispatus was not cultured from 21 of the 162 grade Ia samples. This may be explained by the fact that L. crispatus is not as easily cultured as other lactobacilli. Indeed, L. crispatus colonies were quite often observed as satellites of other bacteria and in some cases no growth at all was observed in samples with numerous L. crispatus-like lactobacilli on Gram stain. Using non culture dependent t-RFLP-analysis (data not presented) the Ia samples negative for L. crispatus culture were tested and 16 were positive for L. crispatus, bringing the agreement between Gram stain grading as grade Ia and the presence of L. crispatus to 96.9%. Similarly, when taking into account t-RFLP-analysis results, the agreement between categorization as grade Iab and t-RFLP-analysis positive for L. crispatus was 92.9% whereas L. crispatus was detected by t-RFLP-analysis only in 27.3%, 20.0%, 22.5% and 0% for grades Ib, I-like, II and III, respectively. These results indicate that – for a trained microbiologist – it is possible to recognize L. crispatus bacteria upon cell morphology, a finding that is of importance since this species is clearly associated with healthy microflora, and possibly better ensures stable healthy microflora than other lactobacilli [9]. Samples were scored as grade Ib when no L. crispatus cell types were observed, but other Lactobacillus cell types were predominant. The agreement with culture results was high: only 13.3% contained L. crispatus upon culture, whereas L. gasseri, L. iners, and L. jensenii were present in respectively 32.0, 39.8, and 24.3% of the grade Ib samples. These were clearly grade I samples since bacterial vaginosis-associated organisms were mostly absent.

The colonisation resistance conferred differs between Lactobacillus species

Overall the frequency of isolation of all Lactobacillus species together was comparable for the different grades in our population, since lactobacilli were cultured from 96.9% of grade Ia, 94.5% of grade Ib, 96.7% of grade Iab, 78.9% of grade I-like, 93.5% of grade II, 59.1% of grade III and 62.5% of grade IV samples. This is in agreement with previous reports [32, 34]. However, we observed a clear difference with regard to the Lactobacillus species frequency distribution for the different grades. While L. crispatus, known as a strongly H2O2-producing species [7, 8], was cultured from 87.0% of grade Ia specimens, it was absent in grade III specimens and only present in 2.8% of grade I-like specimens. In contrast, L. iners, reported as a weakly H2O2-producing species [7, 8], was present in only 3.7% of Ia specimens but in 39.8% of grade Ib and 31.8% of grade III specimens. Whether it is the hydrogen peroxide production by L. crispatus that confers colonisation resistance remains a matter of debate, since a correlation between the presence of hydrogen peroxide production and the type of vaginal microflora was found by some [35], though not by others [36]. Possibly other species specific characteristics, present in L. crispatus, but absent in species like L. gasseri and L. iners, confer colonisation resistance. It has also been hypothesized that the onset of perturbation leading to bacterial vaginosis may be due to competition between Lactobacillus species [36], a situation possibly reflected by grade Iab specimens.

Grade I-likes: a separate category of vaginal microflora status

A number of samples were initially difficult to score because the predominant cell types could not be categorized as Lactobacillus, Gardnerella, Bacteroides-Prevotella or Mobiluncus cell types. These samples were considered as belonging to a separate category because of the presence of Gram positive rods, either quite small and short or otherwise irregularly shaped with clubbing, curved edges and irregular staining and often arranged like Chinese letters ('diphtheroid cell types'). Since it is likely that most microbiologists would score this cell type as 'Lactobacillus-like' and that therefore it would be scored in most cases as grade I, we designated it as 'grade I-like'. Culture and species specific PCR confirmed that indeed these samples represent a separate kind of vaginal microflora. This is reflected by the increased species diversity of 0.83, which is much higher than that for grades Ia, Ib and Iab (0.15–0.30) and which is comparable to that of grade II (0.76), but even more so by the virtual absence of L. crispatus (cultured from only one of 36 samples) as well as of G. vaginalis and A. vaginae (cultured from respectively 1 and 0 samples) and the presence of Bifidobacterium spp. in 19 of 36 samples, a much higher prevalence than in samples from all other grades. This was confirmed by cloning of two grade I-like samples, which contained only L. delbrueckii, L. gasseri and B. breve.

Rosenstein et al. [34] mentioned a category of vaginal smears with aberrant morphology, which they designated as grade I revertants. At first sight, their category shows resemblance with the category we describe here as I-like, because of low numbers of G. vaginalis and increased numbers of bifidobacteria, but on the other hand they reported even more bifidobacteria in their grade II and grade III samples and they designated this category as grade I revertants because the vaginal microflora of all 41 women with such smears reverted to grade I, which was not the case in our study (data to be presented elsewhere).

Importantly, since Gram stain based categorizing can result in the interpretation of grade I-like samples as genuine grade I samples (whereof their designation), this class of samples may jeopardize – and probably has done so in the past – the interpretation of the results of clinical studies.

Grade II: a microbiologically intermediate stage between healthy microflora and bacterial vaginosis

Our results confirm that grade II samples represent a microbiologically clearly intermediate status between grade I and III. L. crispatus is still present in 10.9% of the samples (compared to 59.0% of grade I and 0% of grade III samples), whereas the number of samples with L. gasseri (54.3%) is increased compared to grade I (21.3%) and grade III (9.1%). Species diversity of grade II is intermediate between that for grade I and grade III and species typically associated with bacterial vaginosis, like A. neuii, A. christensenii, A. vaginae, B. ureolyticus, F. magna, G. vaginalis, Peptoniphilus sp. and V. cambriense, are present, but again in a lower number of samples than in grade III specimens.

Grade III: Characterization of bacterial vaginosis -related organisms

The following species are generally considered as bacterial vaginosis related anaerobe organisms: Anaerococcus (Peptostreptococcus) tetradius, A. (Peptostreptococcus) vaginalis, Atopobium vaginae, Bacteroides ureolyticus, Finegoldia (Peptostreptococcus) magna, G. vaginalis, Gemella (Peptostreptococcus) morbillorum, Mobiluncus curtisii, Mycoplasma hominis, Peptoniphilus sp., Peptostreptococcus sp., Prevotella bivia, Prevotella ruminicola and Prevotella sp. [37, 38]. Using tDNA-PCR we were able to identify 87.8% of the cultured isolates to the species level and found our results to be largely in agreement, but in addition we cultured Actinomyces neuii, Aerococcus christensenii, Dialister sp. and Varibaculum cambriense, whereas Mobiluncus spp., Mycoplasma hominis and Ureaplasma urealyticum were not or only sporadically cultured from grade II and grade III specimens. The absence of the latter species in our study can be explained by the fact that we did not use the specific culture methods for these fastidious organisms.

In this study we confirmed the strong association, as established previously [12, 13, 17], between A. vaginae and bacterial vaginosis.


In summary, our characterization of the vaginal microflora by means of detailed Gram stain interpretation and by culture in combination with genotypic identification helps to refine our understanding of normal and disturbed vaginal microflora. We showed that L. crispatus can be recognized as such on Gram stain, we established the existence of a separate additional category, characterized by the absence of L. crispatus and the abundance of bifidobacteria and we confirmed the association of Atopobium vaginae with bacterial vaginosis.

These data have implications for the basic understanding of the vaginal microflora and bacterial vaginosis; in addition, they may add to the value of Gram smear based diagnosis of bacterial vaginosis because of better defined Gram stain criteria.


Study population and sample collection

A total of 515 vaginal swabs were collected by sampling 197 pregnant women attending our out-patient clinic, each at three time points during pregnancy (respectively 197, 171 and 147 first, second and third trimester samples were collected). The swabs were obtained during the first, second and third pregnancy trimester, at mean gestational ages of 9.1 +/- 3.2 weeks, 20.4 +/- 2.3 weeks and 32.2 +/- 1.7 weeks, respectively.

Sampling was carried out by insertion of three sterile cotton swabs into the vaginal vault, after placement of a non-lubricated speculum. The swabs were rotated against the vaginal wall at the midportion of the vault and were carefully removed to prevent contamination with microflora of the vulva and introitus. The first swab was used to prepare a smear on a glass slide for the purpose of grading according to the criteria of Claeys (this study). The second swab was returned to a sterile tube (Copan, Brescia, Italy), for the purpose of DNA-extraction (dry swab). The third swab was placed into Amies transport medium (Nuova Aptaca, Canelli, Italy) for anaerobic culture. The unstained smear and both swabs were sent to the microbiology laboratory and were processed within 4 hours.

Grading of slides

Smears were dried, Gram stained (Mirastainer, Merck-Belgolabo, Overijse, Belgium) and examined under oil immersion at a magnification of 1000. Gram stained smears from vaginal swabs were all scored by one clinical microbiologist (GC) according to Ison & Hay criteria [5, 6]: samples were categorized as grade I when only Lactobacillus cell types (large Gram positive rods) were present, as grade II (intermediate) when both Lactobacillus and Gardnerella or Bacteroides-Prevotella cell types were present, as grade III (bacterial vaginosis) when Lactobacillus cell types were absent and only Gardnerella,Bacteroides-Prevotella or Mobiluncus cell types were present and as grade IV when Gram positive cocci were predominantly present. Further subdivision of grade I samples into categories Ia, Iab and Ib and the description of a separate category, designated grade I-like, is presented in the Results section.

Culture and identification of cultured isolates by tDNA-PCR

For 515 specimens collected from 197 women, the swab on Amies transport medium was streaked onto Schaedler agar enriched with 5% sheep blood, vitamin K, hemin and sodium pyruvate (Becton Dickinson, Franklin Lakes, NJ) and incubated anaerobically at 37°C upon arrival at the microbiology laboratory. After 4 days of incubation, all the isolates with different colony morphology were selected for identification. DNA was extracted by simple alkaline lysis: one colony was suspended in 20 μl of 0.25% sodium dodecyl sulfate-0.05 N NaOH, heated at 95°C for 15 min and diluted with 180 μl of distilled water. tDNA-PCR and capillary electrophoresis were carried out as described previously [20, 22]. The species to which each isolate belonged was determined by comparing the tDNA-PCR fingerprint obtained from each isolate with a library of tDNA-PCR fingerprints obtained from reference strains, using an in-house software program [20]. The library of tDNA-PCR fingerprints is available at our website [39] and the software can be obtained upon request.

DNA extraction of vaginal swab samples

For DNA extraction from the dry vaginal swabs, the QIAamp DNA mini kit (Qiagen, Hilden, Germany) was used according to the manufacturer's recommendations, with minor modifications, as described previously [13]. DNA-extracts were stored at -20°C and were used for the purpose of species specific PCR and cloning experiments.

Species specific PCR for Gardnerella vaginalis

G. vaginalis species specific primers as designed by Zariffard et al. (GZ) [19] were used. Briefly, a 20 μl PCR mixture contained respectively 0.05 and 0.4 μM primers, 10 μl of Promega master mix (Promega, Madison, WI), 2 μl of Qiagen DNA-extract of the samples and distilled water. Thermal cycling with GZ primers consisted of an initial denaturation of 10 min at 94°C, followed by 50 cycles of 5 s at 94°C, 45 s at 55°C and 45 s at 72°C, and a final extension of 10 min at 72°C. Five microliter of the amplified product was visualized on a 2% agarose gel.

Species specific PCR for Atopobium vaginae

A primer set that allowed amplification of the 16S rRNA gene of A. vaginae and that lacked homology with non-target bacteria was used as described earlier [13]. Briefly, a 10 μl PCR mixture contained 0.2 μM each of the primers ato167f (5' GCGAATATGGGAAAGCTCCG) and ato587r (5' GAGCGGATAGGGGTTGAGC), 5 μl of Promega master mix (Promega, Madison, WI), 1 μl of Qiagen DNA-extract of the samples and distilled water. Thermal cycling consisted of an initial denaturation of 5 min at 94°C, followed by three cycles of 1 min at 94°C, 2 min at 58°C and 1 min at 72°C, followed by 35 cycles of 20 sec at 94°C, 1 min at 58°C and 1 min 72°C, with a final extension of 10 min at 72°C, and cooling to 10°C. Five microliter of the amplified product was visualized on a 2% agarose gel. The primers amplified a DNA-fragment of 420 base pairs from A. vaginae and showed no cross reactivity to other organisms, including A. rimae and A. parvulum (data not presented).

Cloning of amplified mixtures of 16S rDNA

Cloning and sequencing was carried out largely as described previously [13]. However, to increase the amplification efficiency of the 16S rRNA-genes of G. vaginalis and bifidobacteria the following mixture of primers (0.1 μM each) was used for the initial amplification of the samples prior to cloning: primers 10 f (5' AGTTTGATCCTGGCTCAG), 534r (5' ATTACCGCGGCTGCTGG) and GV10f (5' GGTTCGATTCTGGCTCAG).

Statistical analysis

The Simpson's Diversity Index was calculated as D = 1-∑ (n/N)2 where n is the number of isolates of a particular species and N is the total number of isolates. Chi square analyses were carried out using the statistical software package SPSS v.11.0.
