Background

Enteropathogenic Escherichia coli (EPEC), mainly causing infantile diarrhoea, represents one of the at least six different categories of diarrheagenic E. coli with corresponding distinct pathogenic schemes [1]. Most of the EPEC strains belong to a series of O antigenic groups known as EPEC O serogroups: O26, O55, O86, O111, O114, O119, O125, O126, O127, O128, O142 and O158.

The main mechanism of EPEC pathogenesis is the ability to introduce attaching-and-effacing (A/E) lesions on intestinal cells characterized by microvillus destruction, intimate adherence of strains to the intestinal epithelium, pedestal formation and aggregation of polarized actin at sites of bacterial attachment [2].

The genetic determinants for the production of A/E lesions are located on the locus of enterocyte effacement (LEE), a pathogenicity island that contains the genes encoding intimin (eae), a type III secretion system, a number of secreted proteins (ESP) and the translocated intimin receptor (Tir) [2]. Characterization of eae genes revealed the existence of different eae variants. At present, 15 (α1, α2, β1, β2, γ1, γ2/θ, δ/κ, ε, ζ, η, ι, λ, μ, ν, ξ) genetic variants of the eae gene have been identified [3–7]. It is discussed that different intimins may be responsible for different host- and tissue cell tropism [8, 9]. In epithelial culture cells EPEC strains produce characteristic adherence patterns: (i) localized adherence (LA), where microcolonies attach after 3 hours incubation to one or two small areas on the cells [10, 11]; (ii) diffuse adherence (DA), where bacteria cover the cells uniformly [10]; (iii) enteroadherent-aggregative adherence (AA), where the bacteria have a characteristic stacked-brick-like arrangement [12] and (iiii) localized adherence-like adherence (LAL), characterized by formation of less-compact microcolonies or clusters of bacteria than those by LA [13]. Localized adherence is associated with the presence of the large EPEC adherence factor (EAF) plasmid, on which also the cluster of genes encoding bundle-forming pili (BFP) is present [1]. EPEC are classified as typical, when possessing the EAF plasmid; whereas atypical EPEC strains do not possess the EAF plasmid [14, 15].

Typical and atypical EPEC strains usually belong to certain serotype clusters, differ in their adherence patterns on cultured epithelial cells (typical: LA; atypical: DA; AA; LAL), are typically found in different hosts (typical EPEC strains have only been recovered from humans), and display difference in their intimin types [15].

The role and the epidemiology of non-traditional enteropathogenic E. coli serogroup strains in human diarrhea are not well established. E. coli O157:H8 and E. coli O157:H45 EPEC strains have been described to be associated with diarrhea in human [4, 16]. Makino et al. [17] reported the first large outbreak with E. coli O157:H45 EPEC in Japan in 1998. Nevertheless, these O157 EPEC strains are not well characterized.

This study reports the first isolation of O157:H45 EPEC strains from cattle and phenotypic and genotypic characteristics of the isolated strains are described.

Results and discussion

All 11 sorbitol-positive E. coli O157:H45 strains, six strains isolated from fattening cattle and five strains isolated from cows tested negative for Shiga toxin genes (stx). The eae gene, which is strongly correlated to the attaching-and-effacing lesions, was present in all strains. Therefore, these strains are considered to be EPEC. Our findings emphasize the fact that E. coli with the O157 O antigen are not always STEC but may belong to other pathotypes. Further results of strain characterization are shown in Tab. 2.

Table 1 Sequences and predicted lengths of PCR amplification products of oligonucleotide primers used
Full size table

In all tested strains, LEE was inserted in selC and thus these strains could be evolutionarily more akin to the EPEC 1 and EHEC 1 clones than to other clones [18]. Further characterization of the eae variants showed in all strains eae subtype α1. Oswald et al. [4] testing in their study the distribution of intimin types among different EPEC strains, found the same eae subtype in O157:H45 strains isolated from human with diarrhea.

The gene encoding the heat-stable enterotoxin (EAST1), representing an additional determinant in the pathogenesis of E. coli diarrhea, was found in ten of the 11 strains. None of the strains, however, carried ehx A genes.

Nine strains were positive for the EAF plasmid and 10 strains harbored the bfpA gene encoding bundlin, the structural subunit of the bundle-forming pilus expressed by typical EPEC strains. The EAF plasmid negative but bfpA positive strain may have a defect in the EAF region that does not interfere with the plasmid's function. All bfpA gene positive strains showed a localized adherence (LA) pattern, the penotpyical characteristic associated with the expression of bundle-forming pili and therefore seem to be a typical EPEC. For HEp-2 and Caco-2 cells similar results were obtained (Figure 1, 2). Caco-2 cells instead of Hela cells were used for adhesion assay and FAS test, because they represent a system close to the human intestinal cells. Furthermore, Vieira et al. [19] have shown that results obtained by Caco-2 cells are comparable to Hela cells.

Figure 1
figure 1

Localized adherence (LA) pattern of the E. coli O157:H45 strain 1070/03 on HEp-2 cells. (a) 3 h assay, (b) 6 h assay

Full size image
Figure 2
figure 2

Localized adherence (LA) pattern of the E. coli O157:H45 strain 1070/03 on Caco-2 cells. (a) 3 h assay, (b) 6 h assay

Full size image

10 of the 11 strains showed an A/E property with the fluorescent actin staining (FAS) test (Figure 3).

Figure 3
figure 3

Actin fluorescence micrograph showing E. coli O157:H45 strain 1070/03-infected Caco-2 cells

Full size image

According to Kaper [14] most of our O157:H45 strains have to be classified as typical EPEC strains, because they are possessing the EAF plasmid and are showing the localized adherence (LA) pattern. However, they are harboring astA genes, which is more common for atypical EPEC strains [15].

Further studies are needed to evaluate the role of such EPEC strains isolated from asymptomatic animals.

Conclusions

Cattle have not only to be considered as important asymptomatic carriers of O157 STEC but can also be a reservoir of O157 EPEC strains, which are described in association with human diseases. These strains appear to play a role as food borne pathogens and have to be considered in view of food safety aspects.

Methods

Origin of the E. coli strains

The strains characterized in this work were isolated during a recent study on prevalence of E. coli O157 in healthy cattle in Switzerland [20]. The study was based on investigations that were carried out within the last one and a half years (January 2002 – June 2003) in two EU-approved slaughterhouses. From 2,930 bovine fecal samples (1,183 calves, 1,201 fattening cattle and 546 cows), 11 sorbitol-fermenting E. coli O157:H45 strains (from 6 fattening cattle and 5 cows) were isolated. The determination of the O and H antigens was performed as previously described using all available O (O1 to O181) and H (H1 to H56) antisera [6].

Genotypic characterization of the O157:H45 strains

PCR for the detection of putative virulence genes were performed in a T3 thermocycler (Biometra, Germany). PCR reagents were purchased from PROMEGA (Madison, Wis.) and primers were synthesized by MICROSYNTH (Balgach, Switzerland). The 50-μl PCR mixtures normally consisted of 2 μl of bacterial suspension in 42 μl of double-distilled water, 5 μl of 10-fold-concentrated polymerase synthesis buffer containing 2.0 mM MgCl2, 200 μM (each) desoxynucleosid triphosphate (dNTP), 30 pmol of each primer and 2.5 U of Taq DNA polymerase. The PCR primers, target sequences and product sizes are listed in Table 1. Differences in the normal PCR mixture and cycling conditions for each PCR were previously described in the cited literature.

Table 2 Characterization results of 11 sorbitol-fermenting O157:H45 EPEC strains isolated from cattle in Switzerland
Full size table

To verify whether LEE was inserted downstream of the selC locus, PCR reactions that amplify the junctions of this locus with the E. coli chromosome were performed according to Sperandio et al. [27]. Primers K255 (5'-GGTTGAGTCGATTGATCTCTGG-3') and K260 (5'-GAGCGAATATTCCGATATCTGGTT-3') were used for the right junction; K296 (5'-CATTCTGAAACAAACTGCTC-3') and K295 (5'-CGCCGATTTTTCTTAGCCCA-3') for the left junction, and K261 (5'-CCTGCAAATAAACACGGCGCAT-3') and K260 for the intact selC gene.

Adhesion assay and FAS test

E. coli colonies were characterized by the pattern of adherence to HEp-2 and Caco-2 cells as described by Karch et al. [28] with minor modifications. Briefly, HEp-2 and Caco-2 cells were grown for 48 h with 5% CO2 on sterilized coverslips (13 mm diameter; Bibby Sterilin™ Ltd., Stone, England) in 24-well flat-bottom tissue culture plates with low evaporation lid (16 mm diameter; BD Falcon™, Bedford, USA) containing Minimum essential medium (MEM with Earle's salts, 25 mM HEPES, without L-Glutamine;GIBCO™ Invitrogen AG, Basel, Switzerland) supplemented with fetal calf serum (FCS, 10%, Bio Concept™, Allschwil, Switzerland), MEM Non Essential Amino Acids (MEM NEAA (100x) without L-Glutamine, GIBCO™ Invitrogen AG, Basel, Switzerland) and GlutaMAX™I Supplement 200 mM (100x), (GIBCO™ Invitrogen AG, Basel, Switzerland). Bacteria used for the adhesion assay were grown over night in LB-broth Miller (Becton Dickinson, Maryland, USA). Prior to incubation, the confluent cells were washed two times with Dulbecco's phospate buffered saline (D-PBS (1x) without Calcium and Magnesium, GIBCO™ Invitrogen AG, Basel, Switzerland). E. coli diluted 1:100 in 1 ml fresh media (MEM with supplements) was added to the cells and was incubated for 3 h at 37°C and 5% CO2. After this incubation period, monolayers were washed five times with D-PBS (3 h assay) or monolayers were washed ten times with D-PBS, fresh media (MEM with supplements) was added and an additional incubation period of 3 h proceeded (6h assay). Subsequently, the monolayers were washed five times with D-PBS and the cells were fixed for 10 min with 4 Methanol. After the staining with May-Grünwald-Giemsa (Fluka™, Buchs SG, Switzerland), the coverslips were examined by light microscopy to determine the adherence patterns of the strains.

The following fluorescent actin-staining (FAS) test was performed on Caco-2 cells according to Karch et al. [28] with minor modifications. The cells were fixed with 4% formaldehyde in D-PBS, then washed three times with D-PBS and incubated for 5 min with 0.1% Triton X-100 (Fluka™, Buchs SG, Switzerland) in D-PBS. After another three washes with D-PBS, the monolayers were incubated with 5 μg/ml of fluorescein isothiocyanate labelled phaloidin (Sigma, Steinheim, Germany) for 30 min. After another three washes with D-PBS, the coverslips were examined by fluorescence microscopy (Leica ™).
