Abstract
Anaplastic lymphoma kinase-positive diffuse large B cell lymphoma represents a distinct subtype of diffuse large B cell lymphoma with a characteristic morphology, a distinct immunophenotypic profile, and recurrent cytogenetic/molecular genetic abnormalities. We report a case of anaplastic lymphoma diagnosed in the bone marrow trephine of a 24-year-old male. Histologically, the tumor cells exhibited plasmablastic morphology with expression of CD45, CD138, EMA, MUM1, and kappa immunoglobulin light chain, but negative for CD20, CD30, CD79a, PAX-5, CD10, and lambda light chain. In addition, the neoplastic cells showed positive immunoreactivity for anaplastic lymphoma kinase (ALK) with exclusive cytoplasmic granular staining pattern. Furthermore, interphase fluorescence in situ hybridization analysis, revealed ALK gene rearrangement in the lymphoid cells. The diagnosis of this rare entity in unusual extranodal sites such as the bone marrow is challenging, and it is based on detailed morphological and immunohistochemical analysis. Fluorescence in situ hybridization provides also a helpful tool in order to establish the diagnosis.
Avoid common mistakes on your manuscript.
Introduction
Anaplastic lymphoma kinase (ALK)-positive diffuse large B cell lymphoma (ALK+/DLBCL) is a rare and distinct subtype of DLBCL, originally described in 1997 by Delsol et al. [1]. To date, approximately 50 cases of ALK+ LBCL have been described in the English literature, and those cases share similar morphologic, immunophenotypic, and molecular genetic characteristics.
ALK+/DLBCL occurs more frequently in male adults and spans all age groups. It shows a very aggressive behavior, high relapse rate, and lack of response to standard regimens [2, 3]. Although it primarily involves lymph nodes, extranodal presentations such as the tongue, nasopharynx, and stomach have been rarely reported [3–7].
Histologically, ALK+/DLBCL exhibits an immunoblastic and/or plasmablastic morphology, often an intrasinusoidal growth pattern, and is derived from B cells based on the expression of monotypic light chain. It shows a unique immunophenotypic profile characterized by strong staining for ALK protein and expression of plasmacytic markers but lack B, T-lineage markers and CD30 [2]. The plasmablastic appearance and CD20 negativity of ALK−DLBCL make this entity a diagnostic challenge with a broad histological differential diagnosis.
Molecular cytogenetics and/or reverse transcriptase polymerase chain reaction has shown that the most commonly observed cytogenetic abnormality of ALK-positive DLBCL is t(2;17)(p23;q23) involving clathrin (CLTC) on 17q23 and ALK on 2p23 [5, 8, 9]. However, cases of ALK-positive DLBCL with underlying t(2;5)(p23;q35) involving ALK on 2p23 and nucleophosmin on 5q35, as seen in the majority of T/null anaplastic large cell lymphoma, have also been described [4]. Other rare cytogenetic abnormalities have been reported including novel ALK fusion partners [10, 11].
In the present study, we describe a case of ALK+/DLBCL diagnosed in the bone marrow trephine, showing the typical morphological and immunohistochemical features of the entity and associated with ALK-1 gene rearrangement detected by fluorescence in situ hybridization (FISH) analysis.
Clinical history
The patient, a 24-year-old male, presented with anemia and B symptoms. Physical examination did not reveal peripheral lymphadenopathy. Laboratory investigation showed normochromic normocytic anemia. The patient was HIV negative. A CT scan of the thorax and abdomen showed multiple liver nodules without additional lymphadenopathy, and a diagnosis of malignancy was suspected. A staging bone marrow biopsy was performed, and the sample was fixed in formalin. Liver biopsy was not performed. Fresh tissue was not procured for conventional cytogenetic analysis.
Materials and methods
Sections were routinely processed in paraffin for light microscopy and immunohistochemistry. FISH analysis was performed using the ALK split probe from DAKO (Denmark) according to the manufacturer’s instructions. Fluorescence images were acquired using a Zeiss Axio Imager Z1 microscope (Carl Zeiss, Jena, Germany) equipped with a Plan Neofluar ×100/1.3 oil objective lens and the appropriate filter settings. Images were recorded using a monochrome progressive scan CV-M4/CL camera (Applied Imaging Corp., CA, USA). The complete setup was controlled by CytoVision software, 3.93.1 release (Applied Imaging Corp.).
Results
Histology showed diffuse infiltration of the marrow trephine by sheets of monomorphic large atypical lymphoid cells with oval to irregular nuclear contours, prominent nucleoli, and abundant eosinophilic or amphophilic cytoplasm (Fig. 1a). Some of the atypical lymphoid cells showed eccentrically located nuclei with perinuclear hof, reminiscent of plasmablasts. In addition, frequent mitoses were easily appreciated.
Immunohistochemically, the atypical lymphoid cells were strongly and diffusely positive for CD45, CD138, and IgA; weakly positive for MUM1; and partially positive for EMA. They showed positive kappa immunoglobulin light chain expression but negative lambda light chain expression (Fig. 1b–d). They exhibited positive ALK immunoreactivity with restricted cytoplasmic granular staining pattern (Fig. 2a) and a high proliferation fraction (approximately 60 %) by Ki-67 staining. The B cell markers PAX-5, CD20, and CD79a were negative. The lymphoid cells were CD30, CD10, Bcl-2, CD3, CD4, and TIA-1 negative. In situ hybridization for Epstein–Barr virus (EBER) was negative as well as immunohistochemistry for human herpes virus-8.
On the basis of morphology and immunophenotype, a diagnosis of ALK+/DLBCL was assigned. Interphase FISH analysis showed that the atypical lymphoid cells displayed isolated red or green signals, indicating the presence of a breakpoint in the ALK locus (Fig. 2b). The patient received six cycles of CHOP. Follow-up imaging studies show no evidence of lymphoma. He is currently in complete continuous remission, 16 months from initial diagnosis.
Discussion
Anaplastic lymphoma kinase-positive large B cell lymphoma is a rare variant of diffuse large B cell lymphoma that occurs more frequently in male adults. It involves nodal and extranodal sites, and it is associated with a poor outcome [3–6, 12]. In our case, the patient presented with liver nodules; however, a liver biopsy was not performed and the diagnosis was made on a staging bone marrow trephine. Liver, as the primary site of ALK+/DLBCL, has been reported in only four cases in the English literature [13], whereas initial diagnosis in bone marrow trephine has not been reported previously. A summary of the key data from all cases with extranodal presentation published in the English literature is provided in Table 1.
Histologically, ALK+/DLBCL shows immunoblastic/plasmablastic cytology and a sinusoidal growth pattern may be seen. Immunohistochemically, in addition to ALK-1 expression, it presents positivity for CD138, VS38c, MUM1, and monotypic cytoplasmic light chain; EMA is usually seen as well. B cell- and T cell-related antigens are negative. CD4, CD57, CD43, and CD45 are variably positive. CD30 and EBV are not expressed [2, 6–8, 12]. Rare tumors express focally CD20 or cytokeratin on scattered cells [6]. A CD30-positive case has been reported [14] as well as a case showing CD10 positivity [7]. Our case showed the typical “plasmacytic” immunohistochemical profile.
ALK+/DLBCL should be distinguished from T-anaplastic large-cell lymphoma (T-ALCL), plasmablastic lymphoma, plasmablastic myeloma, anaplastic variant of diffuse large B cell lymphoma, and carcinoma. The distinction is based on the overall morphologic and immunohistochemical features [2]. T-ALCL is typically CD30+ of T cell phenotype and would be negative for plasma cell markers and immunoglobulin light chain. Plasmablastic lymphomas often occur in the oral region of human immunodeficiency virus-infected individuals and are EBER positive and ALK negative. The anaplastic variant of DLBCL is usually strongly CD20+ and ALK−. Plasmablastic myeloma has not been reported to be ALK positive and would be associated with other features such as lytic bone lesions and a monoclonal protein in serum and/or urine.
ALK+/DLBCL is characterized by ALK rearrangement. In well-characterized cases, three genes have been reported as a fusion partner of ALK: clathrin (CLTC-ALK), nucleophosmin (NPM-ALK), and SEC31A (SEC31A-ALK) [4, 5, 8–10]. Recently, a novel fusion partner of ALK has been reported SEC31A and sequestosome1/SQSTM1 [11]. The ALK immunostaining pattern in ALK+/DLBCL appears to correlate with the type of the underlying rearrangement. Cases with CLTC-ALK/t(2;17) rearrangement show a distinctly cytoplasmic and granular ALK staining pattern, whereas those cases with an NPM-ALK/t(2;5) rearrangement show both cytoplasmic and nuclear staining [2, 6, 8]. The staining pattern for the novel partner sequestosome1/SQSTM1 has been reported as diffusely cytoplasmic [11]. However, this correlation may be imperfect, as Onciu et al. reported one case of ALK+/DLBCL with NPM-ALK fusion that showed cytoplasmic ALK staining only [4]. Because of the heterogeneity of ALK rearrangements in ALK+/DLBCL, in our case, we selected to use a split probe that confirms the ALK rearrangement; however, it does not allow the definition of the specific chromosome partner. Given the cytoplasmic granular staining pattern with ALK immunohistochemistry, it is most likely that the partner in our case is clathrin.
ALK+/DLBCL is a very aggressive neoplasm with high relapse rate and lack of response to standard regimens [2, 3]. The plasmablastic differentiation which is found in these neoplasms is associated with the acquisition of the transcriptional profile of plasma cells in concert with extinction of the B cell differentiation program by proliferating immunoblasts. The deeper insights into the molecular pathogenesis of large B cell lymphomas with plasmablastic differentiation could identify new and effective alternative treatments [15].
In conclusion, we report a rare case of ALK+/DLBCL diagnosed in bone marrow trephine of a young patient who presented with liver masses. The histopathologic diagnosis and differential diagnosis on bone marrow biopsy require detailed immunohistochemical analysis with inclusion of ALK antibody in the immunohistochemical panel for those cases showing anaplastic/plasmablastic morphology and fail to express the usual cellular lineage markers, particularly in the bone marrow biopsy. FISH analysis supports the diagnosis and confirms the ALK gene involvement in the pathogenesis of the disease.
References
Delsol G, Lamant L, Mariamé B, Pulford K, Dastugue N, Brousset P et al (1997) A new subtype of large B-cell lymphoma expressing the ALK kinase and lacking the 2;5 translocation. Blood 89:1483–1490
Swerdlow SH, Campo E, Harris NL, Jaffe ES, Pileri SA, Stein H, Thiele J, Vardiman JW (eds) (2008) World Health Organization classification of tumours of haematopoietic and lymphoid tissues. IARC Press, Lyon, pp 254–255
Laurent C, Do C, Gascoyne RD, Lamant L, Yse-baert L, Laurent G, Delsol G, Brousset P (2009) Anaplastic lymphoma kinase-positive diffuse large B-cell lymphoma: a rare clinicopathologic entity with poor prognosis. J Clin Oncol 27:4211–4216
Onciu M, Behm FG, Downing JR et al (2003) ALK positive plasmablastic B-cell lymphoma with expression of the NPM-ALK fusion transcript: report of 2 cases. Blood 102:2642–2644
Chikatsu N, Kojima H, Suzukawa K et al (2003) ALK+, CD30−, CD20− large B-cell lymphoma containing anaplastic lymphoma kinase (ALK) fused to clathrin heavy chain gene (CLTC). Mod Pathol 16:828–832
Reichard KK, McKenna RW, Kroft SH (2007) ALK-positive diffuse large B-cell lymphoma: report of four cases and review of the literature. Mod Pathol 20:310–319
Li K, Tipps AM, Wang HY (2010) Anaplastic lymphoma kinase-positive diffuse large B-cell lymphoma presenting as an isolated nasopharyngeal mass: a case report and review of literature. Int J Clin Exp Pathol 4(2):190–196
Gascoyne RD, Lamant L, Martin-Subero JI, Lestou VS, Harris NL, Muller-Hermelink HK et al (2003) ALK-positive diffuse large B-cell lymphoma is associated with clathrin-ALK rearrangements: report of 6 cases. Blood 102(7):2568–2573
Alizadeh AA, Eisen MB, Davis RE, Ma C, Lossos IS, Rosenwald A et al (2000) Distinct types of diffuse large B-cell lymphoma identified by gene expression profiling. Nature 403:503–511
Van Roosbroeck K, Cools J, Dierickx D, Thomas J, Vandenberghe P, Stul M et al (2010) ALK-positive large B-cell lymphomas with cryptic SEC31A-ALK and NPM1-ALK fusions. Haematologica 95(3):509–513
Takeuchi K, Soda M, Togashi Y, Ota Y, Sekiguchi Y, Hatano S et al (2011) Identification of a novel fusion, SQSTM1-ALK, in ALK-positive large B-cell lymphoma. Haematologica 96(3):464–467
Li S (2009) Anaplastic lymphoma kinase-positive large B-cell lymphoma: a distinct clinicopathological entity. Int J Clin Exp Pathol 2:508–518
Beltran B, Castillo J, Salas R, Quiñones P, Morales D, Hurtado F, Riva L, Winer E (2009) ALK-positive diffuse large B-cell lymphoma: report of four cases and review of the literature. J Hematol Oncol 2:11. doi:10.1186/1756-8722-2-11
De Paepe P, Baens M, van Krieken H, Verhasselt B, Stul M, Simons A et al (2003) ALK activation by the CLTC-ALK fusion is a recurrent event in large B-cell lymphoma. Blood 102:2638–2641
Montres-Moreno S, Montalban C, Piris MA (2012) Large B cell lymphomas with plasmablastic differentiation: a biological and therapeutic challenge. Leuk Lymphoma 53(2):185–194
McManus DT, Catherwood MA, Carey PD et al (2004) ALK positive diffuse large B-cell lymphoma of the stomach associated with a Clathrin-ALK rearrangement. Hum Pathol 35:1285–1288
Rudzski Z, Rucinska M, Jurczak W et al (2005) ALK positive diffuse large B-cell lymphoma: two more cases and a brief literature review. Pol J Pathol 56:37–45
Gesk S, Gascoyne RD, Schnitzer B et al (2005) ALK positive diffuse large B-cell lymphoma with ALK-clathrin fusion belongs to the spectrum of pediatric lymphomas. Leukemia 19:1839–1858
Bubala H, Maldyk J, Wlodarska I et al (2006) ALK-positive diffuse large B-cell lymphoma. Pediatr Blood Cancer 46:649–653
Isimbaldi G, Bandiera L, d’Amore ES et al (2006) ALK positive plasmablastic B-cell lymphoma with the clathrin-ALK gene rearrangement. Pediatr Blood Cancer 46:390–391
Conflict of interest
The authors declare that they have no conflict of interest.
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Ioannou, Μ.G., Kouvaras, E., Panagiotidis, P. et al. Anaplastic lymphoma kinase-positive diffuse large B cell lymphoma: immunohistochemical and FISH analysis of a rare tumor with unusual clinical presentation. J Hematopathol 6, 231–235 (2013). https://doi.org/10.1007/s12308-013-0183-y
