Abstract
Background
The genus Ternstroemia is associated with the vulnerable tropical montane cloud forest in Mexico and with other relevant vegetation types worldwide. It contains threatened and pharmacologically important species and has taxonomic issues regarding its species limits. This study describes 38 microsatellite markers generated using a genomic-based approach.
Methods and results
We tested 23 of these markers in a natural population of Ternstroemia lineata. These markers are highly polymorphic (all loci polymorphic with 3–14 alleles per locus and expected heterozygosity between 0.202 and 0.908), most of them (19 out of 23) are in Hardy-Weinberg Equilibrium and free of null alleles (18 out of 23). Also we found no evidence of linkage among them. Finally, we tested the transferability to six other American species of Ternstroemia, two other Pentaphylacaceae species, and four species from different families within the order Ericales.
Conclusions
These molecular resources are promising tools to investigate genetic diversity loss and as barcodes for ethnopharmacological applications and species delimitation in the family Pentaphylacaceae and some Ericales, among other applications.
Similar content being viewed by others
Introduction
The genus Ternstroemia Mutis ex L.f. contains between 110 and 160 species mainly distributed across the tropical and subtropical regions worldwide [1, 2]. In Mexico, some Ternstroemia species are considered either diagnostic or associated with tropical montane cloud forests (TMCF) [3], while other species across the world are widespread in both tropical and temperate forests. According to climate-change scenarios, the TMCF will face severe threats regarding physiological adaptation and survival [4]. Among the species of Ternstroemia, some taxa such as T. dentisepala B.M. Barthol. and T. huasteca B.M. Barthol. are considered a priority for conservation since they are endemic and geographically rare [5]. Ternstroemia huasteca is considered “vulnerable” in the IUCN Red List [6]. Moreover, Mexican species such as T. chalichophila, T. dentisepala, and T. impressa belong to the Ternstroemia lineata species complex, a taxonomic group with unresolved relationships, putatively obscured by ongoing interspecific processes [7].
In Mexico, most genetic diversity research on forest species has been focused on timber species, such as the Pinaceae and the genus Quercus. In contrast, the knowledge of genetic patterns in other tree species is relatively scarce [8]. Nevertheless, some studies on Mexican TMCF species such as Abies [9], Chiranthodendron [10], Liquidambar [11], and Podocarpus [12] have identified historical gene drift and populational isolation during the Pleistocene interglacial periods [13].
The biogeographic history of Ternstroemia remains poorly known because there are no comprehensible explanations of its amphipacific distribution. However, efforts like the study of Rose et al. [14] included few Pentaphylacaceae species. Moreover, there are no populational studies of any species of the genus nor specific genetic markers, while during recent years, new species are increasingly being described, frequently endemic and/or threatened [15,16,17,18]. In Mexico, several species of Ternstroemia are considered an ethnopharmacological resource, named as “té de tila”. The dry fruits are used to treat anxiety and insomnia; also, they are known for their analgesic, anti-inflammatory, and anticonvulsant properties [19]. Although, most of the effects result from the neurotoxicity induced by terpenoids and may be considered a health risk [20]. This issue is a health concern because infusions are sold as mixtures with other species (by local sellers and street markets) or in sachets (finely ground in supermarkets).
Currently, there are no published assessments about the impact of the exploitation of Ternstroemia fruits on its genetic diversity and demography. However, similar systems (trees under some exploitation) such as Aquilaria [21], Cedrus [22], and Dipterocarpus [23] have been genetically evaluated using microsatellites or simple sequence repeats (SSRs). This technique offers advantages such as codominance, high polymorphism, individual resolution, technical simplicity, and the ease of applying it to degraded DNA, such as herbarium vouchers [24].
Considering the pharmacological importance and ubiquity of Ternstroemia within the Mexican TMCF, it is urgent to develop specific genetic markers for the genus. Therefore, this manuscript describes the development of a set of 38 nuclear microsatellites. Specifically, we seek to test its utility in (1) estimating genetic diversity in Ternstroemia lineata, and (2) its transferability to six other key species of Ternstroemia and other Ericales.
Materials and methods
Tissue collection and DNA isolation
We collected single, young leaves in silica gel from 20 individuals of Ternstroemia lineata from a mixed temperate forest in southern Morelia (Central-Western Mexico), between the localities of San Miguel del Monte and Ichaqueo. The individuals were georeferenced and sampled at least 250 m apart (Fig. 1). Leaves from species other than T. lineata were either opportunistically collected and dried in silica gel or retrieved from herbarium vouchers (such as Freziera sp. and the South American T. asymmetrica and T. subserrata). These two South American species may give insights about the markers’ transferability success in non-Mexican species. The Ericales sample included some representative families across the order: Ebenaceae (Diospyros xolocotzii), Foquieriaceae (Foquieria splendens), Primulaceae (Rapanea sp.), and Symplocaceae (Symplocos citrea); this selection is intended to provide a rough estimation of cross-amplification success across the order Ericales. We grounded the leaf tissue of all the studied species in individual 2 mL microtubes in a Retsch Mill (MM400). DNA was isolated using the CTAB protocol [25].
Microsatellite search using high throughput sequencing
In order to find the repetitive regions, we outsourced AllGenetics & Biology SL (La Coruña, Spain). One individual was randomly chosen as the source sample and used to construct the genomic DNA library. The library was prepared using the Nextera XT DNA enrichment kit (Illumina) with the microsatellite motifs: AC, AG, AT, ACG, and ATCT and following the manufacturer’s instructions. The library was then sequenced in the Illumina MiSeq platform (PE300), producing 9,921,869 paired-end reads. The quality of the raw sequencing data was checked using FastQC [26]. Finally, reads were processed in Geneious 10.2.3 and using in-house developed scripts. Primer design was implemented in Primer3 [27, 28] in Geneious 10.2.3 (Biomatters, LTD).
Validation and cross-amplification
First, we filtered the database to select only perfect and uninterrupted motifs, and then we randomly selected 38 candidate primer pairs. These 38 loci contained only dinucleotide repeats; by far, the most common (35 loci or 92.1%) motif was (AG)n. Two markers, Tli161 and Tli198, presented the motif (AC)n. The motif (AT)n was present only in the locus Tli175. PCRs were performed using the Platinum Master Mix (Thermo-Fisher, USA) following the manufacturer’s instructions for reaction assembly and program. The annealing temperature was 60 °C since all the primers were designed around this value. Once the 38 markers were validated in the source T. lineata subsp. lineata sample, they were tested in six American Ternstroemia spp., Cleyera Thunb., and Freziera Willd. (Pentaphylacaceae), and other Ericales such as Diospyros L. (Ebenaceae), Fouquieria Kunth. (Fouquieriaceae), Rapanea Aubl. (Primulaceae), and Symplocos Jacq. (Symplocaceae). Out of the 38 candidate markers, we chose 23 “well-working” primer pairs that showed consistent amplification in a 2% agarose gel electrophoresis (high transferability and amplification success across the genus Ternstroemia, few secondary bands and/or bands consistent with the size obtained in the source sample validation). Since the remaining 15 markers show variable amplification success, we decided not to use them in genotyping. However, we report the primer sequences and the expected size. The 23 “well-working” markers subset was fluorescently labeled in the 5′ endings using the Dye Set 33 (Applied Biosystems, USA) and then used to evaluate the parameters of the source sample population. Fragment analysis was performed in Psomagen Inc. (Maryland, USA), and genotyping was achieved using the Microsatellite plugin (v. 1.4.7) of Geneious Prime 2022 (Dotmatics, NZ). Allele scoring was performed manually using as guidelines the supplementary material of Selkoe and Toonen [24]. Genetic parameters such as expected and observed heterozygosity (He, Ho), allelic richness (Na), and deviation from Hardy-Weinberg equilibrium were calculated in GenAlEx 6.503 [29]. PIC was calculated using PIC_CALC [30]. We tested linkage disequilibrium among all the 23 chosen loci using the association index (\(\bar{r}_{d}\)) of Agapow and Burt [31] implemented in the R package poppr [32]. We checked the presence of null alleles using the R package PopGenReport [33]. Finally, we performed an interpolation of the individual heterozygosity using Empirical Bayesian kriging [34] in ArcGIS 10.3 (ESRI, USA), to explore the marker set’s potential in fine-scale genetic approaches. This approach automatically calculated the semivariogram from 1000 simulations using a standard circular neighborhood search (10–15 neighbors data points, radius = 0.013).
Results and discussion
All the evaluated markers presented polymorphism. The number of alleles (Na) ranged from 3 to 14 (mean = 7.174). The observed heterozygosity ranged from 0 to 0.889 (mean = 0.539), and the expected heterozygosity (He) ranged from 0.202 to 0.908 (mean = 0.676). Polymorphism Information Content ranged from 0.19 to 0.90 (mean = 0.643), with only four loci under PIC = 0.5 (Table 2). We found significant evidence of null alleles in five loci, whereas four loci exhibited Hardy-Weinberg disequilibrium (at P > 0.05) (Table 2). The index of association (\(\bar{r}_{d}\)) was 0.0301 (P = 0.618), indicating no evidence of linkage disequilibrium among the markers. All amplicons, including the microsatellite regions, were deposited in NCBI Genbank (accessions in Table 1). For the candidate loci, transferability is relatively high among Ternstroemia spp. (81.6–100%) and the two Pentaphylacaceae (89.5%for Cleyera theaeoides (Sw.) Choisy and 81.6%for Freziera sp.) (Table 3). Across the Ericales, the amplification success (Table 4) was very low in Diospyros xolocotzii Madrigal & Rzed. (7.9% to low in Symplocos sp. (26.3%) but consistent with the expected amplification success among families of the same order [35]. Since we selected the 23 evaluated markers for their consistent amplification, the minimum amplification success of this subset for Pentaphylacaceae was 91.3%. The interpolated map of genetic diversity (measured as individual heterozygosity) showed a clear declining trend from South-West (Fig. 2). Therefore, these markers are a suitable set for fine-scale population genetic research in this family. They can also clarify the taxonomic limits among troublesome groups such as the Ternstroemia lineata species complex (e.g., T. chalicophila Loes., T. dentisepala, and T. impressa Lundell tested in this study). In this species complex, efforts using traditional phylogenetic markers have been insufficient. They are also useful for assessing the genetic diversity in threatened species, as is the case of T. huasteca.
References
Luna-Vega I, Ochoterena H (2004) Phylogenetic relationships of the genera of Theaceae based on morphology. Cladistics 20(3):223–270. https://doi.org/10.1111/j.1096-0031.2004.00024.x
Luna-Vega I, Contreras-Medina R (2000) Distribution of the genera of Theaceae (Angiospermae: Theales): a panbiogeographic analysis. Biogeographica 76(2):79–88
Alcántara O, Luna-Vega I, Velázquez A (2002) Altitudinal distribution patterns of mexican cloud forests based upon preferential characteristic genera. Plant Ecol 161(2):167–174. https://doi.org/10.1023/A:1020343410735
Ponce-Reyes R, Reynoso-Rosales VH, Watson JE, VanDerWal J, Fuller RA, Pressey RL, Possingham HP (2012) Vulnerability of cloud forest reserves in Mexico to climate change. Nat Clim Change 2(6):448–452. https://doi.org/10.1038/nclimate1453
Luna-Vega I, Alcántara O, Contreras-Medina R (2010) Threatened temperate plant species: contributions to their biogeography and conservation in Mexico. In: Tepper G (ed) Species, diversity and extinction. Nova-Science Publishers, New York, pp 317–339
González-Espinosa M, Meave JA, Lorea-Hernández FG, Ibarra-Manriquez G, Newton AC (2011) The red list of Mexican cloud forest trees. Fauna & Flora International, Cambridge
Alcántara-Ayala O, Maradiaga-Ceceña FS, Luna-Vega I, Alvarado-Sizzo H (2022) Ternstroemia guerrerensis (Pentaphylacaceae), a new endangered cloud forest tree from Guerrero. Mexico Phytotaxa 561(2):162–172. https://doi.org/10.11646/phytotaxa.561.2.4
Wehenkel C, Mariscal-Lucero SR, Jaramillo-Correa JP, López-Sánchez CA, Vargas-Hernández JJ, Sáenz-Romero C (2017) Genetic diversity and conservation of mexican forest trees. In: Ahuja M, Jain S (eds) Biodiversity and conservation of woody plants. Springer, Cham, pp 37–67. https://doi.org/10.1007/978-3-319-66426-2_2
Jaramillo-Correa JP, Aguirre-Planter E, Khasa DP, Eguiarte LE, Piñero D, Furnier GR, Bousquet J (2008) Ancestry and divergence of subtropical montane forest isolates: molecular biogeography of the genus Abies (Pinaceae) in southern México and Guatemala. Mol Ecol 17(10):2476–2490. https://doi.org/10.1111/j.1365-294X.2008.03762.x
Hernández-Langford DG, Siqueiros-Delgado ME, Ruíz-Sánchez E (2020) Nuclear phylogeography of the temperate tree species Chiranthodendron pentadactylon (Malvaceae): quaternary relicts in mesoamerican cloud forests. BMC Evol Biol 20(1):1–14. https://doi.org/10.1186/s12862-020-01605-8
Ruiz-Sanchez E, Ornelas JF (2014) Phylogeography of Liquidambar styraciflua (Altingiaceae) in Mesoamerica: survivors of a Neogene widespread temperate forest (or cloud forest) in North America? Ecol Evol 4(4):311–328. https://doi.org/10.1002/ece3.938
Ornelas JF, Ruiz-Sánchez E, Sosa V (2010) Phylogeography of Podocarpus matudae (Podocarpaceae): pre-quaternary relicts in northern mesoamerican cloud forests. J Biogeogr 37:2384–2396. https://doi.org/10.1111/j.1365-2699.2010.02372.x
Ramírez-Barahona S, Eguiarte LE (2013) The role of glacial cycles in promoting genetic diversity in the Neotropics: the case of cloud forests during the last glacial Maximum. Ecol Evol 3(3):725–738. https://doi.org/10.1002/ece3.483
Rose JP, Kleist TJ, Löfstrand SD, Drew BT, Schoenenberger J, Sytsma KJ (2018) Phylogeny, historical biogeography, and diversification of angiosperm order Ericales suggest ancient neotropical and east asian connections. Mol Phylogenet Evol 122:59–79. https://doi.org/10.1016/j.ympev.2018.01.014
Alves Vieira J, Sampaio Silveira D, Matheus V, Jordão M, Soares-Silva JP (2021) Taxonomic novelties in Pentaphylacaceae: four new species of Ternstroemia from Brazil. Neodiversity 14:3–18. https://doi.org/10.13102/neod.141.2
Castillo-Campos G, Palacios-Wassenaar OM (2019) Ternstroemia acajetensis (Pentaphylacaceae), a new species from the cloud forest in central Veracruz. Mexico Phytotaxa 418(2):211–218. https://doi.org/10.11646/phytotaxa.418.2.6
Cheek M, Tchiengue B, Tacham WN (2017) Ternstroemia cameroonensis (Ternstroemiaceae), a new medicinally important species of montane tree, nearly extinct in the Highlands of Cameroon. Blumea 62(1):53–57. https://doi.org/10.3767/000651917X695362
Cheek M, Haba PM, Konomou G, Van Der Burgt XM (2019) Ternstroemia guineensis (Ternstroemiaceae), a new endangered cloud forest shrub with neotropical affinities from Kounounkan, Guinea, W Africa. Willdenowia 49(3):351–360. https://doi.org/10.3372/wi.49.49306
Moreno-Quirós CV, Sánchez-Medina A, Vázquez-Hernández M, Hernández Reyes AG, García-Rodríguez RV, Cham (2017) Antioxidant, anti-inflammatory and antinociceptive potential of Ternstroemia sylvatica Schltdl. Asian Pac J Trop Med 10(11):1047–1053. https://doi.org/10.1016/J.APJTM.2017.10.007
López-Rubalcava C, Estrada-Camarena E (2016) Mexican medicinal plants with anxiolytic or antidepressant activity: focus on preclinical research. J Ethnopharmacol 186:377–391. https://doi.org/10.1016/j.jep.2016.03.053
Nanda P, Singh AK, Negi MS, Tripathi SB (2017) Rapid development and characterization of fifteen novel microsatellite loci in vulnerable tree Aquilaria malaccensis using next generation ion torrent PGM™ sequencing. Indian J Genet Plant Breed 77(1):145–152. https://doi.org/10.5958/0975-6906.2017.00019.0
Barthwal S (2020) Chloroplast microsatellites reveal genetic diversity and population structure in natural populations of Himalayan Cedar (Cedrus deodara (Roxb.) G. Don) in India. Silvae Genet 69(1):86–93. https://doi.org/10.2478/sg-2020-0012
Nguyen TM, Vu DD, Nguyen DM, Dang HP, Phan LK, Bui PX (2020) Microsatellite analysis reveals genetic diversity of the endangered species Dipterocarpus dyeri. J For Res 25(3):198–201. https://doi.org/10.1080/13416979.2020.1747149
Selkoe KA, Toonen RJ (2006) Microsatellites for ecologists: a practical guide to using and evaluating microsatellite markers. Ecol Lett 9(5):615–629. https://doi.org/10.1111/j.1461-0248.2006.00889.x
Doyle JJ, Doyle JL (1987) A rapid DNA isolation procedure for small quantities of fresh leaf tissue. Phytochem Bull 19(1):11–15
Andrews S (2010) Babraham bioinformatics-FastQC a quality control tool for high throughput sequence data. https://www.bioinformatics.babraham.ac.uk/projects/fastqc/
Koressaar T, Remm M (2007) Enhancements and modifications of primer design program Primer3. Bioinformatics 23(10):1289–1291. https://doi.org/10.1093/bioinformatics/btm091
Untergasser A, Cutcutache I, Koressaar T, Ye J, Faircloth BC, Remm M, Rozen SG (2012) Primer3—new capabilities and interfaces. Nucleic Acids Res 40(15):e115–e115. https://doi.org/10.1093/nar/gks596
Peakall R, Smouse PE (2012) GenAlEx 6.5: genetic analysis in excel. Population genetic software for teaching and research–an update. Bioinformatics 28(19):2537–2539. https://doi.org/10.1093/bioinformatics/bts460
Sheng L (2006) PIC_CALC. https://github.com/luansheng/PIC_CALC. Accessed 24 Nov 2022
Agapow PM, Burt A (2001) Indices of multilocus linkage disequilibrium. Mol Ecol Notes 1(1–2):101–102. https://doi.org/10.1046/j.1471-8278.2000.00014.xC
Kamvar ZN, Tabima JF, Grünwald NJ (2014) Poppr: an R package for genetic analysis of populations with clonal, partially clonal, and/or sexual reproduction. PeerJ 2:e281. https://doi.org/10.7717/peerj.281
Adamack AT, Gruber B (2014) PopGenReport: simplifying basic population genetic analyses in R. Methods Ecol Evol 5(4):384–387. https://doi.org/10.1111/2041-210X.12158
Krivoruchko K (2012) Empirical bayesian kriging. ArcUser 6(10):1145
Barbará T, Palma-Silva C, Paggi GM, Bered F, Fay MF, Lexer C (2007) Cross-species transfer of nuclear microsatellite markers: potential and limitations. Mol Ecol 16(18):3759–3767. https://doi.org/10.1111/j.1365-294X.2007.03439.x
