Abstract
Here we present simple examples, showing that solutions of singularly perturbed differential equations naturally have composite asymptotic expansions (ca se s) near turning points. A theory of ca se s might thus help to understand them.All examples are linear equations of first order. The first example is among the simplest ones having a turning point. The second one contains a control parameter for “duck hunting” or “canard hunting”. The third example also contains a control parameter, but the turning point is no longer simple; this implies that the canard solutions are no longer overstable solutions in the sense of Guy Wallet. Finally the fourth example relates to “fake ducks” or “fake canard solutions”: the slow curve is first repelling and then attracting. In this situation, any solution with bounded initial condition at the turning point is defined and bounded on an interval containing this turning point, but this solution can have a ca se only if the initial condition has an asymptotic expansion. We will see that this necessary condition is also sufficient.
Access this chapter
Tax calculation will be finalised at checkout
Purchases are for personal use only
Notes
- 1.
In this memoir, we will use the notation \({y}^{-}\sim \widehat{y}\) for the Poincaré asymptotic.
- 2.
Here we are interested only in the case p even, but the case p odd also has its interest, cf. Eq. (6.15) in Sect. 6.2.
- 3.
Recall that “bounded” means uniformly with respect to \(\epsilon \) in some interval \(]0,{\epsilon }_{0}]\) . In the present context, it turns out that, for all fixed \(\epsilon \) , there is a unique value \(\alpha = \alpha (\epsilon )\) for which (1.13) has a solution \(y = y(x,\epsilon )\) bounded on \(\mathbb{R}\) in the classical sense, and that the function y so defined is also bounded on \(\mathbb{R}\times \,]0,{\epsilon }_{0}]\).
References
Ackerberg, R.C., O’Malley, R.E.: Boundary layer problems exhibiting resonance. Stud. Appl. Math. 49, 277–295 (1970)
Balser, W.: Formal Power Series and Linear Systems of Meromorphic Ordinary Differential Equations. Springer, New York (2000)
Benoît, É., Callot, J.-L., Diener, F., Diener, M.: Chasse au canard. Collect. Math. 31, 37–119 (1981)
Benoît, É., El Hamidi, A., Fruchard, A.: On combined asymptotic expansions in singular perturbations. Electron. J. Diff. Equat. 51, 1–27 (2002)
Benoît, É., Fruchard, A., Schäfke, R., Wallet, G.: Solutions surstables des équations différentielles complexes lentes-rapides à point tournant. Ann. Fac. Sci. Toulouse Math. VII 4, 627–658 (1998)
Benoît, É., Fruchard, A., Schäfke, R., Wallet, G.: Overstability: Toward a global study. C. R. Acad. Sci. Paris I 326, 873–878 (1998)
Bonckaert, P., De Maesschalck, P., Gevrey normal forms of vector fields with one zero eigenvalue. J. Math. Anal. Appl. 344, 301–321 (2008)
Canalis-Durand, M., Mozo-Fernandez, J., Schäfke, R.: Monomial summability and doubly singular differential equations. J. Differ. Equat. 233, 485–511 (2007)
Canalis-Durand, M., Ramis, J.-P., Schäfke, R., Sibuya, Y.: Gevrey solutions of singularly perturbed differential equations. J. Reine Angew. Math. 518, 95–129 (2000)
De Maesschalck, P.: On maximum bifurcation delay in real planar singularly perturbed vector fields. Nonlinear Anal. 68, 547–576 (2008)
De Maesschalck, P.: Ackerberg-O’Malley resonance in boundary value problems with a turning point of any order. Commun. Pure Appl. Anal. 6, 311–333 (2007)
De Maesschalck, P.: Gevrey properties of real planar singularly perturbed systems. J. Differ. Equat. 238, 338–365 (2007)
De Maesschalck, P., Dumortier, F.: Canard solutions at non-generic turning points. Trans. Am. Math. Soc. 358, 2291–2334 (2006)
Diener, M.: Regularizing microscopes and rivers. SIAM J. Math. Anal. 25, 148–173 (1994)
Dorodnitsyn, A.A.: Asymptotic solution of the Van der Pol equation. Priklad. Mat. Mekh. 11, 313–328 (1947) (in russian)
Dumortier, F., Roussarie, R.: Canard cycles and center manifolds. Memoir. Am. Math. Soc. 577, 1996
Eckhaus, W.: Asymptotic analysis of singular perturbations. Studies in Mathematics and its Applications, vol. 9. North-Holland, Amsterdam (1979)
Erdélyi, A.: Singular perturbations of boundary value problems involving ordinary differential equations. J. Soc. Indust. Appl. Math. 11, 105–116 (1963)
Fenichel, N.: Geometric singular perturbation theory for ordinary differential equations. J. Differ. Equat. 31, 53–98 (1979)
Forget, T.: Points tournants dégénérés, Thèse de Doctorat, Université de La Rochelle, 2007
Forget, T.: Solutions canards en des points tournants dégénérés. Ann. Fac. Sci. Toulouse Math. 16, 799–816 (2007)
Forget, T.: Asymptotic study of planar canard solutions. Bull. Belg. Math. Soc. Simon Stevin 15, 809–824 (2008)
Fraenkel, L.E.: On the method of matched asymptotic expansions. Proc. Cambridge Philos. Soc. 65, 209–284 (1969)
Fruchard, A., Schäfke, R.: Exceptional complex solutions of the forced Van der Pol equation. Funkcialaj Ekvacioj 42, 201–223 (1999)
Fruchard, A., Schäfke, R.: Overstability and resonance. Ann. Inst. Fourier Grenoble 53, 227–264 (2003)
Fruchard, A., Schäfke, R.: A survey of some results on overstability and bifurcation delay. Discrete Cont. Dyn. Syst. S 2, 931–965 (2009)
Fruchard, A., Schäfke, R.: De nouveaux développements asymptotiques combinés pour la perturbation singulière. Actes du Colloque à la mémoire d’Emmanuel Isambert Publications Univ. Paris 13, 125–161 (2012)
Fruchard, A., Schäfke, R.: Composite asymptotic expansions and turning points of singularly perturbed ordinary differential equations. C. R. Math. Acad. Sci. 348, 1273–1277 (2010)
Gautheron, V., Isambert, E.: Finitely differentiable ducks and finite expansions. In: Benoît, E. (ed.) Dynamic Bifurcations, Lect. Notes Math., vol. 1493, pp. 40–56. Springer, New York (1991)
Van Gils, S., Krupa, M., Szmolyan, P.: Asymptotic expansions using blow-up Z. Angew. Math. Phys. 56, 369–397 (2005)
Hek, G.: Geometric singular perturbation theory in biological practice. J. Math. Biol. 60, 347–386 (2010)
Isambert, E.: Nonsmooth ducks and regular perturbations of rivers, I and II. J. Math. Anal. Appl. 200, 14–33 and 289–306 (1996)
Jones, C.K.R.T.: Geometric singular perturbation theory. In: Dynamical Systems, Lect. Notes Math., vol. 1609. Springer, New York (1995)
Kaplun, S., Lagerstrom, P.A.: Asymptotic expansions of Navier-Stokes solutions for small Reynolds numbers. J. Math. Mech. 6, 585–593 (1957)
Kevorkian, J., Cole, J.D.: Perturbation methods in applied mathematics. Applied Mathematical Sciences, vol. 34. Springer, New York (1981)
Kopell, N.: A geometric approach to boundary layer problems exhibiting resonance. SIAM J. Appl. Math. 37, 436–458 (1979)
Kopell, N.: The singularly perturbed turning-point problem: a geometric approach. In: Singular perturbations and asymptotics, Proc. Adv. Sem., Math. Res. Center, University of Wisconsin, Madison, Wisconsin (1980) 173–190
Krupa, M., Szmolyan, P.: Relaxation oscillation and canard explosion. J. Differ. Equat. 174, 312–368 (2001)
Krupa, M., Szmolyan, P.: Extending geometric singular perturbation theory to nonhyperbolic points-fold and canard points in two dimensions. SIAM J. Math. Anal., 33, 286–314 (2001)
Lagerstrom, P.A.: Matched asymptotic expansions: ideas and techniques. Applied Mathematical Sciences, vol. 76. Springer, New York (1988)
Lobry, C.: Dynamic bifurcations. In: Benoît, E. (ed.) Dynamic Bifurcations, Lect. Notes Math., vol. 1493, pp. 1–13. Springer, New York (1991)
Matzinger, É.: Étude d’équations différentielles ordinaires singulièrement perturbées au voisinage d’un point tournant. Thesis, Preprint IRMA 2000/53, Strasbourg (2000)
Matzinger, É.: Étude des solutions surstables de l’équation de Van der Pol. Ann. Fac. Sci. Toulouse 10, 713–744 (2001)
Matzinger, É.: Asymptotic behaviour of solutions near a turning point: the example of the brusselator equation. J. Differ. Equat. 220, 478–510 (2006)
Mischenko, E.F., Rozov, N.Ch.: Differential Equations with Small Parameters and Relaxation Oscillations. Plenum Press, New York and London (1980)
O’Malley, R.E.: Singular perturbation methods for ordinary differential equations. Applied Mathematical Sciences, vol. 89. Springer, New York (1991)
Panazzolo, D.: On the existence of canard solutions. Publ. Mat. 44, 503–592 (2000)
Ramis, J.-P.: Dévissage Gevrey. Astérisque 59–60, 173–204 (1978)
Ramis, J.-P.: Les séries k-sommables et leurs applications. In: Complex Analysis, Microlocal Calculus and Relativistic Quantum Theory, Lect. Notes Physics, vol. 126, pp. 178–199. Springer, New York (1980)
Sibuya, Y.: Gevrey property of formal solutions in a parameter. In: Asymptotic and computational analysis (Winnipeg, MB, 1989). Lecture Notes in Pure and Appl. Math., vol. 124, pp. 393–401. Dekker, New York (1990)
Sibuya, Y.: Linear differential equations in the complex domain. Problems of Analytic Continuation. Am. Math. Soc., Providence (RI) (1990)
Sibuya, Y.: Uniform simplification in a full neighborhood of a transition point. Memoi. Am. Math. Soc. 149 (1974)
Sibuya, Y.: A theorem concerning uniform simplification at a transition point and a problem of resonance. SIAM J. Math. Anal. 12(5), 653–668 (1981)
Skinner, L.A.: Singular Perturbation Theory. Springer, New York (2011)
Skinner, L.A.: Uniform solution of boundary layer problems exhibiting resonance. SIAM J. Appl. Math. 47, 225–231 (1987)
Skinner, L.A.: Matched expansion solutions of the first-order turning point problem. SIAM J. Math. Anal. 25, 1402–1411 (1994)
Skinner, L.A.: A class of singularly perturbed singular Volterra integral equations. Asymptot. Anal. 22, 113–127 (2000)
Szmolyan, P., Wechselberger, M.: Canards in R3. J. Differ. Equat. 177, 419–453 (2001)
Vasil’eva, A.B., Butuzov, V.F.: Asymptotic Expansions of the Solutions of Singularly Perturbed Equations. Izdat. “Nauka”, Moscow (1973) (in Russian)
Wallet, G.: Surstabilité pour une équation différentielle analytique en dimension un. Ann. Inst. Fourier 40, 557–595 (1990)
Wasow, W.: Asymptotic Expansions for Ordinary Differential Equations. Interscience, New York (1965)
Wasow, W.: Linear Turning Point Theory. Springer, New York (1985)
Author information
Authors and Affiliations
Rights and permissions
Copyright information
© 2013 Springer-Verlag Berlin Heidelberg
About this chapter
Cite this chapter
Fruchard, A., Schäfke, R. (2013). Four Introductory Examples. In: Composite Asymptotic Expansions. Lecture Notes in Mathematics, vol 2066. Springer, Berlin, Heidelberg. https://doi.org/10.1007/978-3-642-34035-2_1
Download citation
DOI: https://doi.org/10.1007/978-3-642-34035-2_1
Published:
Publisher Name: Springer, Berlin, Heidelberg
Print ISBN: 978-3-642-34034-5
Online ISBN: 978-3-642-34035-2
eBook Packages: Mathematics and StatisticsMathematics and Statistics (R0)
