Energetics of calcium cycling in nonfailing and failing human myocardium

  • G. Hasenfuss
  • L. A. Mulieri
  • C. Holubarsch
  • B. Pieske
  • H. Just
  • N. R. Alpert
Conference paper


Using sensitive antimony-bismuth thermopiles, isometric force and heat output were measured in muscle strips from nonfailing human hearts and from failing dilated cardio-myopathic hearts at a stimulation rate of 60 beats per minute (37°C). This frequency was chosen because analysis of the force-frequency relation showed significant differences in isometric force between failing and nonfailing human myocardium at 60 beats per minute and at higher frequencies, whereas at lower rates of stimulation (30 beats per minute) force of contraction was similar in failing and nonfailing myocardium. The liberated initial heat was partitioned into its two components, tension-dependent heat and tension-independent heat from high-energy phosphate hydrolysis by contractile proteins and excitation-contraction coupling processes, respectively. Tension-dependent heat reflects the total number of cross-bridge interactions, and tension-independent heat is an index of the amount of calcium cycling during the contraction-relaxation cycle. In failing compared to nonfailing human myocardium, peak twitch tension, maximum rate of tension rise and maximum rate of tension fall were reduced significantly. Reduced mechanical performance was associated with reduced liberation of both tension-dependent and tension-independent heat in the failing heart. The reduction of tension-dependent heat by 61% and of tension-independent heat by 69% indicate considerable decreases in the number of crossbridge interactions activated and calcium ions cycled during the isometric twitch. In addition, the rate of calcium removal was reduced in the failing human heart as is indicated by a 71% reduction in tension-independent heat rate. The efficiency of excitation-contraction coupling with respect to crossbridge activation was similar in failing and nonfailing myocardium.

These data indicate that impaired myocardial performance in dilated cardiomyopathy may result from disturbed excitation-contraction coupling with reduced amount of calcium cycling and reduced rate of calcium removal.

Key words

Excitation-contraction coupling myothermal measurements calcium cycling contractile proteins dilated cardiomyopathy


Unable to display preview. Download preview PDF.

Unable to display preview. Download preview PDF.


  1. 1.
    Alpert NR, Mulieri LA (1982) Increased myothermal economy of isometric force generation in compensated cardiac hypertrophy induced by pulmonary artery constriction in the rabbit. Circ Res 50:491–500PubMedGoogle Scholar
  2. 2.
    Alpert NR, Blanchard EM, Mulieri LA (1989) Tension independent heat in rabbit papillary muscle. J Physiol (Lond) 414:433–453Google Scholar
  3. 3.
    Alpert NR, Mulieri LA, Hasenfuss G (1992) Myocardial chemo-mechanical energy transduction. In: Fozzard H (ed) The heart and cardiovascular system. Raven Press, New York, pp 111–128Google Scholar
  4. 4.
    Arai M, Otsu K, McLennan DH, Alpert NR, Periasami M (1991) Effect of thyroid hormone on the expression of mRNA encoding sarcoplasmic reticulum proteins. Circ Res 69:266–276PubMedGoogle Scholar
  5. 5.
    Beuckelmann DJ, Näbauer M, Erdmann E (1991) Characteristics of calcium-current in isolated human ventricular myocytes from patients with terminal heart failure. J Mol Cell Cardiol 23:929–937PubMedCrossRefGoogle Scholar
  6. 6.
    Beuckelman DJ, Erdmann E (1992) Calcium currents and intracellular calcium transients in single ventricular myocytes isolated from terminally failing human myocardium. In: Hasenfuss G, Holubarsch Ch, Just H, Alpert NR (eds) Cellular and molecular alterations in the failing human heart. Steinkopff Verlag, Darmstadt pp 235–243Google Scholar
  7. 7.
    Bing O, Brooks WW, Conrad CH, Sen S, Perreault CL, Morgan JP (1991) Intracellular calcium transients in myocardium from spontaneously hypertensive rats during the transition to heart failure. Circ Res 68:1390–1400PubMedGoogle Scholar
  8. 8.
    Carafoli E (1985) The homeostasis of calcium in heart cells. J Mol Cell Cardiol 17:203–212PubMedCrossRefGoogle Scholar
  9. 9.
    D’Agnolo A, Luciani GB, Mazzucco A, Gallucci V, Salviati G (1992) Contractile properties and Ca2+ release activity of the sarcoplasmic reticulum in dilated cardiomyopathy. Circulation 85:518–525PubMedGoogle Scholar
  10. 10.
    De la Bastie D, Levitsky D, Rappaport L, Mercadier JJ, Marotte F, Wisnewsky C, Brovkovich V, Schwartz K, Lompre AM (1990) Function of the sarcoplasmic reticulum and expression of its Ca2+-ATPase gene in pressure overload-induced cardiac hypertrophy in the rat. Circ Res 66:554–564PubMedGoogle Scholar
  11. 11.
    Fabiato A (1983) Calcium-induced release of calcium from the cardiac sarcoplasmic reticulum. Am J Physiol 245:C1–C14PubMedGoogle Scholar
  12. 12.
    Feldman MD, Gwathmey JK, Phillips P, Schoen F, Morgan JP (1988) Reversal of the force-frequency relationship in working myocardium from patients with end-stage heart failure. J Applied Cardiol 3:273–283Google Scholar
  13. 13.
    Gwathmey JK, Copelas L, Mackinnon R, Schoen FJ, Feldman MD, Grossman W, Morgan JP (1987) Abnormal intracellular calcium handling in myocardium from patients with end-stage heart failure. Circ Res 61:70–76PubMedGoogle Scholar
  14. 14.
    Gwathmey JK, Slawsky MT, Hajjar RJ, Briggs GM, Morgan JP (1990) Role of intracellular calcium handling in force interval relationship of human ventricular myocardium. J Clin Invest 85:1599–1613PubMedCrossRefGoogle Scholar
  15. 15.
    Hasenfuss G, Mulieri LA, Blanchard EM, Holubarsch Ch, Leavitt BJ, Ittleman F, Alpert NR (1991) Energetics of isometric force development in control and volume overload human myocardium. Comparison with animal species. Circ Res 68:836–846PubMedGoogle Scholar
  16. 16.
    Hasenfuss G, Mulieri LA, Leavitt BJ, Allen PD, Haeberle JR, Alpert NR (1992) Alteration of contractile function and excitation-contraction coupling in dilated cardiomyopathy Circ Res 70:1225–1232PubMedGoogle Scholar
  17. 17.
    Holmberg S, Williams AJ (1989) Single channel recordings from human cardiac sarcoplasmic reticulum. Circ Res 65:1445–1449PubMedGoogle Scholar
  18. 18.
    Holubarsch Ch, Goulette RP, Litten RZ, Martin BJ, Mulieri LA, Alpert NR (1985) The economy of isometric force development, myosin isoenzyme pattern and myofibrillar ATPase activity in normal and hypothyroid rat myocardium. Circ Res 56:78–86PubMedGoogle Scholar
  19. 19.
    Huxley AF (1957) Muscle structure and theories of contraction. Prog Biophys Biophys Chem 7:255–318PubMedGoogle Scholar
  20. 20.
    Kammermeier H, Roeb E, Jüngling E, Meyer B (1990) Regulation of systolic force and control of free energy of ATP-hydrolysis in hypoxic hearts. J Mol Cell Cardiol 22:707–713PubMedCrossRefGoogle Scholar
  21. 21.
    Limas CJ, Olivari M, Goldenberg JF, Levine TB, Bendit DG, Simon A (1987) Calcium uptake by cardiac sarcoplasmic reticulum in human dilated cardiomyopathy. Cardiovasc Res 21:601–605PubMedCrossRefGoogle Scholar
  22. 22.
    Mercadier JJ, Lompre AM, Duc P, Boheler KR, Fraysse JB, Wisnewsky C, Allen PD, Komajda M, Schwartz K (1990) Altered sarcoplasmic reticulum Ca2+-ATPase gene expression in the human ventricle during end-stage heart failure. J Clin Invest 85:305–309PubMedCrossRefGoogle Scholar
  23. 23.
    Morgan JP (1991) Abnormal intracellular modulation of calcium as a major cause of cardiac contractile dysfunction. N Engl J Med 325:625–632PubMedCrossRefGoogle Scholar
  24. 24.
    Movsesian MA, Bristow MR, Krall J (1989) Ca2+ uptake by cardiac sarcoplasmic reticulum from patients with idiopathic dilated cardiomyopathy. Circ Res 65:1141–1144PubMedGoogle Scholar
  25. 25.
    Mulieri LA, Luhr G, Trefry J, Alpert NR (1977) Metal-film thermopiles for use with rabbit right ventricular papillary muscle. Am J Physiol 233:C146–C156PubMedGoogle Scholar
  26. 26.
    Mulieri LA, Hasenfuss G, Ittleman F, Blanchard EM, Alpert NR (1989) Protection of human left ventricular myocardium from cutting injury with 2,3-butanedione monoxime. Circ Res 65:1441–1444PubMedGoogle Scholar
  27. 27.
    Mulieri LA, Leavitt BJ, Hasenfuss G, Allen PD, Alpert NR (1992) Contractile frequency dependence of twitch and diastolic tension in dilated cardiomyopathy. In: Hasenfuss G, Holubarsch Ch, Just H, Alpert NR (eds) Cellular and molecular alterations in the failing human heart. Steinkopff Verlag, Darmstadt pp 199–212Google Scholar
  28. 28.
    Mulieri LA, Hasenfuss G, Leavitt BJ, Allen PD, Alpert NR (1992) Altered myocardial force-frequency relation in human heart failure. Circulation 85:1743–1750PubMedGoogle Scholar
  29. 29.
    Philipson KD (1990) The cardiac Na+-Ca+-Exchanger. In: G.A. Langer (ed) Calcium and the heart. Raven Press, New York, pp 85–108Google Scholar
  30. 30.
    Paradise NF, Schmitter JL, Surmitis JM (1981) Criteria for adequate oxygenation of isometric kitten papillary muscle. Am J Physiol 241:H348–353PubMedGoogle Scholar
  31. 31.
    Rasmussen PR, Minobe W, Bristow MR (1990) Calcium antagonist binding sites in failing and nonfailing human ventricular myocardium. Biochemical Pharmacol 39:691–696CrossRefGoogle Scholar
  32. 32.
    Regitz V, Fleck E (1992) Adenine nucleotide metabolism and contractile dysfunction in heart failure — biochemical aspects, animal experiments, and human studies. In: Hasenfuss G, Holubarsch Ch, Just H, Alpert NR (eds) Cellular and molecular alterations in the failing human heart. Steinkopff Verlag, Darmstadt pp 321–329Google Scholar
  33. 33.
    Schultheiss H-P (1992) Dysfunction of the ADP/ATP carrier as a causative factor for the disturbance of the myocardial energy metabolism in dilated cardiomyopathy. In: Hasen-fuss G, Holubarsch Ch, Just H, Alpert NR (eds) Cellular and molecular alterations in the failing human heart. Steinkopff Verlag, Darmstadt pp 311–320Google Scholar
  34. 34.
    Tada M, Inui M (1983) Regulation of calcium transport by the ATPase-phospholamban system. J Mol Cell Cardiol 15:565–575PubMedCrossRefGoogle Scholar

Copyright information

© Dr. Dietrich Steinkopff Verlag GmbH & Co. KG, Darmstadt 1992

Authors and Affiliations

  • G. Hasenfuss
    • 1
    • 3
  • L. A. Mulieri
    • 2
  • C. Holubarsch
    • 1
  • B. Pieske
    • 1
  • H. Just
    • 1
  • N. R. Alpert
    • 2
  1. 1.Medizinische Klinik IIIUniversität FreiburgGermany
  2. 2.Department of Physiology & BiophysicsUniversity of VermontBurlingtonUSA
  3. 3.Abteilung IIIMed. Univ.-KlinikFreiburgGermany
