Mechanics of Composite and Multi-functional Materials, Volume 6 pp 101–110Cite as

Design of Low Composites from Recycled Copper + Aluminium Chips for Tribological Applications

Part of the Conference Proceedings of the Society for Experimental Mechanics Series book series (CPSEMS)

Abstract

In this work, a special copper aluminium matrix composite (ACMMCs) obtained from the fresh scrap – chips of AA7075 and- pure electrolytic copper were designed through combined method of powder metallurgy and sinter + Forging. First of all, Al-Cu matrix was doped with ZnO after the ball milling with two basic reinforcements (Nb2Al– SiC, etc.) was carried out during the 4 h. A basic composition was prepared depending on the doping percentage of ZnO as 30 wt%. Mechanical and physical properties of this composite designed here can be improved with the doping process followed by combined method of powder compacted specimens and doping volume fractions. The surface scratch tests and micro-hardness results were compared according to the optimization conditions of the doping and the reinforcement. Static compression and impact-drop weight tests were carried out. The microstructure and damage analyses have been carried out by Scanning Electron Microscope (SEM).

Keywords

  • ACMMCs
  • Sintered-forging
  • Wear
  • Impact
  • Compression
  • SEM analyze

This is a preview of subscription content, access via your institution.

Chapter
EUR   29.95
Price includes VAT (Finland)
  • Available as PDF
  • Read on any device
  • Instant download
  • Own it forever
eBook
EUR   117.69
Price includes VAT (Finland)
  • Available as EPUB and PDF
  • Read on any device
  • Instant download
  • Own it forever
Softcover Book
EUR   164.99
Price includes VAT (Finland)
  • Compact, lightweight edition
  • Dispatched in 3 to 5 business days
  • Free shipping worldwide - see info
Hardcover Book
EUR   164.99
Price includes VAT (Finland)
  • Durable hardcover edition
  • Dispatched in 3 to 5 business days
  • Free shipping worldwide - see info

Tax calculation will be finalised at checkout

Purchases are for personal use only

Learn about institutional subscriptions
Fig. 10.1
Fig. 10.2
Fig. 10.3
Fig. 10.4
Fig. 10.5
Fig. 10.6
Fig. 10.7
Fig. 10.8

References

  1. Chawla, N.: Industrial paper, “MMCs in automotive applications”. Adv. Mat. Process. 1, 29–31 (2006)

    Google Scholar

  2. Din, T., Campbell, J.: High strength aerospace aluminum casting alloys a comparative study. Mater. Sci. Technol. 12, 644–650 (1996)

    CrossRef  Google Scholar

  3. Lo, S.H.J., Dionne, S., Sahoo, M., Hawthorne, H.M.: Mechanical and tribological properties of zinc-aluminium metal-matrix composites. J. Mater. Sci. 27(21), 5681–5691 (1992)

    CrossRef  Google Scholar

  4. Choi, D.-H., et al.: Microstructure and mechanical property of AA7075 based composite by friction stir processing. Trans. Nonferrous Met. Soc. China. 23, 335–340 (2013)

    CrossRef  Google Scholar

  5. Kaczmar, J.W., Granat, K., Grodzka, E., Kurzawa, A.: Tribological properties of Cu based composite materials strengthened with Al2O3 particles. Archive of Foundry Engineering. 12(2), 33–36 (2012)

    Google Scholar

  6. Kumar, P., Srivastava, V.K.: Wear characterization of mica-loaded Al-Cu dual matrix particulate composites. Tribol. Trans. 59(6), 1134–1114 (2015)

    CrossRef  Google Scholar

  7. Selvakumar, N., Gangatharan, K.: Research article, electrical resistivity, tribological behaviour of multiwall carbon nanotubes and nano boron carbide particles reinforced copper hybrid composites for pantograph application. Adv. Mater. Sci. Eng. 2016, 1–18 (2016)

    CrossRef  Google Scholar

  8. Casstevens, J.M.: Friction and wear characteristics of power metallurgy copper–graphite brushes at high sliding speeds. Wear. 49, 169–178 (1978)

    CrossRef  Google Scholar

  9. Zhao, H., Barber, G.C., Liu, J.: Friction and wear in high speed sliding with and without electrical current. Wear. 249, 409–914 (2001)

    CrossRef  Google Scholar

  10. Lhmn, C.: Tribological properties of unidirectional poly – Phenylene sulfide-carbon fiber laminated composites. Wear. 107, 147–159 (1987)

    Google Scholar

  11. Groth, K., Heidenfelder, F., Holinski, R.: Advancements of tribological performance of carbon brushes in electrical motors. Industrial Lubrication Tribology. 53(1), 5–9 (2001)

    CrossRef  Google Scholar

  12. Esezobor, D., Oladoye, A.: Improvementon the tribological characteristics of particulate copper silicon carbide composites, TMS – EPD, Congress pp. 827–834, 2011

    Google Scholar

  13. Vettivel, S.C., Selvakumar, N., Leema, N., Lenin, A.H.: Electrical resistivity, wear map and modeling of extruded tungsten reinforced copper composite. Mater. Des. 56, 791–806 (2014)

    CrossRef  Google Scholar

  14. Kaya, H.: Dependence of electrical resistivity on temperature and composition of Al–Cu alloys. Mater. Res. Innov. 16(3), 224–229 (2012)

    CrossRef  Google Scholar

  15. Lim, S.C., Gupta, M., Ren, L., Kok, J.K.M.: Tribological properties of Al-Cu/SiCp metal matrix composites fabricated using the rheo-casting technique. J. Mater. Process. Technol. 89–90, 591–596 (1999)

    CrossRef  Google Scholar

Download references

Acknowledgments

This work has been carried out on the frame of collaboration between SUPMECA/PARIS, UNICAMP/SP/CAMPINAS and MICHIGAN TECHNICAL UNIVERSITY/ HOUGHTON-MI-USA. Authors acknowledge and appreciate so much for valuable technical helps and discussions.
