CAD Data Transfer for Solid Models pp 90-111 | Cite as
The CAD*I processors for Matra Datavision’s Euclid
Chapter
Abstract
Euclid is a solid modeller developed and sold by Matra Datavision, France. Its data structure captures both CSG and Polyhedron information. A number of application packages are based on the kernel modeller such as
All of these application modules are attached to the kernel system via the so-called language interface, a library of subroutine calls for creating, manipulating, deleting and evaluating objects in the Euclid data structure. Euclid version 4.2 has been made available during the project by Matra Datavision. It was running on a DEC MicroVAX II minicomputer under operating system VMS at KfK.
-
AEC
-
2D drafting
-
Schematics
-
Sculptured surfaces
-
Sheet metal bending
-
Finite element calculations
-
NC programme generation
Keywords
Entity Type Mapping Problem Geometric Entity Language Interface Subroutine Call
These keywords were added by machine and not by the authors. This process is experimental and the keywords may be updated as the learning algorithm improves.
