Abstract
Reinforcement corrosion is a main durability issue for reinforced concrete structures in the marine environment. Environmental actions on the corrosion rate have been documented by several researchers on actively corroding reinforced concrete structures. Therefore, considering the influences of ambient temperature and relative humidity is very important for prospective studies of corroding structures. In this paper, active corrosion of concrete members in the marine environment was observed for 4.8 years, and a relationship between the corrosion rate and ambient temperature and relative humidity is modeled. This very simple proposal is presented as a complementary tool to experimental measurements when assessing the deterioration rate of concrete structures in the marine environment.
Similar content being viewed by others
Abbreviations
- Δst :
-
Variation due to seasonal effects (mV)
- b :
-
Coefficient for sine function (mV)
- B :
-
The Tafel slope (mV)
- BPC:
-
Blended portland cement
- c :
-
Increasing coefficient for i corr [μA/(cm2·month)]
- CSE:
-
Cu/CuSO4 electrode
- E corr,est :
-
Estimated half-cell potential (mV)
- E corr,mean :
-
Average half-cell potential of the whole exposure period (mV)
- I corr :
-
Corrosion current (μA)
- i corr :
-
Corrosion rate (μA/cm2)
- i corr,0 :
-
Balanced initial corrosion rate (μA/cm2)
- r :
-
Scaling coefficient for b [μA/(cm2·mV)]
- RH:
-
Relative humidity
- R p :
-
Polarization resistance (kΩ)
- t :
-
Exposure time (months)
- t o :
-
Time displacement (months)
- TRH:
-
Temperature multiplied by RH [°C· %]
References
Frederiksen JM, Sørensen HE, Andersen A, Klinghoffer O (1997) HETEK, The effect of the w/c ratio on chloride transport into concrete—immersion, migration and resistivity tests. The Road Directorate, Copenaguen
ASTM C876 (2009) Standard test method for corrosion potentials of uncoated reinforcing steel in concrete. ASTM International, West Conshohocken, USA
Broomfield JP (1997) Corrosion of steel in concrete—understanding, investigation and repair. E & FN SPON, London
Stratfull RF (1973) Corrosion autopsy of a structurally unsound bridge deck. Highw Res Rec 433:1–11
Andrade C, González JA (1978) Quantitative measurements of corrosion rate of reinforcing steels embedded in concrete using polarization resistance measurements. Mater Corr 29:515–519. doi:10.1002/maco.19780290804
Bertolini L, Elsener B, Pedeferri P, Polder R (2003) Corrosion of steel in concrete. prevention, diagnosis, repair. Wiley-VCH, Weinheim
Alonso C, Castellote M, Andrade C (2002) Chloride threshold dependence of pitting potential of reinforcements. Electrochim Acta 47:3469–3481. doi:10.1016/s0013-4686(02)00283-9
Andrade C, Alonso C (1996) Corrosion rate monitoring in the laboratory and on-site. Constr Build Mater 10:315–328. doi:10.1016/0950-0618(95)00044-5
Clear KC (1989) Measuring rate of corrosion of steel in field concrete structures. Transport Res Rec 1211:28–37
López W, González JA (1993) Influence of the degree of pore saturation on the resistivity of concrete and the corrosion rate of steel reinforcement. Cem Concr Res 23:368–376. doi:10.1016/0008-8846(93)90102-F
Enevoldsen JN, Hansson CM, Hope BB (1994) The influence of internal relative humidity on the rate of corrosion of steel embedded in concrete and mortar. Cem Concr Res 24:1373–1382. doi:10.1016/0008-8846(94)90122-8
Andrade C, Alonso C, Sarría J (1998) Influencia de la humedad relativa y la temperatura en las velocidades de corrosión de estructuras de hormigón. Mater Constr 251:5–17. doi:10.3989/mc.1998.v48.i251.468
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Villagrán Zaccardi, Y.A., Bértora, A. & Di Maio, A.A. Temperature and humidity influences on the on-site active marine corrosion of reinforced concrete elements. Mater Struct 46, 1527–1535 (2013). https://doi.org/10.1617/s11527-012-9994-z
