Introduction

Intensive farming practices, that warrant high yield and quality, require extensive use of chemical fertilizers and pesticides, which are costly and create environmental problems. Hence, there has been a resurgence of interest in environmental friendly, sustainable and eco-friendly agricultural practices (Esitken et al. 2002). Application of plant growth-promoting (PGP) bacteria is gaining importance in sustainable agricultural systems because of their low production costs, consumption of less non-renewable resources and eco-friendliness in nature. The mechanisms involved in plant growth promotion by PGP bacteria include secretion of PGP hormones, chelation of iron, nitrogen fixation, solubilization of phosphorus and inhibition of plant pathogens (Tokala et al. 2002; Soares et al. 2006; Cheng et al. 2007; Hao et al. 2011; Panhwar et al. 2012). Application of PGP bacteria on the rhizosphere had been reported to enhance root and shoot growth, nitrogen fixation and solubilization of minerals (Shaukat et al. 2006; Richardson et al. 2009). PGP bacteria such as Rhizobium, Pseudomonas, Bacillus and Streptomyces were reported to help the plants not only by mobilizing the nutrients but also by controlling plant pathogens (Postma et al. 2003; Perner et al. 2006; Gopalakrishnan et al. 2011a, b).

Streptomyces, a Gram positive bacterium with high G + C content, is the largest genus of actinomycetes having more than 500 species found predominantly in soil and decaying vegetation. They are known for PGP, breakdown of carbohydrates such as chitin and cellulose and degradation of soils contaminated with pesticides and heavy metals thereby playing a greater role in the process of phytoremediation (Glick 2010). PGP potential of Streptomyces was reported on cereals such as wheat (Sadeghi et al. 2012) and rice (Gopalakrishnan et al. 2013, 2014), legumes such as beans (Nassar et al. 2003) and peas (Tokala et al. 2002) and vegetables such as tomato (El-Tarabily 2008). Streptomyces promote plant growth by producing indole-3-acetic acid (IAA) (Aldesuquy et al. 1998) or siderophores (Tokala et al. 2002). Besides, Streptomyces has been extensively used for biocontrol of soil-borne fungal pathogens (Mahadevan and Crawford 1997; Trejo-Estrada et al. 1998; Macagnan et al. 2008; Gopalakrishnan et al. 2011b).

Chickpea (Cicer arietinum L) is the third most important pulse crop after beans (Phaseolus vulgaris) and peas (Pisum sativum) on a world basis but of utmost importance in the Mediterranean basin and south Asia, with a total production of 11.6 million tons from an area of 13.2 million ha and a productivity of 880 kg ha−1 (FAOSTAT 2011). Global yields of chickpea have been relatively stagnant for the last two decades (Millan et al. 2006; Rao et al. 2010). Conventional and molecular breeding approaches have made success stories in creating cultivars with improved resistance to various biotic and abiotic stresses. However, adoption of such improved cultivars in developing countries is still limited because of the fluctuating environmental factors and their consequences in yield parameters in crops (Ribaut et al. 2010; Tester and Langridge 2010; Varshney et al. 2012). Hence, in the present study, it was proposed to use PGP Streptomyces as an eco-friendly and sustainable tool to enhance the plant growth and yield of chickpea. Previously, we demonstrated a set of six Streptomyces strains (CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180) isolated from herbal vermicompost, with a potential for PGP in rice (Gopalakrishnan et al. 2014). The objectives of this investigation were to further demonstrate the six Streptomyces strains for their PGP traits in chickpea under field conditions and to confirm the colonizing ability in chickpea by scanning electron microscopy (SEM) analysis.

Materials and methods

Six strains of Streptomyces, CAI-13 (Streptomyces caviscabies; NCBI accession: KF770891), CAI-85 (Streptomyces caviscabies; NCBI accession: KF770897), CAI-93 (Streptomyces globisporus; NCBI accession: KF742498), CAI-140 (Streptomyces griseorubens; NCBI accession: KF742497), CAI-155 (Streptomyces caviscabies; NCBI accession: KF770896) and KAI-180 (Streptomyces globisporus; NCBI accession: KF742499), reported earlier by us as having potential for PGP in rice (Gopalakrishnan et al. 2014), were used in this study to prove their efficiency on plant growth promotion in chickpea.

The field trials were conducted for two cropping seasons in 2012–13 and 2013–14 at ICRISAT, Patancheru (17°30N; 78°16E; altitude 549 m) in peninsular India. The soil depth of the experimental site used was ≥1.2 m and this soil retained 200 mm of plant-available water in the 120 cm (maximum rooting depth) soil profile. The experimental field was kept fallow except for post-rainy season crop. The soil at the experimental site was Vertisols (fine montmorillonitic isohyperthermic typic pallustert) with 53 % clay, 25 % sand and 21 % silt with an alkaline pH of 7.6–8.3 and an organic carbon content of 0.4–0.6 %. The mineral content of the top 0–15 cm soils include 24.7, 8.6 and 298 mg kg−1 soil of available N, P and K, respectively. The fields were prepared into broad beds and furrows with 1.2 m wide beds flanked by 0.3-m furrows in both seasons (2012–13 and 2013–14). Surface application and incorporation of 18 kg N ha−1 and 20 kg P ha−1 as di-ammonium phosphate (DAP), were carried out 3 days before sowing in both seasons. The experiment was laid out with three replicates and subplot sizes of 4.0 × 3 m rows in ridges in a randomized complete block design (RCBD) under irrigated condition.

The Streptomyces strains (CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180) were grown individually on a starch casein broth (starch—10 g; casein—0.3 g; sodium chloride—2 g; potassium nitrate—2 g; dipotassium hydrogen phosphate—2 g; magnesium sulfate—0.05 g; calcium carbonate—0.02 g; ferrous sulfate—0.01 g and; distilled water—1,000 ml) at 28 °C for 4–5 days. Seeds of chickpea variety ICCV 2 (duration 90 days) were treated individually with a Streptomyces strain (108 CFU ml−1) for 45 min and hand sown on Oct 2012 in the first year and Nov 2013 in the second year with a spacing of 30 cm apart, and a depth of 5 cm to have an estimated plant stand of at least 26 plants m−2. Streptomyces strain (1,000 ml/replicate; 108 CFU ml−1) was applied once in 15 days, from the sowing day, on the soil close to the plant until the flowering stage. Control plots contained no strains of Streptomyces. No serious plant pathogens or insect pest attacks were observed during the cropping period and the plots were kept weed-free by manual weeding. The plots were irrigated on 21 and 49 days after sowing (DAS). The chickpea crop was harvested manually on Jan 2013 in the first year and Feb 2014 in the second year. Samplings were done at 30 DAS, 60 DAS and at crop maturity. On the sampling day, plant underground and aerial parts were harvested separately with care to eliminate border effects in each plot. During both the seasons of 2012–13, 2013–14, chickpea growth performance was measured in terms of nodule number, nodule weight, root weight and shoot weight at 30 DAS; plant height, pod number, pod weight, leaf area, leaf weight and stem weight at 60 DAS; and stover yield, grain yield, total dry matter (TDM), 1000-seed weight, pod weight, seed number and seed weight at crop maturity. Also, at crop maturity, rhizosphere soil samples were collected from top 0 to 15 cm soil and analyzed for total nitrogen (Novozamsky et al. 1983), available phosphorous (Olsen and Sommers 1982), organic carbon (Nelson and Sommers 1982), microbial biomass carbon (fumigation method; Anderson and Domsch 1989) and dehydrogenase activity (triphenyl formazan production method; Casida 1977).

The colonizing capability of Streptomyces strains on the roots of chickpea was examined by scanning electron microscopy (SEM) analysis, as per the protocols of Bozzola and Russell (1998). In brief, the seeds of chickpea (variety ICCV 2) were surface-sterilized at first with 2.5 % sodium hypochlorite, followed by 70 % ethanol (for 5 min each) and rinsed thoroughly with sterilized water before being allowed to sprout in a Petri dish overnight. At the end of incubation, the sprouted seeds were soaked into test Streptomyces strains (CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180; grown in starch casein broth separately) for 45 min before being sown in pots containing sterilized coarse sand (six seeds/8 in plastic pot). Streptomyces strains (108 CFU ml−1; 5 ml per seedling), as booster doze, were applied upon germination of the seed by soil drench method. The pots were incubated at 24 ± 2 °C in a greenhouse for 2 weeks. After that, seedlings of chickpea were removed carefully from the pots and the roots were washed in 0.1 M phosphate buffer (pH 7.2). The tips of the roots were cut into 5 mm long pieces and fixed in glutaraldehyde (2.5 %) in phosphate buffer for 24 h at 4 °C. At the end of incubation, the root samples were again washed with phosphate buffer, postfixed in osmium tetroxide (2 %) for 4 h and dehydrated using a graded series of ethanol. The dehydrated samples were dried with critical-point liquid carbon dioxide as a transition fluid and adhered onto aluminum specimen mounted with double-stick adhesive tape. The mounted root samples were coated with gold–palladium in an automated sputter coater (JEOL JFC-1600) and examined under a scanning electron microscope (JOEL-JSM 5600) as per the standardized protocols at RUSKA lab, College of Veterinary Science, Rajendranagar, Hyderabad, India.

Data were analyzed by analysis of variance (ANOVA) and the GLM (General Linear Model) procedure in the software package SAS (SAS Inst. 2002–08, SAS V9.3) considering isolates and replication as fixed in RCBD. Isolate means were tested for significance and compared using Fisher’s protected least significant difference (LSD) test.

Results and discussion

The six Streptomyces strains (CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180) studied in this investigation were reported previously to have potential for PGP in rice (Gopalakrishnan et al. 2014). In the present investigation, these strains were evaluated for their PGP traits in chickpea under field conditions. The plots treated with Streptomyces strains showed significantly enhanced agronomic performance of all the traits measured at 30 and 60 DAS. As seen at 30 DAS in both 2012–13 and 2013–14 seasons, the Streptomyces treated plots showed significantly enhanced agronomic traits including the nodule numbers (35–83 %), nodule weight (27–64 %), root weight (9–14) and shoot weight (32–50 %) over the un-inoculated control (Table 1). Similarly at 60 DAS, the Streptomyces strains significantly enhanced the pod number (29–95 %), pod weight (30–135 %), leaf area (32–34 %), leaf weight (25–63 %) and stem weight (23–68 %) and at crop maturity, stover yield (25–75 %), grain yield (11–26 %), total dry matter (19–32), pod weight (6–51 %), seed number (20–52) and seed weight (3–47 %) in both 2012–13 and 2013–14 seasons over the un-inoculated control plots (Tables 1, 2). In the top 15 cm rhizosphere soils, at crop maturity, the Streptomyces strains treated plots significantly enhanced the microbial biomass carbon (35–55), dehydrogenase activity (27–56 %), total N (4–11), available P (51–106 %) and organic carbon (9–16 %) in both 2012–13 and 2013–14 seasons over the un-inoculated control plots (Table 3).

Table 1 Effect of the six Streptomyces sp. on agronomic performance of chickpea under field conditions––at 30 and 60 days after sowing
Full size table
Table 2 Effect of the six Streptomyces sp. on agronomic performance and yield potential of chickpea under field conditions—at harvest
Full size table
Table 3 Effect of the six Streptomyces sp. on rhizosphere soil microbial biomass carbon, dehydrogenase, total N, available P and organic carbon activities of chickpea under field conditions—at harvest
Full size table

Of the six Streptomyces strains studied in the present investigation, CAI-85, CAI-93 and KAI-180 (in descending order) were found superior to CAI-155, CAI-140 and CAI-13 in terms of their effects on root and shoot development, nodule formation and crop productivity. Further, the six Streptomyces did not inhibit the growth of Mesorhizobium ciceri on yeast extract mannitol agar (YEMA; data not shown). Thus, it is concluded that the six Streptomyces strains are capable of enhancing agronomic and yield traits in chickpea and compatible with Rhizobium, so that co-inoculation of these two genera is possible. The effect of Streptomyces for PGP in crops including vegetables such as tomato, cereals such as wheat and rice and legumes such as beans and peas was reported widely (Tokala et al. 2002; Nassar et al. 2003; El-Tarabily 2008; Sadeghi et al. 2012; Gopalakrishnan et al. 2014). PGP bacteria with broad spectrum properties offer effective novel strategies not only for crop growth and yield but also for controlling insect pests and pathogens that attack crops. PGP bio-agents also bring forth induced systemic resistance against a broad range of pathogens and insect pests (Jetiyanon and Kloepper 2002; Ryu et al. 2007).

SEM analysis of chickpea roots showed a remarkable degree of colonization by all the six strains of Streptomyces. Roots from Streptomyces inoculated plants exhibited significant surface colonization while those from un-inoculated plants did not. Further, the sporulation of Streptomyces strains on the surface cell layer of chickpea roots was clearly evident for all six strains. The hyphae of Streptomyces strains were also found to penetrate the surface cell layer of chickpea roots (Fig. 1). Colonization by PGP bacteria at the right time and place is a pre-requisite for enhanced PGP activity. Host–bacteria interaction is important for colonization which involves sufficient population of bacteria, rhizosphere competence of the bacteria and root colonizing and PGP ability of the bacteria (Lugtenberg and Dekkers 1999). In the present investigation, SEM analysis demonstrated colonization of Streptomyces strains on the roots of chickpea. Therefore, the SEM analysis, in addition to the data for grain and stover yield, root and other agronomical traits, and the mineral nutrients and biological activities of the rhizosphere soil strongly suggest that the six Streptomyces strains had multiplied and colonized on the chickpea roots.

Fig. 1
figure 1

Scanning electron microscopy photographs of the six Streptomyces sp. showing colonization on the roots of chickpea. Representative SEM images of control and treated chickpea roots. a Normal surface of chickpea roots without any microbial treatment, b–g chickpea roots colonized by PGP Streptomyces strains CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180 respectively

Full size image

The mechanism by which the six Streptomyces strains consistently enhanced yield and agronomical traits on rice (from our previous study) and chickpea (from this study) could be attributed to their ability to produce siderophores, indole acetic acid (IAA) and β-1,3-glucanase activities (Gopalakrishnan et al. 2014). Bacteria are reported to have the ability to produce low-molecular weight siderophores that are capable of sequestering Fe3+ and to help plants to have their iron requirement. Siderophores act as solubilizing agents of iron from minerals under conditions of iron limitation (Indiragandhi et al. 2008). Siderophores are reported to form stable complexes with heavy metals such as Al, Cd, Cu, Ga, In, Np, Pb, U and Zn and increase the soluble metal concentration (Rajkumar et al. 2010). Therefore, siderophores help to alleviate the stresses imposed on plants by heavy metals in soils. IAA is the plant hormone that accelerates plant growth by enhancing shoot/root growth and seedling vigour. IAA synthesizing bacteria are known to stimulate seed germination, initiate root formation and increase root length and surface area thereby providing the host plant greater access to water and soil nutrients (Ahemad and Kibret 2014).The cell wall of plant pathogens, such as Fusarium oxysporum (causes wilt in many crops), contain layers of β-1,3-glucan and lysis of β-1,3-glucan layers by β-1,3-glucanase-producing bacteria leads to the leakage of cell contents and the collapse of the pathogenic fungi (Singh et al. 1999). Furthermore, qRT-PCR validation of IAA genes revealed that gene IAA showed higher up regulation in the CAI-85 followed by CAI-93 while gene siderophore was highly up-regulated in CAI-155 followed by CAI-85 and CAI-93 and this results confirmed the results of in vitro PGP attributes of the six Streptomyces strains (from our previous study; Gopalakrishnan et al. 2014).Hence, it is concluded that the Streptomyces strains used in this investigation apparently contained a broad range of PGP traits which can be exploited for PGP in cereal–legum cropping system.

It is concluded that the six Streptomyces strains (CAI-13, CAI-85, CAI-93, CAI-140, CAI-155 and KAI-180) studied in this investigation were apparently well adapted not only in rice rhizosphere, as reported earlier, but also in the chickpea rhizosphere. Among the six Streptomyces strains studied, CAI-85, CAI-93 and KAI-180 were found to be the best performers than other isolates in terms of agronomic performance and crop productivity. Therefore, these three strains are potential candidates for the discovery of novel secondary metabolites and their usefulness in integrated nutrient management programs that can help in furthering the use of eco-friendly bio-fertilizers. Further studies are needed to understand the importance of these six PGP Streptomyces in the rhizosphere and their potential use in the environment. Also, there is a need to do additional comprehensive research to exploit the potential of these PGP Streptomyces under different field conditions (multi-location trials), commercialization and improve sustainability in agricultural production.
