Differential Findings of Tc-99m Sestamibi Dual-Phase Parathyroid Scintigraphy Between Benign and Malignant Parathyroid Lesions in Patients with Primary Hyperparathyroidism

Nuclear Medicine and Molecular Imaging volume 45, pages 276–284 (2011)Cite this article

Abstract

Purpose

This study aimed to investigate the differential findings in clinical and biochemical features, and Tc-99m sestamibi (MIBI) dual-phase parathyroid scintigraphy for malignant and benign parathyroid lesions in patients with primary hyperparathyroidism.

Methods

Subjects were 102 parathyroid lesions from 91 patients with primary hyperparathyroidism. Scintigraphic findings included radioactivity grade, uptake pattern, uptake contour, lesion size on early and delayed images, and degree of washout. Clinical and biochemical features were also evaluated. Histopathology confirmed the final diagnosis for all the patients.

Results

Final diagnoses were 94 benign parathyroid lesions and 8 parathyroid carcinomas. The patients with parathyroid carcinoma were significantly older (p = 0.002) and had significantly higher serum parathyroid hormone concentrations than those with benign parathyroid lesions (p < 0.001). All malignant parathyroid lesions showed intense radioactivity similar to or greater than the submandibular gland activity on delayed images (p = 0.007), and little radioactivity difference between early and delayed images (p = 0.012). The cancer incidence for parathyroid lesions with both intense radioactivity and no washout was 17.0% (8/47). When parathyroid lesions with all of the above-mentioned findings were regarded as malignant, the cancer incidence significantly increased from 17.0% to 33.3% (8/24, p < 0.001).

Conclusion

For Tc-99m MIBI dual-phase parathyroid scintigraphy, uptake grade on delayed images and washout were significantly useful diagnostic criteria for differentiating benign from malignant parathyroid lesions, along with age and parathyroid hormone serum concentration.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6

References

  1. Cohn K, Silverman M, Corrado J, Sedgewick C. Parathyroid carcinoma: the Lahey Clinic experience. Surg. 1985;98:1095–100.

    CAS  Google Scholar

  2. Hakaim AG, Esselstyn Jr CB. Parathyroid carcinoma: 50-year experience at The Cleveland Clinic Foundation. Cleve Clin J Med. 1993;60:331–5.

    PubMed  CAS  Google Scholar

  3. Wang CA, Gaz RD. Natural history of parathyroid carcinoma. Diagnosis, treatment, and results. Am J Surg. 1985;149:522–7.

    PubMed  Article  CAS  Google Scholar

  4. Holmes EC, Morton DL, Ketcham AS. Parathyroid carcinoma: a collective review. Ann Surg. 1969;169:631–40.

    PubMed  Article  CAS  Google Scholar

  5. Koea JB, Shaw JH. Parathyroid cancer: biology and management. Surg Oncol. 1999;8:155–65.

    PubMed  Article  CAS  Google Scholar

  6. Agarwal G, Dhingra S, Mishra SK, Krishnani N. Implantation of parathyroid carcinoma along fine needle aspiration track. Langenbecks Arch Surg. 2006;391:623–6.

    PubMed  Article  Google Scholar

  7. Spinelli C, Bonadio AG, Berti P, Materazzi G, Miccoli P. Cutaneous spreading of parathyroid carcinoma after fine needle aspiration cytology. J Endocrinol Invest. 2000;23:255–7.

    PubMed  CAS  Google Scholar

  8. Shin JW, Ryu JS, Kim JS, Moon DH, Hong SM, Gong G, et al. Lesion localization in patients with hyperparathyroidism using double-phase Tc-99m MIBI parathyroid scintigraphy. Korean J Nucl Med. 1999;33:120–30.

    Google Scholar

  9. Jeon TJ, Lee JD, Rhyu YH, Park JS, Jang HS. Comparison study of lesion localization in patients with primary and secondary hyperparathyroidism using double-phase Tc-99m sestamibi scintigraphy. Korean J Nucl Med. 1999;33:368–80.

    Google Scholar

  10. Ruda JM, Hollenbeak CS, Stack Jr BC. A systematic review of the diagnosis and treatment of primary hyperparathyroidism from 1995 to 2003. Otolaryngol Head Neck Surg. 2005;132:359–72.

    PubMed  Article  Google Scholar

  11. Lu G, Shih WJ, Xiu JY. Technetium-99 m MIBI uptake in recurrent parathyroid carcinoma and brown tumors. J Nucl Med. 1995;36:811–3.

    PubMed  CAS  Google Scholar

  12. Singhal T, Jacobs M, Mantil JC. Tc-99 m pertechnetate/sestamibi subtraction scan in a case of parathyroid carcinoma. Clin Nucl Med. 2008;33:196–7.

    PubMed  Article  Google Scholar

  13. Clark P, Wooldridge T, Kleinpeter K, Perrier N, Lovato J, Morton K. Providing optimal preoperative localization for recurrent parathyroid carcinoma: a combined parathyroid scintigraphy and computed tomography approach. Clin Nucl Med. 2004;29:681–4.

    PubMed  Article  Google Scholar

  14. Favia G, Lumachi F, Polistina F, D'Amico DF. Parathyroid carcinoma: sixteen new cases and suggestions for correct management. World J Surg. 1998;22:1225–30.

    PubMed  Article  CAS  Google Scholar

  15. Kebebew E, Arici C, Duh QY, Clark OH. Localization and reoperation results for persistent and recurrent parathyroid carcinoma. Arch Surg. 2001;136:878–85.

    PubMed  Article  CAS  Google Scholar

  16. Nakamura Y, Kataoka H, Sakoda T, Horie Y, Kitano H. Nonfunctional parathyroid carcinoma. Int J Clin Oncol. 2010;15:500–3.

    PubMed  Article  Google Scholar

  17. Hundahl SA, Fleming ID, Fremgen AM, Menck HR. Two hundred eighty-six cases of parathyroid carcinoma treated in the US between 1985–1995: a National Cancer Data Base Report. The American College of Surgeons Commission on Cancer and the American Cancer Society. Cancer. 1999;86:538–44.

    PubMed  Article  CAS  Google Scholar

  18. Cordeiro AC, Montenegro FL, Kulcsar MA, Dellanegra LA, Tavares MR, Michaluart Jr P, et al. Parathyroid carcinoma. Am J Surg. 1998;175:52–5.

    PubMed  Article  CAS  Google Scholar

  19. Wynne AG, van Heerden J, Carney JA, Fitzpatrick LA. Parathyroid carcinoma: clinical and pathologic features in 43 patients. Med (Baltim). 1992;71:197–205.

    CAS  Google Scholar

  20. Chen Q, Kaji H, Nomura R, Sowa H, Yamauchi M, Tsukamoto T, et al. Trial to predict malignancy of affected parathyroid glands in primary hyperparathyroidism. Endocr J. 2003;50:527–34.

    PubMed  Article  Google Scholar

  21. Carpentier A, Jeannotte S, Verreault J, Lefebvre B, Bisson G, Mongeau CJ, et al. Preoperative localization of parathyroid lesions in hyperparathyroidism: relationship between technetium-99m-MIBI uptake and oxyphil cell content. J Nucl Med. 1998;39:1441–4.

    PubMed  CAS  Google Scholar

  22. Sun SS, Shiau YC, Lin CC, Kao A, Lee CC. Correlation between P-glycoprotein (P-gp) expression in parathyroid and Tc-99m MIBI parathyroid image findings. Nucl Med Biol. 2001;28:929–33.

    PubMed  Article  CAS  Google Scholar

  23. Pons F, Torregrosa JV, Fuster D. Biological factors influencing parathyroid localization. Nucl Med Commun. 2003;24:121–4.

    PubMed  Article  CAS  Google Scholar

  24. Arbab AS, Koizumi K, Toyama K, Araki T. Uptake of technetium-99m-tetrofosmin, technetium-99m-MIBI and thallium-201 in tumor cell lines. J Nucl Med. 1996;37:1551–6.

    PubMed  CAS  Google Scholar

  25. Hassan IM, Sahweil A, Constantinides C, Mahmoud A, Nair M, Oamr YT, et al. Uptake and kinetics of Tc-99m hexakis 2-methoxy isobutyl isonitrile in benign and malignant lesions in the lungs. Clin Nucl Med. 1989;14:333–40.

    PubMed  Article  CAS  Google Scholar

  26. Petrovic NS, Grujicic D, Artiko VM, Sobic-Saranovic DP, Gajic MM, Jaksic E, et al. Investigation of blood perfusion and metabolic activity of brain tumours in adults by using 99m Tc-methoxyisobutylionitile. Nucl Med Commun. 2010;31:962–73.

    PubMed  Article  Google Scholar

  27. Ak I, Gulbas Z, Altinel F, Vardareli E. Tc-99m MIBI uptake and its relation to the proliferative potential of brain tumors. Clin Nucl Med. 2003;28:29–33.

    PubMed  Article  Google Scholar

Download references

Conflict of interest statement

All authors declare that they have no conflict of interest.

Author information

Affiliations

  1. Department of Nuclear Medicine, Samsung Medical Center, Sungkyunkwan, University School of Medicine, 50 Irwon-dong, Gangnam-gu, Seoul, 135-710, Korea

    Miju Cheon, Joon Young Choi, Ji Young Lee, Sook Kyung Cho, Jang Yoo, Soo Bin Park, Kyung-Han Lee & Byung-Tae Kim

  2. Department of Medicine, Samsung Medical Center, Sungkyunkwan University School of Medicine, Seoul, 135-710, Korea

    Jae-Hoon Chung

Authors
  1. Miju Cheon
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Joon Young Choi
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Jae-Hoon Chung
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Ji Young Lee
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Sook Kyung Cho
    View author publications

    You can also search for this author in PubMed Google Scholar

  6. Jang Yoo
    View author publications

    You can also search for this author in PubMed Google Scholar

  7. Soo Bin Park
    View author publications

    You can also search for this author in PubMed Google Scholar

  8. Kyung-Han Lee
    View author publications

    You can also search for this author in PubMed Google Scholar

  9. Byung-Tae Kim
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to Joon Young Choi.

Additional information

*All contributors declare they have no conflicts of interest, real or perceived, financial or nonfinancial support or other relationships.

Rights and permissions

Reprints and Permissions

About this article

Cite this article

Cheon, M., Choi, J.Y., Chung, JH. et al. Differential Findings of Tc-99m Sestamibi Dual-Phase Parathyroid Scintigraphy Between Benign and Malignant Parathyroid Lesions in Patients with Primary Hyperparathyroidism. Nucl Med Mol Imaging 45, 276–284 (2011). https://doi.org/10.1007/s13139-011-0103-y

Download citation

  • Received:

  • Revised:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s13139-011-0103-y

Keywords

  • Primary hyperparathyroidism
  • Parathyroid carcinoma
  • Parathyroid adenoma
  • Parathyroid hyperplasia
  • Tc-99m Sestamibi
  • Parathyroid scintigraphy
