Abstract
To reconstruct deep fluid chemical composition and increase the confidence in estimated reservoir temperatures, a more integral geothermometry method was compared to other classical geothermometers. Here, we apply the integrated multicomponent geothermometry (IMG) method using the GeoT code to estimate reservoir temperatures at the Tengchong geothermal field in Southwestern China. Results show reservoir temperatures calculated using the quartz geothermometer are closest to those estimated with the IMG method. The concentrations of Al and Mg, as well as selected minerals for geothermometry computations, are key factors for successfully using the IMG. Using the IMG method together with classical geothermometers can significantly increase confidence in reservoir temperature estimations. The methods presented and simulation program used here may be useful for analysis of other geothermal fields under similar conditions.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
Explore related subjects
Discover the latest articles and news from researchers in related subjects, suggested using machine learning.References
Ding ZL (2013) Solid earth science research methods. Science Press, Beijing, pp 219–242
Doherty J (2008) PEST—model-independent parameter estimation. Watermark Numerical Computing, Corinda 4075, Brisbane, Australia. http://www.sspa.com/pest/
Fournier RO (1979) A revised equation for the Na/K geothermometer. Geotherm Resour Council Trans 3:221–224
Fournier RO, Potter RW (1982) Revised and expanded silica (quartz) geothermometer. Bull Geotherm Resour Counc 11(10):3–12
Fournier RO, Truesdell AH (1973) An empirical Na–K–Ca geothermometer for natural waters. Geochim Cosmochim Acta 37(5):1255–1275
Giggenbach WF (1988) Geothermal solute equilibria: derivation of Na–K–Mg–Ca geoindicators. Geochim Cosmochim Acta 52(12):2749–2765
Guo TT (2013) Characteristics and genesis of geothermal field in Rehai Tengchong. Kunming University of Science and Technology, Kunming, pp 25–79
Lin MS, Peng SB, Qiao WT, Li H (2014) Petro-geochemistry and geochronology of late Cretaceous-Eocene granites in high geothermal anomaly areas in the Tengchong block, Yunnan Province, China and their tectonic implications. Acta Petrol Sin 30(2):527–546
Liu ML, Cao YW, Wang MD, Li JX, Guo QH (2014) Source of hydrochemical composition and formation mechanism of Rehai geothermal water in Tengchong. Saf Environ Eng 6:1–7
Pang ZH, Reed MH (1998) Theoretical chemical thermometry on geothermal waters: problems and methods. Geochim Cosmochim Acta 62:1083–1091
Pang ZH, Reed M (2010) Geothermometer theory and its application in geothermal research. China Geothermal energy: Achievements and Prospects-Siguang promote geothermal energy development and utilization of China 40th Anniversary Conference and China Geothermal Development Symposium
Peiffer L, Wanner C, Spycher N, Sonnenthal E, Kennedy BM, Iovenitti J (2014) Optimized multicomponent vs. classical geothermometry: insights from modeling studies at the Dixie Valley geothermal area. Geothermics 51:154–169
Reed MH (1982) Calculation of multicomponent chemical equilibria and reaction processes in systems involving minerals, gases and an aqueous phase. Geochim Cosmochim Acta 46:513–528
Reed M, Spycher N (1984) Calculation of pH and mineral equilibria in hydrothermal waters with application to geothermometry and studies of boiling and dilution. Geochim Cosmochim Acta 4(7):1479–1492
Reed MH (1998) Calculation of simultaneous chemical equilibria in aqueous mineral-gas systems and its application to modeling hydrothermal processes. In: Richards J, Larson P (eds) Techniques in hydrothermal ore deposits geology, reviews in economic geology 10:109–124
Reed M, Palandri J (2006) SOLTHERM. H06, A database of equilibrium constants for minerals and aqueous species. Available from the authors, University of Oregon, Eugene, Oregon
Shangguan ZG (2000) Structure of geothermal reservoirs and the temperature of mantle-derived magma hot source in the Rehai area,Tengchong. Acta Petrol Sin 16(1):83–90
Shangguan ZG, Bai CH, Sun ML (2000) Modern mantle magma gas release characteristics of Rehai geothermal in Tengchong. Sci China 30(4):407–414
Spycher N, Peiffer L, Sonnenthal E (2013) GeoT user’s guide a computer program for multicomponent geothermometry and geochemical speciation version 1.4. Ernest Orlando Lawrence Berkeley National Laboratory, Report No. LBNL–6172E
Spycher N, Peiffer L, Sonnenthal EL, Saldi G, Reed MH, Kennedy BM (2014) Integrated multicomponent solute geothermometry. Geothermics 51(7):113–123
Tong W, Zhang MT (1989) Tengchong geothermal. Science Press, Beijing, pp 81–99
Xu T, Spycher N, Sonnenthal E, Zhang G, Zheng L, Pruess K (2011) TOUGHREACT Version 2.0: a simulator for subsurface reactive transport under non-isothermal multiphase flow conditions. Comput Geosci 37:763–774
Zhang ZX, Duan YD (2005) Tengchong of Yunnan is the best geothermal field of geothermal power development. National Symposium on Sustainable Development of geothermal industry, China
Zhang ZS, Sun ZX, Wang SJ (2004) Successful reconstruction the equilibrium status of Tanghu hot spring by using Fixed-Al methods and its meaning. J East China Geol Inst 26(4):306–310
Acknowledgements
This work was supported by the National Natural Science Foundation of China (Grant Nos. 41572215 and 41402205) and the China Geological Survey, Geothermal Resources Investigation in Xining-Guinan of Qinghai Province (Grant Nos. 12120115046201 and 121201012000150011).
Author information
Authors and Affiliations
Corresponding author
Additional information
This article is part of a Topical Collection in Environmental Earth Sciences on ‘Subsurface Energy storage II’, guest edited by Zhonghe Pang, Yanlong Kong, Haibing Shao, and Olaf Kolditz.
Rights and permissions
About this article
Cite this article
Xu, T., Hou, Z., Jia, X. et al. Classical and integrated multicomponent geothermometry at the Tengchong geothermal field, Southwestern China. Environ Earth Sci 75, 1502 (2016). https://doi.org/10.1007/s12665-016-6298-6
Received:
Accepted:
Published:
DOI: https://doi.org/10.1007/s12665-016-6298-6
