Environmental Earth Sciences

, Volume 73, Issue 12, pp 7723–7731 | Cite as

Enhancement of wadi recharge using dams coupled with aquifer storage and recovery wells

  • Thomas M. MissimerEmail author
  • Weixing Guo
  • Robert G. Maliva
  • Jorge Rosas
  • Khan Z. Jadoon
Thematic Issue

Abstract

Wadi channel recharge to the underlying alluvial aquifer is naturally limited by the flashy nature of flood events, evapotranspiration losses of water from the vadose zone, and aquifer heterogeneity, particularly low vertical hydraulic conductivity. Anthropogenic lowering of the water table in many wadi aquifers has also reduced the potential recharge by increasing the thickness of the vadose zone, causing interflow water loss from surface emergence and evaporation. A method to enhance recharge is to slow the flow within wadi channels by placement of dam structures, thereby ponding water and increasing the vertical head gradient to create a more rapid rate of infiltration and percolation. Effectiveness of wadi dams to enhance aquifer recharge reduces over time due to mud deposition within the reservoir caused by storm events. Up to 80 % of the water in old wadi reservoirs is lost to free-surface evaporation before infiltration and recharge can occur. One method to maintain or increase the rate of recharge is to convey clean water by gravity flow from the reservoir down-gradient to artificially recharge the aquifer using existing wells. This type of system is a low-cost and low-energy recharge method which could greatly enhance groundwater storage in wadi aquifers. Modeling results show that existing wells could store up to 1,000 m3/day under gravity-feed conditions and up to 3,900 m3/day with the shut-in of the well to produce a pressurized system.

Keywords

Aquifer storage and recovery Wadi aquifers Dams Recharge Groundwater modeling

References

  1. Abdulrazzak MJ, Morel-Seytoux HJ (1983) Recharge from an ephemeral stream following wetting front arrival to water table. Water Resour Res 19(1):194–200CrossRefGoogle Scholar
  2. Abdulrazzak MJ, Sorman AU (1994) Transmission losses from ephemeral stream in arid regions. J Irrig Drain Eng 120(3):669–675CrossRefGoogle Scholar
  3. Abdulrazzak MJ, Sorman AU, Abu Rizziza OS (1986–1988) Estimation of natural groundwater recharge in alluvial systems: Progress reports nos. 2, 3, 4, 5, and 6. King Abdulaziz City for Science and Technology, Riyadh, Saudi ArabiaGoogle Scholar
  4. Al Maktoumi A (2013) The effect of the Al-Khod Dam on the subsurface soil properties. Infiltration and recharge efficiency. Water Res Centre Bull OmanGoogle Scholar
  5. Alderwish AM (2010) Induced recharge at new dam sits––Sana’s Basin, Yemen. Arab J Geosci 3:283–293CrossRefGoogle Scholar
  6. Al-Muttair FF, Sendil U, Al-Turbak AS (1994) Management of recharge dams in Saudi Arabia. J Water Res Plann Manag 120:749–763CrossRefGoogle Scholar
  7. Al-Nujaidi HA (1978) Hydrogeology of wadi Murwani, Khulais. M.Sc. Thesis, IAG Research Series, King Abdulaziz University, Jeddah, Saudi ArabiaGoogle Scholar
  8. Al-Shaibani AM (2008) Hydrogeology and hydrochemistry of a shallow alluvial aquifer, western Saudi Arabia. Hydrogeol J 16:155–165CrossRefGoogle Scholar
  9. Al-Turbak AS (1991) Effectiveness of recharge from surface reservoir to an underlying unconfined aquifer. In: Shiller G, Lemmela R, Speafico M (eds) Hydrology of natural and man-made lakes, Proceedings of the Vienna symposium. International Association of Hydrological Sciences (IAHS) Publication No. 206, pp 191–196Google Scholar
  10. Al-Turbak AS, Al-Muttair FF (1989) Evaluation of dams as recharge method. Water Res Dev 5(2):119–124CrossRefGoogle Scholar
  11. Bajjali W (2005) Modeling the effects of four recharge dams on the quality of groundwater using geostatistical methods in GIS environment Oman. J Spatial Hydrol 5(2):1–15Google Scholar
  12. Bazuhair AS, Wood WW (1996) Chloride mass-balance for estimating ground water recharge in arid areas: example from western Saudi Arabia. J Hydrol 186:153–159CrossRefGoogle Scholar
  13. Bazuhair AS, Ibrahim MT, Thabet MS (1992) Hydrogeophysical studies of Khulais basin, western region Saudi Arabia. Unpublished report, King Abdulaziz UniversityGoogle Scholar
  14. Besbes M, Delhomme JP, deMarsily G (1978) Estimating recharge from ephemeral streams in arid regions: a case study at Kairouan, Tunisia. Water Resour Res 14:281–290CrossRefGoogle Scholar
  15. Hussein MT, Bazuhair A, Thabet Al-Yamani MS (1993) Groundwater availability in the Khulais Plain, western Saudi Arabia. Hydrol Sci-J-des Sci Hydrol 38(3):203–213CrossRefGoogle Scholar
  16. Italo-Consult (1976) Detailed investigations of Wadi Khulais basin. Unpublished report to the Ministry of Agriculture and Water, Riyadh, Saudi ArabiaGoogle Scholar
  17. Lane LJ, Diskin MH, Renard KG (1971) Input–output relationship for an ephemeral stream channel system. J Hydrol 13:22–40CrossRefGoogle Scholar
  18. Lawrence TE (1922) Seven pillars of wisdom. Oxford Press, OxfordGoogle Scholar
  19. Lemaire B (2009) Jeddah City water and wastewater management contract-Hydrogeological survey, Consultants report to the National Water Company, Jeddah, Saudi ArabiaGoogle Scholar
  20. Maliva RG, Missimer TM (2012) Arid lands water evaluation and management. Springer, HeidelbergCrossRefGoogle Scholar
  21. McDonald MG, Harbaugh AW (1988) A modular three-dimensional finite-difference groundwater flow model. U. S. Geological Survey Techniques of Water Resources Investigations, Book 6, chap A1Google Scholar
  22. Ministry of Regional Municipalities, Environment and Water Resources (2005) Water resources of Oman: Ministry of Regional Municipalities, Sultanate of Oman. Environment and Water ResourcesGoogle Scholar
  23. Missimer TM, Drewes J, Amy G, Maliva RG, Keller S (2012) Restoration of wadi aquifers by artificial recharge with treated wastewater. Ground Water 50(4):514–527. doi: 10.1111/j.1745-6584.2012.00941.x CrossRefGoogle Scholar
  24. Rosas J (2013) Analysis of grain size distribution and hydraulic conductivity for a variety of sediment types with application to wadi sediments. Unpublished M.Sc. Thesis, King Abdullah University of Science and Technology, Thuwal, Saudi ArabiaGoogle Scholar
  25. Sharda VN, Kurothe RS, Sena DR, Pande VC, Tiwari SP (2006) Estimation of groundwater recharge from water storage structures in a semi-arid climate of India. J Hydrol 329(1–2):224–243CrossRefGoogle Scholar
  26. Sorman AU, Abdulrazzak MJ (1993) Infiltration-recharge through wadi beds in arid regions. Hydrol Sci J 38(3):173–186CrossRefGoogle Scholar
  27. Subyani AM (2004) Use of chloride-mass balance and environmental isotopes for evaluation of groundwater recharge in the alluvial aquifer, Wadi Tharad, western Saudi Arabia. Environ Geol 46:741–749CrossRefGoogle Scholar
  28. Subyani AM, Sen Z (2006) Refined chloride mass-balance method and its application in Saudi Arabia. Hydrol Process 20:4373–4380CrossRefGoogle Scholar
  29. Walters MO (1990) Transmission losses in arid regions. J Hydraulic Eng 116:129–138CrossRefGoogle Scholar
  30. Zeelie S (2002) OMDEL dam and recharge ponds to enhance recharge in the Namib Desert. In: Dillon P (ed) Management of aquifer recharge for sustainability. Swets & Zeitlinger, Lisse, pp 387–392Google Scholar

Copyright information

© Springer-Verlag Berlin Heidelberg 2014

Authors and Affiliations

  • Thomas M. Missimer
    • 1
    • 3
    Email author
  • Weixing Guo
    • 2
  • Robert G. Maliva
    • 2
  • Jorge Rosas
    • 1
  • Khan Z. Jadoon
    • 1
  1. 1.Desalination and Water Reuse CenterKing Abdullah University of Science and TechnologyThuwalSaudi Arabia
  2. 2.Schlumberger Water ServicesFort MyersUSA
  3. 3.Florida Gulf Coast University, U. A. Whitaker College of EngineeringFort MyersUSA
