Abstract
This work presents the development of a strategy that integrates multivariate statistical analysis and concepts of green chemistry to obtain the chromatographic profile of Brazilian red wines by HPLC-PAD. An initial screening of variables was performed using fractional factorial design (2IV7–2) to investigate the main parameters responsible for separating phenolic compounds. It was considered the initial and final % of bioethanol in the organic mobile phase, % acetic acid in aqueous mobile phase, flow rate, running time, type of column chemistry, and column temperature. The number of chromatographic bands was used as empiric response. The most important variables were selected to further optimization by Doehlert factorial design. The optimal condition was as follows: initial % of bioethanol=5%, final % of bioethanol=55%, column temperature= 51.8 °C, % acetic acid in H2O =0.1%, flow rate = 0.75 mL·min−1, time=30 min, and column chemical composition=Phenyl-Hexyl (X-Select). The optimized method allowed the separation of 24 chromatographic bands with signal/noise (S/N) higher than 100, a response at least 17% higher than observed in the screening step. The method allowed the separation and identification of the main compounds presented in red wines: gallic acid, caffeic acid, syringic acid, p-coumaric acid, resveratrol, kaempferol, catechin, and epicatechin.





Similar content being viewed by others
References
Alaerts G, Matthijs N, Smeyers-Verbeke J, Vander Heyden Y (2007) Chromatographic fingerprint development for herbal extracts: a screening and optimization methodology on monolithic columns. J Chromatogr A 1172:1–8. https://doi.org/10.1016/j.chroma.2007.07.080
Alfonsi K, Colberg J, Dunn PJ, Fevig T, Jennings S, Johnson TA, Kleine HP, Knight C, Nagy MA, Perry DA, Stefaniak M (2008) Green chemistry tools to influence a medicinal chemistry and research chemistry based organisation. Green Chem 10:31–36. https://doi.org/10.1039/b711717e
Borges MS, Zanatta AC, Souza AO, Pelissari JH et al (2020) A green and sustainable method for monitoring the chemical composition of soybean: an alternative for quality control. Phytochem Anal:1–13. https://doi.org/10.1002/pca.3006
Bueno PCP, Pereira FMV, Torres RB, Cavalheiro AJ (2015) Development of a comprehensive method for analyzing clerodane-type diterpenes and phenolic compounds from Casearia sylvestris Swartz (Salicaceae) based on ultra high performance liquid chromatography combined with chemometric tools. J Sep Sci 38:1649–1656. https://doi.org/10.1002/jssc.201401421
Canizo BV, Escudero LB, Pellerano RG, Wuilloud RG (2019) Quality monitoring and authenticity assessment of wines: analytical and chemometric methods. Elsevier Inc.
Dias FS, Lovillo MP, Barroso CG, David JM (2010) Optimization and validation of a method for the direct determination of catechin and epicatechin in red wines by HPLC/fluorescence. Microchem J 96:17–20. https://doi.org/10.1016/j.microc.2010.01.004
Dias FS, David JM, David JP (2016) Determination of phenolic acids and quercetin in Brazilian red wines from vale do São Francisco region using liquid-liquid ultrasound-assisted extraction and HPLC-DAD-MS. J Braz Chem Soc 27:1055–1059. https://doi.org/10.5935/0103-5053.20150363
Embrapa (2019) Vitivinicultura brasileira: panorama 2018. https://ainfo.cnptia.embrapa.br/digital/bitstream/item/203100/1/Comunicado-Tecnico-210.pdf 2019. Acessed 12 july 2020.
Ferreira SLC, Dos Santos WNL, Quintella CM, Neto BB et al (2004) Doehlert matrix: a chemometric tool for analytical chemistry - review. Talanta 63:1061–1067. https://doi.org/10.1016/j.talanta.2004.01.015
Funari CS, Carneiro RL, Andrade AM, Hilder EF, Cavalheiro AJ (2014) Green chromatographic fingerprinting: an environmentally friendly approach for the development of separation methods for fingerprinting complex matrices. J Sep Sci 37:37–44. https://doi.org/10.1002/jssc.201300955
Gaber Y, Törnvall U, Kumar MA, Amim MA et al (2011) HPLC-EAT (Environmental Assessment Tool): a tool for profiling safety, health and environmental impacts of liquid chromatography methods. Green Chem 13:2021. https://doi.org/10.1039/c0gc00667j
Gałuszka A, Migaszewski Z, Namieśnik J (2013) The 12 principles of green analytical chemistry and the SIGNIFICANCE mnemonic of green analytical practices. TrAC - Trends Anal Chem 50:78–84. https://doi.org/10.1016/j.trac.2013.04.010
Gan F, Ye R (2006) New approach on similarity analysis of chromatographic fingerprint of herbal medicine. J Chromatogr A 1104:100–105. https://doi.org/10.1016/j.chroma.2005.11.099
García-Beneytez E, Cabello F, Revilla E (2003) Analysis of grape and wine anthocyanins by HPLC-MS. J Agric Food Chem 51:5622–5629. https://doi.org/10.1021/jf0302207
Guillarme D, Heinisch S, Rocca JL (2004) Effect of temperature in reversed phase liquid chromatography. J Chromatogr A 1052:39–51. https://doi.org/10.1016/j.chroma.2004.08.052
Guillarme D, Nguyen DTT, Rudaz S, Veuthey JL (2008) Method transfer for fast liquid chromatography in pharmaceutical analysis: application to short columns packed with small particle. Part II: Gradient experiments. Eur J Pharm Biopharm 68:430–440. https://doi.org/10.1016/j.ejpb.2007.06.018
Han F, Oliveira H, Brás NF, Fernandes I, Cruz L, de Freitas V, Mateus N (2020) In vitro gastrointestinal absorption of red wine anthocyanins – impact of structural complexity and phase II metabolization. Food Chem 317:126398. https://doi.org/10.1016/j.foodchem.2020.126398
ICH Harmonised Tripartite Guideline (2005) Validation of analytical procedures: text and methodology Q2(R1). ICH. https://database.ich.org/sites/default/files/Q2%28R1%29%20Guideline.pdf. Accessed 12 May 2020
Henderson RK, Jiménez-González C, Constable DJC, Alston SR, Inglis GGA, Fisher G, Sherwood J, Binks SP, Curzons AD (2011) Expanding GSK’s solvent selection guide - embedding sustainability into solvent selection starting at medicinal chemistry. Green Chem 13:854–862. https://doi.org/10.1039/c0gc00918k
Hernández T, Estrella I, Carlavilla D, Martínz-Álvarez PJ et al (2006) Phenolic compounds in red wine subjected to industrial malolactic fermentation and ageing on lees. Anal Chim Acta 563:116–125. https://doi.org/10.1016/j.aca.2005.10.061
Ivanova-Petropulos V, Hermosín-Gutiérrez I, Boros B, Stefova M, Stafilov T, Vojnoski B, Dörnyei Á, Kilár F (2015) Phenolic compounds and antioxidant activity of Macedonian red wines. J Food Compos Anal 41:1–14. https://doi.org/10.1016/j.jfca.2015.01.002
Lins AR, Sartori GV (2015) Qualidade fenólica e atividade antioxidante de vinhos tintos produzidos no Estado do Paraná. Rev Bras Prod Agroindustriais 16:69–76. https://doi.org/10.15871/1517-8595/rbpa.v16n1p69-76
Moraes V, Locatelli C (2010) Vinho : uma revisão sobre a composição química e benefícios à saúde. Evidência - Ciência e Tecnol 10:57–68
Neto BB, Scarminio IS, Bruns RE (2010) Como fazer experimentos, 4th edn. Bookman, São Paulo
Pena-Pereira F, Wojnowski W, Tobiszewski M (2020) AGREE – Analytical GREEnness metric approach and software. Anal Chem 0–28. https://doi.org/10.1021/acs.analchem.0c01887,
Pereira Filho ER (2015) Planejamento fatorial em química: maximizando a obtenção de resultados. Edufscar, São Carlos
Pereira F, Pereira-Filho E (2018) Aplicação de programa computacional livre em planejamento de experimentos: um tutorial. Quim Nova 2018:1061–1071. https://doi.org/10.21577/0100-4042.20170254
Prado AGS (2003) Química verde, os desafios da química do novo milênio. Quim Nova 26:738–744. https://doi.org/10.1590/s0100-40422003000500018
Prat D, Wells A, Hayler J, Sneddon H, McElroy CR, Abou-Shehada S, Dunn PJ (2015) CHEM21 selection guide of classical- and less classical-solvents. Green Chem 18:288–296. https://doi.org/10.1039/c5gc01008j
Revilla E, Ryan JM (2000) Analysis of several phenolic compounds with potential antioxidant properties in grape extracts and wines by high-performance liquid chromatography-photodiode array detection without sample preparation. J Chromatogr A 881:461–469. https://doi.org/10.1016/S0021-9673(00)00269-7
Revilla E, García-Beneytez E, Cabello F, Martín-Ortega G et al (2001) Value of high-performance liquid chromatographic analysis of anthocyanins in the differentiation of red grape cultivars and red wines made from them. J Chromatogr A 915:53–60. https://doi.org/10.1016/S0021-9673(01)00635-5
Souza OA, Carneiro RL, Vieira THM, Funari CS, Rinaldo D (2018) Fingerprinting Cynara scolymus L. (Artichoke) by means of a green statistically developed HPLC-PAD method. Food Anal Methods 11:1977–1985. https://doi.org/10.1007/s12161-018-1159-4
Teófilo RF, Ferreira MM (2006) Quimiometria II: planilhas eletronicas para cálculos de planejamentos experimentais, um tutorial. Quim Nova 29:338–350. https://doi.org/10.1590/S0100-40422006000200026
Tistaert C, Dejaegher B, Vander Heyden Y (2011) Chromatographic separation techniques and data handling methods for herbal fingerprints: a review. Anal Chim Acta 690:148–161. https://doi.org/10.1016/j.aca.2011.02.023
Vian MA, Tomao V, Gallet S, Coulomb PO, Lacombe JM (2005) Simple and rapid method for cis- and trans-resveratrol and piceid isomers determination in wine by high-performance liquid chromatography using Chromolith columns. J Chromatogr A 1085:224–229. https://doi.org/10.1016/j.chroma.2005.05.083
Waterhouse AL (2002) Wine Phenolics. Ann N Y Acad Sci 957:21–36. https://doi.org/10.1080/09571269508718028
Acknowledgements
The authors thank Prof Valdecir Farias Ximenes, of the Department of Chemistry of São Paulo State University, for the use of HPLC-PAD instrument.
Funding
The authors thank the financial support from the São Paulo Research Foundation (FAPESP, Fundação de Amparo à Pesquisa do Estado de São Paulo), grants # 2016/08179-8; #2018/18212-8; #2019/01102-8, and #2014/50945-4; the National Council for Scientific and Technological Development (CNPq, Conselho Nacional de Desenvolvimento Científico e Tecnológico), grants #307328/2019-8 and National Institute of Science and Technology - INCT BioNat, grant # 465637/2014-0, Brazil; and the Coordination for the Improvement of Higher Education Personnel (CAPES, Coordenação de Aperfeiçoamento de Pessoal de Nível Superior) grant #88887136426/2017/00, Brazil.
Author information
Authors and Affiliations
Corresponding author
Ethics declarations
Ethical Approval
This article does not contain any studies with human participants or animals performed by any of the authors.
Informed Consent
Not applicable.
Conflict of Interest
Author João Henrique Pelissari declares that he has no conflict of interest. Author Felipe Sanchez Bragagnolo declares that he has no conflict of interest. Author Fabíola Manhas Verbi Pereira declares that she has no conflict of interest. Author Maiara Stefanini Borges declares that she has no conflict of interest. Author Cristiano Soleo de Funari declares that he has no conflict of interest. Author Daniel Rinaldo declares that he has no conflict of interest.
Additional information
Publisher’s Note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Cristiano Soleo de Funari and Daniel Rinaldo are part of the GreenBiotech Network.
Rights and permissions
About this article
Cite this article
Pelissari, J.H., Bragagnolo, F.S., Pereira, F.M.V. et al. Green and Multivariate Approach to Obtain a Fingerprint of Red Wines by HPLC-PAD. Food Anal. Methods 14, 1654–1665 (2021). https://doi.org/10.1007/s12161-021-02006-3
