Abstract
Mycotoxins are secondary metabolites produced by fungi, such as Fusarium, Penicillium, and Aspergillus, which are toxic to humans with high risk factors and pose a significant threat to human health. This study was focused mostly on well-known mycotoxins, such as aflatoxins (AFB1, AFB2, AFG1 and AFG2), fumonisin (FB1, FB2), deoxynivalenol (DON), zearalenone (ZON), ochratoxin A, T-2 and HT-2, in grains. The multi-mycotoxin methods developed in this study utilise an analysis of mycotoxin through liquid chromatography tandem mass spectrometry (LC-MS/MS), which can significantly improve sample analysis efficiency. The Myco6in1™ immunoaffinity column was used for purification to reduce interference from the substrate. Gradient separation to obtain the best peak shift was conducted using solvent with 0.1 % formic acid in deionised water and methanol, and gradient separation was performed on an ACQUITY BEH C18 column chromatograph. The recovery rate test for each toxin using substrates such as rice, peanut, wheat and maize mostly indicated good average recovery rates between 70 % and 120 % and the coefficient of variation mostly under 15 %. The limits of quantification (LOQ) identified by this method are less than 5 ng/g in most toxins, except for 20 ng/g in FB1and FB2. This method can rapidly and simultaneously analyse 11 mycotoxins in 9 min. It can be applied for the practical examination of mycotoxins in food to protect public health.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
Explore related subjects
Discover the latest articles and news from researchers in related subjects, suggested using machine learning.References
Anderson B, Frisvad JC (2004) Natural occurrence of fungi and fungal metabolites in moldy tomatoes. J Agric Food Chem 52:7507–7513
Antonello S, Rosalia F, Maria CS, Alejandro A, Alberto R (2009) Multitoxin extraction and detection of trichothecenes in cereals: an improved LC-MS/MS approach. J Sci Food Agric 89:1145–1153
Bayman P, Baker JL (2006) Ochratoxins: a global perspective. Mycopathologia 162:215–223
Birzele B, Prange A, Kramer J (2000) Deoxynivalenil and ochratoxin A in German wheat and changes of level in relation to storage parameters. Food Addit Contam 17(21):1027–1035
Dall’Asta C, Galaverna G, Aureli G, Dossena A, Marchelli R (2008) A LC/MS/MS method for the simultaneous quantification of free and masked fumonisins in maize-based products. World Mycotoxin J 1(3):237–246
EC Commission Regulation No. 1881/2006 (2006) Setting maximum levels for certain contaminants in foodstuffs
EC, European Commission (2001) Reports on tasks for scientific co-operation. Collection of occurrence data of Fusarium toxins in food and assessment of dietary intake by the population of EU Member States
Ferrer I, García-Reyes JF, Mezcua M, Thurman EM, Fernández-Alba AR (2005) Multi-residue pesticide analysis in fruits and vegetables by liquid chromatography–time-of-flight mass spectrometry. J Chromatogr A 1082:81–90
Freire F, Kozakiewics Z, Paterson R (2000) Mycoflora and mycotoxins in Brazilian black pepper, white pepper and Brazi nuts. Mycopathologia 159:281–289
Hesseltine CW (1967) Aflatoxina and other mycotoxins. Health Lab Sci 4:222–228
Homdark S, Fehrmann F, Beck R (2000) Influence of different storage conditions on the mycotoxins production and quality of fusarium-infected wheat grain. J Phytopathol 148:7–15
Huang C-C (2010) Risk and control of mycotoxin. Food Ind Mon 42(4):1–3
Kokkonen Meri K, Jestoi Marika N (2009) A Multi-compound LC-MS/MS method for the screening of mycotoxins in grains. Food Anal Methods 2:128–140
Larsen TO, Gareis M, Frisvad JC (2002) Cell cytotoxicity and mycotoxin and secondary metabolite production by common Penicillia on cheese agar. J Agric Food Chem 50:6148–6152
Lattanzio VMT, Solfrizzo M, Powers S, Visconti A (2007) Simultaneous determination of aflatoxins, ochratoxin A and Fusarium toxins in maize by liquid chromatography/tandem mass spectrometry after multitoxin immunoaffinity cleanup. Rapid Commun Mass Spectrom 21:3253–3261
Lattanzio VMT, Gatta SD, Godula M, Visconti A (2011) Quantitative analysis of mycotoxins in cereal foods by collision cell fragmentation-high-resolution mass spectrometry: performance and comparison with triple-stage quadrupole detection. Food Addit Contam 28:1424–1437
Leong SL, Hocking AD, Pitt JI, Kazi BA, Emmett RW, Scott ES (2006) Australian research on ochratoxigenic fungi and ochratoxin A. Int J Food Microbiol 111:S10–S17
Maurice OM (2002) Risk assessment for aflatoxins in foodstuffs. Int Biodeter Biodegr 50:137–142
Method of Test for Mycotoxin in Foods, www.fda.gov.tw/Bgradation_index.aspx? site_content_sn=42
Michel S, Krska R, Rainer S (2010) Application of an LC-MS/MS based multi-mycotoxin method for the semi-quantitative determination of mycotoxins occurring in different types of food infected by moulds. Food Chem 119:408–416
Miller JD (1997) In: Trenholm HL (ed) Mycotoxin in grain. Compounds other than aflatoxins, 2nd edn. Eagan Press, St Paul, MN
Nakagawa H, Ohmichi K, Sakamoto S, Sago Y, Kushiro M, Nagashima H, Yoshida M, Nakajima T (2011) Detection of a new Fusarium masked mycotoxin in wheat grains by high-resolution LC-Orbitrap™ MS. Food Addit Contam 28:1447–1456
Pena A, Seifrtova M, Lino C, Silveira I, Solich P (2006) Estimation of ochratoxin A in Portuguese population: new data on the occurrence in human urine by high performance liquid chromatography with fluorescence detection. Food Chem Toxicol 44:1449–1454
Ren Y, Zhang Y, Shao S, Cai Z, Feng L, Pan H, Wang Z (2007) Simultaneous determination of multi-component mycotoxin contaminants in food and feed by ultra-performance liquid chromatography tandem mass spectrometry. J Chromatogr A 1143:48–64
Spanjer MC, Rensen PM, Scholten JM (2008) LC-MS/MS multi-method for mycotoxin after single extraction, with validation data for peanut, pistachio, wheat, maize, cornflakes, raisins and figs. Food Addit Contam 25(4):472–489
Stecher G, Jarukamjorn K, Zaborski P, Bakry R, Huck CW, Bonn GK (2007) Evalution of extraction methods for the simultaneous analysis of simple and macrocyclic trichothecenes. Talanta 73:251–257
T-2 and HT-2 Toxins, www.inchem.org/documents/jecfa/jecmono/v47je06.htm
Van Pamel E, Vlaemynck G, Heyndrickx M, Herman L, Verbeken A, Daeseleire E (2011) Mycotoxin production by pure fungal isolates analysed by means of an UHPLC-MS/MS multi-mycotoxin method with possible pitfalls and solutions for patulin-producing isolates. Mycotoxicol Res 27:37–47
Waters Co. (2006) ACQUITY UPLC system quick start guide. Revision C. Waters Corporation, Massachusetts, USA
Zinedine A, Soriano JM, Molto JC, Manes J (2007) Review on the toxicity, occurrence, metabolism, detoxification, regulations and intake of zearalenone: an oestrogen mycotoxin. Food Chem Toxicol 45:1–18
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Tang, Y.Y., Lin, H.Y., Chen, Y.C. et al. Development of a Quantitative Multi-Mycotoxin Method in Rice, Maize, Wheat and Peanut Using UPLC-MS/MS. Food Anal. Methods 6, 727–736 (2013). https://doi.org/10.1007/s12161-012-9473-8
Received:
Accepted:
Published:
Issue Date:
DOI: https://doi.org/10.1007/s12161-012-9473-8
