Abstract
This paper aims at contributing to remedy the narrow treatment of functions at upper secondary level. Assuming that students make sense of functions by working on functional situations in distinctive settings, we propose to consider functional working spaces inspired by geometrical working spaces. We analyse a classroom situation based on a geometric optimization problem pointing out that no working space has been prepared by the teacher for students’ tasks outside algebra. We specify a dynamic geometry space, a measure space and an algebra space, with artefacts in each space and means for connecting these provided by Casyopée. The question at stake is then the functionality of this framework for implementing and analyzing classroom situations and for analyzing students’ and teachers’ evolution concerning functions, in terms of geneses relative to each space.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
Notes
We are aware that ‘genesis’ is used for denoting, in MWS, processes connecting the epistemological and the cognitive planes in a space. However, the way we use this word is consistent with the theoretical construct of ‘instrumental genesis’ (Lagrange 1999), a basis of the work we carried out for more than 15 years. Confronting these two conceptions is a promising perspective.
Studying variations of a continuous function is for instance proving that it is decreasing on some interval and increasing on another adjacent interval, and thus that it has a minimum. See examples in the teaching situations above.
The current programs of study and accompanying documents in France can be found at (http://eduscol.education.fr/).
We submitted a dynamic geometry figure with A a fixed point, C a free point, and B and D constructed in order that ABCD is a rectangle with sides parallel to the axes, to 34 students in a 10th grade class. The students had basic knowledge in dynamic geometry allowing them to understand how the rectangle is constructed and what happens when C is dragged. We asked them whether B and D are free points. Half of the class answered positively and explained that these points “are able to move”. See also Laborde, Kynigos, Hollebrands & Strasser (2006, p. 285).
About quantification and its importance in students’ understanding of functions, see Thompson (2011).
In addition, considering functions in “real world situations” would suppose a space where students could work in a non-mathematical space, for instance around a physical device involving a mechanical dependency. See Lagrange (2013) for an example. Here, for the sake of simplicity, we will keep the type of task of geometric optimization as an object for reflection, and then restrict ourselves to three spaces.
“Much like British A-levels or European Matura, the baccalauréat allows French students to obtain a standardised qualification, typically at the age of 18. This then qualifies holders to (…) go on to tertiary education”. (https://en.wikipedia.org/wiki/Baccalauréat). The students observed here pass the scientific baccalauréat involving a set of subjects among which mathematics has the heavier weight.
More data about this study is provided by Minh (2012b).
Some evidence supporting this assumption is provided by Lagrange and Caliskan (2009) from a study of textbooks and classroom practices in France.
There is a special functionality, based on algebraic theorems dealing with functions, that helps building proofs.
References
Elbaz-Vincent, P. (2005). A cas as an assistant to reasoned instrumentation. In D. Guin, K. Ruthven, & L. Trouche (Eds.), The didactical challenge of symbolic calculators: turning a computational device into a mathematical instrument (pp. 41–65). New York: Springer.
Halbert, R., Lagrange, J.-B., Le Bihan, C., Le Feuvre, B., Manens, M.-C., & Meyrier, X. (2013). Les fonctions: Comprendre la notion et résoudre des problèmes de la 3ème à la Terminale. L’apport d’un logiciel dédié. I.R.E.M de RENNES– Université de RENNES.
Kieran, C. (2007). Learning and teaching algebra at the middle school through college levels. In F. K. Lester Jr (Ed.), Second handbook of research on mathematics teaching and learning (pp. 707–762). Charlotte: National Council of Teachers of Mathematics, Information Age Publishing.
Kuzniak, A. (2013). Teaching and learning geometry and beyond. In B. Ubuz, Ç. Haser, & M. A. Mariotti (Eds.), Proceedings of the Eighth Congress of European Research in Mathematics Education (CERME 8), (pp. 33–49). Antalya, Turkey.
Laborde, C., Kynigos, C., Hollebrands, K., & Strasser, R. (2006). Teaching and learning geometry with technology. In A. Gutierrez & P. Boero (Eds.), Handbook of research on the psychology of mathematics education: Past, present and future (pp. 275–304). Rotterdam: Sense Publishers.
Lagrange, J.-B. (1999). Complex calculators in the classroom: theoretical and practical reflections on teaching pre-calculus. International Journal of Computers for Mathematical Learning, 4(1), 51–81.
Lagrange, J.-B. (2011). Working with teachers: Innovative software at the boundary between research and classroom. In B. Ubuz (Ed.), Proceedings of 35th conference of the international group for the psychology of mathematics education (Vol. 3, pp. 113–120). Ankara: PME.
Lagrange, J.-B. (2013). A functional perspective on the teaching of algebra: current challenges and the contribution of technology. International Journal for Technology in Mathematics Education, 21(1), 3–8.
Lagrange, J.-B., & Caliskan, N. (2009). Usages de la technologie dans des conditions ordinaires: le cas de la géométrie dynamique au collège. Recherches en Didactique des Mathématiques, 29(2), 189–226.
Lagrange, J.-B., & Psycharis, G. (2014). Investigating the potential of computers environments for the teaching and learning of functions. Technology, Knowledge and Learning, 19(3), 255–286.
MEN/DGESCO-IGEN. (2013). Les compétences mathématiques au lycée. http://eduscol.education.fr/ressources-maths.
Minh, T. K. (2012a). Learning about functions with the help of technology: students’ instrumental genesis of a geometrical and symbolic environment. In T. Y. Tso (Ed.), Proceedings of the 36th conference of the international group for the psychology of mathematics education (Vol. 3, pp. 217–223). Taipei: PME.
Minh, T. K. (2012b). Les fonctions dans un environnement numérique d’apprentissage: étude des apprentissages des élèves sur deux ans. Canadian Journal of Science, Mathematics and Technology Education, 12(3), 233–258.
Robert, A., & Vandebrouck, F. (2014). Proximités-en-acte mises en jeu en classe par les enseignants du secondaire et ZPD des élèves: analyses de séances sur des tâches complexes. Recherches en didactique des mathématiques, 43(2–3), 239–285.
Thi, NN. (2011). La périodicité dans les enseignements scientifiques en France et au Viêt Nam : une ingénierie didactique d’introduction aux fonctions périodiques par la modélisation. Thèse de doctorat, Université Joseph Fourier et Université Pédagogique d’Ho Chi Minh Ville.
Thompson, P. W. (2011). Quantitative reasoning and mathematical modeling. In L. L. Hatfield, S. Chamberlain, & S. Belbase (Eds.), New perspectives and directions for collaborative research in mathematics education. WISDOMe Mongraphs (Vol. 1, pp. 33–57). Laramie: University of Wyoming.
Acknowledgments
This research was supported by Vietnam National Foundation for Science and Technology Development (NAFOSTED), under Grant Number VI1.99-2012.16.
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Minh, T.K., Lagrange, JB. Connected functional working spaces: a framework for the teaching and learning of functions at upper secondary level. ZDM Mathematics Education 48, 793–807 (2016). https://doi.org/10.1007/s11858-016-0774-z
Accepted:
Published:
Issue Date:
DOI: https://doi.org/10.1007/s11858-016-0774-z
