Factors related to disagreement in implant size between preoperative CT-based planning and the actual implants used intraoperatively for total hip arthroplasty

  • Takeshi Ogawa
  • Masaki Takao
  • Takashi Sakai
  • Nobuhiko Sugano
Original Article
  • 241 Downloads

Abstract

Purpose

In total hip arthroplasty, prediction of the optimal implant size is important in order to prevent perioperative complications. However, it is not easy to achieve complete agreement between the planned size and the actual size required appropriate implant fit. No previous report has adequately discussed the factors related to mismatch between predicted and actual implant sizes. The purpose was to report the results of a single surgeon case series of patients undergoing THA using computed tomography (CT)-based templating and the possible factors related to implant size mismatch.

Methods

The study included 141 hips of 126 patients who underwent primary total hip arthroplasty with CT-based navigation. We retrospectively reviewed the planned and actual implant sizes used in these patients. Cup position, cup orientation and stem alignment were evaluated as surgical factors that could possibly be related to mismatch in implant size. Cortical index and canal flare index were also evaluated as morphological factors.

Results

The final inclusions in this study were 124 hips of 111 patients including 82% of those were developmental dysplasia of the hip. Agreement in implant size was seen for 94.4% of cups and 85.5% of stems, respectively. No related factors were found for cup size mismatch. Stem alignment in the sagittal and coronal planes showed significant differences between the size-matched stem group and the smaller stem group (\(p<0.05\)).

Conclusions

Implant size agreement rates between the three-dimensional plan and the actual implants used intraoperatively were high. However, broach alignment should be checked in the coronal and sagittal planes if the intraoperative broach is smaller than the planned size.

Keywords

Total hip arthroplasty Implant size Preoperative planning CT-based navigation Three-dimensional planning

Notes

Compliance with ethical standards

Conflicts of interest

The authors declare that they have no conflict of interest.

Ethical approval

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional research committee and with the 1964 Helsinki Declaration and its later amendments or comparable ethical standards

Informed consent

For this type of study formal consent is not required.

References

  1. 1.
    Eggli S, Pisan M, Müller ME (1998) The value of preoperative planning for total hip arthroplasty. J Bone Joint Surg Br 80(3):382–390CrossRefPubMedGoogle Scholar
  2. 2.
    Bono JV (2004) Digital templating in total hip arthroplasty. J Bone Joint Surg Am 86–A(Suppl 2):118–122CrossRefGoogle Scholar
  3. 3.
    Sariali E, Mouttet A, Pasquier G, Durante E, Catone Y (2009) Accuracy of reconstruction of the hip using computerised three-dimensional pre-operative planning and a cementless modular neck. J Bone Joint Surg Br 91(3):333–340.  https://doi.org/10.1302/0301-620X.91B3.21390 CrossRefPubMedGoogle Scholar
  4. 4.
    Aldinger PR, Jung AW, Pritsch M, Breusch S, Thomsen M, Ewerbeck V, Parsch D (2009) Uncemented grit-blasted straight tapered titanium stems in patients younger than fifty-five years of age. Fifteen to twenty-year results. J Bone Joint Surg Am 91(6):1432–1439.  https://doi.org/10.2106/JBJS.H.00297 CrossRefPubMedGoogle Scholar
  5. 5.
    Hananouchi T, Sugano N, Nakamura N, Nishii T, Miki H, Yamamura M, Yoshikawa H (2007) Preoperative templating of femoral components on plain X-rays. Rotational evaluation with synthetic X-rays on ORTHODOC. Arch Orthop Trauma Surg 127(5):381–385CrossRefPubMedGoogle Scholar
  6. 6.
    Hassani H, Cherix S, Ek ET, Rüdiger HA (2014) Comparisons of preoperative three-dimensional planning and surgical reconstruction in primary cementless total hip arthroplasty. J Arthroplasty 29(6):1273–1277.  https://doi.org/10.1016/j.arth.2013.12.033 CrossRefPubMedGoogle Scholar
  7. 7.
    Sariali E, Mauprivez R, Khiami F, Pascal-Mousselard H, Catonné Y (2012) Accuracy of the preoperative planning for cementless total hip arthroplasty. A randomised comparison between three-dimensional computerised planning and conventional templating. Orthop Traumatol Surg Res 98(2):151–158.  https://doi.org/10.1016/j.otsr.2011.09.023 CrossRefPubMedGoogle Scholar
  8. 8.
    Viceconti M, lattanzi R, Antonietti B, Paderni S, Olmi R, Sudanese A, Toni A (2003) CT-based surgical planning software improves the accuracy of total hip replacement preoperative planning. Med Eng Phys 25(5):371–377CrossRefPubMedGoogle Scholar
  9. 9.
    Inoue D, Kabata T, Maeda T, Kajino Y, Fujita K, Hasegawa K, Yamamoto T, Tsuchiya H (2015) Value of computed tomography-based three-dimensional surgical preoperative planning software in total hip arthroplasty with developmental dysplasia of the hip. J Orthop Sci 20(2):340–346.  https://doi.org/10.1007/s00776-014-0683-3 CrossRefPubMedGoogle Scholar
  10. 10.
    Nishihara S, Sugano N, Nishii T, Ohzono K, Yoshikawa H (2003) Measurements of pelvic flexion angle using three-dimensional computed tomography. Clin Orthop Relat Res 411:140–151CrossRefGoogle Scholar
  11. 11.
    Kingsley PC, Olmsted KL (1948) A study to determine the angle of anteversion of the neck of the femur. J Bone Joint Surg Am 30A(3):745–751CrossRefPubMedGoogle Scholar
  12. 12.
    Takao M, Nakamura N, Ohzono K, Sakai T, Nishii T, Sugano N (2011) The results of a press-fit-only technique for acetabular fixation in hip dysplasia. J Arthroplasty 26(4):562–568.  https://doi.org/10.1016/j.arth.2010.05.025 CrossRefPubMedGoogle Scholar
  13. 13.
    Sugano N, Tsuda K, Miki H, Takao M, Suzuki N, Nakamura N (2012) Dynamic measurements of hip movement in deep bending activities after total hip arthroplasty using a 4-dimensional motion analysis system. J Arthroplasty 27(8):1562–1568.  https://doi.org/10.1016/j.arth.2012.01.029 CrossRefPubMedGoogle Scholar
  14. 14.
    Kitada M, Nakamura N, Iwana D, Kakimoto A, Nishii T, Sugano N (2011) Evaluation of the accuracy of computed tomography-based navigation for femoral stem orientation and leg length discrepancy. J Arthroplasty 26(5):674–679.  https://doi.org/10.1016/j.arth.2010.08.001 (Epub 2010 Sep 25)CrossRefPubMedGoogle Scholar
  15. 15.
    Iwana D, Nakamura N, Miki H, Kitada M, Hananouchi T, Sugano N (2013) Accuracy of angle and position of the cup using computed tomography-based navigation systems in total hip arthroplasty. Comput Aided Surg 18(5–6):187–194.  https://doi.org/10.3109/10929088.2013.818713 (Epub 2013 Jul 17)CrossRefPubMedGoogle Scholar
  16. 16.
    Sugano N, Takao M, Sakai T, Nishii T, Miki H, Nakamura N (2009) Comparison of mini-incision total hip arthroplasty through an anterior approach and a posterior approach using navigation. Orthop Clin North Am 40(3):365–370.  https://doi.org/10.1016/j.ocl.2009.04.003 CrossRefPubMedGoogle Scholar
  17. 17.
    Dorr LD, Faugere MC, Mackel AM, Gruen TA, Bognar B, Malluche HH (1993) Structural and cellular assessment of bone quality of proximal femur. Bone 14(3):231–242CrossRefPubMedGoogle Scholar
  18. 18.
    Sugano N, Noble PC, Kamaric E, Salama JK, Ochi T, Tullos HS (1998) The morphology of the femur in developmental dysplasia of the hip. J Bone Joint Surg Br 80(4):711–719CrossRefPubMedGoogle Scholar
  19. 19.
    Noble PC, Box GG, Kamaric E, Fink MJ, Alexander JW, Tullos HS (1995) The effect of aging on the shape of the proximal femur. Clin Orthop Relat Res 316:31–44Google Scholar
  20. 20.
    Muller M, Crucius D, Perka C, Tohtz S (2011) The association between the sagittal femoral stem alignment and the resulting femoral head centre in total hip arthroplasty. Int Orthop 35(7):981–987.  https://doi.org/10.1007/s00264-010-1047-z CrossRefPubMedGoogle Scholar
  21. 21.
    Murray DW (1993) The definition and measurement of acetabular orientation. J Bone Joint Surg Br 75(2):228–232CrossRefPubMedGoogle Scholar
  22. 22.
    Engh CA, Glassman AH, Suthers KE (1990) The case for porous-coated hip implants. The femoral side. Clin Orthop Relat Res 261:63–81Google Scholar
  23. 23.
    Callaghan JJ, Dysart SH, Savory CG (1988) The uncemented porous-coated anatomic total hip prosthesis. Two-year results of a prospective consecutive series. J Bone Joint Surg Am 70(3):337–346CrossRefPubMedGoogle Scholar
  24. 24.
    Sugano N, Nishii T, Miki H, Yoshikawa H, Sato Y, Tamura S (2007) Mid-term results of cementless total hip replacement using a ceramic-on-ceramic bearing with and without computer navigation. J Bone Joint Surg Br 89(4):455–460CrossRefPubMedGoogle Scholar
  25. 25.
    Crowe JF, Mani VJ, Ranawat CS (1979) Total hip replacement in congenital dislocation and dysplasia of the hip. J Bone Joint Surg Am 61(1):15–23CrossRefPubMedGoogle Scholar
  26. 26.
    Shaarani SR, McHugh G, Collins DA (2013) Accuracy of digital preoperative templating in 100 consecutive uncemented total hip arthroplasties: a single surgeon series. J Arthroplasty 28(2):331–337.  https://doi.org/10.1016/j.arth.2012.06.009 CrossRefPubMedGoogle Scholar
  27. 27.
    Gamble P, de Beer J, Petruccelli D, Winemaker M (2010) The accuracy of digital templating in uncemented total hip arthroplasty. J Arthroplasty 25(4):529–532.  https://doi.org/10.1016/j.arth.2009.04.011 CrossRefPubMedGoogle Scholar
  28. 28.
    Zhao X, Zhu ZA, Zhao J, Li MQ, Wang G, Yu DG, Yu B (2011) The utility of digital templating in Total Hip Arthroplasty with Crowe type II and III dysplastic hips. Int Orthop 35(5):631–638.  https://doi.org/10.1007/s00264-010-0991-y CrossRefPubMedGoogle Scholar
  29. 29.
    Petretta R, Strelzow J, Ohly NE, Misur P, Masri BA (2015) Acetate templating on digital images is more accurate than computer-based templating for total hip arthroplasty. Clin Orthop Relat Res 473(12):3752–3759.  https://doi.org/10.1007/s11999-015-4321-y CrossRefPubMedPubMedCentralGoogle Scholar
  30. 30.
    Davila JA, Kransdorf MJ, Duffy GP (2006) Surgical planning of total hip arthroplasty: accuracy of computer-assisted EndoMap software in predicting component size. Skeletal Radiol 35(6):390–393CrossRefPubMedGoogle Scholar
  31. 31.
    Schmidutz F, Steinbrück A, Wanke-Jellinek L, Pietschmann M, Jansson V, Fottner A (2012) The accuracy of digital templating: a comparison of short-stem total hip arthroplasty and conventional total hip arthroplasty. Int Orthop 36(9):1767–1772.  https://doi.org/10.1007/s00264-012-1532-7 CrossRefPubMedPubMedCentralGoogle Scholar
  32. 32.
    Issa K, Pivec R, Boyd B, Harwin SF, Wuestemann T, Nevelos J, Mont MA (2012) Comparing the accuracy of radiographic preoperative digital templating for a second- versus a first-generation THA stem. Orthopedics 35(12):1028–1034.  https://doi.org/10.3928/01477447-20121120-03 CrossRefPubMedGoogle Scholar
  33. 33.
    Unnanuntana A, Wagner D, Goodman SB (2009) The accuracy of preoperative templating in cementless total hip arthroplasty. J Arthroplasty 24(2):180–186.  https://doi.org/10.1016/j.arth.2007.10.032 CrossRefPubMedGoogle Scholar
  34. 34.
    Sugano N, Ohzono K, Nishii T, Haraguchi K, Sakai T, Ochi T (1998) Computed-tomography-based computer preoperative planning for total hip arthroplasty. Comput Aided Surg 3(6):320–4CrossRefPubMedGoogle Scholar
  35. 35.
    Akiyama H, Hoshino A, Iida H, Shindo H, Takakura Y, Miura H, Yamamoto K, Yoshiya S, Hasegawa Y, Shimamura T, Kurosaka M, Otsuka H, Kawanabe K, Kawate K, Harada Y, Nakamura T, Committee Implant, Association Japanese Orthopaedic (2012) A pilot project for the Japan arthroplasty register. J Orthop Sci 17(4):358–369.  https://doi.org/10.1007/s00776-012-0229-5 CrossRefPubMedGoogle Scholar
  36. 36.
    Hananouchi T, Takao M, Nishii T, Miki H, Iwana D, Yoshikawa H, Sugano N (2009) Comparison of navigation accuracy in THA between the mini-anterior and -posterior approaches. Int J Med Robot 5(1):20–5.  https://doi.org/10.1002/rcs.226 CrossRefPubMedGoogle Scholar
