Abstract
Lignin is one of the main barriers to obtaining added-value products from cellulosic fraction of lignocellulosic biomass due to its random aromatic structure and strong association with cellulose and hemicellulose. Inorganic and organic compounds have been used as enzyme inducers to increase the ligninolytic potential of white-rot fungi, without considering their effect on the selectivity of degradation. In this study, the selective lignin degradation in wheat straw by Ganoderma lobatum was optimized using a central composite design to evaluate the combined effect of Fe2+ and Mn2+ as inducers of ligninolytic enzymes and NO3 − as an additional nitrogen source. Selective lignin degradation was promoted to maximize lignin degradation and minimize weight losses. The optimal conditions were 0.18 M NO3 −, 0.73 mM Fe2+, and 1 mM Mn2+, which resulted in 50.0% lignin degradation and 18.5% weight loss after 40 days of fungal treatment. A decrease in absorbance at 1505 and 900 cm−1 in fungal-treated samples was observed in the FTIR spectra, indicating lignin and cellulose degradation in fungal-treated wheat straw, respectively. The main ligninolytic enzymes detected during lignin degradation were manganese-dependent and manganese-independent peroxidases. Additionally, confocal laser scanning microscopy revealed that lignin degradation in wheat straw by G. lobatum resulted in higher cellulose accessibility. We concluded that the addition of enzyme inducers and NO3 − promotes selective lignin degradation in wheat straw by G. lobatum.
Similar content being viewed by others
References
Acevedo F, Pizzul L, Castillo MP, Rubilar L, Lienqueo ME, Tortella G, Diez MC (2011) A practical culture technique for an enhanced production of manganese peroxidase by the Chilean white-rot fungus Anthracophyllum discolor Sp4. Braz Arch Biol Techn 54:1175–1186
Arantes V, Saddler JN (2011) Cellulose accessibility limits the effectiveness of minimum cellulase loading on the efficient hydrolysis of pretreated lignocellulosic substrates. Biotechnol Biofuels 4:1–16
Bisaria R, Madan M, Vasudevan P (1997) Utilization of agro-residues as animal feed through bioconversion. Bioresour Technol 59:5–8
Blanchette RA (1984) Screening wood decayed by white rot fungi for preferential lignin degradation. Appl Environ Microbiol 48:647–653
Bond L, Donaldson L, Hill S, Hitchcock K (2008) Safranin fluorescent staining of wood cell walls. Biotech Histochem 83:161–171
Chandra R, Ewanick S, Hsieh C, Saddler JN (2008) The characterization of pretreated lignocellulosic substrates prior to enzymatic hydrolysis, part 1: a modified Simons’ staining technique. Biotechnol Prog 24:1178–1185
Cianchetta S, Di Maggio B, Burzi PL, Galletti S (2014) Evaluation of selected white-rot fungal isolates for improving the sugar yield from wheat straw. Appl Biochem Biotechnol 173:609–623
Couto SR, Longo MA, Cameselle C, Sanromán A (1998) Influence of some inducers on activity of ligninolytic enzymes from corncob cultures of Phanerochaete chrysosporium in semi-solid-state conditions. Progr Biotechnol 5:703–708
Dias AA, Freitas GS, Marques GSM, Sampaio A, Fraga IS, Rodrigues MAM, Evtuguin DV, Bezerra RMF (2010) Enzymatic saccharification of biologically pre-treated wheat straw with white-rot fungi. Bioresour Technol 101:6045–6050
Fackler K, Schmutzer M, Manoch L, Schwanninger M, Hinterstoisser B, Ters T, Messner K, Gradinger C (2007) Evaluation of the selectivity of white rot isolates using near infrared spectroscopic techniques. Enzym Microb Technol 41:881–887
Gahda AY, Mahmoud MB (2009) Improved production of endoglucanase enzyme by Aspergillus terreus; application of plackett burman design for optimization of process parameters. Biotechnol 8:212–219
Gianfreda L, Rao M (2004) Potential of extra cellular enzymes in remediation of polluted soils: a review. Enzyme Microb Tech 35:339–354
Gupta R, Mehta G, Pal Y, Kuhad R (2011) Fungal delignification of lignocellulosic biomass improves the saccharification of cellulosics. Biodegradation 22:797–804
Jonathan SG, Adeoyo OR (2011) Effect of environmental and nutritional factors on mycelial biomass yield of ten wild Nigerian mushrooms during cellulase and amylase production. Elect J Environ Agric Food Chem 10:2891–2899
Kannaiyan R, Mahinpey N, Kostenko V, Martinuzzi RJ (2015) Nutrient media optimization for simultaneous enhancement of the laccase and peroxidases production by coculture of Dichomitus squalens and Ceriporiopsis subvermispora. Biotechnol Appl Bioc 62:173–185
Kersten P, Cullen D (2007) Extracellular oxidative systems of the lignin-degrading Basidiomycete Phanerochaete chrysosporium. Fungal Genet Biol 44:77–87
Kim HM, Lee KH, Kim KH, Lee DS, Nguyen QA, Bae HJ (2014) Efficient function and characterization of GH10 xylanase (Xyl10g) from Gloeophyllum trabeum in lignocellulose degradation. J Biotechnol 172:38–45
Knežević A, Stajic M, Vukojevic J, Milovanovic I (2014) The effect of trace elements on wheat straw degradation by Trametes gibbosa. Int Biodeterior Biodegradation 96:152–156
Kuhad RC, Singh A (2007) Lignocellulose biotechnology: future prospects. IK International Publications, New Delhi
Lestan D, Lestan M, Lamar RT (1998) Growth and viability of mycelial fragments of white-rot fungi on some hydrogels. J Ind Microbiol Biotechnol 20:244–250
Lin S, Dence CW (1992) The determination of lignin. In: Lin S, Dence C (eds) Methods in lignin chemistry. Springer Series in Wood Science, Springer Berlin Heidelberg, pp 33–61
Mane V, Patil S, Syed A, Baig M (2007) Bioconversion of low quality lignocellulosic agricultural waste into edible protein by Pleurotussajor-caju (Fr.) singer. J Zhejiang Univ Sci B 8:745–751
Martínez AT, Rencoret J, Nieto L, Jiménez-Barbero J, Gutiérrez A, del Rio JC (2011) Selective lignin and polysaccharide removal in natural fungal decay of wood as evidenced by in situ structural analyses. Environ Microbial 13:96–107
Mester T, Field JA (1998) Characterization of a novel manganese peroxidase-lignin peroxidase hybrid isozyme produced by Bjerkandera species strain BOS55 in the absence of manganese. J Biol Chem 273:15412–15417
Miller GL (1959) Use of dinitrosalicylic acid. Reagent for determination of reducing sugar. Anal Chem 31:426–428
Monheit JE, Cowan DF, Moore DG (1984) Rapid detection of fungi in tissues using calcofluor white and fluorescence microscopy. Arch Pathol Lab Med 108:616–618
Oliva-Taravilla A, Moreno AD, Demuez M, Ibarra D, Tomás-Pejó E, González-Fernández C, Ballesteros M (2015) Unraveling the effects of laccase treatment on enzymatic hydrolysis of steam-exploded wheat straw. Bioresour Technol 175:209–215
Parenti A, Muguerza E, Redin IA, Omarini A, Conde E, Alfaro M, Castanera R, Santoyo F, Ramírez L, Pisabarro AG (2013) Induction of laccase activity in the white-rot fungus Pleurotus ostreatus using water polluted with wheat straw extracts. Bioresour Technol 133:142–149
Rouches E, Herpoël-Gimbert I, Steyer JP, Carrere H (2016) Improvement of anaerobic degradation by white-rot fungi pretreatment of lignocellulosic biomass: a review. Renew Sust Energ Rev 59:179–198
Rubilar O, Feijoo G, Diez MC, Lu-Chau T, Moreira MT, Lema JM (2007) Biodegradation of penthachlorophenol (PCP) in soil slurry cultures by Bjerkandera adusta and Anthracopyllum discolor. Ind Eng Chem Res 46:6744–6751
Saha BC, Qureshi N, Kennedy GJ, Cotta MA (2016) Biological pretreatment of corn stover with white-rot fungus for improved enzymatic hydrolysis. Int Biodeterior Biodegradation 109:29–35
Salvachúa D, Prieto A, Lopez-Abelairas M, Lu-Chau T, Martinez AT, Martinez MJ (2011) Fungal pretreatment: an alternative in second-generation ethanol from wheat straw. Bioresour Technol 102:7500–7506
Salvachúa D, Prieto A, Vaquero ME, Martínez ÁT, Martínez MJ (2013) Sugar recoveries from wheat straw following treatments with the fungus Irpex lacteus. Bioresour Technol 131:218–225
Sawada T, Nakamura Y, Kobayashi F, Kuwahara M, Watanabe T (1995) Effects of fungal pretreatment and steam explosion pretreatment on enzymatic saccharification of plant biomass. Biotechnol Bioeng 48:719–724
Shrivastava B, Nandal P, Sharma A, Jain KK, Khasa YP, Das TK, Mani V, Kewalramani NJ, Kundu SS, Kuhad RC (2012) Solid state bioconversion of wheat straw into digestible and nutritive ruminant feed by Ganoderma sp. rckk02. Bioresour Technol 107:347–351
Shrivastava B, Thakur S, Pal Y, Gupte A, Kumar A, Kuhad R (2011) White-rot fungal conversion of wheat straw to energy rich cattle feed. Biodegradation 22:823–831
Singleton VL, Rossi JA (1965) Colorimetry of total phenolics with phosphomolybdic-phosphotungstic acid reagents. Am J Enol Vitic 16:144–158
Sun XF, Xu F, Sun RC, Fowler P, Baird MS (2005) Characteristics of degraded cellulose obtained from steam-exploded wheat straw. Carbohydr Res 340:97–106
Thakur S, Shrivastava B, Ingale S, Kuhad R, Gupte A (2012) Degradation and selective ligninolysis of wheat straw and banana stem for an efficient bioethanol production using fungal and chemical pretreatment. 3. Biotech 3:365–372
Tien M, Kirk TK (1983) Lignin-degrading enzyme from the hymenomycete Phanerochaete chrysosprium Burd. Sci 221:661–663
Tijani IDR, Jamal P, Alam Z, Mirgham M (2011) Valorization of casava peels by white-rot fungus Panus tigrinus M609RQY. Aust J Basic Applied Sci 5:808–816
van Kuijk SJA, Sonnenberg ASM, Baars JJP, Hendriks WH, Cone JW (2016) The effect of adding urea, manganese and linoleic acid to wheat straw and wood chips on lignin degradation by fungi and subsequent in vitro rumen degradation. Anim Feed Sci Technol 213:22–28
Verbelen JP, Kerstens S (2000) Polarization confocal microscopy and Congo red fluorescence: a simple and rapid method to determine the mean cellulose fibril orientation in plants. J Microsc 198:101–107
Wan C, Li Y (2010) Microbial delignification of corn stover by Ceriporiopsis subvermispora for improving cellulose digestibility. Enzym Microb Technol 47:31–36
Wan C, Li Y (2012) Fungal pretreatment of lignocellulosic biomass. Biotechnol Adv 30:1447–1457
Wiman M, Dienes D, Hansen M, van der Meulen T, Zacchi G, Lidén G (2012) Cellulose accessibility determines the rate of enzymatic hydrolysis of steam-pretreated spruce. Bioresour Technol 126:208–215
Wood TM, Bhat KM (1988) Methods for measuring cellulase activities. Meth Enzymol 160:87–112
Wu JM, Zhang YZ (2010) Gene expression in secondary metabolism and metabolic switching phase of Phanerochaete chrysosporium. Appl Biochem Biotech 162:1961–1977
Xu F, Yu J, Tesso T, Dowell F, Wang D (2013) Qualitative and quantitative analysis of lignocellulosic biomass using infrared techniques: a mini-review. Appl Energ 104:801–809
Acknowledgements
This research was supported by CONICYT Doctoral scholarship 21120634 and FAPERJ-UFRO FPJ15-0005 projects and, partially, by the CONICYT/FONDAP/15130015 and FONDECYT No. 3130650 projects. Edward Hermosilla is grateful to BQ. Karina Godoy of Scientific and Technological Bioresource Nucleus (BIOREN), Universidad de La Frontera, Temuco, Chile, by the support provided in CLSM analysis of wheat straw.
Author information
Authors and Affiliations
Corresponding author
Additional information
Responsible editor: Yi-ping Chen
Electronic supplementary material
Supplementary A1
(DOCX 383 kb)
Rights and permissions
About this article
Cite this article
Hermosilla, E., Schalchli, H., Mutis, A. et al. Combined effect of enzyme inducers and nitrate on selective lignin degradation in wheat straw by Ganoderma lobatum . Environ Sci Pollut Res 24, 21984–21996 (2017). https://doi.org/10.1007/s11356-017-9841-4
Received:
Accepted:
Published:
Issue Date:
DOI: https://doi.org/10.1007/s11356-017-9841-4
