Abstract
Bioaccumulation of As, Cd, Cu, Pb and Zn by Macrobrachium prawns was observed to occur in the Strickland River downstream of a gold mine at Porgera, Papua New Guinea. This was despite the total metal concentrations of waters and sediments indicating no difference from reference sites within tributaries. To provide information on potential sources and bioavailability of metals to prawns, an extensive range of analyses were made on waters, suspended solids, deposited sediments and plant materials within the river system. Dissolved metal concentrations were mostly sub-micrograms per liter and no major differences existed in concentrations or speciation between sites within the Strickland River or its tributaries. Similarly, no differences were detected between sites for total or dilute acid-extractable metal concentrations in bed sediments and plant materials, which may be ingested by the prawns. However, the rivers in this region are highly turbid and the dilute acid-extractable cadmium and zinc concentrations in suspended solids were greater at sites in the Strickland River than at sites in tributaries. The results indicated that mine-derived inputs increased the proportion of these forms of metals or metalloids in the Strickland River. These less strongly bound metals and metalloids would be more bioavailable to the prawns via the dietary pathway. The results highlighted many of the difficulties in using routine monitoring data without information on metal speciation to describe metal uptake and predict potential effects when concentrations are low and similar to background. The study indicated that the monitoring of contaminant concentrations in organisms that integrate the exposure from multiple exposure routes and durations may often be more effective for detecting impacts than intermittent monitoring of contaminants in waters and sediments.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
References
Albertoni EF, Palma-Silva C, Esteves FD (2003) Natural diet of three species of shrimp in a tropical coastal lagoon. Braz Arch Biol Technol 46(3):395–403
Allen HE (2000) Importance of clean techniques and speciation in assessing water quality for metals. Hum Ecol Risk Assess 6(6):989–1002
Baken S, Degryse F, Verheyen L, Merckx R, Smolders E (2011) Metal complexation properties of freshwater dissolved organic matter are explained by its aromaticity and by anthropogenic ligands. Environ Sci Technol 45(7):2584–2590
Baumann Z, Fisher NS (2011) Modeling metal bioaccumulation in a deposit-feeding polychaete from labile sediment fractions and from pore water. Sci Total Environ 409:2607–2615
Bondgaard M, Bjerregaard P (2005) Association between cadmium and calcium uptake and distribution during the moult cycle of female shore crabs, Carcinus maenas: an in vivo study. Aquat Toxicol 72(1–2):17–28
Bunn SE, Tenakanai C, Storey A (1999) Energy sources supporting Fly River fish communities; Report to Ok Tedi Mining Ltd Environment Department. http://www.oktedi.com/attachments/218_MWMP_EnergySources.pdf. Accessed 23 May 2013
Campbell PGC (1995) Interaction between trace metals and aquatic organisms: a critique of the free-ion activity model. In: Tessier A, Turner DR (eds) Metal speciation and aquatic systems. Wiley, New York, pp 45–102
Cresswell T, Smith REW, Nugegoda D, Simpson SL (2013) Challenges with tracing the fate and speciation of mine-derived metals in trurbid river systems: implications for bioavailability. Env Sci Pol Res. DOI: 10.1007/s11356-013-2066-2
Filella M (2010) Quantifying ‘humics’ in freshwaters: purpose and methods. Chem Ecol 26:177–186
Fleming AW, Handley GA, Williams KL, Hills AL, Corbett GJ (1986) The Porgera gold deposit, Papua New Guinea. Econ Geol 81(3):660–680
Ling SW (1967) The general biology and development of Macrobrachium rosenbergii (De Man). FAO Fish Rep 57(3):589–606
Linge KL (2008) Methods for investigating trace element binding in sediments. Crit Rev Environ Sci Technol 38(3):165–196
Lofts S, Tipping E (2011) Assessing WHAM/model VII against field measurements of free metal ion concentrations: model performance and the role of uncertainty in parameters and inputs. Environ Chem 8(5):501–516
Luoma SN, Rainbow PS (2008) Metal contamination in aquatic environments: science and lateral management. Cambridge University Press, Cambridge
New MB (2002) Farming freshwater prawns. A manual for the culture of the giant river prawn (Macrobrachium rosenbergii). Food and Agriculture Organisation of the United Nations, Rome.
Peerzada N, Nojok M, Lee C (1992) Distribution of heavy-metals in prawns from Northern-Territory, Australia. Mar Pollut Bull 24(8):416–418
PJV (2012) Porgera Joint Venture Environmental Monitoring: January–December 2011. 2011 Annual Report. Porgera Joint Venture. http://www.barrick.com/files/porgera/2011-Porgera-Annual-Environmental-Report.pdf. Accessed 02 August, 2013
Rao LM, Vani S, Ramaneswari K (1998) Metal accumulation in tissues of Macrobrachium rude from Mehadrigedda Stream, Visakhapatnam. Pollut Res 17(2):137–140
Santore RC, Di Toro DM, Paquin PR, Allen HE, Meyer JS (2001) Biotic ligand model of the acute toxicity of metals. 2. Application to acute copper toxicity in freshwater fish and Daphnia. Environ Toxicol Chem 20(10):2397–2402
Simpson SL, Apte SC, Davies CM (2005) Bacterially assisted oxidation of copper sulfide minerals in tropical river waters. Environ Chem 2(1):49–55
Snape I, Scouller RC, Stark SC, Stark J, Riddle MJ, Gore DB (2004) Characterisation of the dilute HCl extraction method for the identification of metal contamination in Antarctic marine sediments. Chemosphere 57(6):491–504
Tan Q-G, Wang W-X (2011) Acute toxicity of cadmium in Daphnia magna under different calcium and ph conditions: importance of influx rate. Environ Sci Technol 45(5):1970–1976
Tessier A, Fortin D, Belzile N, DeVitre RR, Leppard GG (1996) Metal sorption to diagenetic iron and manganese oxyhydroxides and associated organic matter: narrowing the gap between field and laboratory measurements. Geochim Cosmochim Acta 60(3):387–404
Tipping E (1994) WHAM—a chemical-equilibrium model and computer code for waters, sediments, and soils incorporating a discrete site electrostatic model of ion-binding by humic substances. Comput Geosci 20(6):973–1023
Tu NPC, Ha NN, Ikemoto T, Tuyen BC, Tanabe S, Takeuchi I (2008) Bioaccumulation and distribution of trace elements in tissues of giant river prawn Macrobrachium rosenbergii (Decapoda: Palaemonidae) from South Vietnam. Fish Sci 74(1):109–119
Turner A, Olsen YS (2000) Chemical versus enzymatic digestion of contaminated estuarine sediment: relative importance of iron and manganese oxides in controlling trace metal bioavailability. Estuarine Coastal Shelf Sci 51(6):717–728
Acknowledgments
This work was primarily funded by Porgera Joint Venture, who also provided logistical support for the fieldwork. The study was also funded by an Endeavour International Postgraduate Research Scholarship (overseen by Prof. Dayanthi Nugegoda) and a CSIRO Top-Up scholarship (overseen by Dr. Stuart Simpson) awarded to Tom Cresswell. The authors would like to thank Dr. Graeme Batley and Dr. Lisa Golding for editorial assistance with this manuscript and Dr. Debashish Mazumder for assistance with the stable isotope data interpretation. We would also like to thank three unnamed reviewers for their constructive comments on this manuscript.
Author information
Authors and Affiliations
Corresponding author
Additional information
Responsible editor: Vera Slaveykova
Electronic supplementary material
Below is the link to the electronic supplementary material.
ESM 1
(DOCX 27 kb)
Rights and permissions
About this article
Cite this article
Cresswell, T., Smith, R.E.W. & Simpson, S.L. Challenges in understanding the sources of bioaccumulated metals in biota inhabiting turbid river systems. Environ Sci Pollut Res 21, 1960–1970 (2014). https://doi.org/10.1007/s11356-013-2086-y
