Abstract
Icariin, the primary active component of Epimedium extracts, has recently been shown to induce cardiomyocyte differentiation of murine embryonic stem (mES) cells in vitro. However, as these cardiomyocytes were not functionally characterized, the potential application of icariin-induced cardiomyocytes in clinical practice remains unclear. Therefore, in this study, we characterized the structure and function of icariin-induced cardiomyocytes to evaluate their potential application in transplantation for cardiac failure treatment. mES cells were cultured as embryoid bodies (EBs) via the direct suspension method in the presence of icariin. The protein expression profiles and ultrastructural characteristics of mES cell-derived cardiomyocytes were then characterized by immunofluorescence and transmission electron microscopy, respectively. In addition, the expression of cardiac-specific and calcium handling genes was detected by semi-quantitative reverse transcription-polymerase chain reaction (RT-PCR). Cardiomyocytes induced by icariin treatment expressed the cardiac-specific proteins myosin light chain-1v (MLC1v), atrial natriuretic polypeptide (ANP), and cardiac troponin I (cTnI). Furthermore, these cells appeared to possess myofibrils organized into mature sarcomeres that had formed A and I bands. In addition, icariin treatment upregulated the mRNA levels of MLC1v, ANP, cTnI, calsequestrin (CSQ), and sodium–calcium exchanger (NCX) in these cells. Icariin induces the differentiation of mES cells into beating cardiomyocytes with normal structure and function. Therefore, these cells may have promising applications in cardiac cell therapy or tissue engineering.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
Explore related subjects
Discover the latest articles and news from researchers in related subjects, suggested using machine learning.References
MacLellan WR, Schneider MD (2000) Genetic dissection of cardiac growth control pathways. Annu Rev Physiol 62:289–319
Terrovitis JV, Smith RR, Marbán E (2010) Assessment and optimization of cell engraftment after transplantation into the heart. Circ Res 106:479–494
Singla DK (2009) Embryonic stem cells in cardiac repair and regeneration. Antioxid Redox Signal 11:1857–1863
Mummery C, Ward D, van den Brink CE et al (2002) Cardiomyocyte differentiation of mouse and human embryonic stem cells. J Anat 200:233–242
Takahashi T, Lord B, Schulze PC et al (2003) Ascorbic acid enhances differentiation of embryonic stem cells into cardiac myocytes. Circulation 107:1912–1916
Wu S, Ding Q, Ding NS et al (2004) Small molecules that induce cardiomyogenesis in embryonic stem cells. J Am Chem Soc 126:1590–1591
Zhang YW, Morita I, Shao G et al (2000) Screening of anti-hypoxia/reoxygenation agents by an in vitro model. Part 1: natural inhibitors for protein tyrosine kinase activated by hypoxia/reoxygenation in cultured human umbilical vein endothelial cells. Planta Med 66:114–118
Zhu DY, Lou YJ (2005) Inducible effects of icariin, icaritin and desmethylicaritin on directional differentiation of embryonic stem cells into cardiomyocytes in vitro. Acta Pharmacol Sin 26:477–485
Scholz G, Pohl I, Genschow E et al (1999) Embryotoxicity screening using embryonic cells in vitro: correlation to in vivo teratogenicity. Cells Tissues Organs 165:203–211
Laver DR, Dulhunty AF (2004) Calsequestrin and the calcium release channel of skeletal and cardiac muscle. Prog Biophys Mol Biol 85:33–69
Pucéat M (2008) Protocols for cardiac differentiation of embryonic stem cells. Methods 45:168–171
Shimoji K, Yuasa S, Onizuka T et al (2010) G-CSF promotes the proliferation of developing cardiomyocytes in vivo and in derivation from ESCs and iPSCs. Cell Stem Cell 6:227–237
Berkessel A, Seelig B, Schwengberg S et al (2010) Chemically induced cardiomyogenesis of mouse embryonic stem cells. Chembiochem 11:208–217
Ding L, Liang XG, Hu Y et al (2008) Involvement of p38MAPK and reactive oxygen species in icariin-induced cardiomyocyte differentiation of murine embryonic stem cells in vitro. Stem Cells Dev 17:751–760
Wo Y, Zhu D, Yu Y et al (2008) Involvement of NF-kappaB and AP-1 activation in icariin promoted cardiac differentiation of mouse embryonic stem cells. Eur J Pharmacol 586:59–66
Guan K, Furst DO, Wobus AM (1999) Modulation of sarcomere organization during embryonic stem cell-derived cardiomyocyte differentiation. Eur J Cell Biol 78:813–823
Liu J, Lieu DK, Siu CW et al (2009) Facilitated maturation of Ca2+ handling properties of human embryonic stem cell-derived cardiomyocytes by calsequestrin expression. Am J Physiol Cell Physiol 297:C152–C159
Jin MS, Shi S, Zhang Y, Yan Y, Sun XD, Liu W, Liu HW (2010) Icariin-mediated differentiation of mouse adipose-derived stem cells into cardiomyocytes. Mol Cell Biochem 344:1–9
Acknowledgments
We thank Miss Qiuxia Yang (Australia) for financial support, CYAGEN (Guangzhou) Biotech Ltd. for technical support, and Medical Research Center at Mudanjiang Medical College for experimental help. This study was supported by research grants from the National Natural Science Foundation of China (30971537), the Natural Science Foundation of Heilongjiang Province (ZA2006-09), Heilongjiang Province Educational Committee for backbone teacher (1055G058), and technological project of Mudanjiang Technology Bureau (G2009s2021).
Author information
Authors and Affiliations
Corresponding author
Electronic supplementary material
Below is the link to the electronic supplementary material.
Rights and permissions
About this article
Cite this article
Sun, X., Sun, X., Jin, X. et al. Icariin induces mouse embryonic stem cell differentiation into beating functional cardiomyocytes. Mol Cell Biochem 349, 117–123 (2011). https://doi.org/10.1007/s11010-010-0666-4
Received:
Accepted:
Published:
Issue Date:
DOI: https://doi.org/10.1007/s11010-010-0666-4
