Abstract
Cytokines and soluble cytokine receptors serve as important protein biomarkers for chronic and infectious disease diagnosis. The development of biosensors capable of detecting cytokines or their soluble receptors in patient bodily fluids is a growing area of research. In an ongoing series of studies to understand the thermal analytical behavior of cytokines and their soluble receptors, dielectric thermal analysis (DETA) and thermogravimetry (TG) were used in investigations to determine if differentiations based on dielectric properties (e.g., conductivity) of the proteins could be identified. Permittivity (ε′) and dielectric loss factor (ε″) measurements were performed over a frequency range of 0.1–300,000 Hz. Up to 20 min, water associated with the samples was conductive, interacting with the proteins and affecting the temperature-dependent relaxation spectra of proteins. A trend analysis revealed differences between surface charge at 0.1 Hz and bulk charge at 300,000 Hz. In addition, the greatest change detected among proteins was due to the conductivity (dielectric loss factor). Beyond a 20 min drying time, the observed conductivity was due to intrinsic properties of the proteins with limited dependence on frequency. A 100% water loss was obtained for samples within 20–30 min by TG. Sample drying by TG could serve as a preparatory step in drying protein samples for further DETA and DSC analysis.
![](http://media.springernature.com/m312/springer-static/image/art%3A10.1007%2Fs10973-011-1643-1/MediaObjects/10973_2011_1643_Fig1_HTML.gif)
![](http://media.springernature.com/m312/springer-static/image/art%3A10.1007%2Fs10973-011-1643-1/MediaObjects/10973_2011_1643_Fig2_HTML.gif)
![](http://media.springernature.com/m312/springer-static/image/art%3A10.1007%2Fs10973-011-1643-1/MediaObjects/10973_2011_1643_Fig3_HTML.gif)
Similar content being viewed by others
References
Clark IA, Budd AC, Alleva LM, Cowden WB. Human malaria disease: a consequence of inflammatory cytokine release. Malaria J. 2006;5:85.
Prakash D, Fesel C, Jain R, Cazanave P, Mishra GC, Pied S. Clusters of cytokines determine malaria severity in Plasmodium falciparum-infected patients from endemic areas of Central India. J Infect Dis. 2006;194:198–207.
Armah HB, Wilson NO, Sarfo BY, Powell MD, Bond VC, Anderson W, Adjei AA, Gyasi RK, Tettey Y, Wiredu EK, Tongren JE, Udhayakumar V, Stiles JK. Cerebrospinal fluid and serum biomarkers of cerebral malaria mortality in Ghanaian children. Malaria J. 2007;6:147.
Akanmori BD, Kurtzhalas JAL, Goka BQ, Adabayeri V, Ofori MF, Nkrumah FK, Behr C, Hviid L. Distinct patterns of cytokine regulation in discrete clinical forms of Plasmodium falciparum malaria. Eur Cytokine Netw. 2000;11:113–8.
Kindt TJ, Goldsby RA, Osborne BA. Kuby immunology. 6th ed. New York: W.H. Freeman and Company; 2007.
Baker J, Ho M, Pelecanos A, et al. Global sequence variation in the histidine-rich proteins 2 and 3 of Plasmodium falciparum: implications for the performance of malaria rapid diagnostic tests. Malaria J. 2010;9:129.
Gamboa D, Ho MF, Bendeezu J, Torres K, Chiodini PL, Barnwell JW, Incardonas S, Perkins M, Bell D, McCarthy J, Cheng Q. A large proportion of P. falciparum isolates in the Amazon region of Peru lack pfhrp2 and pfhrp3: implications for malaria diagnostic tests. PLoS One. 2010;5:e8091.
Matthews ME, Atkinson I, Presswala L, Najjar O, Gerhardstein N, Wei R, Rye E, Riga AT. Dielectric classification of D- and L-amino acids by thermal and analytical methods. J Therm Anal Calorim. 2008;93:281–7.
Marzec E, Warchol W. Dielectric properties of a protein–water system in selected animal tissues. Bioelectrochemistry. 2005;65:89–94.
Presswala L, Matthews ME, Atkinson I, Najjar O, Gerhardstein N, Moran J, Wei R, Riga AT. Discovery of bound and unbound waters in crystalline amino acids revealed by thermal analysis. J Therm Anal Calorim. 2008;93:295–300.
Suherman PM, Taylor P, Smith G. Low frequency dielectric study on hydrated ovalbumin. J Non Cryst Solids. 2002;305:317–21.
Oliverberg M, Tan Y, Fershi AR. Negative activation enthalpies in the kinetics of protein folding. Proc Natl Acad Sci USA. 1995;92:8926–9.
Saleh S, Moreno-Molek S, Manthen DR, Maheswaram MPK, Sam-Yellowe T, Riga AT. Thermal behavior and signature patterns of human cytokine and soluble cytokine receptors investigated using dielectric thermal analysis and thermogravimetry. J Therm Anal Calorim. doi:10.1007/s10973-011-1530-9.
Michnik A, Michalik K, Kluczewska A, Drazga Z. Comparativr DSC study of human and bovine serum albumin. J Therm Anal Calorim. 2006;84:113–7.
Michnik A, Drazga Z. Thermal denaturation of mixture of human serum proteins DSC study. J Therm Anal Calorim. 2010;101:513–8.
Mantheni DR, Maheswaram MPK, Sobhi HF, Riga A, Matthews ME, Alexander KS. Solid state studies of drugs and chemicals by dielectric and calorimetric analysis. J Therm Anal Calorim. doi:10.1007/s10973-011-1423-y.
Ruderman G, De Xammar Oro JR. On the dielectric spectra of proteins in conducting media. J Biol Phys. 1992;18:167–74.
Cinelli A, Onori S, Stravato A. Dielectric behavior of lysozyme and ferricytochrome-c in water/ethylene-glycol solution. Biophys J. 2004;86:1118–23.
Acknowledgements
We extend our gratitude to Hareesha Reddy Venumuddala for helpful discussions. Funding for the study was provided by Cleveland State University’s Undergraduate Summer Research Program 2010.
