Electrical Characteristics of Superconducting Ti Transition Edge Sensors

Journal of Low Temperature Physics volume 184, pages11–16(2016)Cite this article

Abstract

We have designed and fabricated superconducting Ti transition edge sensors (TES) with different microbridge lengths varying from 1 to 6 \(\upmu \)m. The current–voltage characteristics of the fabricated Ti TESs are measured at different bath temperatures using a commercial SQUID amplifier. The thermal conductance (G) is found to be about 300 pW/K for a 2.6-\(\upmu \)m-long device. In addition, the effective response time measured with a current pulse signal is about 3 \(\upmu \)s, and decreases with increasing the bias voltage because of negative electro-thermal feedback. The obtained electrical noise equivalent power from the measured current noise is about \(4 \times 10^{-17}\) W/Hz\(^{0.5}\), which is sufficiently low for TeSIA instrument.
