Validation of QuEChERS analytical technique for organochlorines and synthetic pyrethroids in fruits and vegetables using GC-ECD

  • J. K. Dubey
  • S. K. Patyal
  • Ajay Sharma


In the present day scenario of increasing awareness and concern about the pesticides, it is very important to ensure the quality of data being generated in pesticide residue analysis. To impart confidence in the products, terms like quality assurance and quality control are used as an integral part of quality management. In order to ensure better quality of results in pesticide residue analysis, validation of analytical methods to be used is extremely important. Keeping in view the importance of validation of method, the validation of QuEChERS (quick, easy, cheap, effective, rugged, and safe) a multiresidue method for extraction of 13 organochlorines and seven synthetic pyrethroids in fruits and vegetables followed by GC ECD for quantification was done so as to use this method for analysis of samples received in the laboratory. The method has been validated as per the Guidelines issued by SANCO (French words Sante for Health and Consommateurs for Consumers) in accordance with their document SANCO/XXXX/2013. Various parameters analyzed, viz., linearity, specificity, repeatability, reproducibility, and ruggedness were found to have acceptable values with a per cent RSD of less than 10%. Limit of quantification (LOQ) for the organochlorines was established to be 0.01 and 0.05 mg kg−1 for the synthetic pyrethroids. The uncertainty of the measurement (MU) for all these compounds ranged between 1 and 10%. The matrix-match calibration was used to compensate the matrix effect on the quantification of the compounds. The overall recovery of the method ranged between 80 and 120%. These results demonstrate the applicability and acceptability of this method in routine estimation of pesticide residues of these 20 pesticides in the fruits and vegetables by the laboratory.


Organochlorines Synthetic pyrethroids QuEChERS GC-ECD Fruits Vegetables


  1. Anastassiades, M., Lehotay, S. J., & Stajnbaher, F. J. (2003). Fast and easy multiresidue method employing acetonitrile extraction/partitioning and dispersive solid-phase extraction for the determination of pesticide residues in produce. Journal of AOAC International, 86(2), 412–443.Google Scholar
  2. EURACHEM. (2000). Quantifying uncertainty in analytical measurement (2nd ed.).Google Scholar
  3. EURACHEM GUIDE. (1998). The fitness for purpose of analytical methods. A laboratory guide to method validation and related topics. Available at EN.Pdf. Accessed June 2016).
  4. Huber, W. (2004). On the use of the correlation coefficient r for testing the linearity of calibration functions. Accretion of Quality Assurance, 9, 726.CrossRefGoogle Scholar
  5. Lehotay, S. J. (2007). Determination of pesticide residues in foods by acetonitrile extraction and partitioning with magnesium sulfate: Collaborative study. Journal of AOAC International, 90(2), 485–520.Google Scholar
  6. Lehotay, S. J., Kok, A. D., Hiemstra, M., & Bodegraven, P. V. (2005a). Validation of a fast and easy method for the determination of residues from 229 pesticides in fruits and vegetables using gas and liquid chromatography and mass spectrometric detection. Journal of AOAC International, 88(2), 595–614.Google Scholar
  7. Lehotay, S. J., Mastovská, K., & Lightfield, A. R. (2005b). Use of buffering and other means to improve results of problematic pesticides in a fast and easy method for residue analysis of fruits and vegetables. Journal of AOAC International, 88(2), 615–629.Google Scholar
  8. Lehotay, S. J., Son, K. A., Kwon, H., Koesukwiwat, U., Fu, W., & Mastovska, K. (2010). Comparison of QuEChERS sample preparation methods for the analysis of pesticide residues in fruits and vegetables. Journal of Chromatography A, 1217(16), 2548–2560.CrossRefGoogle Scholar
  9. Lopes, R. P., Freitas, E. E., Filho, J. F. A., Vargas, E. A., Augusti, D. V., & Augusti, R. (2012). Development and validation of a method for the determination of sulfonamides in animal feed by modified QuEChERS and LCeMS/MS analysis. Food Control, 28, 192–198.CrossRefGoogle Scholar
  10. Pay, P., Anastassiades, M., Mack, D., Sigalova, I., Tasdelen, B., Oliva, J., & Barba, A. (2007). Analysis of pesticide residues using the quick easy cheap effective rugged and safe (QuEChERS) pesticide multiresiduemethod in combination with gas and liquid chromatography and tandem mass spectrometric detection. Analytical and Bioanalytical Chemistry, 389, 1697–1714.CrossRefGoogle Scholar
  11. Raphaella, P. C., Fabiano, A. S., Fernando, D. M., Gilsara, S., Wesley, R., & Renata, P. L. (2013). Development and method validation for determination of 128 pesticides in bananas by modified QuEChERS and UHPLCeMS/MS analysis. Food Control, 33, 413–423.CrossRefGoogle Scholar
  12. Rashid, A., Nawaz, S., Barker, H., Ahmad, I., & Ashraf, M. (2010). Development of a simple extraction and clean-up procedure for determination of organochlorine pesticides in soil using gas chromatography-tandem mass spectrometry. Journal of Chromatogrphy. A., 1217, 2933–2939.CrossRefGoogle Scholar
  13. SANCO. (2014). Guidance Document on Analytical Quality Control and Validation Procedures for Pesticide Residues Analysis in Food and Feed. Document No. SANCO/XXXX/2013, EC, Health & Consumer Protection Directorate-General, Almeria Spain, 1–42.Thompson, M., Wood, R.(1995) Harmonized guidelines for international quality control in analytical chemistry laboratories. Pure and Applied Chemistry, 67(4), 649–666.Google Scholar
  14. Tiryaki, O. (2016). Validation of QuEChERS method for the determination of some pesticide residues in two apple varieties. Journal of Environmental Science and Health, Part B, 51(10), 722–729.CrossRefGoogle Scholar
  15. United States Pharmacopeia, (2007)Validation of compendial methods, 30, National Formulary 25, Rockville, Md., USA, The United States Pharmacopeial Convention, Inc., General Chapter 1225, 729.Google Scholar

Copyright information

© Springer International Publishing AG, part of Springer Nature 2018

Authors and Affiliations

  1. 1.Department of EntomologyDr. Y.S. Parmar University of Horticulture and ForestrySolanIndia
  2. 2.College of Horticulture and ForestryPO KhaggalIndia
