Development of a fully implantable wireless pressure monitoring system

Tan, Robert; McClure, Timothy; Lin, C. K.; Jea, David; Dabiri, Foad; Massey, Tammara; Sarrafzadeh, Majid; Srivastava, Mani; Montemagno, C. D.; Schulam, Peter; Schmidt, Jacob

doi:10.1007/s10544-008-9232-1

Published: 03 October 2008

Development of a fully implantable wireless pressure monitoring system

Robert Tan¹,
Timothy McClure²,
C. K. Lin¹,
David Jea³,
Foad Dabiri⁴,
Tammara Massey⁴,
Majid Sarrafzadeh⁴,
Mani Srivastava³,
C. D. Montemagno⁵,
Peter Schulam² &
Jacob Schmidt¹

Biomedical Microdevices volume 11, pages 259–264 (2009)Cite this article

957 Accesses
47 Citations
3 Altmetric
Metrics details

Abstract

A fully implantable wireless pressure sensor system was developed to monitor bladder pressures in vivo. The system comprises a small commercial pressure die connected via catheter to amplifying electronics, a microcontroller, wireless transmitter, battery, and a personal digital assistant (PDA) or computer to receive the wireless data. The sensor is fully implantable and transmits pressure data once every second with a pressure detection range of 1.5 psi gauge and a resolution of 0.02 psi. In vitro calibration measurements of the device showed a high degree of linearity and excellent temporal response. The implanted device performed continuously in vivo in several porcine studies lasting over 3 days. This system can be adapted for other pressure readings, as well as other vital sign measurements; it represents the first step in developing a ubiquitous sensing platform for telemedicine and remote patient monitoring.
