, Volume 135, Issue 3, pp 239–249 | Cite as

The concurrent use of novel soil surface microclimate measurements to evaluate CO2 pulses in biocrusted interspaces in a cool desert ecosystem

  • Colin L. TuckerEmail author
  • Theresa A. McHugh
  • Armin Howell
  • Richard Gill
  • Bettina Weber
  • Jayne Belnap
  • Edmund Grote
  • Sasha C. Reed


Carbon cycling associated with biological soil crusts, which occupy interspaces between vascular plants in drylands globally, may be an important part of the coupled climate-carbon cycle of the Earth system. A major challenge to understanding CO2 fluxes in these systems is that much of the biotic and biogeochemical activity occurs in the upper few mm of the soil surface layer (i.e., the ‘mantle of fertility’), which exhibits highly dynamic and difficult to measure temperature and moisture fluctuations. Here, we report a multi-sensor approach to simultaneously measuring temperature and moisture of this biocrust surface layer (0–2 mm), and the deeper soil profile, concurrent with automated measurement of surface soil CO2 effluxes. Our results illuminate robust relationships between biocrust water content and field CO2 pulses that have previously been difficult to detect and explain. All observed CO2 pulses over the measurement period corresponded to surface wetting events, including when the wetting events did not penetrate into the soil below the biocrust layer (0–2 mm). The variability of temperature and moisture of the biocrust surface layer was much greater than even in the 0–5 cm layer of the soil beneath the biocrust, or deeper in the soil profile. We therefore suggest that coupling surface measurements of biocrust moisture and temperature to automated CO2 flux measurements may greatly improve our understanding of the climatic sensitivity of carbon cycling in biocrusted interspaces in our study region, and that this method may be globally relevant and applicable.


Biological soil crusts Carbon cycle Drylands Pulse-dynamic wetting Soil respiration Surface soil moisture



This material is based upon work supported by the U.S. Department of Energy Office of Science, Office of Biological and Environmental Research Terrestrial Ecosystem Sciences Program, under Award Number DE-SC-0008168 and by the U.S. Geological Survey Ecosystem Mission Area. TAM was supported by a National Science Foundation Postdoctoral Research Fellowship in Biology under Grant No. 1402451 and BW by a Paul Crutzen Nobel Laureate Fellowship. Any use of trade, firm, or product names is for descriptive purposes only and does not imply endorsement by the U.S. Government.


  1. Ahlström A, Raupach MR, Schurgers G, Smith B, Arneth A, Jung M, Reichstein M, Canadell JG, Friedlingstein P, Jain AK, Kato E, Poulter B, Sitch S, Stocker BD, Viovy N, Wang YP, Wiltshire A, Zaehle S, Zeng N (2015) The dominant role of semi-arid ecosystems in the trend and variability of the land CO2 sink. Science 348(6237):895–899CrossRefGoogle Scholar
  2. Austin AT, Vivanco L (2006) Plant litter decomposition in a semi-arid ecosystem controlled by photodegradation. Nature 442(7102):555–558CrossRefGoogle Scholar
  3. Austin A, Yahdjian L, Stark J, Belnap J, Porporato A, Norton U, Ravetta D, Schaeffer S (2004) Water pulses and biogeochemical cycles in arid and semiarid ecosystems. Oecologia 141(2):221–235CrossRefGoogle Scholar
  4. Barger NN, Weber B, Garcia-Pichel F, Zaady E, Belnap J (2016) Patterns and controls on nitrogen cycling of biological soil crusts. Biological soil crusts: an organizing principle in drylands. Springer, New York, pp 257–285CrossRefGoogle Scholar
  5. Belnap J, Weber B, Büdel B (2016) Biological Soil Crusts as an Organizing Principle in Drylands. In: Biological Soil Crusts: An Organizing Principle in Drylands. Springer International Publishing. p 3-13Google Scholar
  6. Cable JM, Huxman TE (2004) Precipitation pulse size effects on Sonoran Desert soil microbial crusts. Oecologia 141(2):317–324CrossRefGoogle Scholar
  7. Castillo-Monroy AP, Maestre FT, Rey A, Soliveres S, Garcia-Palacios P (2011) Biological soil crust microsites are the main contributor to soil respiration in a semiarid ecosystem. Ecosystems 14(5):835–847CrossRefGoogle Scholar
  8. Coe KK, Belnap J, Sparks JP (2012) Precipitation-driven carbon balance controls survivorship of desert biocrust mosses. Ecology 93(7):1626–1636CrossRefGoogle Scholar
  9. Darrouzet-Nardi A, Reed SC, Grote EE, Belnap J (2015) Observations of net soil exchange of CO2 in a dryland show experimental warming increases carbon losses in biocrust soils. Biogeochemistry 126(3):363–378CrossRefGoogle Scholar
  10. Davidson EA, Janssens IA (2006) Temperature sensitivity of soil carbon decomposition and feedbacks to climate change. Nature 440(7081):165–173CrossRefGoogle Scholar
  11. Ferrenberg S, Reed SC, Belnap J (2015) Climate change and physical disturbance cause similar community shifts in biological soil crusts. Proc Natl Acad Sci 112(39):12116–12121CrossRefGoogle Scholar
  12. Garcia-Pichel F, Johnson SL, Youngkin D, Belnap J (2003) Small-scale vertical distribution of bacterial biomass and diversity in biological soil crusts from arid lands in the Colorado Plateau. Microb Ecol 46(3):312–321CrossRefGoogle Scholar
  13. Grote EE, Belnap J, Housman DC, Sparks JP (2010) Carbon exchange in biological soil crust communities under differential temperatures and soil water contents: implications for global change. Glob Change Biol 16(10):2763–2774CrossRefGoogle Scholar
  14. Huxman T, Snyder K, Tissue D, Leffler AJ, Ogle K, Pockman W, Sandquist D, Potts D, Schwinning S (2004) Precipitation pulses and carbon fluxes in semiarid and arid ecosystems. Oecologia 141(2):254–268CrossRefGoogle Scholar
  15. Lange OL, Meyer A, Budel B (1994) Net photosynthesis activation of a desiccated cyanobacterium without liquid water in high air humidity alone—experiments with microcoleus-sociatus isolated from a desert soil crust. Funct Ecol 8(1):52–57CrossRefGoogle Scholar
  16. McHugh TA, Morrissey EM, Reed SC, Hungate BA, Schwartz E (2015) Water from air: an overlooked source of moisture in arid and semiarid regions. Sci Rep 5:13767CrossRefGoogle Scholar
  17. Phillips CL, Nickerson N, Risk D, Bond BJ (2011) Interpreting diel hysteresis between soil respiration and temperature. Glob Change Biol 17(1):515–527CrossRefGoogle Scholar
  18. Pointing SB, Belnap J (2012) Microbial colonization and controls in dryland systems. Nat Rev Microbiol 10(8):551CrossRefGoogle Scholar
  19. Poulter B, Frank D, Ciais P, Myneni RB, Andela N, Bi J, Broquet G, Canadell JG, Chevallier F, Liu YY, Running SW, Sitch S, van der Werf GR (2014) Contribution of semi-arid ecosystems to interannual variability of the global carbon cycle. Nature 509(7502):600–603CrossRefGoogle Scholar
  20. Reed SC, Coe KK, Sparks JP, Housman DC, Zelikova TJ, Belnap J (2012) Changes to dryland rainfall result in rapid moss mortality and altered soil fertility. Nat Clim Change 2(10):752–755CrossRefGoogle Scholar
  21. Rey A (2015) Mind the gap: non-biological processes contributing to soil CO2 efflux. Glob Change Biol. doi: 10.1111/gcb.12821 Google Scholar
  22. Rutherford WA, Painter TH, Ferrenberg S, Belnap J, Okin GS, Flagg C, Reed SC (2017) Albedo feedbacks to future climate via climate change impacts on dryland biocrusts. Sci Rep 7:44188CrossRefGoogle Scholar
  23. Schlesinger W, Pilmanis A (1998) Plant-soil interactions in deserts. Biogeochemistry 42(1–2):169–187CrossRefGoogle Scholar
  24. Tucker CL, Reed SC (2016) Low soil moisture during hot periods drives apparent negative temperature sensitivity of soil respiration in a dryland ecosystem: a multi-model comparison. Biogeochemistry 128(1–2):155–169CrossRefGoogle Scholar
  25. Weber B, Wu D, Tamm A, Ruckteschler N, Rodríguez-Caballero E, Steinkamp J, Meusel H, Elbert W, Behrendt T, Sörgel M, Cheng Y, Crutzen PJ, Su H, Pöschl U (2015) Biological soil crusts accelerate the nitrogen cycle through large NO and HONO emissions in drylands. Proc Natl Acad Sci 112(50):15384–15389CrossRefGoogle Scholar
  26. Weber B, Berkemeier T, Ruckteschler N, Caesar J, Heintz H, Ritter H, Braß H (2016) Development and calibration of a novel sensor to quantify the water content of surface soils and biological soil crusts. Methods Ecol Evol 7(1):14–22CrossRefGoogle Scholar
  27. Wertin T, Reed S, Belnap J (2015) C3 and C4 plant responses to increased temperatures and altered monsoonal precipitation in a cool desert on the Colorado Plateau, USA. Oecologia 177(4):997–1013CrossRefGoogle Scholar
  28. Wilske B, Burgheimer J, Karnieli A, Zaady E, Andreae M, Yakir D, Kesselmeier J (2008) The CO2 exchange of biological soil crusts in a semiarid grass-shrubland at the northern transition zone of the Negev desert, Israel. Biogeosci Discuss 5(3):1969–2001CrossRefGoogle Scholar

Copyright information

© Springer International Publishing AG (outside the USA) 2017

Authors and Affiliations

  1. 1.US Geological SurveySouthwest Biological Science CenterMoabUSA
  2. 2.Department of Biological SciencesColorado Mesa UniversityGrand JunctionUSA
  3. 3.Department of BiologyBrigham Young UniversityProvoUSA
  4. 4.Multiphase Chemistry DepartmentMax Planck Institute for ChemistryMainzGermany
