Hydrogeology Journal

, Volume 25, Issue 4, pp 1003–1016 | Cite as

Transient bacterial contamination of the dual-porosity aquifer at Walkerton, Ontario, Canada

  • Stephen R. H. WorthingtonEmail author
  • C. Christopher Smart
Paper

Abstract

Contamination of the Paleozoic carbonate aquifer at Walkerton (Ontario, Canada) by pathogenic bacteria following heavy rain in May 2000 resulted in 2,300 illnesses and seven deaths. Subsequent tracer testing showed that there was rapid groundwater flow in the aquifer, and also rapid exchange between the aquifer and the ground surface. Electrical conductivity (EC) profiling during a 3-day pumping test showed that most flow was through bedding-plane fractures spaced about 10 m apart, that there were substantial contrasts in EC in the major fracture flows, and that there were rapid changes over time. Total coliform sampling revealed transient groundwater contamination, particularly after heavy rain and lasting up to a few days. These characteristics can be understood in terms of the dual-porosity nature of the aquifer. Most of the storage is in the matrix, but this can be considered to be static in the short term. Almost all transport is through the fracture network, which has rapid groundwater flow (∼100 m/day) and rapid transmission of pressure pulses due to the high hydraulic diffusivity. Rapid recharge can occur through thin and/or fractured overburden and at spring sites where flow is reversed by pumping during episodes of surface flooding. These characteristics facilitated the ingress of surface-derived bacteria into the aquifer, and their rapid transport within the aquifer to pumping wells. Bacterial presence is common in carbonate aquifers, and this can be explained by the well-connected, large-aperture fracture networks in these dual-porosity aquifers, even though many, such as at Walkerton, lack karst landforms.

Keywords

Dual porosity Canada Microbial processes Karst Health

Contamination bactérienne transitoire d’un aquifère à double-porosité à Walkerton, Ontario, Canada

Résumé

La contamination de l’aquifère carbonaté paléozoïque à Walkerton (Ontario, Canada) par des bactéries pathogènes suite à un épisode pluvieux intense en mai 2000 a entrainé 2300 malades et sept décès. Des essais de traçage ultérieurs ont montré qu’il y avait un écoulement rapide des eaux souterraines au sein de l’aquifère, et également un transfert rapide entre l’aquifère et la surface du sol. Des profils de conductivité électrique lors d’un pompage d’essai de 3 jours ont montré que l’essentiel de l’écoulement se faisait à travers des fractures planes d’inter-bancs espacées d’environ 10 m les unes des autres, qu’il existait des contrastes substantiels de conductivité électrique au droit des principales fractures où se produisent les écoulements, et que des changements rapides apparaissaient au cours du temps. L’analyse des coliformes totaux a révélé une contamination transitoire des eaux souterraines, en particulier après des pluies intenses et durant les quelques jours qui suivent. Ces caractéristiques peuvent être appréhendées du fait de la double-porosité de l’aquifère. La majeure partie du stockage prend place dans la matrice, mais elle peut être considérée comme étant non mobile à court terme. La quasi-totalité du transport se fait à travers le réseau de fractures, qui présente un écoulement rapide des eaux souterraines (∼ 100 m/j) et une transmission des impulsions de pression du fait de la diffusivité hydraulique élevée. La recharge rapide peut se produire à travers une couverture peu épaisse et/ou fracturée et au niveau des sites des sources où l’écoulement est inversé à cause des pompages lors des épisodes d’inondation. Ces caractéristiques ont facilité la pénétration des bactéries issues de la surface dans l’aquifère, et leur transfert rapide au sein de l’aquifère vers les puits de pompage. La présence de bactéries est fréquente dans les aquifères carbonatés, et cela peut s’expliquer par les réseaux de fractures à grande ouverture et bien connectés dans ces aquifères à double porosité, même si nombre d’entre eux, comme à Walkerton, ne présentent pas de figures karstiques en surface.

Contaminación bacteriana transitoria de un acuífero de doble porosidad en Walkerton, Ontario, Canadá

Resumen

La contaminación del acuífero carbonático del Paleozoico en Walkerton (Ontario, Canadá) por bacterias patógenas después de fuertes lluvias en mayo de 2000 resultó en 2300 enfermedades y siete muertes. Las pruebas de trazabilidad posteriores mostraron que había un flujo rápido de agua subterránea en el acuífero y también un intercambio rápido entre el acuífero y la superficie del suelo. La evaluación del perfil de conductividad eléctrica (EC) durante un ensayo de bombeo de tres días mostró que la mayor parte del flujo se realizó a través de las fracturas de los planos de estratificación espaciadas a una distancia de aproximadamente 10 m entre sí, que tuvieron contrastes sustanciales en la EC en los flujos de las fracturas mayores, y cambios rápidos en el tiempo. El muestreo de coliformes totales reveló la contaminación transitoria del agua subterránea, especialmente después de lluvias intensas y con una duración de hasta unos pocos días. Estas características se pueden entender en términos de la naturaleza de la doble porosidad del acuífero. La mayor parte del almacenamiento está en la matriz, pero esto puede considerarse estático en el corto plazo. Casi todo el transporte se realiza a través de la red de fracturas, que tiene un flujo rápido de agua subterránea (∼ 100 m/día) y una transmisión rápida de los impulsos de presión debido a la alta difusividad hidráulica. La recarga rápida puede ocurrir a través de la cubierta delgada y/o fracturada y en sitios de manantiales donde se invierte el flujo por el bombeo durante los episodios de inundación superficial. Estas características facilitaron el ingreso de bacterias derivadas de la superficie en el acuífero, y su transporte rápido dentro del acuífero a los pozos de bombeo. La presencia de bacterias es común en los acuíferos carbonatados, lo que puede explicarse por las redes de fractura de gran abertura bien conectadas en estos acuíferos de doble porosidad, aunque muchos, como en Walkerton, carecen de formas de relieve kárstico.

加拿大安大略省沃克顿地区双重介质含水层瞬态细菌污染

摘要

2000年5月一场暴雨之后致病菌造成的(加拿大安大略省)沃克顿地区古生代碳酸盐岩含水层的污染致使2300人患病,7 人死亡。后来的示踪实验显示,含水层地下水流非常快,含水层的水和地表水交换也非常迅速。三天的抽水实验期间电导率显示,大部分水流通过间隔为10米的层理面断裂,主要断裂水流中的电导率有和大差别,并随着时间的过去变化迅速。总大肠杆菌采样揭示,存在着瞬态地下水污染,特别是在暴雨之后,并可持续几天。依据含水层的双重介质性质,可以了解这些特征。大部分储存的水在基质里,但被认为是短时间内是静止的。几乎所有的传输通过断裂网络,由于水力扩散系数很高,断裂网络中地下水流速度很快(∼ 100 m/day),压力脉冲传播也很快。通过薄的和/或者断裂的表层以及在地表洪水期间抽水导致水流反转的泉点可出现快速补给。这些特征促进了源自地表的细菌进入含水层,及含水层内快速运移到抽水井。碳酸盐岩含水层中存在细菌很常见,这可以通过这些双重介质含水层中联通良好、大孔断裂网络得到解释,尽管许多含水层,诸如沃克顿地区的含水层,缺乏岩溶地貌。

Contaminação bacteriana transiente do aquífero com porosidade dual em Wakerton, Ontário, Canadá

Resumo

A contaminação do aquífero carbonatico Paleozóico em Walkerton (Ontário, Canadá) por bactérias patogênicas após chuvas pesadas em Maio de 2000 resultou em 2300 doenças/enfermidades e sete mortes. Testes de traçadores subsequentes mostraram que houve um rápido fluxo das águas subterrâneas no aquífero e também uma rápida troca entre a superfície do solo e o aquífero. O perfilamento de condutividade elétrica (CE) durante um teste de bombeamento de três dias mostrou que a maior parte do fluxo ocorreu através de plano de fraturas espaçadas a cerca de 10 m, que houveram substanciais contrastes na CE nos principais fluxos de fraturas, e que houveram rápidas mudanças ao longo do tempo. Amostras de coliformes totais revelaram uma contaminação transiente das águas subterrâneas, particularmente depois de chuvas pesadas e permaneceu por alguns dias. Estas características podem ser entendidas em termos da natureza de porosidade dual do aquífero. A maior parte do armazenamento está na matriz, porém isto pode ser considerado estático a curto prazo. Grande parte do transporte é através da rede de fraturas, que tem acelerado fluxo das águas subterrâneas (∼ 100 m/dia) e rápida transmissão de pulsos de pressão devido à alta difusão hidráulica. A rápida recarga pode ocorrer através da sobrecarga fina e /ou fraturada e nos locais de fonte/nascente onde o fluxo é revertido devido ao bombeamento durante episódios de inundações superficiais. Estas características facilitaram o ingresso de bactérias derivadas da superfície no aquífero, e seu rápido transporte dentro dos poços de bombeamento. A presença de bactérias é comum em aquíferos carbonaticos, e este fato pode ser explicado pela forte conexão e grande abertura nas redes de fraturas nestes aquíferos de porosidade dual, mesmo que muitos, como em Walkerton, carecem de formações cársticas.

Notes

Acknowledgments

Thanks go to Brad Simpson for help with fieldwork. This work was partially funded by Concerned Walkerton Citizens, by the Walkerton Inquiry, and by Western University.

References

  1. Atherholt TB, Bousenberry RT, Carter GP, Korn LR, Louis JB, Serfes ME, Waller DA (2013) Coliform bacteria in New Jersey domestic wells: influence of geology, laboratory, and method. Groundwater 51:562–574Google Scholar
  2. Barenblatt GI, Zheltov IP, Kochina IN (1960) Basic concepts in the theory of seepage of homogeneous liquids in fissured rocks [strata]. J Appl Math Mech 24:1286–1303CrossRefGoogle Scholar
  3. Borchardt MA, Bradbury KR, Alexander EC Jr, Kolberg RJ, Alexander SC, Archer JR, Braatz LA, Forest BM, Green JA, Spencer SK (2011) Norovirus outbreak caused by a new septic system in a dolomite aquifer. Ground Water 49:85–97CrossRefGoogle Scholar
  4. Boulton NS (1963) Analysis of data from non-equilibrium pumping tests allowing for delayed yield from storage. Proc Inst Civ Eng 26:469–482Google Scholar
  5. Clark CG, Price L, Ahmed R, Woodward DL, Melito PL, Rodgers FG, Jamieson F, Ciebin B, Li A, Ellis A (2003) Characterization of waterborne outbreak-associated Campylobacter jejuni, Walkerton, Ontario. Emerg Infect Dis 9:1232–1241CrossRefGoogle Scholar
  6. Cook SJ, Fitzpatrick CM, Burgess WG, Lytton L, Bishop P, Sage R (2012) Modelling the influence of solution-enhanced conduits on catchment-scale contaminant transport in the Hertfordshire Chalk aquifer. In: Shepley MG,Whiteman MI, Hulme PJ, Grout MW (eds) Groundwater resources modelling: a case study from the UK. Geol Soc London Spec Publ 364, pp 205–225Google Scholar
  7. Currell M, Gleeson T, Dahlhaus P (2016) A new assessment framework for transience in hydrogeological systems. Groundwater 54:4–14CrossRefGoogle Scholar
  8. Cuthbert MO (2014) Straight thinking about groundwater recession. Water Resour Res 50:2407–2424CrossRefGoogle Scholar
  9. Deming D (2002) Introduction to hydrogeology. McGraw Hill, Boston, MA, 468 ppGoogle Scholar
  10. Domenico PA, Schwartz FW (1998) Physical and chemical hydrogeology. Wiley, New York, 506 ppGoogle Scholar
  11. Embrey SS, Runkle DL (2006) Microbial quality of the nation’s ground-water resources, 1993–2004. US Geol Surv Sci Invest Rep 2006-5290, 34 ppGoogle Scholar
  12. Feighery J, Mailloux BJ, Ferguson AS, Ahmed KM, Geen A, Culligan PJ (2013) Transport of E. coli in aquifer sediments of Bangladesh: implications for widespread microbial contamination of groundwater. Water Resour Res 49:3897–3911CrossRefGoogle Scholar
  13. Fitts CR (2013) Groundwater science. Elsevier, Amsterdam, 672 ppGoogle Scholar
  14. Foster SS (1975) The Chalk groundwater tritium anomaly: a possible explanation. J Hydrol 25:159–165CrossRefGoogle Scholar
  15. Francy DS, Helsel DR, Nally RA (2000) Occurrence and distribution of microbiological indicators in groundwater and stream water. Water Environ Res 72:152–161CrossRefGoogle Scholar
  16. Freeze RA, Cherry JA (1979) Groundwater. Prentice-Hall, Englewood Cliffs, NJ, 604 ppGoogle Scholar
  17. Gleeson T, Smith L, Moosdorf N, Hartmann J, Dürr HH, Manning AH, van Beek LPH, Jellinek AM (2011) Mapping permeability over the surface of the Earth. Geophys Res Lett 46:L02401. doi: 10.1029/2010GL045565 Google Scholar
  18. Golder Associates (2000a) Interim report on hydrogeological assessment, well integrity testing, geophysical surveys and land use inventory, bacteriological impacts, Walkerton town wells, Municipality of Brockton, County of Bruce, Ontario. Walkerton Inquiry Exhibit 258, Golder, Calgary, AB, 351 ppGoogle Scholar
  19. Golder Associates (2000b) Report on hydrogeological assessment, bacteriological impacts, Walkerton town wells, Municipality of Brockton, County of Bruce, Ontario. Walkerton Inquiry Exhibit 258, Golder, Calgary, AB, 534 ppGoogle Scholar
  20. Golder Associates (2001a) Hydrogeological assessment, Walkerton Well 9, Municipality of Brockton, County of Bruce, Ontario. Golder, Calgary, AB, 114 ppGoogle Scholar
  21. Golder Associates (2001b) Preliminary tracer tests, Walkerton Municipal wells 7 and 9, Municipality of Brockton, county of Bruce, Ontario. Golder, Calgary, AB, 30 ppGoogle Scholar
  22. Golder Associates (2002) Tracer test on Walkerton Municipal well 7, Municipality of Brockton, county of Bruce, Ontario. Golder, Calgary, AB, 35 ppGoogle Scholar
  23. Goss MJ (2001) Addendum to the oral testimony. Walkerton Inquiry, Exhibit 375. Golder, Calgary, AB, 5 pp plus attachmentsGoogle Scholar
  24. Haitjema HM, Anderson MP (2016) Darcy velocity is not a velocity. Groundwater 54:1CrossRefGoogle Scholar
  25. Hrudey SE, Payment P, Huck PM, Gillham RW, Hrudey EJ (2003) A fatal waterborne disease epidemic in Walkerton, Ontario: comparison with other waterborne outbreaks in the developed world. Water Sci Technol 47:7–14Google Scholar
  26. Hynds PD, Misstear BD, Gill LW (2012) Development of a microbial contamination susceptibility model for private domestic groundwater sources. Water Resour Res 48:W12504CrossRefGoogle Scholar
  27. Hynds PD, Thomas MK, Pintar KDM (2014) Contamination of groundwater systems in the US and Canada by enteric pathogens, 1990–2013: a review and pooled-analysis. PLoS One 9:e93301CrossRefGoogle Scholar
  28. Ingebritsen S, Sanford W, Neuzil C (2006) Groundwater in geologic processes. Cambridge University Press, Cambridge, UK, 536 ppGoogle Scholar
  29. John DE, Rose JB (2005) Review of factors affecting microbial survival in groundwater. Environ Sci Technol 39:7345–7356CrossRefGoogle Scholar
  30. Johnson AI (1963) Specific yield: compilation of specific yields for various materials. US Geol Surv Open-File Rep 63-59Google Scholar
  31. Kelly RI, Carter TR (1993) Drift thickness, Walkerton area, southern Ontario. Preliminary Map P3202, scale 1:50,000, Ontario Geological Survey, Sudbury, ONGoogle Scholar
  32. Kvitsand HM, Ilyas A, Østerhus SW (2015) Rapid bacteriophage MS2 transport in an oxic sandy aquifer in cold climate: field experiments and modeling. Water Resour Res 51:9725–9745CrossRefGoogle Scholar
  33. Marshall JK, Thabane M, Garg AX, Clark WF, Moayyedi P, Collins SM (2010) Eight year prognosis of postinfectious irritable bowel syndrome following waterborne bacterial dysentery. Gut 59:605–611CrossRefGoogle Scholar
  34. Maurice L, Barker JA, Atkinson TC, Williams AT, Smart PL (2011) A tracer methodology for identifying ambient flows in boreholes. Ground Water 49:227–238CrossRefGoogle Scholar
  35. O’Connor DR (2002a) Report of the Walkerton Inquiry, part 1: the events of May 2000 and related issues. Ontario Ministry of the Attorney General, Toronto, 691 ppGoogle Scholar
  36. O’Connor DR (2002b) Report of the Walkerton Inquiry, part 2: a strategy for safe drinking water. Ontario Ministry of the Attorney General, Toronto, 588 ppGoogle Scholar
  37. OCWA (Ontario Clean Water Agency) (2001a) All bacteriological sample results, May 24 2000 to August 31 2000. Submission to Walkerton Inquiry, 2 volumes, Exhibits 231a and 231b, OCWA, TorontoGoogle Scholar
  38. OCWA (Ontario Clean Water Agency) (2001b) Adverse bacteriological sample results, August 28 2000 to September 29 2000. Submission to Walkerton Inquiry, Exhibit 232a, OCWA, TorontoGoogle Scholar
  39. Oliver JD (2016) The viable but nonculturable state for bacteria: status update. Microbe 11:159–164Google Scholar
  40. Price M, Downing RA, Edmunds WM (1993) The Chalk as an aquifer. In: Downing RA, Price M, Jones GP (eds) The hydrogeology of the chalk of North-West Europe. Clarendon, Oxford, pp 35–58Google Scholar
  41. Pronk M, Goldscheider N, Zopfi J (2006) Dynamics and interaction of organic carbon, turbidity and bacteria in a karst aquifer system. Hydrogeol J 14:473–484CrossRefGoogle Scholar
  42. Richardson HY, Nichols G, Lane C, Lake IR, Hunter P (2009) Microbiological surveillance of private water supplies in England: the impact of environmental and climate factors on water quality. Water Res 43:2159–2168CrossRefGoogle Scholar
  43. Rousseau‐Gueutin P, Love AJ, Vasseur G, Robinson NI, Simmons CT, Marsily G (2013) Time to reach near‐steady state in large aquifers. Water Resour Res 49:6893–6908CrossRefGoogle Scholar
  44. Ruland WW, Cherry JA, Feenstra S (1991) The depth of fractures and active ground‐water flow in a clayey till plain in southwestern Ontario. Ground Water 29:405–417CrossRefGoogle Scholar
  45. Scholl MA, Mills AL, Herman JS, Hornberger GM (1990) The influence of mineralogy and solution chemistry on the attachment of bacteria to representative aquifer materials. J Contam Hydrol 6:321–336CrossRefGoogle Scholar
  46. Smart CC, Worthington SRH (2003) Electrical conductivity profiling of boreholes as a means of identifying karst aquifers. Geotech Spec Publ no. 122, Amer. Soc. Civil Engineers, Reston, VA, pp 265–276Google Scholar
  47. Smith DB, Wearn PL, Richards HJ, Rowe PC (1970) Water movement in the unsaturated zone of high and low permeability strata by measuring natural tritium. Isotope Hydrology 1970, International Atomic Energy Agency, Vienna, pp 73–86Google Scholar
  48. Sorensen JPR, Lapworth DJ, Read DS, Nkhuwa DCW, Bell RA, Chibesa M, Chirwa M, Kabika J, Liemisa M, Pedley S (2015) Tracing enteric pathogen contamination in sub-Saharan African groundwater. Sci Total Environ 538:888–895CrossRefGoogle Scholar
  49. Stedmon CA, Seredyńska-Sobecka B, Boe-Hansen R, Le Tallec N, Waul CK, Arvin E (2011) A potential approach for monitoring drinking water quality from groundwater systems using organic matter fluorescence as an early warning for contamination events. Water Res 45:6030–6038CrossRefGoogle Scholar
  50. Taylor RG, Cronin AA, Lerner DN, Tellam JH, Bottrell SH, Rueedi J, Barrett MH (2006) Hydrochemical evidence of the depth of penetration of anthropogenic recharge in sandstone aquifers underlying two mature cities in the UK. Appl Geochem 21:1570–1592CrossRefGoogle Scholar
  51. Taylor AB, Martin NA, Everard E, Kelly TJ (2012) Modelling the Vale of St. Albans: parameter estimation and dual storage. In: Shepley MG, Whiteman MI, Hulme PJ, Grout MW (eds) (2012) Groundwater Resources Modelling: a case study from the UK. Geol Soc London Spec Publ 364:193–204Google Scholar
  52. Tsang CF, Rosberg JE, Sharma P, Berthet T, Juhlin C, Niemi A (2016) Hydrologic testing during drilling: application of the flowing fluid electrical conductivity (FEEC) method to drilling of a deep borehole. Hydrogeol J 24:1333–1341CrossRefGoogle Scholar
  53. Worthington SRH (2015) Diagnostic tests for conceptualizing transport in bedrock aquifers. J Hydrol 529:365–372CrossRefGoogle Scholar
  54. Worthington SRH, Smart CC (2016) Determination of tracer mass for effective groundwater tracer tests. Carbonates Evaporites. doi: 10.1007/s13146-013-0171-4 Google Scholar
  55. Worthington SRH, Smart CC, Ruland WW (2001a) Karst hydrogeological investigations at Walkerton. Walkerton Inquiry, Exhibit 416, CELA, Toronto, 101 ppGoogle Scholar
  56. Worthington SRH, Smart CC, Ruland WW (2001b) Karst hydrogeological investigations at Walkerton. Addendum report, submitted to the Walkerton Inquiry, CELA, Toronto, 27 ppGoogle Scholar
  57. Worthington SRH, Smart CC, Ruland WW (2012) Effective porosity of a carbonate aquifer with bacterial contamination: Walkerton, Ontario, Canada. J Hydrol 464–465:517–527CrossRefGoogle Scholar
  58. Worthington SRH, Davies GJ, Alexander EC Jr (2016) Enhancement of bedrock permeability by weathering. Earth Sci Rev 160:188–202CrossRefGoogle Scholar
  59. Zuber A, Różański K, Kania J, Purtschert R (2011) On some methodological problems in the use of environmental tracers to estimate hydrogeologic parameters and to calibrate flow and transport models. Hydrogeol J 19:53–69CrossRefGoogle Scholar
