Archives of Virology

, Volume 164, Issue 4, pp 1049–1058 | Cite as

Prokaryotic expression, purification and evaluation of goatpox virus ORF117 protein as a diagnostic antigen in indirect ELISA to detect goatpox

  • M. Dashprakash
  • G. VenkatesanEmail author
  • Amit Kumar
  • M. Sankar
  • Sargam Arya
  • M. A. Ramakrishnan
  • A. B. Pandey
  • B. Mondal
Original Article


Goatpox is an economically significant transboundary viral disease of goats that is caused by goatpox virus (GTPV). This study describes the prokaryotic expression of the GTPV ORF117 protein, a homologue of vaccinia virus A27L, and evaluation of its diagnostic potential in ELISA. The GTPV ORF117 gene was cloned into the pET32a vector to express recombinant ORF117 protein (rA27L) in E. coli BL21-CodonPlus (DE3)-RIPL. The bacterial expression of the protein was confirmed by western blot analysis using anti-GTPV polyclonal antibodies that detected rA27L, which is ~ 35 kDa in size. rA27L was affinity purified under native conditions and used to assess the antibody response in an optimized indirect ELISA. The purified antigen specifically reacted with anti-GTPV and anti-SPPV serum in ELISA. A preliminary screening of random and purposive serum samples (n = 520) from sheep and goats using this optimized ELISA gave a positivity rate of 19.4 % with a diagnostic specificity of 88.7% and diagnostic sensitivity of 98.5% when compared to the gold standard serum neutralization test. Our results suggest that the indirect ELISA based on the rA27L protein has potential for serosurveillance and seromonitoring of GTPV in goats.



The authors thank the Director, ICAR-Indian Veterinary Research Institute, for providing necessary facilities to carry out this work, and the staff of Pox Virus Laboratory, IVRI, Mukteswar, for their valuable and timely help in carrying out this work. The financial support provided by the ICAR-Indian Veterinary Research Institute, Izatnagar, under institute project (IXX09899) is also acknowledged.

Compliance with ethical standards

Conflict of interest

There are no conflicts of interest among the authors.

Ethical approval

This article does not contain any studies involving human participants or animals performed by any of the authors.


  1. 1.
    OIE (2008) Office Internationale des epizooties (World Health Organization for animals), 12, Rue de prony, 75017. OIE, ParisGoogle Scholar
  2. 2.
    Madhavan A, Venkatesan G, Kumar A (2016) Capripoxviruses of small ruminants: current updates and future perspectives. Asian J Anim Vet Adv 11:757–770CrossRefGoogle Scholar
  3. 3.
    Tuppurainen ESM, Venter EH, Shisler JL, Gari G, Mekonnen GA, Juleff N, Lyons NA, De Clercq K, Upton C, Bowden TR, Babiuk S, Babiuk LA (2015) Review: capripoxvirus diseases: current status and opportunities for control. Transbound Emerg Dis 64(3):729–745CrossRefGoogle Scholar
  4. 4.
    Garner MG, Sawarkar SD, Brett EK, Edwards JR, Kulkarni VB, Boyle DB, Singh SN (2000) The extent and economic impact of sheep pox and goat pox in the state of Maharashtra, India. Trop Anim Health Prod 32:205–223CrossRefGoogle Scholar
  5. 5.
    Bhanuprakash V, Hosamani M, Singh RK (2011) Prospects of control and eradication of capripox from the Indian subcontinent: a perspective. Antiviral Res 91:225–232CrossRefGoogle Scholar
  6. 6.
    Rao TVS, Bandyopadhyay SK (2000) A comprehensive review of goat pox and sheep pox and their diagnosis. Anim Health Res Rev 1(2):127–136CrossRefGoogle Scholar
  7. 7.
    Venkatesan G, Balamurugan V, Singh RK, Bhanuprakash V (2010) Goat pox virus isolated from an outbreak at Akola, Maharashtra (India) phylogenetically related to Chinese strain. Trop Anim Health Prod 42(6):1053–1056CrossRefGoogle Scholar
  8. 8.
    Bowden TR, Coupara BE, Babiuk SL, White JR, Boyd V, Ducha CJ, Shiell BJ, Ueda N, Park GR, Copps JS, Boyle DB (2009) Detection of antibodies specific for sheeppox and goatpox viruses using recombinant capripoxvirus antigens in an indirect enzyme-linked immunosorbent assay. J Virol Methods 161:19–29CrossRefGoogle Scholar
  9. 9.
    Bhanot V, Balamurugan V, Bhanuprakash V, Venkatesan G, Sen A, Yadav V, Yogisharadhya R, Singh RK (2009) Expression of P32 protein of goatpox virus in Pichia pastoris and its potential use as a diagnostic antigen in ELISA. J Virol Methods 162(1–2):251–257CrossRefGoogle Scholar
  10. 10.
    Balamurugan V, Venkatesan G, Sen A, Annamalai L, Bhanuprakash V, Singh RK (2010) Recombinant protein-based viral disease diagnostics in veterinary medicine. Exp Rev Mol Diag 10(6):731–753CrossRefGoogle Scholar
  11. 11.
    Venkatesan G, Kumar TM, Sankar M, Kumar A, Dashprakash M, Arya S, Madhavan A, Ramakrisnan MA, Pandey AB (2018) Expression and evaluation of recombinant P32 protein based ELISA for sero-diagnostic potential of capripox in sheep and goats. Mol Cell Probes 37:48–54CrossRefGoogle Scholar
  12. 12.
    Tulman ER, Afonso CL, Lu Z, Zsak L, Sur JH, Sandybaev NT, Kerembekova UZ, Zaitsev VL, Kutish GF, Rock DL (2002) The genomes of sheeppox and goatpox viruses. J Virol 76(12):6054–6061CrossRefGoogle Scholar
  13. 13.
    Hsiao JC, Chung CS, Chang W (1998) Cell surface proteoglycans are necessary for A27L protein-mediated cell fusion: identification of the N-terminal region of A27L protein as the glycosaminoglycan-binding domain. J Virol 72:8374–8379Google Scholar
  14. 14.
    Kumar A, Yogisharadhya R, Bhanuprakash V, Venkatesan G, Shivachandra SB (2015) Structural analysis and immunogenicity of recombinant major envelope protein (rA27L) of buffalpox virus, a zoonotic Indian vaccinia-like virus. Vaccine 33(41):5396–5405CrossRefGoogle Scholar
  15. 15.
    Dashprakash M, Venkatesan G, Ramakrishnan MA, Muthuchelvan D, Sankar M, Pandey AB, Mondal B (2015) Genetic diversity of fusion gene (ORF 117), an analogue of vaccinia virus A27L gene of capripox virus isolates. Virus Genes 50(2):325–328CrossRefGoogle Scholar
  16. 16.
    Sole MP, Massimiliano B, Carlo Z, Carlo DGM, Elena I, Antonio R (2013) L1R, A27L, A33R and B5R vaccinia virus genes expressed by fowlpox recombinants as putative novel orthopox vaccines. J Transl Med 11:95CrossRefGoogle Scholar
  17. 17.
    Kumar A, Yogisharadhya R, Venkatesan G, Bhanuprakash V, Shivachandra SB (2016) Immunogenicity and protective efficacy of recombinant major envelope protein (rH3L) of buffalopox virus in animal models. Antiviral Res 126:108–116CrossRefGoogle Scholar
  18. 18.
    Lupas A, Van Dyke M, Stock J (1991) Predicting coiled—coils from protein sequences. Science 252:1162–1164CrossRefGoogle Scholar
  19. 19.
    Chang T, Chang S, Hsieh F, Ko T, Lin C, Ho MR, Wang I, Hsu ST, Guo RT, Chang W, Wang AH (2013) Crystal structure of vaccinia viral A27 protein reveals a novel structure critical for its function and complex formation with A26 protein. PLoS Pathog 9:e1003563CrossRefGoogle Scholar
  20. 20.
    Sambrook J, Fritsch EF, Maniatis T (1989) Molecular cloning: a laboratory manual, 1989, 2nd edn. Cold Spring Harbor Laboratory, Cold Spring HarborGoogle Scholar
  21. 21.
    Kitching RP, Carn VM (2008) Sheep pox and goat pox. Office International des Epizooties Manual of Diagnostic Tests and Vaccines for Terrestrial Animals (mammals, birds and bees). OIE, Paris, pp 1058–1068Google Scholar
  22. 22.
    Sharma B, Negi BS, Yadav MP, Shankar H, Pandey AB (1988) Application of ELISA in the detection of goat pox antigen and antibody. Acta Virol 32:65–69Google Scholar
  23. 23.
    Yeruham I, Yadin H, Van Ham M, Bumbarov V, Soham A, Perl S (2007) Economic and epidemiological aspects of an outbreak of sheeppox in a dairy sheep flock. Vet Rec 160(7):236–237CrossRefGoogle Scholar
  24. 24.
    Lai C, Gong S, Esteban M (1990) Structural and functional properties of the 14-kDa envelope protein of vaccinia virus synthesized in Escherichia coli. J Biol Chem 265:22174–22180Google Scholar
  25. 25.
    Vázquez MI, Rivas G, Cregut D, Serrano L, Esteban M (1998) The vaccinia virus 14-kilodalton (A27L) fusion protein forms a triple coiled-coil structure and interacts with the 21-kilodalton (A17L) virus membrane protein through a C-terminal alpha-helix. J Virol 2:10126–10137Google Scholar
  26. 26.
    Vazquez M, Esteban M (1999) Identification of functional domains in the 14-kilodalton envelope protein (A27L) of vaccinia virus. J Virol 73:9098–9109Google Scholar
