Abstract
Background
The study of the distinct structure and function of the human central nervous system, both in healthy and diseased states, is becoming increasingly significant in the field of neuroscience. Typically, cortical and subcortical tissue is discarded during surgeries for tumors and epilepsy. Yet, there is a strong encouragement to utilize this tissue for clinical and basic research in humans. Here, we describe the technical aspects of the microdissection and immediate handling of viable human cortical access tissue for basic and clinical research, highlighting the measures needed to be taken in the operating room to ensure standardized procedures and optimal experimental results.
Methods
In multiple rounds of experiments (n = 36), we developed and refined surgical principles for the removal of cortical access tissue. The specimens were immediately immersed in cold carbogenated N-methyl-D-glucamine-based artificial cerebrospinal fluid for electrophysiology and electron microscopy experiments or specialized hibernation medium for organotypic slice cultures.
Results
The surgical principles of brain tissue microdissection were (1) rapid preparation (<1 min), (2) maintenance of the cortical axis, (3) minimization of mechanical trauma to sample, (4) use of pointed scalpel blade, (5) avoidance of cauterization and blunt preparation, (6) constant irrigation, and (7) retrieval of the sample without the use of forceps or suction. After a single round of introduction to these principles, multiple surgeons adopted the technique for samples with a minimal dimension of 5 mm spanning all cortical layers and subcortical white matter. Small samples (5–7 mm) were ideal for acute slice preparation and electrophysiology. No adverse events from sample resection were observed.
Conclusion
The microdissection technique of human cortical access tissue is safe and easily adoptable into the routine of neurosurgical procedures. The standardized and reliable surgical extraction of human brain tissue lays the foundation for human-to-human translational research on human brain tissue.
Avoid common mistakes on your manuscript.
Introduction
Access to human brain tissue is limited, and sampling for research faces technical and ethical challenges. There is limited information available on patient consent, as well as technical and logistic requirements for neurosurgeons, technical staff, and scientists to conduct research using human brain tissue. The neurosurgeon responsible for tissue removal primarily has to guarantee patient safety and the success of the procedure. However, in cases of deep-seated pathologies, cortical and subcortical access tissue, which is often removed and discarded, could be dissected and used to analyze human-relevant functional, structural, and molecular mechanisms in health and disease [2, 6, 16].
For experiments with vital brain tissue, it is necessary to prepare acute brain slices with a thickness of 300 to 400 μm using a vibrating microtome (vibratome) (Fig. 1a). Slicing allows the tissue that has been severed from circulation to receive glucose and oxygen through diffusion. Different methods for acute brain slice preparations and organotypic slice cultures of human tissue have been described [9, 23, 38]. Using these methods, cortical access tissue was successfully used for electrophysiological experiments ex vivo [10, 12, 19, 40] including the investigation of the effects of pharmaceuticals at a cellular and synaptic level [15].
Volumetric electron microscopy studies of the human cortex obtained from neurosurgical procedures have also been recently reported [16, 32]. Such studies highly depend on tissue quality and preservation. Various fixation protocols have been described such as block immersion fixation [32, 42], preparation of acute slices in fixative [16], or fixation of acute tissue slices after recovery [15, 41].
Organotypic human brain tissue cultures can be successfully cultured for several weeks [1, 14, 23, 31, 37]. This methodological advancement opens a range of possibilities also for long-term experiments including neurooncological studies involving tumor growth, the tumor micromilieu, immunological responses, and pharmaceutical treatment ex vivo [7]. This, in turn, may allow for more personalized approaches to neurooncological treatment.
Although optimal tissue preservation is the key to standardization of sample quality allowing reproducible experimental investigations, a description of the surgical technique of how to safely and optimally microdissect and remove cortical access tissue is still lacking. Here, we describe the surgical technique and technical aspects of microdissection and immediate treatment of human cortical access tissue for basic and clinical research, highlighting the measures needed to be taken in the operating room (OR) to ensure optimal experimental results, thereby placing the neurosurgical OR at the center of neurooncological and neurophysiological studies.
Methods
All human tissue samples were microdissected and processed with the approval of the local ethics committee (Biobank of the Department of Neurosurgery and Institute of Neuropathology, AZ 472/15_160880, AZ 593/19 and AZ 100020/09). Written informed consent was obtained from all patients. Tissue collection was performed from July 2019 to March 2021. The tissue samples were obtained as part of clinically indicated neurosurgical operations and were not resected for the purpose of research only.
As part of the preoperative planning, a safe putative cortical entry point was defined. Intraoperatively, after exposure of the pial surface, each surgeon evaluated and, if necessary, adjusted the cortical access according to criteria including macroscopic anatomy, position of superficial blood vessels, neuronavigation (Cranial Map Neuro Navigation Cart 2; Stryker), and where applicable intraoperative ultrasound (BK Medical). The location of the cortical access tissue was saved in the neuronavigation software for post-hoc analysis. Next, in contrast to standard neurosurgical training, the cortical access tissue was not cauterized, aspirated, or removed and discarded, but recovered for scientific investigations. In multiple rounds of experiments including feedback from scientists, the surgical technique of tissue dissection was iteratively developed and refined. Tissue was cut using a pointed scalpel (no. 11; Feather, Japan), disconnected from the white matter using a dissector (OL165R; Aesculap Surgical), and recovered using a brain spatula.
Transportation media
For electrophysiological experiments, cold (7–10°C) N-methyl-D-glucamine-based artificial cerebrospinal fluid (aCSF) saturated with carbogen (95% O2, 5% CO2) was used as described in the literature [15, 38]. Larger (10–30 mm) samples used for organotypic slice cultures and transcriptomic experiments were transferred to sterile ice-cold carbogenated “preparation medium” (Hibernate-A Medium (Gibco) supplemented with 1 mM GlutaMAX (Gibco), 13 mM Glucose (Sigma-Aldrich), 30 mM NMDG (Sigma-Aldrich), and 1% Anti-Anti). Depending on the distance from the OR to the laboratory facilities, the transport time ranged from 5 to 15 min. For a transport time >5 min, the medium was carbogenated using a nitrile examination glove filled with carbogen (95% O2, 5% CO2) and connected to a 3-way valve (Luer/Lock) and perfusor line (B. Braun Melsungen AG) (Supplementary Fig. 1). A single glove (size XL) lasted up to 30 min.
Patch-clamp recordings and visualization of neurons
The protocols for the recovery of acute human brain slices, electrophysiological whole-cell patch-clamp recordings, post-hoc visualization of neurons, and immunohistochemistry were performed as previously described [15]. Light microscopic images were acquired using a Leica SP8 laser-scanning confocal microscope equipped with a 40× oil-immersion (NA 1.30; Leica) objective.
Electron microscopy
Acute 400 μm slices were immersed in EM fixative (4% Paraformaldehyd (Polyscience) (w/v) 2.5% Glutaraldehyd (Serva) (w/v) in 0.1 M phosphate buffer) and kept at room temperature for 2 h, then stored at 4 °C. Next, ~1.5 mm wide samples were trimmed spanning the entire cortical height. Staining and embedding of samples was then performed as described in the literature [15]. Electron micrographs were taken with a Philips CM100 transmission electron microscope equipped with a Gatan Kamera Orius SC600 with a magnification of 6600.
Processing of large brain tissue sample
After transport of the samples to the laboratory, they were further divided into blocks ranging from 1 to 40 mm depending on the experimental use case (Table 2). Dissection was performed using sterile tools on a cutting platform consisting of aseptic filter paper (Whatman Merck, UK) moistened with sterile “preparation medium” (see above) and placed on an ice-cold metal block (−20 °C) on a sterile surgical drape. Visibly damaged or pathological tissue and capillaries were removed. For slice culture experiments, tissue blocks (7–20 mm) were cut into 300-μm-thick sections in a disinfected vibratome (Leica VT1200 Wetzlar, Germany) and filled with cold, sterile carbonated preparation medium. Depending on the apparent stiffness of the tissue, the cutting speed ranged from 0.14 to 0.16 mm/s with an amplitude of 1.5 mm. Immunofluorescent labeling was performed, and ex vivo glioblastoma invasion models were generated as described in the literature [7, 23] by injecting primary cultured GBM cells that were virally tagged with zsGreen into human organotypic slice cultures.
Stimulated Raman histology
Small 1–4 mm large tissue and tumor samples were removed using a 2-mm cutting forceps (8591A; Karl Storz, Tuttlingen, Germany). The samples were then compressed in a custom microscope slide according to the manufacturer’s instructions and imaged in a clinical stimulated Raman scattering microscope (NIO Laser Imaging System, Invenio Imaging, Santa Clara, CA) [21].
Results
In multiple rounds of experiments, we developed and refined a set of surgical principles (Table 1) for the removal of cortical access tissue for clinical and basic research. Depending on the experimental use case, we developed two intraoperative sampling strategies: Smaller single samples were used for electrophysiology and electron microscopy (5–7 mm, Fig. 1), and larger samples were subdivided in the laboratory for the cultivation of organotypic slice cultures and transcriptomic analysis (1–3 cm, Fig. 2).
Multiple surgeons (n = 8) adopted the technique after a single round of explanation using the graphics shown in Fig. 1a–c. No adverse events from sample resection were observed, especially no bleeding complications. The duration of sample extraction ranged from 40 to 120 s and was ideally performed in less than 1 min.
A prerequisite for standardization of the experimental settings is the maintenance of the cortical axis perpendicular to the pial surface already at the stage of the sample removal (Fig. 1b). The apical dendrites (Figs. 1b and 3c) of cortical pyramidal neurons are orientated along the perpendicular cortical axis. A transection of the apical dendrite of cortical neurons should be avoided to preserve electrophysiological properties [6, 13] and allow the identification of neurons. Deviations of the cortical axis during the intraoperative dissection require later adjustments representing a time delay, loss of tissue, and additional mechanical trauma.
Preparation of single cortical samples
Rectangular incisions (~5–7 mm) were made perpendicular to the pial surface using a pointed scalpel (Fig. 1d). Incision should be placed at the top of gyri to avoid entering sulci where larger blood vessels are found to prevent bleeding complications. To avoid compression and shear of the tissue, serrating movements of the blade were applied (see Supplementary Video 1). A narrow dissector was introduced from one side, and the white matter under the sample was carefully dissected while causing minimal mechanical disturbance to the cortical part of the sample (Fig. 1c). It was helpful to angulate (~45°) (Fig. 1a) one side of the rectangular incision to allow the introduction of the dissector and minimize compression of the surrounding tissue during preparation. The tissue block was lifted using the dissector and flipped onto a brain spatula (Fig. 1c). The tissue and the brain spatula were immediately immersed into a non-sterile container filled with transportation media and removed from the operating field and transported to the internal (5 min) and external laboratory facilities (15 min).
This preparation technique is optimized for the preservation of superficial layer cortical neurons. Deep layers of neurons, as well as the underlying white matter, are at risk of mechanical damage. An optimally prepared single block of 5–7 mm size can immediately be processed in the vibratome (Supplementary Fig. 2), minimizing delay and mechanical damage. Without the need for further trimming, the slices can be cut at slightly higher temperatures (7–11 °C), reducing the effect of low temperatures on ultrastructure and electrophysiological properties [11]. Blood clots on the sample may lead to detachment during processing in the vibratome and are not easily removed once they are attached to the sample. Therefore, constant irrigation of the sample during surgery proved to be beneficial (Table 1).
Using this technique, 36 brain tissue samples, of which 8 were reported previously [15], were obtained from frontal (n = 14), parietal (n = 2), temporal (n = 16), and occipital lobe (n = 4). Twenty-nine samples were from tumors and 7 from epilepsy surgeries. Eight to ten brain slices can result from one single block of tissue. Under ideal conditions, up to 20–70 cells could be recorded from a single sample.
Preparation of large samples
The same surgical steps as described above were applied for the microdissection of larger (10–30 mm) brain tissue samples. In larger samples, subcortical structures remained intact (Fig. 2). After transfer to the laboratory in preparation medium, larger samples were divided into blocks of various sizes according to the intended experimental use case (Table 2). Dissection was best performed in an ice-cold preparation medium, taking care to discard macroscopically infiltrated and tumorous tissue (Fig. 2a). For the generation of tumor invasion models [7], a certain portion (3–5 mm) of the white matter was preserved (Fig. 5). As previously shown in the literature [23], a single block of the size of 7–20 mm resulted in 18–20 organotypic slice models that could be cultivated for up to 12 days (n = 25).
Preparation of samples for intraoperative stimulated Raman histology
Stimulated Raman histology (SRH) [8, 21, 22, 35] allows the intraoperative label-free histological evaluation of tumorous samples. These samples were the least sensitive to mechanical damage, as the preparation itself consisted of a squash preparation. However, cauterization and the use of ultrasonic aspirators (CUSA) should be avoided. We found an endoscopic biopsy forceps optimal for targeted sampling of tumor and infiltrated brain tissue [21] (Fig. 6b). Samples sized 1–4 mm were sufficient for SRH imaging (Fig. 6b, c). The ease of use and the standardized imaging conditions make intraoperative SRH also an ideal tool to assess the quality and tumor burden of unstained neocortical access tissue slices (Fig. 6e–g).
Example cases
Case 1: Figure 3 shows a whole-cell patch-clamp recording of a superficial layer 2/3 pyramidal neuron from a 73-year-old male patient undergoing surgery for the resection of an IDH wild-type glioblastoma in the left frontal lobe (Figs. 1d and 3a, Supplementary Video 1). The action potential firing patterns in response to a current injection as well as spontaneous excitatory synaptic currents demonstrate the viability of the tissue (Fig. 3b). Two-layer 2/3 pyramidal neurons from the same sample were recorded and visualized with a streptavidin-coupled fluorescent labeling (Fig. 3c). The recordings were performed in a laboratory situated 10 min away from the neurosurgical operating room [15].
Case 2: Figure 4a shows the case of a 19-year-old female patient who underwent the resection of a diffuse astrocytoma CNS-WHO grade 2 (IDH mutated) in the right supramarginal gyrus during awake surgery. Electron micrographs generated from an acute slice of a small block of the tissue showed a high quality of ultrastructural preservation that allows the analysis of synapses as well as intracellular organelles like the spine apparatus organelle (Fig. 4b) [29].
Case 3: Figure 5 shows an ex vivo glioblastoma invasion model based on organotypic slice cultures generated from the access tissue of a 59-year-old male patient who underwent surgery for the removal of a glioblastoma IDH wild-type in the right frontal lobe. The slice cultures were subcortically injected with fluorescently labeled GBM cells, and the growth was monitored for 10 days, highlighting the interaction with astrocytes of the slices.
Case 4: Figure 6a–d shows the case of a 57-year-old female patient who underwent surgery for a recurrent CNS-WHO grade 4 astrocytoma (IDH mutated) in the left occipital lobe; 7 months prior to surgery, radiation therapy was performed. A 2–3 mm sample of the tumor was removed using biopsy forceps and stimulated Raman histology was performed in the OR.
Case 5: Figure 6e–g shows the neocortical access tissue of a 60-year-old female who underwent resection of a left temporal metastasis of an adenocarcinoma. Stimulated Raman histology was used to assess tissue quality and to rule out tumor infiltration in a slice of access tissue.
Discussion
In this technical report, we describe a surgical technique for the safe removal of human cortical access tissue ideal for various applications in basic neuroscientific and clinical research. The technique can easily be integrated into routine neurosurgical procedures without the necessity for additional surgical instruments.
The neurosurgeon should be aware of the intended use of the tissue (Table 2) and lays the foundation for the experimental success by the recruitment of appropriate candidate patients and by choosing the appropriate microdissection strategy. By optimizing the size and orientation of the sample in the OR, additional time-consuming and traumatic handling of the sample in the laboratory can be avoided. Counterintuitively, we found that larger samples that require further trimming are not necessarily better for the experimental success of acute slice experiments. In our experience, optimal electrophysiological results can already be achieved with relatively small samples (5–7 mm, Fig. 1).
The location of the sample is determined on the basis of clinical findings intraoperatively. Clinical and basic research interests must not interfere with the decision about the surgical strategy, the surgical route or trajectory, or the location of the cortical access tissue. We suggest that the exact location of the cortical access should be documented using neuronavigation in every case. Brain tissue acquisition will cause only a minimal temporal delay in the course of the operation (<2 min).
Ethics and biobanking
To ensure a consistent and ethically sensitive approach, in the absence of standard guidelines on this emerging field of translational research, the pre-, peri-, and postoperative procedures should be formalized in a research protocol and ethics approval for this protocol should be sought by the local research ethics committee. To ensure consistency in the ethical standards for such procedures, an international and participatory consensus process should be initiated, e.g., organized by professional neurosurgery associations.
The technique outlined here allows to maximize the scientific gain of every cortical and subcortical tissue donation, leading to fewer sample numbers required to answer a range of questions in translational neuroscience. The combination of several techniques maximized the use of each individual sample. We encourage to set up an experimental protocol and biobanking infrastructure that allows the exchange of tissue and data among research institutions. With emerging technologies, the benefit of analyzing human tissue with a multitude of technologies is paramount.
Standardization of tissue sampling
Human cortical access tissue has to be considered pathologically altered. The alterations arise from sample removal, sample processing [11], and the pathology (tumor, epilepsy) leading to the operation. The effects of the underlying pathology on cortical access tissue may range from tissue edema and histopathologically diagnosable tumor infiltration to subtle changes in the ultrastructure [5].
The macroscopic pathological effect can be controlled by measuring the distance of the cortical access tissue to the pathologies (contrast-enhancing border or FLAIR signal) [23] and microscopically using histological methods (e.g., immuno/H&E stain, stimulated Raman histology [22, 26, 35]) to assess tumor infiltration (Fig. 6e–f). Nonetheless, subtle changes will most likely only be discernible by exploration of the electrophysiological [9] and ultrastructural properties [16] across different samples, under the condition that the artifacts introduced by tissue microdissection and processing are reduced to a minimum.
Limitations
The resection of neocortical tissue blocks and subsequent slice preparations involve a severing of long range and local axons as well as dendrites, thus preserving only parts of the neocortical circuitry [18]. Subcortical neuromodulatory inputs, which are essential for physiological function in vivo, will not be preserved ex vivo, a fact that has to be taken into consideration in the experimental design. In animal models, a solution to overcome the limitation of acute slice preparations includes a combination of in vivo recordings and post-hoc morphological reconstructions across entire brains [20, 28].
Future outlook
A standardized sampling technique that reliably produces high-quality human brain tissue specimens forms the basis for the investigation of unique neurophysiological features in individual patients. Such characteristics can, for instance, include comorbidities such as neurodevelopmental and neurodegenerative disorders that can lead to or arise from alterations of neuronal wiring and plasticity [39, 43], or the intake of pharmacological agents. Furthermore, it will be possible to study the effect of interventions on the human brain, such as invasive and non-invasive brain stimulation techniques (e.g., TMS [4]), radiation [27], or tumor-treating fields [36]. A standardized sampling technique is therefore of utmost importance for current and future basic and clinical research and treatment development.
Improved tissue quality will also have an impact on pathological diagnosis. Although neuropathological diagnostic methods are moving toward molecular diagnostics that are also performed with lower-quality tissue [3], the interpretation of tumor infiltration in intact neuropil might greatly benefit from optimally preserved tissue. Further novel intraoperative imaging and spectroscopic techniques (SRH, FTIR) [8, 21, 22, 26, 34] that permit close to real-time histological examination of brain tissue in the operating room (Fig. 6) may influence surgical decision-making in the future [35]. Thus, optimally preserved tissue is essential for the validation of anatomical, molecular, and physiological findings of methods for intraoperative tissue analysis.
Conclusion
The surgical extraction of human brain tissue lays the foundation for translational neuroscientific research on vital human brain tissue. The microdissection technique of human cortical access tissue is safe and easily adoptable to routine neurosurgical procedures. Even small samples of a few millimeters in size can be successfully used for electrophysiological experiments. Standardized techniques of sample extraction greatly improve the success rate and the reliability of results obtained from intraoperative human brain tissue specimens.
Data availability
Not applicable.
Code availability
Not applicable.
Abbreviations
- CNS:
-
central nervous system
- GBM:
-
Glioblastoma
- OR:
-
Operating room
- SRH:
-
Stimulated Raman histology
References
Andersson M, Avaliani N, Svensson A, Wickham J, Pinborg LH, Jespersen B, Christiansen SH, Bengzon J, Woldbye DPD, Kokaia M (2016) Optogenetic control of human neurons in organotypic brain cultures. Sci Rep 6:24818. https://doi.org/10.1038/srep24818
Campagnola L, Seeman SC, Chartrand T, Kim L, Hoggarth A, Gamlin C, Ito S, Trinh J, Davoudian P, Radaelli C, Kim M-H, Hage T, Braun T, Alfiler L, Andrade J, Bohn P, Dalley R, Henry A, Kebede S et al Local connectivity and synaptic dynamics in mouse and human neocortex. Science 375:eabj5861. https://doi.org/10.1126/science.abj5861
Capper D, Jones DTW, Sill M, Hovestadt V, Schrimpf D, Sturm D, Koelsche C, Sahm F, Chavez L, Reuss DE, Kratz A, Wefers AK, Huang K, Pajtler KW, Schweizer L, Stichel D, Olar A, Engel NW, Lindenberg K et al (2018) DNA methylation-based classification of central nervous system tumours. Nature 555:469–474. https://doi.org/10.1038/nature26000
Duffau H (2020) Functional mapping before and after low-grade glioma surgery: a new way to decipher various spatiotemporal patterns of individual neuroplastic potential in brain tumor patients. Cancers 12:2611
Fiala JC, Spacek J, Harris KM (2002) Dendritic spine pathology: cause or consequence of neurological disorders? Brain Res Rev 39:29–54
Gidon A, Zolnik TA, Fidzinski P, Bolduan F, Papoutsi A, Poirazi P, Holtkamp M, Vida I, Larkum ME (2020) Dendritic action potentials and computation in human layer 2/3 cortical neurons. Science 367:83. https://doi.org/10.1126/science.aax6239
Henrik Heiland D, Ravi VM, Behringer SP, Frenking JH, Wurm J, Joseph K, Garrelfs NWC, Strähle J, Heynckes S, Grauvogel J, Franco P, Mader I, Schneider M, Potthoff A-L, Delev D, Hofmann UG, Fung C, Beck J, Sankowski R et al (2019) Tumor-associated reactive astrocytes aid the evolution of immunosuppressive environment in glioblastoma. Nat Commun 10:2541. https://doi.org/10.1038/s41467-019-10493-6
Hollon TC, Pandian B, Adapa AR, Urias E, Save AV, Khalsa SSS, Eichberg DG, D’Amico RS, Farooq ZU, Lewis S, Petridis PD, Marie T, Shah AH, Garton HJL, Maher CO, Heth JA, McKean EL, Sullivan SE, Hervey-Jumper SL et al (2020) Near real-time intraoperative brain tumor diagnosis using stimulated Raman histology and deep neural networks. Nat Med 26:52–58. https://doi.org/10.1038/s41591-019-0715-9
Jones RSG, da Silva AB, Whittaker RG, Woodhall GL, Cunningham MO (2016) Human brain slices for epilepsy research: pitfalls, solutions and future challenges. J Neurosci Methods 260:221–232. https://doi.org/10.1016/j.jneumeth.2015.09.021
Kato H, Ito Z, Matsuoka S, Sakurai Y (1973) Electrical activities of neurons in the sliced human cortex in vitro. Electroencephalogr Clin Neurophysiol 35:457–462
Kirov SA, Petrak LJ, Fiala JC, Harris KM (2004) Dendritic spines disappear with chilling but proliferate excessively upon rewarming of mature hippocampus. Neuroscience 127:69–80. https://doi.org/10.1016/j.neuroscience.2004.04.053
Kovacs FE, Knop T, Urbanski MJ, Freiman I, Freiman TM, Feuerstein TJ, Zentner J, Szabo B (2012) Exogenous and endogenous cannabinoids suppress inhibitory neurotransmission in the human neocortex. Neuropsychopharmacology 37:1104–1114
Larkum ME, Waters J, Sakmann B, Helmchen F (2007) Dendritic spikes in apical dendrites of neocortical layer 2/3 pyramidal neurons. J Neurosci 27:8999. https://doi.org/10.1523/JNEUROSCI.1717-07.2007
Le Duigou C, Savary E, Morin-Brureau M, Gomez-Dominguez D, Sobczyk A, Chali F, Milior G, Kraus L, Meier JC, Kullmann DM (2018) Imaging pathological activities of human brain tissue in organotypic culture. J Neurosci Methods 298:33–44
Lenz M, Kruse P, Eichler A, Straehle J, Beck J, Deller T, Vlachos A (2021) All-trans retinoic acid induces synaptic plasticity in human cortical neurons. Elife 10:e63026
Loomba S, Straehle J, Gangadharan V, Heike N, Khalifa A, Motta A, Ju N, Sievers M, Gempt J, Meyer HS, Helmstaedter M (2022) Connectomic comparison of mouse and human cortex. Science 377:eabo0924. https://doi.org/10.1126/science.abo0924
Maier JP, Ravi VM, Kueckelhaus J, Behringer SP, Garrelfs N, Will P, Sun N, von Ehr J, Goeldner JM, Pfeifer D, Follo M, Hannibal L, Walch AK, Hofmann UG, Beck J, Heiland DH, Schnell O, Joseph K (2021) Inhibition of metabotropic glutamate receptor III facilitates sensitization to alkylating chemotherapeutics in glioblastoma. Cell Death Dis 12:723–723. https://doi.org/10.1038/s41419-021-03937-9
Mohan H, Verhoog MB, Doreswamy KK, Eyal G, Aardse R, Lodder BN, Goriounova NA, Asamoah B, Brakspear ABC, Groot C, van der Sluis S, Testa-Silva G, Obermayer J, ZSRM B, Narayanan RT, Baayen JC, Segev I, Mansvelder HD, de Kock CPJ (2015) Dendritic and axonal architecture of individual pyramidal neurons across layers of adult human neocortex. Cereb Cortex 25:4839–4853. https://doi.org/10.1093/cercor/bhv188
Molnár G, Oláh S, Komlósi G, Füle M, Szabadics J, Varga C, Barzó P, Tamás G (2008) Complex events initiated by individual spikes in the human cerebral cortex. PLoS Biol 6:e222. https://doi.org/10.1371/journal.pbio.0060222
Narayanan RT, Mohan H, Broersen R, de Haan R, Pieneman AW, de Kock CP (2014) Juxtasomal biocytin labeling to study the structure-function relationship of individual cortical neurons. J Vis Exp 84:e51359
Neidert N, Straehle J, Erny D, Sacalean V, El Rahal A, Steybe D, Schmelzeisen R, Vlachos A, Reinacher PC, Coenen VA, Mizaikoff B, Heiland DH, Prinz M, Beck J, Schnell O (2022) Stimulated Raman histology in the neurosurgical workflow of a major European neurosurgical center — part A. Neurosurg Rev 45:1731–1739. https://doi.org/10.1007/s10143-021-01712-0
Orringer DA, Pandian B, Niknafs YS, Hollon TC, Boyle J, Lewis S, Garrard M, Hervey-Jumper SL, Garton HJL, Maher CO, Heth JA, Sagher O, Wilkinson DA, Snuderl M, Venneti S, Ramkissoon SH, McFadden KA, Fisher-Hubbard A, Lieberman AP et al (2017) Rapid intraoperative histology of unprocessed surgical specimens via fibre-laser-based stimulated Raman scattering microscopy. Nat Biomed Eng 1:0027. https://doi.org/10.1038/s41551-016-0027
Ravi VM, Joseph K, Wurm J, Behringer S, Garrelfs N, d’Errico P, Naseri Y, Franco P, Meyer-Luehmann M, Sankowski R, Shah MJ, Mader I, Delev D, Follo M, Beck J, Schnell O, Hofmann UG, Heiland DH (2019) Human organotypic brain slice culture: a novel framework for environmental research in neuro-oncology. Life Sci Alliance 2:e201900305. https://doi.org/10.26508/lsa.201900305
Ravi VM, Neidert N, Will P, Joseph K, Maier JP, Kückelhaus J, Vollmer L, Goeldner JM, Behringer SP, Scherer F, Boerries M, Follo M, Weiss T, Delev D, Kernbach J, Franco P, Schallner N, Dierks C, Carro MS et al (2022a) T-cell dysfunction in the glioblastoma microenvironment is mediated by myeloid cells releasing interleukin-10. Nat Commun 13:925. https://doi.org/10.1038/s41467-022-28523-1
Ravi VM, Will P, Kueckelhaus J, Sun N, Joseph K, Salié H, Vollmer L, Kuliesiute U, von Ehr J, Benotmane JK, Neidert N, Follo M, Scherer F, Goeldner JM, Behringer SP, Franco P, Khiat M, Zhang J, Hofmann UG et al (2022b) Spatially resolved multi-omics deciphers bidirectional tumor-host interdependence in glioblastoma. Cancer Cell 40:639–655.e13. https://doi.org/10.1016/j.ccell.2022.05.009
Reinecke D, von Spreckelsen N, Mawrin C, Ion-Margineanu A, Fürtjes G, Jünger ST, Khalid F, Freudiger CW, Timmer M, Ruge MI, Goldbrunner R, Neuschmelting V (2022) Novel rapid intraoperative qualitative tumor detection by a residual convolutional neural network using label-free stimulated Raman scattering microscopy. Acta Neuropathol Commun 10:109. https://doi.org/10.1186/s40478-022-01411-x
Robbins M, Greene-Schloesser D, Peiffer A, Shaw E, Chan M, Wheeler K (2012) Radiation-induced brain injury: a review. Front Oncol 2:73. https://doi.org/10.3389/fonc.2012.00073
Rojas-Piloni G, Guest JM, Egger R, Johnson AS, Sakmann B, Oberlaender M (2017) Relationships between structure, in vivo function and long-range axonal target of cortical pyramidal tract neurons. Nat Commun 8:870. https://doi.org/10.1038/s41467-017-00971-0
Rosado J, Bui VD, Haas CA, Beck J, Queisser G, Vlachos A (2022) Calcium modeling of spine apparatus-containing human dendritic spines demonstrates an “all-or-nothing” communication switch between the spine head and dendrite. PLoS Comput Biol 18:e1010069. https://doi.org/10.1371/journal.pcbi.1010069
Schneider M, Vollmer L, Potthoff A-L, Ravi VM, Evert BO, Rahman MA, Sarowar S, Kueckelhaus J, Will P, Zurhorst D (2021) Meclofenamate causes loss of cellular tethering and decoupling of functional networks in glioblastoma. Neuro-oncology
Schwarz N, Uysal B, Welzer M, Bahr JC, Layer N, Löffler H, Stanaitis K, Pa H, Weber YG, Hedrich UB, Honegger JB, Skodras A, Becker AJ, Wuttke TV, Koch H (2019) Long-term adult human brain slice cultures as a model system to study human CNS circuitry and disease. eLife 8:e48417. https://doi.org/10.7554/eLife.48417
Shapson-Coe A, Januszewski M, Berger DR, Pope A, Wu Y, Blakely T, Schalek RL, Li PH, Wang S, Maitin-Shepard J, Karlupia N, Dorkenwald S, Sjostedt E, Leavitt L, Lee D, Bailey L, Fitzmaurice A, Kar R, Field B et al (2021) A connectomic study of a petascale fragment of human cerebral cortex. bioRxiv, p 2021.05.29.446289. https://doi.org/10.1101/2021.05.29.446289
Ståhl PL, Fredrik S, Sanja V, Anna L, Fernández NJ, Jens M, Stefania G, Michaela A, Westholm JO, Mikael H, Annelie M, Sten L, Simone C, Åke B, Fredrik P, Igor CP, Pelin S, Jan M, Olaf B et al (2016) Visualization and analysis of gene expression in tissue sections by spatial transcriptomics. Science 353:78–82. https://doi.org/10.1126/science.aaf2403
Steiner G, Galli R, Preusse G, Michen S, Meinhardt M, Temme A, Sobottka SB, Juratli TA, Koch E, Schackert G, Kirsch M, Uckermann O (2022) A new approach for clinical translation of infrared spectroscopy: exploitation of the signature of glioblastoma for general brain tumor recognition. J Neurooncol. https://doi.org/10.1007/s11060-022-04204-3
Straehle J, Erny D, Neidert N, Heiland DH, El Rahal A, Sacalean V, Steybe D, Schmelzeisen R, Vlachos A, Mizaikoff B, Reinacher PC, Coenen VA, Prinz M, Beck J, Schnell O (2022) Neuropathological interpretation of stimulated Raman histology images of brain and spine tumors: part B. Neurosurg Rev 45:1721–1729. https://doi.org/10.1007/s10143-021-01711-1
Stupp R, Taillibert S, Kanner A, Read W, Steinberg DM, Lhermitte B, Toms S, Idbaih A, Ahluwalia MS, Fink K, Di Meco F, Lieberman F, Zhu J-J, Stragliotto G, Tran DD, Brem S, Hottinger AF, Kirson ED, Lavy-Shahaf G et al (2017) Effect of tumor-treating fields plus maintenance temozolomide vs maintenance temozolomide alone on survival in patients with glioblastoma: a randomized clinical trial. JAMA 318:2306–2316. https://doi.org/10.1001/jama.2017.18718
Ting JT, Kalmbach B, Chong P, Frates R, Keene CD, Gwinn RP, Cobbs C, Ko AL, Ojemann JG, Ellenbogen RG (2018a) A robust ex vivo experimental platform for molecular-genetic dissection of adult human neocortical cell types and circuits. Sci Rep 8:8407
Ting JT, Lee BR, Chong P, Soler-Llavina G, Cobbs C, Koch C, Zeng H, Lein E (2018b) Preparation of acute brain slices using an optimized N-methyl-D-glucamine protective recovery method. J Vis Exp 132:e53825. https://doi.org/10.3791/53825
Toga AW, Thompson PM (2014) Connectopathy in ageing and dementia. Brain 137:3104–3106
Verhoog MB, Goriounova NA, Obermayer J, Stroeder J, Hjorth JJJ, Testa-Silva G, Baayen JC, de Kock CPJ, Meredith RM, Mansvelder HD (2013) Mechanisms underlying the rules for associative plasticity at adult human neocortical synapses. J Neurosci 33:17197. https://doi.org/10.1523/JNEUROSCI.3158-13.2013
Witcher MR, Park YD, Lee MR, Sharma S, Harris KM, Kirov SA (2010) Three-dimensional relationships between perisynaptic astroglia and human hippocampal synapses. Glia 58:572–587
Yakoubi R, Rollenhagen A, von Lehe M, Shao Y, Sätzler K, Lübke JHR (2019) Quantitative three-dimensional reconstructions of excitatory synaptic boutons in layer 5 of the adult human temporal lobe neocortex: a fine-scale electron microscopic analysis. Cereb Cortex 29:2797–2814. https://doi.org/10.1093/cercor/bhy146
Yamasaki T, Maekawa T, Fujita T, Tobimatsu S (2017) Connectopathy in autism spectrum disorders: a review of evidence from visual evoked potentials and diffusion magnetic resonance imaging. Front Neurosci 11:627
Acknowledgements
The authors thank B. Joch, J. Göldner, and O. Müller for excellent technical support.
Funding
Open Access funding enabled and organized by Projekt DEAL. The work was supported by the Berta Ottenstein Clinician-Scientist Program of the Faculty of Medicine, University of Freiburg, to J.S., I.V., and N.N.N and the EQUIP-Medical Scientist Program of the Faculty of Medicine, University of Freiburg, to M.L. V.M.R. was supported by Freiburg Institute of Advanced Sciences (FRIAS). This project was funded by the German Cancer Consortium (DKTK) and Else Kröner-Fresenius Foundation (D.H.H) and by the BMBF (German Ministry of Education and Research; project numbers: 031L0260B and 13N16460).
Author information
Authors and Affiliations
Contributions
J. S., V. M.R., M.L., A.V., J.B., D.H.H., and O. S. designed the project; funding: D. H. H., M.L., A. V., V.M.R, and J.B.; data acquisition: J.S., R.V.M., N.N.N., J.Z., C.G., and M.L.; provided surgical samples: D.H.H., C.S., C.F., J.H.K., J.B., and O.S.; data analysis: J. S., R.V.M., D.H.H., C.G., and M.L.; manuscript writing: J. S., J. B., and O. S. with contributions of all authors.
Corresponding author
Ethics declarations
Ethics approval
Tissue samples were collected and imaged in accordance with the guidelines of the biobank at the Department of Neurosurgery, Medical Center, University of Freiburg, with the approval of the local ethics committee of the University of Freiburg (protocol 472/15_160880, 593/19 and 100020/09) and with written informed patient consent
Consent to participate
Written informed consent from participants is available.
Consent for publication
Consent for publication from participants is available.
Conflict of interest
The authors declare no competing interests.
Additional information
Comments
The current paper is an informative and comprehensive account for the handling of cortical access tissue for subsequent basic experimentation. I anticipate and hope it will engage more neurosurgeons in this kind of research as neurosurgeons by their unique access to the viable human CNS should and must play a greater role in basic research initiatives.
Carsten Reidies Bjarkam
Aalborg, Denmark
Publisher’s note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Supplementary information
ESM 1
Suppl. Figure 1. Box for the transport of human brain samples under constant carbogenation (95% O2 5% CO2) built from standard clinical supplies. (TIF 8626 kb)
ESM 2
Suppl. Figure 2. Single 5-7 mm sample of human cortical access tissue prepared according to the schematic in Fig. 1 that can be immediately processed in a vibratome. Acute 300-400 μm thick slices can then be analyzed using electrophysiology, light- and electron microscopy. (TIF 5937 kb)
Suppl. Video 1. Supplementary Video 1 shows the microdissection of the sample depicted in Fig. 1d. (MP4 34529 kb)
