Ventral compression in adult patients with Chiari 1 malformation sans basilar invagiantion: cause and management

Acta Neurochirurgica Aims and scope Submit manuscript

Abstract

Background

A small subset of patients with adult Chiari I malformation without basilar invagination (BI) and instability show ventral cervicomedullary distortion/compression and have symptoms pertaining to that. The cause of this ventral compression remains speculative. Additionally, it is unclear if these patients would require ventral decompression with posterior fusion or only posterior decompression would suffice.

Methods

Sixteen adult patients with Chiari I malformation with significant ventral cervicomedullary compression, in the absence of BI, were included in the study. Atlantoaxial dislocation (AAD) was excluded in these patients by flexion-extension craniovertebral junction X-rays and computed tomography (CT). Their clinical profile, especially symptoms pertaining to cervicomedullary compression, i.e. dysphagia, dysarthria and spasticity, were graded. The ventral cervicomedullary compression (VCMC) was quantified using pBC2 (maximum perpendicular distance to the basion-infero posterior point of the C2 body) on sagittal magnetic resonance imaging (MRI) and only those patients with pBC2 ≥9 mm were included. Furthermore, retroversion of dens and retro odonotid tissue thickness was calculated in each patient. Fifteen patients underwent posterior decompression alone and one refused surgery. Follow-up was done every 3 months. Repeat MRI was done at 1 year following surgery to look for pBC2.

Results

The mean pBC2 was 11 ± 0.2 mm. Retroversion of dens was responsible for VCMC in three patients and periodontoid crown in 13. There was no correlation between the tonsillar descent, age and the pBC2. All patients improved in symptoms of cervicomedullary compression following surgery. One patient worsened 6 months after initial improvement. The pBC2 did not change, as seen on follow-up MRI done in five patients.

Conclusions

VCMC in adult patients with Chiari I malformation in the absence of BI and/or AAD is due to periodontoid tissue (crown) or retroverted dens. Though a long-term study is required, it appears that all patients with Chiari I malformation, irrespective of the VCMC, can be given a chance with posterior decompression alone. Transoral decompression with posterior fusion may be required in a small subset of patients who fail to improve or worsen following posterior decompression only.

This is a preview of subscription content, log in via an institution to check access.

Access this article

Price includes VAT (France)

Instant access to the full article PDF.

Institutional subscriptions

Fig 1
Fig 2
Fig 3
Fig 4
Fig 5

References

  1. Bindal AK, Dunsker SB, Tew JM Jr (1995) Chiari I malformation: classification and management. Neurosurgery 37:1069–1074

    Article  PubMed  CAS  Google Scholar

  2. Dyste GN, Menezes AH, VanGilder JC (1989) Symptomatic Chiari malformations. An analysis of presentation, management, and long-term outcome. J Neurosurg 71(2):159–168

    Article  PubMed  CAS  Google Scholar

  3. Elster AD, Chen MY (1992) Chiari I malformations: clinical and radiologic reappraisal. Radiology 183(2):347–353

    PubMed  CAS  Google Scholar

  4. Goel A (2009) Basilar invagination, Chiari malformation, syringomyelia: a review. Neurol India 57(3):235–246

    Article  PubMed  Google Scholar

  5. Goto S, Umehara J, Aizawa T, Kokubun S (2007) Crowned dens syndrome. J Bone Joint Surg Am 89(12):2732–2736

    Article  PubMed  Google Scholar

  6. Grabb PA, Mapstone TB, Oakes WJ (1999) Ventral brain stem compression in pediatric and young adult patients with Chiari I malformations. Neurosurgery 44(3):520–528

    Article  PubMed  CAS  Google Scholar

  7. Grob D, Würsch R, Grauer W, Sturzenegger J, Dvorak J (1997) Atlantoaxial fusion and retrodental pannus in rheumatoid arthritis. Spine (Phila Pa 1976) 22(14):1580–1583, discussion 1584

    Article  CAS  Google Scholar

  8. Menezes AH (1995) Primary craniovertebral anomalies and the hindbrain herniation syndrome (Chiari I): data base analysis. Pediatr Neurosurg 23(5):260–269

    Article  PubMed  CAS  Google Scholar

  9. Pujol J, Roig C, Capdevila A, Pou A, Martí-Vilalta JL, Kulisevsky J, Escartín A, Zannoli G (1995) Motion of the cerebellar tonsils in Chiari type I malformation studied by cine phase-contrast MRI. Neurology 45(9):1746–1753

    PubMed  CAS  Google Scholar

  10. Tubbs RS, Wellons JC 3rd, Blount JP, Grabb PA, Oakes WJ (2003) Inclination of the odontoid process in the pediatric Chiari I malformation. J Neurosurg 98(1 Suppl):43–49

    PubMed  Google Scholar

  11. Young WF, Boyko O (2002) Magnetic resonance imaging confirmation of resolution of periodontoid pannus formation following C1/C2 posterior transarticular screw fixation. J Clin Neurosci 9(4):434–436

    Article  PubMed  Google Scholar

Download references

Conflicts of interest

None.

Author information

Authors and Affiliations

Authors

Corresponding author

Correspondence to Pravin Salunke.

Rights and permissions

Reprints and permissions

About this article

Cite this article

Salunke, P., Sura, S., Futane, S. et al. Ventral compression in adult patients with Chiari 1 malformation sans basilar invagiantion: cause and management. Acta Neurochir 154, 147–152 (2012). https://doi.org/10.1007/s00701-011-1215-y

Download citation

  • Received:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s00701-011-1215-y
