Accuracy of a proximal tibial cutting method using the anterior tibial border in TKA

European Journal of Orthopaedic Surgery & Traumatology volume 24, pages 1525–1530 (2014)Cite this article

Abstract

Purpose

In conventional total knee arthroplasty (TKA) using extramedullary alignment guides, it is not always easy to cut the proximal tibia precisely perpendicular to the tibial axis. The purpose of this study was to compare the radiographic accuracy of cutting the proximal tibia between the use of the bony landmarks of the anterior tibial border and the use of the conventional technique.

Methods

A total of 173 patients underwent primary TKA. In 76 TKAs, we used the bony landmark method, and in 97 TKAs, we used the conventional method. In the bony landmark method, we set the coronal alignment in reference to the line connecting the proximal and distal one-third of the anterior tibial border, and we determined the 5° posterior slope in reference to this line. Six months postoperatively, radiological evaluations were performed using full-length standing anteroposterior and lateral radiographs of the knee.

Results

No significant differences in the coronal tibial component angle were found between the groups. The posterior tilt of the tibial component was significantly smaller in the bony landmark method than in the conventional method (5.1° ± 2.9° vs. 6.4° ± 3.2°, respectively; p = 0.007). The percentage of patients whose posterior tilt of the tibial component was within ±3° of 5° was significantly larger in the bony landmark method than in the conventional method (70 vs. 62 %, respectively; p = 0.04).

Conclusions

The bony landmark method provided a more accurate posterior tibial slope than the conventional method. However, there was no difference in coronal alignment compared with the conventional method.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2

References

  1. Cates HE, Ritter MA, Keating EM, Faris PM (1993) Intramedullary versus extramedullary femoral alignment systems in total knee replacement. Clin Orthop 286:32–39

    PubMed  Google Scholar

  2. Meding JB, Berend ME, Ritter MA, Galley MR, Malinzak RA (2011) Intramedullary vs extramedullary femoral alignment guides: a 15-year follow-up of survivorship. J Arthrolast 26:591–595

    Article  Google Scholar

  3. Tew M, Waugh W (1985) Tibiofemoral alignment and the results of knee replacement. J Bone Joint Surg Br 67:551–556

    CAS  PubMed  Google Scholar

  4. Fang DM, Ritter MA, Davis KE (2009) Coronal alignment in total knee arthroplasty: just how important is it? J Arthroplast 24(6 Suppl 1):39–43

    Article  Google Scholar

  5. Simmons ED Jr, Sullivan JA, Rackemann S, Scott RD (1991) The accuracy of tibial intramedullary alignment devices in total knee arthroplasty. J Arthroplast 6:45–50

    Article  Google Scholar

  6. Schneider M, Heisel C, Aldinger PR, Breusch SJ (2007) Use of palpable tendons for extramedullary tibial alignment in total knee arthroplasty. J Arthroplast 22:219–226

    Article  Google Scholar

  7. Rajadhyaksha AD, Mehta H, Zelicof SB (2009) Use of tibialis anterior tendon as distal landmark for extramedullary tibial alignment in total knee arthroplasty: an anatomical study. Am J Orthop 38:E68–E70

    PubMed  Google Scholar

  8. Sugimura N, Ikeuchi M, Izumi M, Aso K, Ushida T, Tani T (2013) The dorsal pedis artery as a new distal landmark for extramedullary tibial alignment in total knee arthroplasty. Knee Surg Sports Traumatol Arthrosc (in press)

  9. Mizu-uchi H, Matsuda S, Miura H, Higaki H, Okazaki K, Iwamoto Y (2006) The effect of ankle rotation on cutting of the tibia in total knee arthroplasty. J Bone Joint Surg Am 88:2632–2636

    PubMed  Article  Google Scholar

  10. Laskin RS (2003) Instrumentation pitfalls: you just can’t go on autopilot! J Arthroplast 18(Suppl 1):18–22

    Article  Google Scholar

  11. Yoo JH, Chang CB, Shin KS, Seong SC, Kim TK (2008) Anatomical references to assess the posterior tibial slope in total knee arthroplasty: a comparison of 5 anatomical axes. J Arthroplast 23:586–592

    Article  Google Scholar

  12. Fukagawa S, Matsuda S, Mitsuyasu H, Miura H, Okazaki K, Tashiro Y, Iwamoto Y (2011) Anterior border of the tibia as a landmark for extramedullary alignment guide in total knee arthroplasty for varus knees. J Orthop Res 29:919–924

    PubMed  Article  Google Scholar

  13. Tsukeoka T, Lee TH, Tsuneizumi Y, Suzuki M (2012) The tibial crest as a practical useful landmark in total knee arthroplasty. Knee (in press)

  14. Dutton AQ, Yeo SJ, Yang KY, Lo NN, Chia KU, Chong HC (2008) Computer-assisted minimally invasive total knee arthroplasty compared with standard total knee arthroplasty. A prospective, randomized study. J Bone Joint Surg Am 90:2–9

    PubMed  Article  Google Scholar

  15. Chin PL, Yang KY, Yeo SJ, Lo NN (2005) Randomized control trial comparing radiographic total knee arthroplasty implant placement using computer navigation versus conventional technique. J Arthroplast 20:618–626

    Article  Google Scholar

  16. Decking R, Markmann Y, Fuchs J, Puhl W, Scharf HP (2005) Leg axis after computer-navigated total knee arthroplasty: a prospective randomized trial comparing computer-navigated and manual implantation. J Arthroplast 20:282–288

    Article  Google Scholar

  17. Hasegawa M, Yoshida K, Wakabayashi M, Sudo A (2011) Minimally invasive total knee arthroplasty: comparison of jig-based technique versus computer navigation for clinical and alignment outcome. Knee Surg Sports Traumatol Arthrosc 19:904–910

    PubMed  Article  Google Scholar

  18. Shi X, Shen B, Kang P, Yang J, Zhou Z, Pei F (2013) The effect of posterior tibial slope on knee flexion in posterior-stabilized total knee arthroplasty. Knee Surg Sports Traumatol Arthrosc 21:2696–2703

    PubMed  Article  Google Scholar

  19. Yoo JH, Chang CB, Shin KS, Seong SC, Kim TK (2008) Anatomical references to assess the posterior tibial slope in total knee arthroplasty: a comparison of 5 anatomical axes. J Arthroplast 23:586–592

    Article  Google Scholar

  20. Han HS, Chang CB, Seong SC, Lee S, Lee MC (2008) Evaluation of anatomic references for tibial sagittal alignment in total knee arthroplasty. Knee Surg Sports Traumatol Arthrosc 16:373–377

    PubMed  Article  Google Scholar

  21. Novicoff WM, Saleh KJ, Mihalko WM, Wang XQ, Knaebel HP (2010) Primary total knee arthroplasty: a comparison of computer-assisted and manual techniques. Instr Course Lect 59:109–117

    PubMed  Google Scholar

  22. Kim YH, Kim JS, Choi Y, Kwon OR (2009) Computer-assisted surgical navigation does not improve the alignment and orientation of the components in total knee arthroplasty. J Bone Joint Surg Am 91:14–19

    PubMed  Article  Google Scholar

  23. Macule-Beneyto F, Hernández-Vaquero D, Segur-Vilalta JM, Colomina-Rodrı′guez R, Hinarejos-Go′mez P, Garcı′a-Forcada I, Seral-Garcı′a B (2006) Navigation in total knee arthroplasty: a multicenter study. Int Orthop 30:536–540

    CAS  PubMed Central  PubMed  Article  Google Scholar

  24. Hernández-Vaquero D, Suárez-Vázquez A (2007) Complications of fixed infrared emitters in computer-assisted total knee arthroplasties. BMC Musculoskelet Disord 8:71

    Google Scholar

  25. Nagamine R, Miyanishi K, Miura H et al (2003) Medial torsion of the tibia in Japanese patients with osteoarthritis of the knee. Clin Orthop Relat Res 408:218–224

    PubMed  Article  Google Scholar

  26. Hovinga KR, Lerner AL (2009) Anatomic variations between Japanese and Caucasian populations in the healthy young adult knee joint. J Orthop Res 27:1191–1196

    PubMed  Article  Google Scholar

Download references

Conflict of interest

None.

Author information

Affiliations

  1. Department of Orthopaedic Surgery, Jichi Medical University, 3311-1 Yakushiji, Shimotsuke, Tochigi, 3290498, Japan

    Hideyuki Sasanuma, Hitoshi Sekiya, Kenzo Takatoku, Takashi Ajiki & Hiroyoshi Hagiwara

Authors
  1. Hideyuki Sasanuma
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Hitoshi Sekiya
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Kenzo Takatoku
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Takashi Ajiki
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Hiroyoshi Hagiwara
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to Hideyuki Sasanuma.

Rights and permissions

Reprints and Permissions

About this article

Cite this article

Sasanuma, H., Sekiya, H., Takatoku, K. et al. Accuracy of a proximal tibial cutting method using the anterior tibial border in TKA. Eur J Orthop Surg Traumatol 24, 1525–1530 (2014). https://doi.org/10.1007/s00590-014-1415-2

Download citation

  • Received:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s00590-014-1415-2

Keywords

  • Total knee arthroplasty
  • Tibial bone resection
  • Anterior tibial border
  • Extramedullary alignment guide
