Surgical treatment of double thoracic adolescent idiopathic scoliosis with a rigid proximal thoracic curve

European Spine Journal volume 25, pages 569–577 (2016)Cite this article

Abstract

Purpose

There is limited consensus on the optimal surgical strategy for double thoracic adolescent idiopathic scoliosis (AIS). Recent studies have reported that pedicle screw constructs to maximize scoliosis correction cause further thoracic spine lordosis. The objective of this study was to apply a new surgical technique for double thoracic AIS with rigid proximal thoracic (PT) curves and assess its clinical outcomes.

Methods

Twenty one consecutive patients with Lenke 2 AIS and a rigid PT curve (Cobb angle ≥30º on side-bending radiographs, flexibility ≤30 %) treated with the simultaneous double-rod rotation technique (SDRRT) were included. In this technique, a temporary rod is placed at the concave side of the PT curve. Then, distraction force is applied to correct the PT curve, which reforms a sigmoid double thoracic curve into an approximate single thoracic curve. As a result, the PT curve is typically converted from an apex left to an apex right curve before applying the correction rod for PT and main thoracic curve.

Results

All patients were followed for at least 2 years (average 2.7 years). The average main thoracic and PT Cobb angle correction rate at the final follow-up was 74.7 and 58.0 %, respectively. The average preoperative T5–T12 thoracic kyphosis was 9.3°, which improved significantly to 19.0° (p < 0.0001) at the final follow-up. Although 71 % patients had preoperative level shoulders or a positive radiographic shoulder height, all patients had mildly imbalanced or balanced shoulders at the final follow-up. The average preoperative main thoracic apical vertebral rotation angle of 20.7° improved significantly after surgery to 16.4° (p = 0.0046), while the average preoperative total SRS questionnaire score of 3.7 improved significantly to 4.4 (p = 0.0012) at the final follow-up.

Conclusions

Radiographic findings and patient outcomes were satisfactory. Thoracic kyphosis can be maintained or improved, while coronal and axial deformities can be corrected using SDRRT for Lenke 2 AIS with a rigid PT curve.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3

References

  1. Aaro S, Dahlborn M (1981) Estimation of vertebral rotation and the spinal and ribcage deformity in scoliosis by computer tomography. Spine 6:460–467

    PubMed  CAS  Article  Google Scholar

  2. Cao K, Watanabe K, Kawakami N et al (2014) Selection of lower instrumented vertebra in treating Lenke type 2A adolescent idiopathic scoliosis. Spine 39:E253–E261

    PubMed  Article  Google Scholar

  3. Cao K, Watanabe K, Hosogane N et al (2014) Association of postoperative shoulder balance with adding-on in Lenke Type II adolescent idiopathic scoliosis. Spine 39:E705–E712

    PubMed  Article  Google Scholar

  4. Di Silvestre M, Lolli F, Bakaloudis G et al (2013) Apical vertebral derotation in the posterior treatment of adolescent idiopathic scoliosis: myth or reality? Eur Spine J 22:313–323

    PubMed  PubMed Central  Article  Google Scholar

  5. Geck MJ, Rinella A, Hawthorne D et al (2009) Comparison of surgical treatment in Lenke 5C adolescent idiopathic scoliosis: anterior dual rod versus posterior pedicle fixation surgery: a comparison of two practices. Spine 34:1942–1951

    PubMed  Article  Google Scholar

  6. Ito M, Abumi K, Kotani Y et al (2010) Simultaneous double-rod rotation technique in posterior instrumentation surgery for correction of adolescent idiopathic scoliosis. J Neurosurg Spine 12:293–300

    PubMed  Article  Google Scholar

  7. Kim YJ, Lenke LG, Kim J et al (2006) Comparative analysis of pedicle screw versus hybrid instrumentation in posterior spinal fusion of adolescent idiopathic scoliosis. Spine 31:291–298

    PubMed  Article  Google Scholar

  8. Kuklo TR, Lenke LG, Graham EJ et al (2002) Correlation of radiographic, clinical, and patient assessment of shoulder balance following fusion versus nonfusion of the proximal thoracic curve in adolescent idiopathic scoliosis. Spine 27:2013–2020

    PubMed  Article  Google Scholar

  9. Lee CS, Chung SS, Shin SK et al (2011) Changes of upper thoracic curve and shoulder balance in thoracic adolescent idiopathic scoliosis treated by anterior selective thoracic fusion using VATS. J Spinal Disord Tech 24:462–468

    PubMed  Article  Google Scholar

  10. Lenke LG, Betz RR, Clements D et al (2002) Curve prevalence of a new classification of operative adolescent idiopathic scoliosis: does classification correlate with treatment? Spine 27:604–611

    PubMed  Article  Google Scholar

  11. Lenke LG, Betz RR, Harms J et al (2001) Adolescent idiopathic scoliosis: a new classification to determine extent of spinal arthrodesis. J Bone Joint Surg Am 83:1169–1181

    PubMed  Google Scholar

  12. Lenke LG, Bridwell KH, O’Brien MF et al (1994) Recognition and treatment of the proximal thoracic curve in adolescent idiopathic scoliosis treated with Cotrel-Dubousset instrumentation. Spine 19:1589–1597

    PubMed  CAS  Article  Google Scholar

  13. Li M, Gu S, Ni J et al (2009) Shoulder balance after surgery in patients with Lenke Type 2 scoliosis corrected with the segmental pedicle screw technique. J Neurosurg Spine 10:214–219

    PubMed  Article  Google Scholar

  14. Lowenstein JE, Matsumoto H, Vitale MG et al (2007) Coronal and sagittal plane correction in adolescent idiopathic scoliosis: a comparison between all pedicle screw versus hybrid thoracic hook lumbar screw constructs. Spine 32:448–452

    PubMed  Article  Google Scholar

  15. Lubicky JP, Hanson JE, Riley EH, Spinal Deformity Study Group (2011) Instrumentation constructs in pediatric patients undergoing deformity correction correlated with scoliosis research society scores. Spine 36:1692–700

  16. Mladenov KV, Vaeterlein C, Stuecker R (2011) Selective posterior thoracic fusion by means of direct vertebral derotation in adolescent idiopathic scoliosis: effects on the sagittal alignment. Eur Spine J 20:1114–1117

    PubMed  PubMed Central  Article  Google Scholar

  17. Newton PO, Marks MC, Bastrom TP et al (2013) Surgical treatment of Lenke 1 main thoracic idiopathic scoliosis: results of a prospective, multicenter study. Spine 38:328–338

    PubMed  Article  Google Scholar

  18. Newton PO, Yaszay B, Upasani VV et al (2010) Preservation of thoracic kyphosis is critical to maintain lumbar lordosis in the surgical treatment of adolescent idiopathic scoliosis. Spine 35:1365–1370

    PubMed  Google Scholar

  19. Salmingo RA, Tadano S, Abe Y et al (2014) Influence of implant rod curvature on sagittal correction of scoliosis deformity. Spine J 14:1432–1439

    PubMed  Article  Google Scholar

  20. Schwab F, Patel A, Ungar B et al (2010) Adult spinal deformity-postoperative standing imbalance: how much can you tolerate? An overview of key parameters in assessing alignment and planning corrective surgery. Spine 35:2224–2231

    PubMed  Article  Google Scholar

  21. Sucato DJ, Agrawal S, O’Brien MF et al (2008) Restoration of thoracic kyphosis after operative treatment of adolescent idiopathic scoliosis: a multicenter comparison of three surgical approaches. Spine 33:2630–2636

    PubMed  Article  Google Scholar

  22. Sudo H, Ito M, Abe Y et al (2014) Surgical treatment of Lenke 1 thoracic adolescent idiopathic scoliosis with maintenance of kyphosis using the simultaneous double-rod rotation technique. Spine 39:1163–1169

    PubMed  Article  Google Scholar

  23. Sudo H, Ito M, Kaneda K et al (2013) Long-term outcomes of anterior dual-rod instrumentation for thoracolumbar and lumbar curves in adolescent idiopathic scoliosis: a twelve to twenty-three-year follow-up study. J Bone Joint Surg Am 95:e49

    PubMed  Article  Google Scholar

  24. Sudo H, Ito M, Kaneda K et al (2013) Long-term outcomes of anterior spinal fusion for treating thoracic adolescent idiopathic scoliosis curves: average 15-year follow-up analysis. Spine 38:819–826

    PubMed  Article  Google Scholar

  25. Suk SI, Kim WJ, Lee CS et al (2000) Indications of proximal thoracic curve fusion in thoracic adolescent idiopathic scoliosis: recognition and treatment of double thoracic curve pattern in adolescent idiopathic scoliosis treated with segmental instrumentation. Spine 25:2342–2349

    PubMed  CAS  Article  Google Scholar

Download references

Author information

Affiliations

  1. Department of Orthopaedic Surgery, Hokkaido University Hospital, North-15, West-7, Kita-ku, Sapporo, Hokkaido, 060-8638, Japan

    Hideki Sudo & Norimasa Iwasaki

  2. Eniwa Hospital, Koganemachi 2-1, Eniwa, Hokkaido, 061-1449, Japan

    Yuichiro Abe

  3. Sapporo Orthopaedic Hospital, Hassamu 13-4, Sapporo, Hokkaido, 063-0833, Japan

    Kuniyoshi Abumi

  4. Department of Spine and Spinal Cord Disorders, Hokkaido Medical Center, Yamanote 5-7, Sapporo, Hokkaido, 063-0005, Japan

    Manabu Ito

  5. Department of Advanced Medicine for Spine and Spinal Cord Disorders, Hokkaido University Graduate School of Medicine, North-15, West-7, Kita-ku, Sapporo, Hokkaido, 060-8638, Japan

    Hideki Sudo

Authors
  1. Hideki Sudo
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Yuichiro Abe
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Kuniyoshi Abumi
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Norimasa Iwasaki
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Manabu Ito
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to Hideki Sudo.

Ethics declarations

Conflict of interest

None.

Rights and permissions

Reprints and Permissions

About this article

Verify currency and authenticity via CrossMark

Cite this article

Sudo, H., Abe, Y., Abumi, K. et al. Surgical treatment of double thoracic adolescent idiopathic scoliosis with a rigid proximal thoracic curve. Eur Spine J 25, 569–577 (2016). https://doi.org/10.1007/s00586-015-4139-z

Download citation

  • Received:

  • Revised:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s00586-015-4139-z

Keywords

  • Adolescent idiopathic scoliosis
  • Lenke type 2 scoliosis
  • Surgical correction
  • Thoracic kyphosis
  • Patient outcome measures
