Estimation of sensible heat, water vapor, and CO2 fluxes using the flux-variance method

International Journal of Biometeorology volume 52, pages 521–533 (2008)Cite this article

Abstract

This study investigated the flux-variance relationships of temperature, humidity, and CO2, and examined the performance of using this method for predicting sensible heat (H), water vapor (LE), and CO2 fluxes (FCO2) with eddy-covariance measured flux data at three different ecosystems: grassland, paddy rice field, and forest. The H and LE estimations were found to be in good agreement with the measurements over the three fields. The prediction accuracy of LE could be improved by around 15% if the predictions were obtained by the flux-variance method in conjunction with measured sensible heat fluxes. Moreover, the paddy rice field was found to be a special case where water vapor follows flux-variance relation better than heat does. However, the CO2 flux predictions were found to vary from poor to fair among the three sites. This is attributed to the complicated CO2 sources and sinks distribution. Our results also showed that heat and water vapor were transported with the same efficiency above the grassland and rice paddy. For the forest, heat was transported 20% more efficiently than evapotranspiration.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13

References

  • Andreas EL, Hill RJ, Gosz JR, Moore DI, Otto WD, Sarma AD (1998) Statistics of surface layer turbulence over terrain with meter-scale heterogeneity. Boundary-Layer Meteorol 86:379–408

    Article  Google Scholar

  • Asanuma J, Brutsaert W (1999) Turbulence variance characteristics of temperature and humidity in the unstable atmospheric surface layer above a variable pine forest. Water Resour Res 35:2281–2288

    Article  Google Scholar

  • Campbell GS, Norman JM (1998) An introduction to environmental biophysics, 2nd edn. Springer, New York

    Book  Google Scholar

  • Castellvi F, Martinez-Cob A (2005) Estimation sensible heat flux using surface renewal analysis and the flux variance method: a case study over olive trees at Sastago (NE of Spain). Water Resour Res 41:W09422

    Article  Google Scholar

  • de Bruin HAR, Kohsiek W, Van Den Hurk BJJM (1993) A verification of some methods to determine the fluxes of momentum, sensible heat, and water vapor using standard deviation and structure parameter of scalar meteorological quantities. Boundary-Layer Meteorol 63:231–257

    Article  Google Scholar

  • Detto M, Katul GG (2007) Simplified expressions for adjusting higher-order turbulent statistics obtained from open path gas analyzers. Boundary-Layer Meteorol 122:205–216

    Article  Google Scholar

  • Gao Z, Bian L, Chen Z, Sparraw M, Zhang J (2006) Turbulent variance characteristics of temperature and humidity over a non-uniform land surface for an agriculture ecosystem in China. Adv Atmos Sci 23:365–374

    Article  Google Scholar

  • Hsieh CI Katul GG, Sigmon J, Knoerr KR (1996) Estimation of momentum and heat fluxes using dissipation and flux-variance methods in the unstable surface layer. Water Resour Res 32:2453–2462

    Article  Google Scholar

  • Hsieh CI, Katul GG, Chi TW (2000) An approximate analytical model for footprint estimation of scalar fluxes in thermally stratified atmospheric flows. Adv Water Resour 23:765–772

    Article  Google Scholar

  • Hsieh CI, Kiely G, Birkby A, Katul G (2005) Photosynthetic responses of a humid grassland ecosystem to future climate perturbations. Adv Water Resour 28:910–916

    Article  Google Scholar

  • Jaksic V, Kiely G, Albertson J, Oren R, Katul G, Leahy P, Byrne KA (2006) Net ecosystem exchange of grassland in contrasting wet and dry years. Agri For Meteorol 139:323–334

    Article  Google Scholar

  • Katul GG, Goltz M, Hsieh C, Cheng Y, Mowry F, Sigmon J (1995) Estimation of surface heat and momentum fluxes using the flux-variance method above uniform and non-uniform terrain. Boundary-Layer Meteorol 74:237–260

    Article  Google Scholar

  • Lamaud E, Irvine M (2006) Temperature-humidity dissimilarity and heat-to-water vapor transport efficiency above and within a pine forest canopy: the role of the Bowen ratio. Boundary-Layer Meteorol 120:87–109

    Article  Google Scholar

  • Lloyd CR, Culf AD, Dolman AJ, Gash JH (1991) Estimates of sensible heat flux from observations of temperature fluctuations. Boundary-Layer Meteorol 57:311–322

    Article  Google Scholar

  • McBean GA, Miyake M (1972) Turbulent transfer mechanisms in the atmospheric surface layer. Quart J R Meteorol Soc 98:383–398

    Article  Google Scholar

  • McMillen R (1988) An eddy correlation technique with extended applicability to non-simple terrain. Boundary-Layer Meteorol 43:231–245

    Article  Google Scholar

  • Michiaki S, Noriaki K (2003) Surface and mixed-layer variance methods to estimate regional sensible heat flux at the surface. Boundary-Layer Meteorol 106:117–145

    Article  Google Scholar

  • Moore CJ (1986) Frequency response corrections for eddy correlation systems. Boundary-Layer Meteorol 37:17–35

    Article  Google Scholar

  • Moriwaki M, Kanda M (2006) Local and global similarity in turbulent transfer of heat, water vapor, and CO2 in the dynamic convective sublayer over a suburban area. Boundary-Layer Meteorol 120:163–179

    Article  Google Scholar

  • Ohtaki E (1985) On the similarity in atmospheric fluctuations of carbon dioxide, water vapor and temperature over vegetated fields. Boundary-Layer Meteorol 32:25–37

    Article  Google Scholar

  • Padro J (1993) An investigation of flux-variance methods and universal functions applied to three land-use types in unstable conditions. Boundary-Layer Meteorol 66:413–425

    Article  Google Scholar

  • Tillman JE (1972) The indirect determination of stability, heat and momentum fluxes in the atmosphere boundary layer from simple scalar variables during dry unstable conditions. J Appl Meteorol 44:13–31

    Google Scholar

  • Weaver HL (1990) Temperature and humidity flux-variance relarions determined by one-dimensional eddy correlations. Boundary-Layer Meteorol 53:77–91

    Article  Google Scholar

  • Webb EK, Perman GI, Leuning R (1980) Correction of flux measurements for density effects due to heat and water transfer. Quart J R Meteorol Soc 106:85–100

    Article  Google Scholar

  • Wesely ML (1988) Use of variance techniques to measure dry air-surface exchange rates. Boundary-Layer Meteorol 44:13–31

    Article  Google Scholar

  • Wesson KH, Katul GG, Lai CT (2001) Sensible heat flux estimation by flux variance and half-order time derivative methods. Water Resour Res 37:2333–2343

    Article  Google Scholar

  • Wilczak JM, Oncley SP, Stage SA (2001) Sonic anemometer tilt correction algorithms. Boundary-Layer Meteorol 99:127–150

    Article  Google Scholar

  • Williams CA, Scanlon TM, Albertson JD (2007) Influence of surface heterogeneity on scalar dissimilarity in the roughness sublayer. Boundary-Layer Meteorol 122:149–165

    Article  Google Scholar

Download references

Acknowledgments

The authors would like to thank the National Science Council and Environmental Protection Agency, Taiwan, for their support of this study. We are also very grateful to Professor Gerard Kiely for his data support and the two reviewers for their helpful comments.
