Abstract
Neural tube defects, mostly believed to result from closure defects of the neural tube during embryonic development, are frequently observed congenital malformations in humans. Since the etiology of these defects is not well understood yet, many animal models for neural tube defects, either arising from spontaneous mutations or generated by gene targeting, are being studied. The Bent tail mouse is a model for X-linked neural tube defects. This mutant has a characteristic short and kinked tail. Exencephaly occurs in Bent tail embryos with a frequency of 11–16%. Laterality defects also belong to the phenotypic spectrum. In this study, we analyzed the embryonic phenotype in further detail using scanning electron microscopy during the stages of neurulation. We observed a number of defects in both wild type and Bent tail embryos, including a kinked neural tube, tight amnion, delay in axial rotation and even malrotation. The severity or frequency of most defects, the delay in axial rotation excluded, was significantly higher in Bent tail embryos compared to wild type embryos. Other abnormalities were seen in Bent tail embryos only. These defects were related to anterior and posterior neural tube closure and resulted in exencephaly and a closure delay of the posterior neuropore, respectively. The exencephalic phenotype was further analyzed by light microscopy in ED14 embryos, showing disorganization and overgrowth in the mesencephalon and rhombencephalon. In conclusion, the anterior and posterior neural tube closure defects in the Bent tail are strictly linked to the genetic defect in this mouse. Other phenotypic features described in this study also occur in the wild type genetic background of the Bent tail strain. Apparently, the genetic background contains elements conducive to these developmental abnormalities.
Similar content being viewed by others
References
Aruga J, Inoue T, Hoshino J, Mikoshiba K (2002) Zic2 controls cerebellar development in cooperation with Zic1. J Neurosci 22:218–225
Carrel T, Purandare SM, Harrison W, Elder F, Fox T, Casey B, Herman GE (2000) The X-linked mouse mutation Bent tail is associated with a deletion of the Zic3 locus. Hum Mol Genet 9:1937–1942
Copp AJ (1994) Genetic models of mammalian neural tube defects. Ciba Found Symp 181:118–134
Deuchar EM (1975) Reconstitutive ability of axial tissue in early rat embryos after operations and culture in vitro. J Embryol Exp Morphol 33:217–226
Franke B, Klootwijk R, Lemmers B, de Kovel CGF, Steegers-Theunissen RPM, Mariman ECM (2003) The phenotype of the NTD mouse model Bent tail is not sensitive to maternal folinic acid, myo-inositol or zinc supplementation. Birth Defects Res Part A:in press
Fujinaga M, Hoffman BB, Baden JM (1995) Axial rotation in rat embryos: morphological analysis and microsurgical study on the role of the allantois. Teratology 51:94–106
Garber ED (1952) Bent-tail, a dominant, sex-linked mutation in the mouse. Proc Natl Acad Sci USA 38:876–879
Gebbia M, Ferrero GB, Pilia G, Bassi MT, Aylsworth A, Penman-Splitt M, Bird LM, Bamforth JS, Burn J, Schlessinger D, Nelson DL, Casey B (1997) X-linked situs abnormalities result from mutations in ZIC3. Nat Genet 17:305–308
Harris MJ (2001) Why are the genes that cause risk of human neural tube defects so hard to find? Teratology 63:165–166
Harris MJ, Juriloff DM (1999) Mini-review: toward understanding mechanisms of genetic neural tube defects in mice. Teratology 60:292–305
Johnson DR (1976) The interfrontal bone and mutant genes in the mouse. J Anat 121:507–513
Juriloff DM, Harris MJ (2000) Mouse models for neural tube closure defects. Hum Mol Genet 9:993–1000
Kaufman MH (1992) The atlas of mouse development. Academic Press, London.
Klootwijk R, Franke B, van der Zee CE, de Boer RT, Wilms W, Hol FA, Mariman EC (2000) A deletion encompassing Zic3 in bent tail, a mouse model for X-linked neural tube defects. Hum Mol Genet 9:1615–1622
Li Q, Estepa G, Memet S, Israel A, Verma IM (2000) Complete lack of NF-kappaB activity in IKK1 and IKK2 double-deficient mice: additional defect in neurulation. Genes Dev 14:1729–1733
Lomaga MA, Henderson JT, Elia AJ, Robertson J, Noyce RS, Yeh WC, Mak TW (2000) Tumor necrosis factor receptor-associated factor 6 (TRAF6) deficiency results in exencephaly and is required for apoptosis within the developing CNS. J Neurosci 20:7384–7393
Navin A, Prekeris R, Lisitsyn NA, Sonti MM, Grieco DA, Narayanswami S, Lander ES, Simpson EM (1996) Mouse Y-specific repeats isolated by whole chromosome representational difference analysis. Genomics 36:349–353
Peeters MCE, Shum AS, Hekking JWM, Copp AJ, van Straaten HWM (1996) Relationship between altered axial curvature and neural tube closure in normal and mutant (curly tail) mouse embryos. Anat Embryol (Berl) 193:123–130
Peeters MCE, Hekking JWM, Shiota K, Drukker J, van Straaten HWM (1998) Differences in axial curvature correlate with species-specific rate of neural tube closure in embryos of chick, rabbit, mouse, rat and human. Anat Embryol (Berl) 198:185–194
Poelmann RE, Mentink MM, van Leeuwen JL (1987) Axial rotation of murine embryos, a study of asymmetric mitotic activity in the neural tube of somite stages. Anat Embryol (Berl) 176:99–103
Purandare SM, Ware SM, Kwan KM, Gebbia M, Bassi MT, Deng JM, Vogel H, Behringer RR, Belmont JW, Casey B (2002) A complex syndrome of left-right axis, central nervous system and axial skeleton defects in Zic3 mutant mice. Development 129:2293–2302
Ruland J, Duncan GS, Elia A, del BB, I, Nguyen L, Plyte S, Millar DG, Bouchard D, Wakeham A, Ohashi PS, Mak TW (2001) Bcl10 is a positive regulator of antigen receptor-induced activation of NF-kappaB and neural tube closure. Cell 104:33–42
Sabapathy K, Jochum W, Hochedlinger K, Chang L, Karin M, Wagner EF (1999) Defective neural tube morphogenesis and altered apoptosis in the absence of both JNK1 and JNK2. Mech Dev 89:115–124
Theiler K (1972) The house mouse. Springer, Berlin Heidelberg New York
van Straaten HWM, Hekking JWM, Copp AJ, Bernfield M (1992) Deceleration and acceleration in the rate of posterior neuropore closure during neurulation in the curly tail (ct) mouse embryo. Anat Embryol (Berl) 185:169–174
Acknowledgements
We thank Wiljan Wilms, Bianca Lemmers and Iris Elemans for providing care for the Bent tail mice, Dr. C.E.E.M. van der Zee for her help with the phenotype analysis, Mascha Schijvenaars for technical assistance, Hans Rensema for processing the SEM images and Dr. Carolien de Kovel for statistical analysis. Furthermore we would like to thank our colleagues for inspiring discussions at the NTD Symposium in Charleston, May 2002, and Dr. Madeleine Brouns for critically reading the manuscript. This study was supported by the Dutch Prinses Beatrix Fonds, grant 00-0208, and by the Dutch Organization for Scientific Research (ZonMW), grant 925-01-006.
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Franke, B., Klootwijk, R., Hekking, J.W.M. et al. Analysis of the embryonic phenotype of Bent tail, a mouse model for X-linked neural tube defects. Anat Embryol 207, 255–262 (2003). https://doi.org/10.1007/s00429-003-0345-2
