An improved method for the isolation and culture of retinal pigment epithelial cells from adult rats

Graefe's Archive for Clinical and Experimental Ophthalmology volume 253, pages 1493–1502 (2015)Cite this article

Abstract

Purpose

Since adult rats are used in pre-clinical studies, and due to the necessity of investigating the side-effects of drugs on RPE cells in vitro, there is a great need for primary RPE cells from these animals. The aim of this study was to develop a reproducible and quantifiable method of isolation, culture, and maintenance of adult rat RPE cells. Moreover, potential differences between RPE cells from albino versus pigmented rats were also investigated.

Methods

A total of 180 pigmented rats and 340 albino rats aged 6–14 weeks were used. RPE cells were isolated and cultured for several weeks by using three different methods: 1) growing directly on flat mounts, 2) after enzymatic isolation, and 3) after they spontaneously detached from the flat mounts and continued to grow on the plastic. Yield, cell survival, and morphological characteristics were investigated using light and electron microscopy as well as immunohistochemistry.

Results

After 0 weeks, the yield of the first method was 30,000 cells/eye; after 2 weeks 18,000 cells/eye; and after 4 weeks 11,000 cells/eye. The yield of RPE cells was very low after enzymatic isolation in method 2 (0 weeks, 13.000 cells/eye; 2 weeks, 30,000 cells/eye; 4 weeks 38,000 cells/eye), whereas it was higher when the RPE cells spontaneously detached from the flat mounts and then continued to grow on the plastic in method three. (0 weeks, 30,000 cells/eye; 2 weeks, 314,000 cells/eye; 4 weeks, 659,000 cells/eye). The second method often showed contamination with fibroblasts, whereas the two other methods showed pure RPE cultures. The RPE cells were able to proliferate when using the second and the third method, but not when they were cultivated directly on the flat mounts (first method).

Conclusion

The qualitative and quantitative best method for isolating adult rat RPE cells is the culture of RPE cells which spontaneously detach from flat mounts. No differences were observed between albino and pigmented RPE cells.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7

References

  1. Stroeva OG, Panova IG (1983) Retinal pigment epithelium: pattern of proliferative activity and its regulation by intraocular pressure in postnatal rats. Embryol Exp Morphol 75:271

    CAS  Google Scholar

  2. Schraermeyer U, Heimann K (1999) Current understanding on the role of retinal pigment epithelium and its pigmentation. Pigment Cell Res 12(4):219–36

    Article  CAS  PubMed  Google Scholar

  3. Mecklenburg L, Schraermeyer U (2007) An overview on the toxic morphological changes in the retinal pigment epithelium after systemic compound administration. Toxicol Pathol 35:252–267

    Article  CAS  PubMed  Google Scholar

  4. Konari K, Sawada N, Zhong Y, Isomura H, Nakagawa T, Mori M (1995) Development of the blood-retinal barrier in vitro: formation of tight junctions as revealed by occludin and ZO-1 correlates with the barrier function of chick retinal pigment epithelial cells. Exp Eye Res 61:99–108

    Article  CAS  PubMed  Google Scholar

  5. Rizzolo LJ (1997) Polarity and the development of the outer blood-retinal barrier. Histol Histopathol 12(4):1057–67

    CAS  PubMed  Google Scholar

  6. Zinn KM, Greenseid DZ (1975) Toxicology of the retinal pigment epithelium. Int Ophthalmol Clin 15:147–58

    Article  CAS  PubMed  Google Scholar

  7. Koneru PB, Lienm EJ, Koda RT (1986) Oculotoxicities of systemically administered drugs. Ocul Pharmacol 2:385–404

    Article  CAS  Google Scholar

  8. Moorthy RS, Valluri S (1999) Ocular toxicity associated with systemic drug therapy. Curr Opin Ophthalmol 10:438–46

    Article  CAS  PubMed  Google Scholar

  9. Thumann G, Hoffmann S, Hinton DR (2006) Cell Biology of the Pigment Epithelium. In: Ryan SJ (ed) Retina., fourth ed. Elsevier Inc, Philadelphia, pp 137–152

    Chapter  Google Scholar

  10. Young RW, Bok D (1969) Participation of the retinal pigment epithelium in the rod outer segment renewal process. Cell Biol 42:392

    Article  CAS  Google Scholar

  11. Mayerson PL, Hall MO (1983) Rat retinal pigment epithelial cells show specificity of phagocytosis in vitro. (Abst). Cell Biol 97:425a

    Article  Google Scholar

  12. Tamai M, Chader GJ (1979) The early appearance of disc shedding in the rat retina. Invest Ophthalmol Vis Sci 18:913

    CAS  PubMed  Google Scholar

  13. Mannagh J, Ayra DV, Irvine AR (1973) Tissue culture of human retinal pigment epithelium. Invest Ophthalmol Vis Sci 12:52–64

    CAS  Google Scholar

  14. Flood MT, Gouras P, Kjeldbye H (1980) Growth characteristics and ultrastructure of human retinal pigment epithelium in vitro. Invest Ophthalmol Vis Sci 19:1309–1320

    CAS  PubMed  Google Scholar

  15. Edwards RB (1982) Glycosaminoglycan synthesis by cultured human retinal pigmented epithelium from normal postmortem donors and a postmortem donor with retinitis pigmentosa. Invest Ophthalmol Vis Sci 23:435–446

    CAS  PubMed  Google Scholar

  16. Anderson RE, Oissandrello PM, Maude MB, Mathes MT (1976) Lipids of bovine retinal pigment epithelium. Exp Eye Res 23:149–157

    Article  CAS  PubMed  Google Scholar

  17. Saari JC, Bunt AH, Futterman S, Berman ER (1977) Localization of cellular retinal-binding protein in bovine retina and retinal pigment epithelium, with a consideration of the pigment epithelium isolation technique. Invest Ophthalmol Vis Sci 16(9):797–806

    CAS  PubMed  Google Scholar

  18. Heller J, Jones P (1980) Purification of bovine retinal pigment epithelial cells by dissociation in calcium free buffers and centrifugation in Ficoll density gradients followed by "recovery" in tissue culture. Exp Eye Res 30:481–487

    Article  CAS  PubMed  Google Scholar

  19. Salceda R (1986) Isolation and biochemical characterization of frog retinal pigment epithelium cells. Invest Ophthalmol Vis Sci 27:1172–1176

    CAS  PubMed  Google Scholar

  20. Edwards RB (1981) The isolation and culturing of retinal pigment epithelium of the rat. Vis Res 21:147–150

    Article  CAS  PubMed  Google Scholar

  21. Mayerson PL, Hall MO, Clark V, Abrams T (1985) An improved method for isolation and culture of rat retinal pigment epithelial cells. Invest Ophthalmol Vis Sci 26:1599–1609

    CAS  PubMed  Google Scholar

  22. Wang N, Koutz CA, Anderson (1993) A method for the isolation of Retinal Pigment Epithelial Cells From Adult Rats. Invest Ophthalmol Vis Sci 34:101–107

    CAS  PubMed  Google Scholar

  23. Xin-Zhao Wang C, Zhang K, Aredo B, Lu H (2012) Ufret-Vincenty RL: novel method for the rapid isolation of RPE cells specifically for RNA extraction and analysis. Exp Eye Res 102:1–9

    Article  PubMed  Google Scholar

  24. Blenkinsop TA, Salero E, Stern JH, Temple S (2013) The culture and maintenance of functional retinal pigment epithelial monolayers from adult human eye. Methods Mol Biol 945:45–65

    Article  PubMed  Google Scholar

  25. Mc Menamin PG (2000) Optimal methods for preparation and immunostaining of iris, ciliar body and choroidal wholemounts. Invest Ophthalmol Vis Sci 41:3043–3048

    CAS  Google Scholar

  26. Arnhold S, Heiduschka P, Klein H, Absenger Y, Basnaoglu S, Kreppel F, Henke-Fahle S, Kochankek S, Bartz-Schmidt KU, Addicks K, Schraermeyer U (2006) Adenovirally transduced bone marrow stromal cells differentiate into pigment epithelial cells and induce rescue effects in RCS rats. Invest Ophthalmol Vis Sci 47(9):4121–4129

    Article  PubMed  Google Scholar

  27. Sakagami K, Naka H, Hayashi A, Kamei M, Sasabe T, Tano Y (1995) A rapid method for isolation of retinal pigment epithelial cells from rat eyeballs. Ophthalmic Res 27(5):262–7

    Article  CAS  PubMed  Google Scholar

  28. Zauberman H (1979) Adhesive forces between the retinal pigment epithelium and sensory retina. In: Zinn KM, Marmor MF (eds) The retinal pigment epithelium. Harvard University Press, Cambridge, pp 192–204

    Google Scholar

  29. Zinn KM, Benjamin-Henkind JV (1979) Anatomy of the human retinal pigment epithelium. In: Zinn KM, Marmor MF (eds) The retinal pigment epithelium. Harvard University Press, Cambridge, pp 3–31

    Google Scholar

  30. Weidman TA, Kuwabara T (1968) Postnatal development of the rat retina. Arch Ophthalmol 79:470–484

    Article  CAS  PubMed  Google Scholar

  31. Hall MO, Quon DS (1981) Tissue culture of rat pigment epithelium on different supporting media. Vis Res 21:127

    Article  CAS  PubMed  Google Scholar

  32. Clark VM, Hall MO, Mayerson PL, Schechter C (1984) Identification of some plasma membrane proteins of cultured rat pigment epithelial cells. Exp Eye Res 39:611

    Article  CAS  PubMed  Google Scholar

Download references

Acknowledgments

The authors thank Monika Rittgarn, Sabine Hofmeister, and Sigrid Schultheiss for their excellent technical assistance and Judith Birch for her great editorial support. (Section of Experimental Vitreoretinal Surgery, Centre for Ophthalmology, Tuebingen, Germany).

Conflict of interest

The authors have no conflict of interest concerning this work. Ulrich Schraermeyer has funding for his research by Novartis Pharma; however, this is not related to the present project.

Ethical approval

All authors hereby declare that "Principles of laboratory animal care" (NIH publication No. 85–23, revised 1985) were followed, as well as specific national laws, where applicable. All experiments have been examined and approved by the appropriate ethics committee.
