Analysed snoring sounds correlate to obstructive sleep disordered breathing

European Archives of Oto-Rhino-Laryngology volume 265, pages 105–113 (2008)Cite this article

Abstract

Snoring occurs as a major symptom in patients with sleep disordered breathing (SDB). The aetiology of snoring remains still unclear despite various attempts to localize snoring. The correlation between different snoring sounds and the severity of SDB has not yet been investigated in a larger population. The aim of this study was to record and analyse snoring sounds and to correlate the obtained data with clinical and polysomnographical parameters. Sixty male patients with suspected SDB and reported snoring underwent a clinical examination and night time polysomnography. The parallel digitally recorded snoring sounds were analysed by fast fourier transformation (FFT). Peak intensity was determined from the power spectrum. The periodicity of snoring was classified into rhythmic and non-rhythmic snoring according to the presence of air flow interruptions due to obstructive apneas. Patients with primary snoring revealed peak intensities between 100 and 300 Hz. Patients with an obstructive sleep apnea syndrome (OSAS) revealed peak intensities above 1,000 Hz. Polysomnographical data (AHI, mean and minimum SpO2) as well as body mass index (BMI) correlated with peak intensity of the power spectrum. None of the parameters of the clinical examination correlated with peak intensity. Frequency analysis of snoring sounds provides a useful diagnostic tool to distinguish between different patterns of snoring and respective SDB. The topodiagnosis of snoring is not possible by means of frequency analysis or clinical examination alone. Acoustical analysis of snoring sounds seems a promising additional diagnostic tool to verify different types of SDB in snoring patients.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7

References

  1. (1995) AARC-APT (American Association of Respiratory Care–Association of Polysomnography Technologists) clinical practice guideline. Polysomnography. Respir Care 40(12): 1336–1343

  2. Agrawal S, Stone P, McGuinness K, Morris J, Camilleri AE (2002) Sound frequency analysis and the site of snoring in natural and induced sleep. Clin Otolaryngol Allied Sci 27(3):162–166

    PubMed  Article  CAS  Google Scholar

  3. Bao G, Guilleminault C (2004) Upper airway resistance syndrome–one decade later. Curr Opin Pulm Med 10(6):461–467

    PubMed  Article  Google Scholar

  4. Berg S, Cole P, Hoffstein V, Haight JS (2001) Upper airway pressures in snorers and nonsnorers during wakefulness and sleep. J Otolaryngol 30(2):69–74

    PubMed  Article  CAS  Google Scholar

  5. Bonora M, St John WM, Bledsoe TA (1985) Differential elevation by protriptyline and depression by diazepam of upper airway respiratory motor activity. Am Rev Respir Dis 131(1):41–45

    PubMed  CAS  Google Scholar

  6. Chervin RD, Guilleminault C (1996) Obstructive sleep apnea and related disorders. Neurol Clin 14(3):583–609

    PubMed  Article  CAS  Google Scholar

  7. Counter P, Wilson JA (2004) The management of simple snoring. Sleep Med Rev 8(6):433–441

    PubMed  Google Scholar

  8. Croft CB, Pringle M (1991) Sleep nasendoscopy: a technique of assessment in snoring and obstructive sleep apnoea. Clin Otolaryngol Allied Sci 16(5):504–509

    PubMed  Article  CAS  Google Scholar

  9. Dalmasso F, Prota R (1996) Snoring: analysis, measurement, clinical implications and applications. Eur Respir J 9(1):146–159

    PubMed  Article  CAS  Google Scholar

  10. Dreher A, de la Chaux R, Klemens C, Werner R, Baker F, Barthlen G, Rasp G (2005) Correlation between otorhinolaryngologic evaluation and severity of obstructive sleep apnea syndrome in snorers. Arch Otolaryngol Head Neck Surg 131(2):95–98

    PubMed  Article  Google Scholar

  11. Fiz JA, Abad J, Jane R, Riera M, Mananas MA, Caminal P, Rodenstein D, Morera J (1996) Acoustic analysis of snoring sound in patients with simple snoring and obstructive sleep apnoea. Eur Respir J 9(11):2365–2370

    PubMed  Article  CAS  Google Scholar

  12. Hara H, Murakami N, Miyauchi Y, Yamashita H (2006) Acoustic analysis of snoring sounds by a multidimensional voice program. Laryngoscope 116(3):379–381

    PubMed  Article  Google Scholar

  13. Herzog M, Metz T, Schmidt A, Bremert T, Venohr B, Hosemann W, Kaftan H (2006) The prognostic value of simulated snoring in awake patients with suspected sleep-disordered breathing: introduction of a new technique of examination. Sleep 29(11):1456–1462

    PubMed  Google Scholar

  14. Jones TM, Ho MS, Earis JE, Swift AC, Charters P (2006) Acoustic parameters of snoring sound to compare natural snores with snores during “steady-state” propofol sedation. Clin Otolaryngol 31(1):46–52

    PubMed  Article  CAS  Google Scholar

  15. Marais J (1998) The value of sedation nasendoscopy: a comparison between snoring and non-snoring patients. Clin Otolaryngol Allied Sci 23(1):74–76

    PubMed  Article  CAS  Google Scholar

  16. Miyazaki S, Itasaka Y, Ishikawa K, Togawa K (1998) Acoustic analysis of snoring and the site of airway obstruction in sleep related respiratory disorders. Acta Otolaryngol (Suppl 537):47–51

  17. Okada T, Fukatsu H, Ishigaki T, Yasuma F, Kayukawa Y (1996) Ultra-low-field magnetic resonance imaging in upper airways obstruction in sleep apnea syndrome. Psychiatry Clin Neurosci 50(5):285–289

    PubMed  CAS  Article  Google Scholar

  18. Osborne JE, Osman EZ, Hill PD, Lee BV, Sparkes C (1999) A new acoustic method of differentiating palatal from non-palatal snoring. Clin Otolaryngol Allied Sci 24(2):130–133

    PubMed  Article  CAS  Google Scholar

  19. Perez-Padilla JR, Slawinski E, Difrancesco LM, Feige RR, Remmers JE, Whitelaw WA (1993) Characteristics of the snoring noise in patients with and without occlusive sleep apnea. Am Rev Respir Dis 147(3):635–644

    PubMed  CAS  Google Scholar

  20. Quinn SJ, Huang L, Ellis PD, Williams JE (1996) The differentiation of snoring mechanisms using sound analysis. Clin Otolaryngol Allied Sci 21(2):119–123

    PubMed  Article  CAS  Google Scholar

  21. Roosli C, Schneider S, Hausler R (2006) Long-term results and complications following uvulopalatopharyngoplasty in 116 consecutive patients. Eur Arch Otorhinolaryngol 263(8):754–758

    PubMed  Article  Google Scholar

Download references

Author information

Affiliations

  1. Department of Oto-Rhino-Laryngology, Head and Neck Surgery, Ernst-Moritz-Arndt University, Walther-Rathenau-Street 43-45, 17487, Greifswald, Germany

    Herzog Michael, Bremert Thomas, Hosemann Werner & Kaftan Holger

  2. Department of Oto-Rhino-Laryngology, Head and Neck Surgery, University of Würzburg, Würzburg, Germany

    Schmidt Andreas

  3. Institute of Community Medicine, Section Epidemiology of Health Care and Community Health, Ernst-Moritz-Arndt University, Greifswald, Germany

    Herzog Beatrice

Authors
  1. Herzog Michael
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Schmidt Andreas
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Bremert Thomas
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Herzog Beatrice
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Hosemann Werner
    View author publications

    You can also search for this author in PubMed Google Scholar

  6. Kaftan Holger
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to Herzog Michael.

Rights and permissions

Reprints and Permissions

About this article

Cite this article

Michael, H., Andreas, S., Thomas, B. et al. Analysed snoring sounds correlate to obstructive sleep disordered breathing. Eur Arch Otorhinolaryngol 265, 105–113 (2008). https://doi.org/10.1007/s00405-007-0408-8

Download citation

  • Received:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s00405-007-0408-8

Keywords

  • Snoring
  • Frequency analysis
  • Peak intensity
  • Obstructive sleep apnea syndrome
