Abstract
Background
Treatment of lesions in small coronary arteries by percutaneous transluminal coronary intervention is limited by a high recurrence rate. We assessed the use of a paclitaxel-coated balloon in this indication.
Methods
One-hundred eighteen patients with stenoses in small coronary vessels were treated by a paclitaxel-coated balloon (3 μg/mm2). The main inclusion criteria encompassed diameter stenosis of ≥70% and ≤22 mm in length with a vessel diameter of 2.25–2.8 mm. Follow-up angiography was performed at scheduled 6-month post-intervention or whenever driven by clinical or electrocardiographic signs of ischemia. The primary endpoint was angiographic in-segment late lumen loss.
Results
Eighty-two of 118 patients (70%) with a vessel diameter of 2.35 ± 0.19 mm were treated with the drug-coated balloon only, while 32 patients required additional stent deployment. The mean in-segment late lumen loss was 0.28 ± 0.53 mm. In patients treated with the drug-coated balloon only, the in-segment late lumen loss was 0.16 ± 0.38 mm. At 12 months, the rate of major adverse cardiac events was 15% which was primarily due to the need for target lesion revascularization in 14 patients (12%). In those with additional bare metal stent implantation geographical mismatch between coated-balloon dilatation and stent implantation was significantly associated with the occurrence of restenosis.
Conclusion
Treatment of coronary stenosis in small coronary vessels with the paclitaxel-coated balloon was well tolerated. It may offer an alternative to the implantation of a drug-eluting stent (ClinicalTrials.gov Identifier: NCT00404144).
Similar content being viewed by others
References
Moreno R, Fernández C, Alfonso F, Hernández R, Pérez-Vizcayno MJ, Escaned J, Sabaté M, Bañuelos C, Angiolillo DJ, Azcona L, Macaya C (2004) Coronary stenting versus balloon angioplasty in small vessels: a meta-analysis from 11 randomized studies. J Am Coll Cardiol 43:1964–1972
Agostoni P, Biondi-Zoccai GG, Gasparini GL, Anselmi M, Morando G, Turri M, Abbate A, McFadden EP, Vassanelli C, Zardini P, Colombo A, Serruys PW (2005) Is bare-metal stenting superior to balloon angioplasty for small vessel coronary artery disease? Evidence from a meta-analysis of randomized trials. Eur Heart J 26:881–889
Hausleiter J, Kastrati A, Mehilli J, Schühlen H, Pache J, Dotzer F, Dirschinger J, Schömig A (2002) Predictive factors for early cardiac events and angiographic restenosis after coronary stent placement in small coronary arteries. J Am Coll Cardiol 40:882–889
Waksman R (1999) Late thrombosis after radiation. Sitting on a time bomb. Circulation 100:780–782
Verin V, Popowski Y, de Bruyne B, Baumgart D, Sauerwein W, Lins M, Kovacs G, Thomas M, Calman F, Disco C, Serruys PW, Wijns W, Dose-Finding Study Group (2001) Endoluminal beta-radiation therapy for the prevention of coronary restenosis after balloon angioplasty. The Dose-Finding Study Group. N Engl J Med 344:243–249
Brunner-La Rocca HP, Kaiser C, Pfisterer M (2007) BASKET Investigators. Targeted stent use in clinical practice based on evidence from the Basel Stent Cost Effectiveness Trial (BASKET). Eur Heart J 28:719–725
Joner M, Finn AV, Farb A, Mont EK, Kolodgie FD, Ladich E, Kutys R, Skorija K, Gold HK, Virmani R (2006) Pathology of drug-eluting stents in humans: delayed healing and late thrombotic risk. J Am Coll Cardiol 48:193–202
Carlsson J, von Wagenheim B, Linder R, Anwari TM, Qvist J, Petersson I, Magounakis T, Lagerqvist B (2007) Is late stent thrombosis in drug-eluting stents a real clinical issue? A single-center experience and review of the literature. Clin Res Cardiol 96:86–93
Scheller B, Hehrlein C, Bocksch W, Rutsch W, Haghi D, Dietz U, Böhm M, Speck U (2006) Treatment of in-stent restenosis with a paclitaxel-coated balloon catheter. N Engl J Med 355:2113–2124
Tepe G, Zeller T, Albrecht T, Heller S, Schwarzwälder U, Beregi JP, Claussen CD, Oldenburg A, Scheller B, Speck U (2008) Local taxane with short exposure for reduction of restenosis in distal arteries: THUNDER trial. N Engl J Med 358:689–699
Cutlip DE, Windecker S, Mehran R et al (2007) Clinical end points in coronary stent trials: a case for standardized definitions. Circulation 115:2344–2351
ICH Harmonized Tripartite Guideline (1994) Clinical safety data management: definitions and standards for expedited reporting E2A. International conference on harmonisation of technical requirements for registration of pharmaceuticals for human use, October 1994. Available at: http://www.ich.org/LOB/media/MEDIA436.pdf. Accessed 23 Jun 2006
Park SW, Lee CW, Hong MK, Kim JJ, Cho GY, Nah DY, Park SJ (2000) Randomized comparison of coronary stenting with optimal balloon angioplasty for treatment of lesions in small coronary arteries. Eur Heart J 21:1785–1789
Kastrati A, Schömig A, Dirschinger J, Mehilli J, Dotzer F, von Welser N, Neumann FJ (2000) A randomized trial comparing stenting with balloon angioplasty in small vessels in patients with symptomatic coronary artery disease. ISAR-SMART Study Investigators. Intracoronary Stenting or Angioplasty for Restenosis Reduction in Small Arteries. Circulation 102:2593–2598
Koning R, Chan C, Eltchaninoff H, Tron C, Janorkar S, Gupta V, Cribier A (1998) Primary stenting of de novo lesions in small coronary arteries: a prospective, pilot study. Cathet Cardiovasc Diagn 45:235–238
Hausleiter J, Kastrati A, Mehilli J, Schühlen H, Pache J, Dotzer F, Glatthor C, Siebert S, Dirschinger J, Schömig A (2004) ISAR-SMART-2 Investigators. A randomized trial comparing phosphorylcholine-coated stenting with balloon angioplasty as well as abciximab with placebo for restenosis reduction in small coronary arteries. J Intern Med 256:388–397
Schofer J, Schluter M, Gershlick AH, Wijns W, Garcia E, Schampaert E, Breithardt G (2003) Sirolimus-eluting stents for treatment of patients with long atherosclerotic lesions in small coronary arteries: double-blind, randomised controlled trial (E-SIRIUS). Lancet 362:1093–1099
Ardissino D, Cavallini C, Bramucci E, Indolfi C, Marzocchi A, Manari A, Angeloni G, Carosio G, Bonizzoni E, Colusso S, Repetto M, Merlini PA (2004) SES-SMART Investigators. Sirolimus-eluting vs uncoated stents for prevention of restenosis in small coronary arteries: a randomized trial. JAMA 292:2727–2734
Mehilli J, Dibra A, Kastrati A, Pache J, Dirschinger J, Schömig A (2006) Intracoronary Drug-Eluting Stenting to Abrogate Restenosis in Small Arteries (ISAR-SMART 3) Study Investigators. Eur Heart J 27:260–266
Morice MC, Colombo A, Meier B, Serruys P, Tamburino C, Guagliumi G, Sousa E, Stoll HP, REALITY Trial Investigators (2006) Sirolimus- vs paclitaxel-eluting stents in de novo coronary artery lesions: the REALITY trial: a randomized controlled trial. JAMA 295:895–904
Stone GW, Ellis SG, Cannon L, Mann JT, Greenberg JD, Spriggs D, O’Shaughnessy CD, DeMaio S, Hall P, Popma JP, Koglin J, Russell ME, for the TAXUS V Investigators (2005) Comparison of a polymer-based paclitaxel-eluting stent with a bare metal stent in patients with complex coronary artery disease. A randomized controlled trial. JAMA 294:1215–1223
Elezi S, Dibra A, Mehilli J, Pache J, Wessely R, Schömig A, Kastrati A (2006) Vessel size and outcome after coronary drug-eluting stent placement: results from a large cohort of patients treated with sirolimus- or paclitaxel-eluting stents. J Am Coll Cardiol 48:1304–1309
Tanimoto S, Daemen J, Tsuchida K, García-García HM, de Jaegere P, van Domburg RT, Serruys PW (2007) Two-year clinical outcome after coronary stenting of small vessels using 2.25-mm sirolimus- and paclitaxel-eluting stents: insight into the RESEARCH and T-SEARCH registries. Catheter Cardiovasc Interv 69(1):94–103
Scheller B, Speck U, Abramjuk C, Bernhardt U, Böhm M, Nickenig G (2004) Paclitaxel balloon coating—a novel method for prevention and therapy of restenosis. Circulation 110:810–814
Speck U, Scheller B, Abramjuk C, Breitwieser C, Dobberstein J, Böhm M, Hamm B (2006) Neointima inhibition: comparison of effectiveness of non-stent-based local drug delivery and a drug-eluting stent in porcine coronary arteries. Radiology 240:411–418
Cremers C, Speck U, Kaufels N, Mahnkopf D, Kühler M, Böhm M (2009) Scheller B: drug-eluting balloon: very short-term exposure and overlapping. Thromb Haemost 101:201–206
Scheller B, Hehrlein C, Bocksch W, Rutsch W, Haghi D, Dietz U, Böhm M, Speck U (2008) Two year follow-up after treatment of coronary in-stent restenosis with a paclitaxel-coated balloon catheter. Clin Res Cardiol 97:773–781
Unverdorben M, Vallbracht C, Heuer H, Hengstenberg C, Maikowski C, Werner GS, Antoni D, Kleber FX, Bocksch W, Leschke M, Ackermann H, Boxberger M, Speck U, Degenhardt R, Scheller B (2009) Paclitaxel-coated balloon catheter versus paclitaxel-coated stent for the treatment of coronary in-stent restenosis. Circulation 119:2986–2994
Werk M, Langner S, Reinkensmeier B, Boettcher HF, Tepe G, Dietz U, Hosten N, Hamm B, Speck U, Ricke J (2008) Inhibition of restenosis in femoropopliteal arteries: paclitaxel-coated versus uncoated balloon—FemPac randomized pilot trial. Circulation 118:1358–1365
Scheller B, Speck U, Böhm M (2007) Prevention of restenosis—is angioplasty the answer? Heart 93:539–541
Virmani R, Guagliumi G, Farb A, Musumeci G, Grieco N, Motta T, Mihalcsik L, Tespili M, Valsecchi O, Kolodgie FD (2004) Localized hypersensitivity and late coronary thrombosis secondary to a sirolimus-eluting stent: should we be cautious? Circulation 109:701–705
King SB 3rd, Smith SC Jr, Hirshfeld JW Jr, Jacobs AK, Morrison DA, Williams DO, WRITING COMMITTEE MEMBERS, Feldman TE, Kern MJ, O’Neill WW, Schaff HV, Whitlow PL, Adams CD, Anderson JL, Buller CE, Creager MA, Ettinger SM, Halperin JL, Hunt SA, Krumholz HM, Kushner FG, Lytle BW, Nishimura R, Page RL, Riegel B, Tarkington LG, Yancy CW (2008) 2007 Focused Update of the ACC/AHA/SCAI 2005 Guideline Update for Percutaneous Coronary Intervention: a report of the American College of Cardiology/American Heart Association Task Force on Practice Guidelines: 2007 Writing Group to Review New Evidence and Update the ACC/AHA/SCAI 2005 Guideline Update for Percutaneous Coronary Intervention, Writing on Behalf of the 2005 Writing Committee. Circulation 117:261–295
Herdeg C, Göhring-Frischholz K, Haase KK, Geisler T, Zürn C, Hartmann U, Wöhrle J, Nusser T, Dippon J, May AE, Gawaz M (2009) Catheter-based delivery of fluid paclitaxel for prevention of restenosis in native coronary artery lesions after stent implantation. Circ Cardiovasc Intervent 2:294–301
Acknowledgments
The study was supported by B. Braun Melsungen, Germany. Dr. Unverdorben receives salaries from the Institut für Klinische Forschung, Herz- und Kreislaufzentrum, Rotenburg an der Fulda, Germany; end of 2008 (after finishing this trial) he became an employee of B. Braun USA (orthopedics and medical affairs). Prof. Scheller reports being co-inventor of a patent application for various methods of restenosis inhibition, including the technique employed in this trial, by Charité University Hospital, Berlin.
Author information
Authors and Affiliations
Corresponding author
Appendix: PEPCAD I Study Group
Appendix: PEPCAD I Study Group
Principal Investigator: Martin Unverdorben, Institut für Klinische Forschung, Herz- und Kreislaufzentrum, Rotenburg an der Fulda, Germany
CRO and Angiographic Core Lab: Ralf Degenhardt, Institut für Klinische Forschung, Herz- und Kreislaufzentrum, Rotenburg an der Fulda, Germany. Staff: Tina Iffland, Melanie Häußler
Statistical Advisor: Hanns Ackermann, Zentrum für medizinische Informatik, Abteilung für Biomathematik, Universität Frankfurt/Main, Germany
Klinik für Innere Medizin, Unfallkrankenhaus Berlin, Charité Universitätsmedizin, Berlin, Germany: Franz X. Kleber, Sascha Rux, Daniel Grund; Heike Bull; 50 patients
Medizinische Klinik, Kardiologie, St. Johannes Hospital, Dortmund, Germany: Hubertus Heuer, Norbert Schulze Waltrup, Joachim Weber-Albers, Maritta Marks, Axel Bünemann, Dietmar Schmitz, Mathias Stratmann; Martin Schulz, Claudia Rosendahl, Birgit Laschewski, Alexandra Thrun, Kathrin Euler, Ute Dieckheuer; 35 patients
Klinik für Innere Medizin, Universitätsklinikum Jena, Germany: Stefan Betge, Hans-Reiner Figulla; 13 patients
Kardiologische Klinik, Herz- und Kreislaufzentrum, Rotenburg an der Fulda, Germany: Christian Vallbracht, Manfred Scholz, Henning Köhler, Bernd Abt, Eberhard Wagner; seven patients
Klinik für Kardiologie, Pneumologie und Angiologie, Klinikum Esslingen, Germany: Matthias Leschke, Jean Rieber; Birgit Blaich; eight patients
Klinik für Innere Medizin III, Universitätsklinikum des Saarlandes, Homburg/Saar, Germany: Bruno Scheller, Bodo Cremers, Michael Kindermann, Michael Böhm; Nicole Hollinger, Bianca Werner; four patients
Innere Medizin III, Universitätsklinikum Heidelberg, Germany: Helmut Kücherer, Stefan Hardt; Christiane Selter; two patients
Universitätsklinik und Poliklinik für Innere Medizin III, Halle, Germany: Michael Buerke; Michaela König; one patient
