Regeneration of herbicide-tolerant black locust transgenic plants by SAAT

  • Genetic Transformation and Hybridization
  • Published:
Plant Cell Reports Aims and scope Submit manuscript

Abstract

A protocol based on SAAT (sonication-assisted Agrobacterium-mediated transformation) has been developed to obtain herbicide-resistant transgenic black locust (Robinia pseudoacacia L.) plants. Cotyledon explants were co-cultivated with Agrobacterium AGL1 strain carrying the pTAB16 plasmid (bar and gusA genes). The effects of bacterial concentration (OD550 of 0.3, 0.6, 0.8) and method of infection (sonication vs immersion) on bacterial delivery were determined by assaying cotyledons for transient β-glucuronidase expression 3 days after infection. SAAT increases transient expression efficiency especially at an OD550 of 0.6. After determining bacterial concentration and infection method, other factors affecting transformation efficiency, such as explant preconditioning and period of time before applying selection, were tested. From these experiments, the preferred protocol for black locust cotyledon transformation should include sonication of preconditioned cotyledons in AGL1 suspension, coculture for 3 days with 100 µM acetosyringone and transfer to selection medium with 4 mg/l phosphinothricin and 150 mg/l timentin. Of the initial explants, 2% produced at least one transgenic shoot. Genetic transformation was confirmed by Southern hybridization, chlorophenol red assay and herbicide tolerance of the regenerated plants.

This is a preview of subscription content, log in via an institution to check access.

Access this article

Log in via an institution

Price excludes VAT (USA)
Tax calculation will be finalised during checkout.

Instant access to the full article PDF.

Institutional subscriptions

Fig. 1
Fig. 2a,b
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7

Similar content being viewed by others

Abbreviations

AS :

Acetosyringone

BA :

N-(Phenylmethyl)-1H-purin-6-amine (benzyladenine)

CR :

Chlorophenol red

2,4-D :

2,4-Dichlorophenoxyacetic acid

GUS :

β-Glucuronidase

IAA :

Indole-3-acetic acid

IBA :

Indole-3-butyric acid

PPT :

Phosphinothricin

References

  • Arrillaga I, Merkle SA (1993) Regenerating plants from in vitro culture of black locust cotyledon and leaf explants. HortScience 28:942–945

    Google Scholar

  • Arrillaga I, Merkle SA (1994) Transient gene expression in embryogenic black locust cultures following microprojectile bombardment. In: Pardos JA, Ahuja MR, Rossello RE (eds) Biotechnology of trees. Proc IUFRO Working Party, Rev Invest Agra Ser Sist: Rec Fore. Fuera de Serie N.4:209–213

  • Doyle JJ, Doyle JL (1990) Isolation of plant DNA from fresh tissue. Focus 12:13–15

    Google Scholar

  • Gamborg OL, Miller RA, Ojima K (1968) Nutrient requirements of suspension cultures of soybean root cells. Exp Cell Res 50:151–158

    CAS  PubMed  Google Scholar

  • Han HK, Gordon MP, Keathley DE (1999) Genetic transformation of Black locust (Robinia pseudoacacia L.) In: Bajaj YPS (ed) Biotechnology in agriculture and forestry, vol 44. Transgenic trees. Springer, Berlin Heidelberg New York, pp 273–282

  • Igasaki T, Mohri T, Ichikawa H Shinohara K (2000) Agrobacterium tumefaciens-mediated transformation of Robinia pseudoacacia. Plant Cell Rep 19:448–453

    CAS  Google Scholar

  • Jefferson RA, Kavanagh TA, Bevan MV (1987) GUS fusions: β-glucuronidase as a sensitive and versatile gene fusion marker in higher plants. EMBO J 6:3901–3907

    CAS  PubMed  Google Scholar

  • Kramer C, DiMaio J, Carswell GK, Shillito R (1993) Selection of transformed protoplast-derived Zea mays colonies with phosphinotricin and a novel assay using pH indicator chlorophenol red. Planta 190:454–458

    CAS  Google Scholar

  • Lazo GR, Stein PA, Ludwig RA (1991) A DNA transformation-competent Arabidopsis genomic library in Agrobacterium. Biotechnology 9:963–967

    CAS  PubMed  Google Scholar

  • Lloyd G, McCown B (1980) Commercially feasible micropropagation of mountain laurel, Kalmia latifolia, by use of shoot-tip culture. Comb Proc Intl Plant Prop Soc 30:421–427

    Google Scholar

  • Merkle SA, Wiecko AT (1989) Regeneration of Robinia pseudoacacia via somatic embryogenesis. Can J For Res 19:285–288

    Google Scholar

  • Mitchell CP (1988) The world perspective. In: Hummel RC, Palz W, Grassi G (eds) Biomass forestry in Europe: a strategy for the future. Elsevier, Barking, UK

  • Murashige T, Skoog F (1962) A revised medium for rapid growth bioassays with tobacco tissue culture. Physiol Plant 15:473–497

    CAS  Google Scholar

  • Peña L, Cervera M, Juárez J, Ortega C, Pina JA, Durán-Vila N, Navarro L (1995) High efficiency Agrobacterium-mediated transformation and regeneration of citrus. Plant Sci 104:183–191

    CAS  Google Scholar

  • Ranney JW, Ehrenshaft AR, Layton PA, McNabb WA, Wright LL (1988) Short rotation woody crops program annual progress report for 1987. Oak Ridge Natl Lab Rep, ORNL 6440, Oak Ridge, Tenn.

  • Sales E, Segura J, Arrillaga I (2003) Agrobacterium tumefaciens-mediated genetic transformation of the cardenolide-producing plant Digitalis minor L. Planta Med 69:143–147

    Article  CAS  PubMed  Google Scholar

  • Schenk RV, Hildebrandt AL (1972) Medium and techniques for induction and growth of monocotyledonous and dicotyledonous plant cell cultures. Can J Bot 50:199–204

    CAS  Google Scholar

  • Schröeder HE, Schotz AH, Wardley-Richardson T, Spencer D, Higgins TJV (1993) Transformation and regeneration of two cultivars of pea (Pisum sativum L.). Plant Physiol 101:751–757

    CAS  Google Scholar

  • Toki S, Takamatsu S, Noriri C, Ooba S, Anzai H, Iwata M, Christensen AH, Quail PH, Uchimiya H (1992) Expression of a maize ubiquitin gene promoter-bar chimeric gene in transgenic rice plants. Plant Physiol 100:1503–1507

    CAS  Google Scholar

  • Trick HN, Finer JJ (1997) SAAT: sonication-assisted Agrobacterium-mediated transformation. Transgenic Res 6:329–336

    CAS  Google Scholar

  • Tukey JW (1953) Some selected quick and easy methods of statistical analysis. Trans N Y Acad Sci Ser II 16:88–97

    Google Scholar

  • You W, Barker AV (2002) Herbicidal actions of root-applied glufosinate ammonium on tomato plants. J Am Soc Hortic Sci 127:200–204

    CAS  Google Scholar

Download references

Acknowledgements

The financial support of the former IVEI (Generalitat Valenciana, Spain, Project 002/075) is gratefully acknowledged. We thank Drs. S. González-Nebauer (UPV) and C. Roig for their technical support.

Author information

Authors and Affiliations

  1. Dpt. Biología Vegetal, Facultad de Farmacia, Universidad de Valencia, 46100 , Burjassot, Valencia, Spain

    C. Zaragozá, J. Muñoz-Bertomeu & I. Arrillaga

Authors
  1. C. Zaragozá
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. J. Muñoz-Bertomeu
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. I. Arrillaga
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to I. Arrillaga.

Additional information

Communicated by P. Ozias-Akins

Rights and permissions

Reprints and permissions

About this article

Cite this article

Zaragozá, C., Muñoz-Bertomeu, J. & Arrillaga, I. Regeneration of herbicide-tolerant black locust transgenic plants by SAAT. Plant Cell Rep 22, 832–838 (2004). https://doi.org/10.1007/s00299-004-0766-2
