Abstract
The distribution of ticks is essentially determined by the presence of climatic conditions and ecological contexts suitable for their survival and development. We build a model that explicitly takes into account each physiological state through a system of infinite differential equations where tick population density are structured on an infinite discrete set. We suppose that intrastage development process is temperature dependent (Arrhenius temperatures function) and that larvae hatching and adult mortality are temperature and water vapor deficit dependent. We analysed mathematically the model and have explicit the \(R_0\) of the tick population.
This is a preview of subscription content, access via your institution.
References
Arendt W, Grabosch A, Greiner G et al (1986) One-parameter semigroups of positive operators. Lecture Notes in Mathematics, vol 1184. Springer, Berlin, Heidelberg. https://doi.org/10.1007/BFb0074922
Bacaër N, Khaladi M (2013) On the basic reproduction number in a random environment. J Math Biol 67(6–7):1729–1739. https://doi.org/10.1007/s00285-012-0611-0
Batkai A, Fijavz MK, Rhandi A et al (2019) Positive operator semigroups: from finite to infinite dimensions. Birkhäuser Verlag, Basel
Engel KJ, Nagel R (2000) One-parameter semigroups for linear evolution equations. Springer
Estrada-Pena A, Venzal JM (2007) Climate niches of tick species in the Mediterranean region: modeling of occurrence data, distributional constraints, and impact of climate change. J Med Entomol 44:1130–1138
Estrada-Peña A, Gray JS, Kahl O et al (2013) Research on the ecology of ticks and tick-borne pathogens-methodological principles and caveats. https://doi.org/10.3389/fcimb.2013.00029
Gettinby G, Gardiner WP, Gray JS et al (1981) Models based on weather for the development phases of the sheep tick, Ixodes ricinus L. Vet Parasitol 9(1932):75–86. https://doi.org/10.1016/0304-4017(81)90009-1
Gharbi M, Darghouth MA, Elati K, Al-Hosary AAT, Ayadi O, Salih DA, El Hussein AM, Mhadhbi M, Khamassi Khbou M, Hassan SM, Obara I, Ahmed LS, Ahmed J (2020) Current status of tropical theileriosis in Northern Africa: a review of recent epidemiological investigations and implications for control. Transbound Emerg Dis 67(Suppl 1):8–25. https://doi.org/10.1111/tbed.13312
Ghosh M, Pugliese A (2004) Seasonal population dynamics of ticks, and its influence on infection transmission: a semi-discrete approach. Bull Math Biol 66(6):1659–1684. https://doi.org/10.1016/j.bulm.2004.03.007
Ghosh M, Chandra P, Sinha P et al (2004) Modelling the spread of carrier-dependent infectious diseases with environmental effect. Appl Math Comput 152(2):385–402
Glasstone S, Laidler KJ, Eyring H (1941) The theory of rate processes. McGraw-Hill, London
Hassell MP, May RM, Pacala SW et al (1991) The persistence of host-parasitoid associations in patchy environments I. A general criterion. Am Nat 138(3):568–583. https://doi.org/10.1086/285235
King D, Gettinby G, Newson RM (1988) A climate-based model for the development of the ixodid tick, Rhipicephalus appendiculatus in east coast fever zones. Vet Parasitol 29(1):41–51. https://doi.org/10.1016/0304-4017(88)90006-4
Kooijman SSALM (2010) Dynamic Energy Budget theory for metabolic organisation, 3rd edn. Cambridge University Press, Cambridge, New York, Port Chester, Melbourne, Sydney
Lees AD, Milne A (1951) The seasonal and diurnal activities of individual sheep ticks (ixodes ricinusl.). Parasitology 41(3–4):189–208. https://doi.org/10.1017/S0031182000084031
Lou Y, Wu J (2017) Modeling Lyme disease transmission. Infect Dis Model 2(2):229–243. https://doi.org/10.1016/j.idm.2017.05.002
Metz JAJ, Diekmann O (1986) The dynamics of physiologically structured populations, vol 68. Springer
Mwambi HG (2002) Ticks and tick borne diseases in Africa: a disease transmission model. Math Med Biol 2002:275–292
Mwambi HG, Baumgartner J, Hadeler KP et al (2000) Ticks and tick-borne diseases: a vector-host interaction model for the brown ear tick (Rhipicephalus appendiculatus). Stat Methods Med Res 9(3):279–301. https://doi.org/10.1177/096228020000900307
Norman R, Bowers RG, Begon M et al (1999) Persistence of tick-borne virus in the presence of multiple host species: tick reservoirs and parasite mediated competition. J Theor Biol 200(1):111–118. https://doi.org/10.1006/jtbi.1999.0982
Norman RA, Worton AJ, Gilbert L (2016) Past and future perspectives on mathematical models of tick-borne pathogens. Parasitology 143(7):850–859. https://doi.org/10.1017/S0031182015001523
O’Callaghan CJ, Medley GF, Peter TF et al (1998) Investigating the epidemiology of heartwater (Cowdria ruminantium infection) by means of a transmission dynamics model. Water Res 117:49–61
Ogden NH, Bigras-Poulin M, O’callaghan CJ et al (2007) Vector seasonality, host infection dynamics and fitness of pathogens transmitted by the tick Ixodes scapularis. Parasitology 134(Pt 2):209–227. https://doi.org/10.1017/S0031182006001417
Perret JL, Guerin PM, Diehl PA et al (2003) Darkness induces mobility, and saturation deficit limits questing duration, in the tick Ixodes ricinus. J Exp Biol 206(11):1809–1815. https://doi.org/10.1242/jeb.00345
Perret JL, Rais O, Gern L (2009) Influence of climate on the proportion of Ixodes ricinus nymphs and adults questing in a tick population. J Med Entomol 41(3):361–365. https://doi.org/10.1603/0022-2585-41.3.361
Randolph SE (1997) Abiotic and biotic determinants of the seasonal dynamics of the tick Rhipicephalus appendiculatus in South Africa. Med Vet Entomol 11(1):25–37. https://doi.org/10.1111/j.1365-2915.1997.tb00286.x
Randolph SE (2009) Tick-borne disease systems emerge from the shadows: the beauty lies in molecular detail, the message in epidemiology. Parasitology 136(12):1403–1413. https://doi.org/10.1017/S0031182009005782
Randolph SE, Rogers DJ (1997) A generic population model for the African tick Rhipicephalus appendiculatus. Parasitology 115(Pt 3):265–279
Randolph SE, Green RM, Hoodless AN et al (2002) An empirical quantitative framework for the seasonal population dynamics of the tick Ixodes ricinus. Int J Parasitol 32(8):979–989 (S0020-7519(02)00030-9)
Rosà R, Pugliese A (2007) Effects of tick population dynamics and host densities on the persistence of tick-borne infections. Math Biosci 208(1):216–240. https://doi.org/10.1016/j.mbs.2006.10.002
Rosà R, Pugliese A, Norman R et al (2003) Thresholds for disease persistence in models for tick-borne infections including non-viraemic transmission, extended feeding and tick aggregation. J Theor Biol 224(3):359–376
Schoolfield R, Sharpe P, Magnuson C (1981) Non-linear regression of biological temperature-dependent rate models based on absolute reaction-rate theory. J Theor Biol 88(4):719–731. https://doi.org/10.1016/0022-5193(81)90246-0
Sharpe PJ, DeMichele DW (1977) Reaction kinetics of poikilotherm development. J Theor Biol 64(4):649–670. https://doi.org/10.1016/0022-5193(77)90265-X
Thieme H (2009) Spectral bound and reproduction number for infinite-dimensional population structure and time heterogeneity. SIAM J Appl Math 70(1):188–211. https://doi.org/10.1137/080732870
Tuljapurkar S, Caswell H (1997) Structured-population models in marine, terrestrial, and freshwater systems. Kluwer Academic Publishers
Voigt J (1989) On resolvent positive operators and positiveC 0-semigroups onAL-spaces, vol 38. Springer. https://doi.org/10.1007/BF02573236
Walker AR, Bouattor A, Camicas J-L, Estrada-Pena A, Latif A, Pegram R, Preston P (2003) Ticks of domestic animals in Africa: a guide to identification of species. Bioscience reports (ISBN-10:095451730X)
Webb GF (1987) An operator-theoretic formulation of asynchronous exponential growth. Trans Am Math Soc 303(2):751. https://doi.org/10.2307/2000695
Wu X, Duvvuri VR, Lou Y et al (2013) Developing a temperature-driven map of the basic reproductive number of the emerging tick vector of Lyme disease Ixodes scapularis in Canada. J Theor Biol 319:50–61. https://doi.org/10.1016/j.jtbi.2012.11.014
Acknowledgements
The work was funded by the Laboratoire d’épidémiologie des infections enzootiques des herbivores en Tunisie: application à la lutte (LR16AGR01) (Ministère de l’enseignement supèrieure et de la recherche scientifique, Tunisie), the laboratory of Bioinformatic, biomathematics et biostatistics (LR16IPT09) (Ministère de l’enseignement supérieur et de la recherche scientifique, Tunisie) and was partly supported by the CGIAR Research Program on Livestock from the International Center for Agricultural Research in the Dry Areas (ICARDA). The Departement de Mathematiques of UADB provides travel grant that contribute to realize this work. SBM and PIN acknowledge the Director, Pr Alassane Sy, the dean department, Dr Abdoul Aziz Fall of UFR SATIC and Pr Henda el Fekih of ENIT who facilitate their collaboration and scientific visits. We would like to thank the associate editor and the reviewer for their comments which greatly improved the reading of the manuscript. We would like also to thank reviewers of the first version of this manuscript that advise us to split our work in two, in order to improved the reading.
Author information
Authors and Affiliations
Corresponding author
Additional information
Publisher's Note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Rights and permissions
About this article
Cite this article
Ndongo, M.S., Ndiaye, P.I., Gharbi, M. et al. A climate-based model for tick life cycle: positive semigroup theory on Cauchy problem approach. J. Math. Biol. 84, 52 (2022). https://doi.org/10.1007/s00285-022-01755-x
Received:
Revised:
Accepted:
Published:
DOI: https://doi.org/10.1007/s00285-022-01755-x
Keywords
- Differential equation model
- Ticks life-cycle model
- Basic reproduction number
- Tick life-cycle growth model
- Positive operators
- Spectral theory
- Quasi-compactness
- Temperature
Mathematics Subject Classification
- 92-10
- 47A13
- 47B65
- 34C60
