The retromolar canals and foramina: radiographic observation and application to oral surgery

  • Shogo Kikuta
  • Joe Iwanaga
  • Ken Nakamura
  • Kiyosato Hino
  • Moriyoshi Nakamura
  • Jingo Kusukawa
Original Article
  • 72 Downloads

Abstract

Purpose

The retromolar canal (RMC) and foramen (RMF) are anatomic variants in the retromolar area of the mandible. The purpose of this study was to clarify the relationship between the RMC and RMF and related complications, and to reveal how the RMC could impact the mandibular anatomy using cone-beam computed tomography (CBCT) and panoramic images (PAN).

Materials and methods

CBCT and PAN images of 50 patients were retrospectively analyzed to investigate the morphology of the RMC and RMF, and their impact on impacted third molar surgery and orthognathic surgery.

Results

In PAN images, neither the RMC nor RMF was detected. In CBCT images, the RMCs were detected in 26% (13/50) of the patients. A double RMC was detected on one side of one patient. The diameter of the RMC ranged from 0.8 to 2.9 mm (mean; 1.5 ± 0.6 mm), and the RMF ranged from 0.6 to 2.3 mm (mean; 1.1 ± 0.5 mm). No patients experienced unexpected bleeding. Unilateral postoperative hypoesthesia of the buccal gingiva in the molar region was reported in 6.7% of patients with the RMC.

Conclusions

Hypoesthesia of the buccal gingiva in the lower molar region may be the main complication when the RMC is damaged.

Keywords

Cone-beam computed tomography Anatomic variation Mandible Oral surgery Retromolar canal Retromolar foramen

Notes

Acknowledgements

The authors wish to express their gratitude to the radiological technician Reiji Katayama in the Diagnostic Imaging Center, Kurume University Hospital.

Author contributions

SK: protocol/project development, data collection or management, data analysis, and manuscript writing/editing, final approval/guarantor of manuscript. JI: protocol/project development, data analysis, manuscript writing/editing, and final approval/guarantor of manuscript. KN: data collection or management, data analysis, and final approval/guarantor of manuscript. KH: data collection or management, data analysis, and final approval/guarantor of manuscript. MN: protocol/project development, manuscript writing/editing, andfinal approval/guarantor of manuscript. JK: protocol/project development, data analysis, manuscript writing/editing, and final approval/guarantor of manuscript.

Compliance with ethical standards

Conflict of interest

The authors declare no conflict of interest.

References

  1. 1.
    Iwanaga J, Watanabe K, Saga T, Tubbs RS, Tanaka K, Kikuta S, Tabira Y, Fisahn C, Kamura Y, Kusukawa J, Yamaki K (2017) A novel method for observation of the mandibular foramen: application to a better understanding of dental anatomy. Anat Rec 300:1875–1880CrossRefGoogle Scholar
  2. 2.
    Ossenberg NS (1987) Retromolar foramen of the human mandible. Am J Phys Anthropol 73:119–128CrossRefPubMedGoogle Scholar
  3. 3.
    Motamedi MHK, Gharedaghi J, Mehralizadeh S, Navi F, Badkoobeh A, Valaei N, Azizi T (2016) Anthropomorphic assessment of the retromolar foramen and retromolar nerve: anomaly or variation of normal anatomy? Int J Oral Maxillofac Surg 45:241–244CrossRefPubMedGoogle Scholar
  4. 4.
    Muinelo-Lorenzo J, Suárez-Quintanilla JA, Fernández-Alonso A, Marsillas-Rascado S, Suárez-Cunqueiro MM (2014) Descriptive study of the bifid mandibular canals and retromolar foramina: cone beam CT vs panoramic radiography. Dentomaxillofac Radiol 43:20140090CrossRefPubMedPubMedCentralGoogle Scholar
  5. 5.
    Sisman Y, Ercan-Sekerci A, Payveren-Arikan M, Sahman H (2015) Diagnostic accuracy of cone-beam CT compared with panoramic images in predicting retromolar canal during extraction of impacted mandibular third molars. Med Oral Patol Oral Cir Bucal 20:e74–81PubMedGoogle Scholar
  6. 6.
    Rosset A, Spadola L, Ratib O (2004) OsiriX: An open-source software for navigating in multidimensional DICOM images. J Digit Imaging 17:205–216CrossRefPubMedPubMedCentralGoogle Scholar
  7. 7.
    von Arx T, Hanni A, Sendi P, Buser D, Bornstein MM (2011) Radiographic study of the mandibular retromolar canal: an anatomic structure with clinical importance. J Endod 37:1630–1635CrossRefGoogle Scholar
  8. 8.
    Capote TS, Gonçalves Mde A, Campos J (2015) Retromolar canal associated with age, side, sex, bifid mandibular canal, and accessory mental foramen in panoramic radiographs of Brazilians. Anat Res Int 434083Google Scholar
  9. 9.
    Han SS, Hwang YS (2014) Cone beam CT findings of retromolar canals in a Korean population. Surg Radiol Anat 36:871–876CrossRefPubMedGoogle Scholar
  10. 10.
    Kuribayashi A, Watanabe H, Imaizumi A, Tantanapornkul W, Katakami K, Kurabayashi T (2010) Bifid mandibular canals: cone beam computed tomography evaluation. Dentomaxillofac Radiol 39:235–239CrossRefPubMedPubMedCentralGoogle Scholar
  11. 11.
    Orhan K, Aksoy S, Bilecenoglu B, Sakul BU, Paksoy CS (2011) Evaluation of bifid mandibular canals with cone-beam computed tomography in a Turkish adult population: a retrospective study. Surg Radiol Anat 33:501–507CrossRefPubMedGoogle Scholar
  12. 12.
    Patil S, Matsuda Y, Nakajima K, Araki K, Okano T (2013) Retromolar canals as observed on cone-beam computed tomography: their incidence, course, and characteristics. Oral Surg Oral Med Oral Pathol Oral Radiol 115:692–699CrossRefPubMedGoogle Scholar
  13. 13.
    Alves N, Deana NF (2015) Anatomical and radiographical study of the retromolar canal and retromolar foramen in macerated mandibles. Int J Clin Exp Med 8:4292–4296PubMedPubMedCentralGoogle Scholar
  14. 14.
    Gamieldien MY, Van Schoor A (2016) Retromolar foramen: an anatomical study with clinical considerations. Br J Oral Maxillofac Surg 54:784–787CrossRefPubMedGoogle Scholar
  15. 15.
    Kawai T, Asaumi R, Kumazawa Y, Sato I, Yosue T (2014) Observation of the temporal crest canal in the mandibular ramus by cone beam computed tomography and macroscopic study. Int J Comput Assist Radiol Surg 9:295–299CrossRefPubMedGoogle Scholar
  16. 16.
    Kawai T, Asaumi R, Sato I, Kumazawa Y, Yosue T (2012) Observation of the retromolar foramen and canal of the mandible: a CBCT and macroscopic study. Oral Radiol 28:10–14CrossRefGoogle Scholar
  17. 17.
    Rossi AC, Prado GB, Prado FB, Botacin PR, Caria PH (2012) Incidence of retromolar foramen in human mandibles: ethnic and clinical aspects. Int J Morphol 30:1074–1078CrossRefGoogle Scholar
  18. 18.
    Senthil Kumar S, Kesavi D (2010) A study on the incidence of retromolar foramen and canal in indian dried human mandibles and its clinical significance. Int J Anat Sci 1:14–16Google Scholar
  19. 19.
    He P, Iwanaga J, Truong MK, Adeeb N, Tubbs RS, Yamaki K (2017) First report of tripled retromolar foramina. Cureus 9:e1440PubMedPubMedCentralGoogle Scholar
  20. 20.
    Bilecenoglu B, Tuncer N (2006) Clinical and anatomical study of retromolar foramen and canal. J Oral Maxillofac Surg 64:1493–1497CrossRefPubMedGoogle Scholar
  21. 21.
    Yu SK, Lee MH, Jeon YH, Chung YY, Kim HJ (2016) Anatomical configuration of the inferior alveolar neurovascular bundle: a histomorphometric analysis. Surg Radiol Anat 38:195–201CrossRefPubMedGoogle Scholar
  22. 22.
    Singh S (1981) Aberrant buccal nerve encountered at third molar surgery. Oral Surg Oral Med Oral Pathol 52:142CrossRefPubMedGoogle Scholar
