Anatomy of lateral ankle ligaments and their relationship to bony landmarks

Surgical and Radiologic Anatomy volume 28, pages 391–397 (2006)Cite this article

Abstract

This study was designed to determine and describe precise anatomy of the lateral ankle ligaments and their relationship to adjacent osseous structures. This study was performed on 42 legs of 22 adult human embalmed cadavers. The lateral ankle ligaments were carefully dissected using a 2.5× surgical loupe. Mean values for the length, width and angle of the individual lateral ankle ligaments were measured. The precise location of insertion points and course of each ligament was observed and noted with ankle placed in neutral position. The anterior talofibular and calcaneofibular ligaments were coated with radio-opaque material. Radiographs were then taken in the anteroposterior, mortise and lateral projections. The anterior talofibular ligament (ATFL) was a flat, quadrilateral ligament and it made mean angle of 25° (range 5°–45°) with horizontal plane, and a mean angle of 47° (range 45°–56°) with sagittal plane. The posterior talofibular ligament was oriented in a nearly horizontal plane. Calcaneofibular ligament (CFL) was a flat oval ligament. It made a mean angle of 40° (range 30°–58°) with horizontal plane, and mean angle of 51° (range 32°–60°) with sagittal plane. The angle between CFL and ATFL was approximately 132° (range 118°–145°). These data provides important information for diagnosing injury and reconstructing lateral ankle ligaments.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
