Abstract
Appropriate geometries and depths of containers are essential in obtaining suitable available water and temperature in the root zone of containerized grown plants. The objectives of the present study were to examine the effect of the geometry of a growth container with a given volume and irrigation frequency, on water content and temperature of the growing medium and on water uptake, yield and quality of lettuce (Lactuca sativa L.) as a model plant. Two experiments, in the spring and fall, were conducted in a greenhouse. Plants were grown in a volume of 4 L per plant of medium mixture of 0–8 mm tuff (90 %) with compost (10 %). Treatments included three container heights (10, 20 and 30 cm) and two irrigation frequencies (4–6 and 12–18 applications per day and 2 night applications for both). Lettuce head fresh weight was lower in the spring than in the fall and was not significantly affected by container geometry or irrigation frequency. However, the number of tip burn damaged leaves per plant increased significantly with container height, especially for the high irrigation frequency treatments. Container geometry had an effect on the water and temperature regimes. Water content values in tall and narrow containers were lower than those in short and wide containers that had an equal volume of growth medium per unit length. Higher medium temperatures and daily fluctuations were observed in the tall containers. The calculated evapotranspiration rate was higher in the tall containers, and a stronger effect on evapotranspiration was obtained with high irrigation frequency.
Abbreviations
- LIF:
-
Low irrigation frequency
- HIF:
-
High irrigation frequency
- ET:
-
Evapotranspiration (L day−1 plant−1)
- IR:
-
Irrigation (L day−1 plant−1)
- DR:
-
Drainage (L day−1 plant−1)
References
Al Naddaf O, Livieratos I, Stamatakis A, Tsirogiannis I, Gizas G, Savvas D (2011) Hydraulic characteristics of composted pig manure, perlite, and mixtures of them and their impact on cucumber grown on bags. Sci Hort 129:135–141
Assouline S (2002) The effects of micro-drip and conventional drip irrigation on water distribution and uptake. Soil Sci Soc Am J 66(5):1630–1636
Assouline S, Cohen S, Meerbach D, Harodi T, Rozner M (2002) Micro-drip irrigation of field crops: the effect on yield, water uptake and drainage in sweet corn. Soil Sci Soc Am J 66(1):228–235
Assouline S, Möller M, Cohen S, Ben-Hur M, Grava A, Narkis K, Silber A (2006) Soil-plant response to pulsed drip irrigation and salinity: Bell pepper case study. Soil Sci Soc Am J 70:1556–1568
Assouline S, Furman A, Möller M, Narkis K, Silber A (2012) Impact of water regime and growing conditions on soil-plant interactions: from single plant to field scale. Vadose Zone J 11:3–14
Bar-Tal A (1999) The significance of root size for plant nutrition in intensive horticulture. In: Rengel Z (ed) Mineral nutrition of crops: fundamental mechanisms and implications. CRC Press, Boca Raton, pp 115–135
Bar-Tal A, Bar-Yosef B, Kafkafi U (1993) Modeling pepper seedling growth and nutrients uptake as a function of cultural conditions. Agron J 85:718–724
Biderback TE, Fonteno WC (1987) Effects of container geometry and media physical properties on air and water volumes in containers. J Environ Hort 5(4):180–182
Bumgarner NR, Bennett MA, Ling PP, Mullen RW, Kleinhenz MD (2011) Canopy cover and root-zone heating effects on fall- and spring- grown leaf lettuce yield in Ohio. Hortechnology 21(6):737–744
Campbell WF, Wagenet RJ, Jones A (1985) Interactive effects of pot geometry, water management, salinity, and growing medium on growth and yield components of Snapbean in the greenhouse. Agron J 77:707–710
Du YC, Tachibana S (1994) Effect of supraoptimal root temperature on the growth, root respiration and sugar content of cucumber plants. Sci Hort 58:289–301
Frantz JM, Ritchie G, Cometti NN, Robinson J, Bugbee B (2004) Exploring the limits of crop productivity: beyond the limits of tipburn in lettuce. J Am Soc Hortic Sci 129(3):331–338
Gitz DC, Xin Z, Baker JT, Lascano RJ, Burke JJ (2012) The effect of solar loading on soil temperature and developmental variation in greenhouse studies. Agron J 104(2):388–392
Gizas G, Savvas D (2007) Particle size and hydraulic properties of Pumice affect growth and yield of greenhouse crops in soilless culture. HortScience 42(5):1274–1280
Gizas G, Ttsirogiannis I, Bakea M, Mantzos N, Savvas D (2012) Impact of hydraulic characteristics of raw or composted Posidonia residues, Coir, and their mixtures with Pumice on root aeration, water availability, and yield of Lettuce crop. HortScience 47(7):896–901
Gorbe E, Calatayudo A (2010) Optimization of nutrition in soilless systems: A review. Adv Bot Res 53:194–219
Hillel D (1980) Fundamentals of soil physics. Academic Press, New York, p 413
Kafkafi U (2001) Root zone parameters controlling plant growth in soilless culture. Acta Hortic 554:27–38
Kafkafi U (2008) Functions of the root system. In: Raviv M, Lieth JH (eds) Soilless culture: theory and practice. Elsevier, Amsterdam, pp 13–40
Lieth JH, Oki LR (2008) Irrigation in soilless production. In: Raviv M, Lieth JH (eds) Soilless culture: theory and practice. Elsevier, Amsterdam, pp 117–153
Lyons EM, Pote J, DaCosta M, Huang B (2007) Whole-plant carbon relations and root respiration associated with root tolerance to high soil temperature for Agrotis grasses. Environ Exp Bot 59:307–313
Markham JW, Bremer DJ, Boyer CR, Shroeder KR (2011) Effect of container color on substrate temperatures and growth of Red Maple and Redbud. HortScience 46(5):721–726
Martin CA, Ingram DL (1991) Evaluation of thermal properties and effect of irrigation on temperature dynamics in container media. J Environ Hort 9(1):24–28
Mathers HM, Lowe SB, Scagel C, Struve DK, Case LT (2007) Abiotic factors influencing root growth of woody nursery plants in containers. Hortechnology 17(2):151–162
Misaghi IJ, Grogan RG (1978) Effect of temperature on tipburn development in head Lettuce. Phytopathology 68:1738–1743
NeSmith DS, Duval JR (1998) The effect of container size. HortTechnology 8:495–498
Passioura JB (2006) The perils of pot experiments. Func Plant Biol 33:1075–1079
Poorter H, Buhler J, van Dusschoten D, Climent J, Postma JA (2012) Pot size matters: a meta-analysis of the effects of rooting volume on plant growth. Func Plant Biol 39:839–850
Ray JD, Sinclair TR (1998) The effect of pot size on growth and transpiration of maize and soybean during water deficit stress. J Exp Bot 49(325):1381–1386
Saure MC (1998) Causes of the tipburn disorder in leaves of vegetables. Sci Hort 76:131–147
Silber A, Bar-Tal A (2008) Nutrition of substrate-grown plants. In: Raviv M, Lieth JH (eds) Soilless culture: theory and practice. Elsevier, Amsterdam, pp 291–340
Silber A, Xu G, Levkovitch I, Soriano S, Bilu A, Wallach R (2003) High fertigation frequency: the effects on uptake of nutrients, water and plant growth. Plant Soil 253:467–477
Silber A, Bruner M, Kenig E, Reshef G, Zohar H, Posalski I, Yehezkel H, Shmuel D, Cohen S, Dinar M, Matan E, Dinkin I, Cohen Y, Karni L, Aloni B, Assouline S (2005) High fertigation frequency and phosphorus level: Effects on summer-grown bell pepper growth and blossom rot incidence. Plant Soil 270:135–146
Spomer LA (1990) Evaluating drainage in container and other short drained horticultural soils. Commun Soil Sci Plant Anal 21:221–235
Van Genuchten MT (1980) A closed form equation for predicting the hydraulic conductivity of unsaturated soils. Soil Sci Soc Am J 44:892–898
Van Iersel M (1997) Root restriction effects on growth and development of Salvia (Salvia splendens). HortScience 32(7):1186–1190
Wallach R (2008) Physical characteristics of soilless media. In: Raviv M, Lieth JH (eds) Soilless culture: theory and practice. Elsevier, Amsterdam, pp 41–108
Wallach R, Raviv M (2005) The dependence of moisture-tension relationship and water availability on irrigation frequency in containerized growing medium. Acta Hort 697:293–300
Wallach R, Da Silva FF, Chen Y (1992) Hydraulic characteristics of Tuff (Scoria) used as a container medium. J Am Soc Hort Sci 117(3):415–421
Wang D, Shannon MC, Grieve CM, Yates SR (2000) Soil water and temperature regimes in drip and sprinkler irrigation, and implications to soybean emergence. Agri Water Manag 43:15–28
Wu Y, Huang M, Warrington DN (2011) Growth and transpiration of maize and winter wheat in response to water deficits in pots and plots. J Exp Bot 50:799–804
Xu GH, Wolf S, Kafkafi U (2001) Interactive effect of nutrient concentration and container volume on flowering, fruiting, and nutrient uptake of sweet pepper. J Plant Nutr 24:479–501
Xu GH, Levkovitch I, Soriano S, Wallach R, Silber A (2004) Integrated effect of irrigation frequency and phosphorus level on lettuce: P uptake, root growth and yield. Plant Soil 263:297–309
Acknowledgments
We thank Ms. Sara Davidov for her technical assistance, Mr. Elisha Kenig for the professional advice regarding the irrigation system and Mr. Meiron Sofer, head of MOP Darom, Research and Development Farm, Habesor, The Western Negev, Israel, for his support. We thank Mr. Zvi Rub from Mapal Plastics, Mevo Hamma, Israel, for designing and manufacturing the growth containers to meet the experimental requirements. This research was supported by grant number 301-0696-09 of the Chief Scientist, Ministry of Agriculture and Rural Development, Israel. The support of the Chief Scientist is gratefully acknowledged.
Author information
Authors and Affiliations
Corresponding author
Additional information
Communicated by E. Fereres.
Rights and permissions
About this article
Cite this article
Heller, H., Bar-Tal, A., Assouline, S. et al. The effects of container geometry on water and heat regimes in soilless culture: lettuce as a case study. Irrig Sci 33, 53–65 (2015). https://doi.org/10.1007/s00271-014-0448-y
