Environmental Management

, Volume 58, Issue 6, pp 1027–1045 | Cite as

Comparing and refining karst disturbance index methods through application in an island karst setting

  • Brandon L. Porter
  • Leslie A. NorthEmail author
  • Jason S. Polk
Article

Abstract

The interconnected nature of surface and subsurface karst environments allows easy disturbance to their aquifers and specialized ecosystems from anthropogenic impacts. The karst disturbance index is a holistic tool used to measure disturbance to karst environments and has been applied and refined through studies in Florida and Italy, among others. Through these applications, the karst disturbance index has evolved into two commonly used methods of application; yet, the karst disturbance index is still susceptible to evaluation and modification for application in other areas around the world. The geographically isolated and highly vulnerable municipality of Arecibo, Puerto Rico’s karst area provides an opportunity to test the usefulness and validity of the karst disturbance index in an island setting and to compare and further refine the application of the original and modified methods. This study found the both methods of karst disturbance index application resulted in high disturbance scores (Original Method 0.54 and Modified Method 0.69, respectively) and uncovered multiple considerations for the improvement of the karst disturbance index. An evaluation of multiple methods together in an island setting also resulted in the need for adding additional indicators, including Mogote Removal and Coastal Karst. Collectively, the results provide a holistic approach to using the karst disturbance index in an island karst setting and suggest a modified method by which scaling and weighting may compensate for the difference between the original and modified method scores and allow interested stakeholders to evaluate disturbance regardless of his or her level of expertise.

Keywords

Karst Human impact Disturbance index Resource conservation Puerto Rico

Notes

Acknowledgments

We graciously thank individuals and agencies that supported this research, including Abel Vale of Citizens of the Karst, the U.S. Geological Survey, Dr. Pat Kambesis, and Victoria Allen. This work was funded in part through a Western Kentucky University New Faculty Research Grant.

Compliance with Ethical Standards

Conflict of Interest

The authors declare that they have no conflict of interest.

References

  1. Andrew EG Jonas (2006) Pro scale: further reflections on the 'scale debate' in human geography. Trans Inst Br Geogr 31(3):399–406Google Scholar
  2. Cahill R (2007) EPA enforcement actions in puerto rico lead to environmental improvements. Retrieved from: http://yosemite.epa.gov/opa/admpress.nsf/d0cf6618525a9efb85257359003fb69d/67e0bb8778f26f3f85257394006706ae!
  3. Calo F, Parise M (2006) Evaluating the human disturbance to karst environments in southern Italy. Acta Carsologica 35(2):47–56Google Scholar
  4. Day M, Halfen A, Chenoweth S (2011) The Cockpit Country, Jamaica: Boundary Issues in Assessing Disturbance and Using a Karst Disturbance Index in Protected Areas Planning. In: Karst Management van Beynen (ed). Karst Management Springer, Netherlands, p 489Google Scholar
  5. De Waele J (2009) Evaluating disturbance on Mediterranean karst areas: the example of Sardinia (Italy). Environ Geol 58:239–255CrossRefGoogle Scholar
  6. Freeman TW (1986) The unity of geography: introduction. Trans Inst Br Geogr 11(4):441Google Scholar
  7. Ford D, Williams P (2007) Karst Hydrogeology and Geomorphology. John Wiley and Sons Ltd, West SussexCrossRefGoogle Scholar
  8. Gardiner J, Azzato B, Joacobi M (2007) Coastal and estuarine hazardous waste site reports. Assessment and Restoration Division, Office of Response and Restoration, National Oceanic and Atmospheric Administration, Seattle, December 2007Google Scholar
  9. Giusti EV (1978) U.S. Department of the Interior, Geological Survey. Hydrogeology of the karst of Puerto Rico (76-26183). U.S. Government Printing Office, Washington, DCGoogle Scholar
  10. Gómez-Gómez F (1987) Planning report for the Caribbean Islands Regional Aquifer-System Analysis Project: U.S. Geological Survey Water-Resources Investigations Report 86-4074, 50Google Scholar
  11. H.R. 3213. Bill U.S. House of Representatives, 2001, 107th Congress, 1st Session.Google Scholar
  12. Hunter JM, Arbona SI (1995) Paradise lost: an introduction to the geography of water pollution in Puerto Rico. Soc. Sci. Med. 40(10):1331–1355CrossRefGoogle Scholar
  13. Kovarik JL, van Beynen PE (2015) Application of the Karst disturbance index as a raster-based model in a developing country. Appl Geogr 63:396–407CrossRefGoogle Scholar
  14. Kuhn TS (1962) The structure of scientific revolutions. University of Chicago Press: Chicago, pp. 172Google Scholar
  15. Library of Congress, (2010). Puerto Rico Karst Conservation Act of 2010. Bill summary & status 110th congress (2007 - 2008) h.r.672. Retrieved from: http://thomas.loc.gov/cgi-bin/bdquery/z?d110:h672
  16. Lugo AE, Castro LM, Vale A, Lopez TM, Prieto EH, Martino AG, Rolon AR, Tossas AG, McFarlane DA, Miller T, Rodriquez A, Lundberg J, Thomlinson J, Colon J, Schellekens JH, Ramos O, Helmer E (2001) U.S. Department of Agriculture, Forest Service. Puerto Rican karst-a vital resource (WO-65).Google Scholar
  17. Neal JW, Bacheler NM, Noble RL, Shea D, Cope WG (2005) The Mystery of dos bocas reservoir, puerto rico: explaining extreme spatial heterogeneity in largemouth bass distribution. Caribb J Sci 41(4):804–814CrossRefGoogle Scholar
  18. North LA (2007) Application and refinement of the karst disturbance index in west-central, Florida. Thesis, University of South Florida, TampaGoogle Scholar
  19. North LA, van Beynen PE, Parise M (2009) Interregional comparison of karst disturbance: west-central Florida and southeast Italy. J Environ Manage 90:1770–1781CrossRefGoogle Scholar
  20. Palmer AN (2007) Cave Geology. Cave Books, Dayton, OHGoogle Scholar
  21. Papp M (1984) Secondary succession in a herbaceous vegetation after deforestation. Acta Bot Hung 30(1-2):139–154Google Scholar
  22. Rodríguez JM and Gómez-Gómez F (2005) Potentiometric surface of the upper and lower aquifers of the North Coast Limestone aquifer system and hydrologic conditions in the Arecibo-Manatí area, Puerto Rico, November 27–December 1, 2006: U.S. Geological Survey Scientific Investigations Map 3030, 2 sheetsGoogle Scholar
  23. Sohn Y, Moran E, Gurri F (1999) Deforestation in north-central yucatan (1985-1995): mapping secondary succession of forest and agricultural land use in sotuta using the cosine of the angle concept. Photogramm Eng Remote Sen 65(8):947–958Google Scholar
  24. U.S. Environmental Protection Agency (USEPA) (2010) Superfund site progress profile upjohn facility. Superfund Information Systems, June 19. Retrieved from: http://cfpub2.epa.gov/supercpad/cursites/csitinfo.cfm?id=0202480
  25. U.S. Geological Survey (2006). Orthoimagery of Puerto Rico. 200409_puerto_rico-us_virgin_islands_pr_1x0000m_utm_clrGoogle Scholar
  26. van Beynen P, Feliciano N, North L, Townsend K (2007) Application of a karst disturbance index in Hillsborough county, Florida. Environ. Assess. 39:261–277Google Scholar
  27. van Beynen P, Townsend K (2005) A disturbance index for karst environments. Environ Manage 36(1):101–116CrossRefGoogle Scholar
  28. van Beynen P, Bialkowska-Jelinska E (2012) Human disturbance of the Waitomo catchment, New Zealand. J Environ Manage 108:130–40. doi: 10.1016/j.jenvman.2012.04.038 CrossRefGoogle Scholar
  29. White, W (1988) Geomorphology and hydrology of karst terrains. Oxford Press: Oxford and New YorkGoogle Scholar
  30. Zack A, Rodriquez-Alsono T, Roman-Mas A (1988) Puerto Rico: Ground-water quality. Water-Supply Paper 2325 USGS, 437–442Google Scholar

Copyright information

© Springer Science+Business Media New York 2016

Authors and Affiliations

  • Brandon L. Porter
    • 1
  • Leslie A. North
    • 2
    Email author
  • Jason S. Polk
    • 2
  1. 1.International School of PanamaPanamaRepublic of Panama
  2. 2.Center for Human GeoEnvironmental Studies, Department of Geography and GeologyWestern Kentucky UniversityBowling GreenUSA
