The predictive value of MRI in the syndesmotic instability of ankle fracture

Skeletal Radiology volume 47, pages 533–540 (2018)Cite this article

Abstract

Objective

Although many types of ankle fracture can be combined with syndesmosis injury, preoperative imaging studies rarely reveal instability of the syndesmosis. This study assessed the use of magnetic resonance imaging (MRI) for syndesmotic instability in patients with unstable ankle fracture.

Methods

A total of 74 patients who were treated for Lauge-Hansen supination external rotation/Weber B type fracture or pronation external rotation/Weber C type fracture and who underwent MRI for preoperative assessment were enrolled. The MRI findings of the syndesmotic ligament and the results of an intraoperative stress test were evaluated.

Results

Twenty-six patients had a positive result on the intraoperative stress test for syndesmotic instability. The MRI findings of the syndesmotic ligaments revealed that complete tear of the posterior inferior tibiofibular ligament (PITFL) was the most reliable predictor of syndesmotic instability (sensitivity, 74%; specificity, 78%; positive predictive value, 54%). Interobserver agreement for the intraoperative stress test and MRI assessment was excellent, except for the MRI findings of the interosseous ligament (62% agreement; kappa, 0.3).

Conclusions

Complete tear of the PITFL on MRI has additional diagnostic value for syndesmotic instability in ankle fracture. However, because the sensitivity might not be sufficient to justify the costs associated with MRI, cost-effectiveness should be considered.
