Whole-body MRI in neurofibromatosis: incidental findings and prevalence of scoliosis

Skeletal Radiology volume 41, pages 917–923 (2012)Cite this article

Abstract

Objective

To demonstrate incidental findings and scoliosis on whole-body MRI (WBMRI) in patients with neurofibromatosis type 1 and 2 (NF1 & NF2, respectively), and schwannomatosis.

Materials and methods

Institutional review board approval and written informed consent were obtained for this prospective HIPAA-compliant study. A total of 247 subjects (141 with NF1, 55 with NF2, 51 with schwannomatosis; 132 women (53.5%); mean age, 41 years, range, 18–97 years) underwent WBMRI using coronal STIR (TR/TE: 4190/111 ms, TI: 150 ms) and T1-weighted images (TR/TE: 454/10 ms), 10-mm slice thickness, imaging time ~40 min. Images were reviewed for the presence of incidental findings, outside of nerve sheath tumors. The presence of scoliosis was recorded and curve morphology was assessed and quantified.

Results

Incidental findings other than scoliosis were recorded in 104/247 (42%) patients, most often affecting the musculoskeletal system (65/247 patients, 26%). We found 16/247 (6.5%) significant incidental findings likely to affect clinical management, including avascular necrosis of bone in eight patients (five with NF2), eight insufficiency fractures, and four non-neurogenic neoplasms (Hodgkin's lymphoma, liposarcoma, dermoid cyst, large uterine myoma requiring excision). Scoliosis was seen in 50/247 patients (20%), including 8/55 with NF2 (15%) and 11/51 with schwannomatosis (22%).

Conclusions

Incidental findings in the neurofibromatoses frequently involve the skeleton. Given the relatively high incidence of unsuspected osteonecrosis and stress fractures, close attention to the skeleton on WBMRI is advised. In addition, knowledge of common incidental findings can help clinicians prepare patients who undergo WBMRI for potential unexpected findings.

This is a preview of subscription content, access via your institution.

Access options

Buy single article

Instant access to the full article PDF.

43,34 €

Price includes VAT (Finland)
Tax calculation will be finalised during checkout.

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5

References

  1. Cai W, Kassarjian A, Bredella MA, et al. Tumor burden in patients with neurofibromatosis types 1 and 2 and schwannomatosis: determination on whole-body MR images. Radiology. 2009;250:665–73.

    PubMed  Article  Google Scholar

  2. Mautner VF, Asuagbor FA, Dombi E, et al. Assessment of benign tumor burden by whole-body MRI in patients with neurofibromatosis 1. Neuro Oncol. 2008;10:593–8.

    PubMed  Article  Google Scholar

  3. Van Meerbeeck SF, Verstraete KL, Janssens S, Mortier G. Whole-body MR imaging in neurofibromatosis type 1. Eur J Radiol. 2009;69:236–42.

    PubMed  Article  Google Scholar

  4. Morin SH, Cobbold JF, Lim AK, et al. Incidental findings in healthy control research subjects using whole-body MRI. Eur J Radiol. 2009;72:529–33.

    PubMed  Article  CAS  Google Scholar

  5. Gutmann DH, Aylsworth A, Carey JC, et al. The diagnostic evaluation and multidisciplinary management of neurofibromatosis 1 and neurofibromatosis 2. JAMA. 1997;278:51–7.

    PubMed  Article  CAS  Google Scholar

  6. MacCollin M, Chiocca EA, Evans DG, et al. Diagnostic criteria for schwannomatosis. Neurology. 2005;64:1838–45.

    PubMed  Article  CAS  Google Scholar

  7. Soucacos PN, Zacharis K, Soultanis K, Gelalis J, Xenakis T, Beris AE. Risk factors for idiopathic scoliosis: review of a 6-year prospective study. Orthopedics. 2000;23:833–8.

    PubMed  CAS  Google Scholar

  8. Glockner JF. Incidental findings on renal MR angiography. AJR Am J Roentgenol. 2007;189:693–700.

    PubMed  Article  Google Scholar

  9. McKenna DA, Laxpati M, Colletti PM. The prevalence of incidental findings at cardiac MRI. Open Cardiovasc Med J. 2008;2:20–5.

    PubMed  Article  Google Scholar

  10. Abdel-Wanis ME, Kawahara N. Bone development in neurofibromatosis 1. Med Hypotheses. 2003;60:459–62.

    PubMed  Article  CAS  Google Scholar

  11. Tucker T, Schnabel C, Hartmann M, et al. Bone health and fracture rate in individuals with neurofibromatosis 1 (NF1). J Med Genet. 2009;46:259–65.

    PubMed  Article  CAS  Google Scholar

  12. Jett K, Friedman JM. Clinical and genetic aspects of neurofibromatosis 1. Genet Med. 2010;12:1–11.

    PubMed  Article  Google Scholar

  13. Alwan S, Tredwell SJ, Friedman JM. Is osseous dysplasia a primary feature of neurofibromatosis 1 (NF1)? Clin Genet. 2005;67:378–90.

    PubMed  Article  CAS  Google Scholar

  14. Mandell GA, Dalinka MK, Coleman BG. Fibrous lesions in the lower extremities in neurofibromatosis. AJR Am J Roentgenol. 1979;133:1135–8.

    PubMed  CAS  Google Scholar

  15. Walden MJ, Murphey MD, Vidal JA. Incidental enchondromas of the knee. AJR Am J Roentgenol. 2008;190:1611–5.

    PubMed  Article  Google Scholar

  16. Crawford AH, Herrera-Soto J. Scoliosis associated with neurofibromatosis. Orthop Clin North Am. 2007;38:553–62. vii.

    PubMed  Article  Google Scholar

  17. Winter RB, Moe JH, Bradford DS, Lonstein JE, Pedras CV, Weber AH. Spine deformity in neurofibromatosis. A review of one hundred and two patients. J Bone Joint Surg Am. 1979;61:677–94.

    PubMed  CAS  Google Scholar

  18. Sirois 3rd JL, Drennan JC. Dystrophic spinal deformity in neurofibromatosis. J Pediatr Orthop. 1990;10:522–6.

    PubMed  Google Scholar

  19. Ramachandran M, Tsirikos AI, Lee J, Saifuddin A. Whole-spine magnetic resonance imaging in patients with neurofibromatosis type 1 and spinal deformity. J Spinal Disord Tech. 2004;17:483–91.

    PubMed  Article  Google Scholar

  20. Lu-Emerson C, Plotkin SR. The Neurofibromatoses. Part 1: NF1. Rev Neurol Dis. 2009;6:E47–53.

    PubMed  Google Scholar

  21. Lu-Emerson C, Plotkin SR. The neurofibromatoses. Part 2: NF2 and schwannomatosis. Rev Neurol Dis. 2009;6:E81–6.

    PubMed  Google Scholar

  22. Wessberg P, Danielson BI, Willen J. Comparison of Cobb angles in idiopathic scoliosis on standing radiographs and supine axially loaded MRI. Spine (Phila Pa 1976). 2006;31:3039–44.

    Article  Google Scholar

Download references

Conflict of interest

The authors declare that they have no conflicts of interest.

Funding support

Department of Defense Neurofibromatosis Research Program (NF0502020) and the NIH/NINDS (P01NS024279).

Author information

Affiliations

  1. Musculoskeletal Imaging and Intervention, Department of Radiology, Massachusetts General Hospital and Harvard Medical School, Yawkey 6E, 55 Fruit Street, Boston, MA, 02114, USA

    Jacob L. Jaremko, Peter J. MacMahon, Martin Torriani & Miriam A. Bredella

  2. Department of Neurology and Cancer Center, Massachusetts General Hospital, Boston, MA, 02114, USA

    Vanessa L. Merker & Scott R. Plotkin

  3. Department of Neurology, University Medical Center Hamburg-Eppendorf, Hamburg, Germany

    Victor F. Mautner

Authors
  1. Jacob L. Jaremko
    View author publications

    You can also search for this author in PubMed Google Scholar

  2. Peter J. MacMahon
    View author publications

    You can also search for this author in PubMed Google Scholar

  3. Martin Torriani
    View author publications

    You can also search for this author in PubMed Google Scholar

  4. Vanessa L. Merker
    View author publications

    You can also search for this author in PubMed Google Scholar

  5. Victor F. Mautner
    View author publications

    You can also search for this author in PubMed Google Scholar

  6. Scott R. Plotkin
    View author publications

    You can also search for this author in PubMed Google Scholar

  7. Miriam A. Bredella
    View author publications

    You can also search for this author in PubMed Google Scholar

Corresponding author

Correspondence to Miriam A. Bredella.

Additional information

Scott R. Plotkin and Miriam A. Bredella were equal senior authors.

Rights and permissions

Reprints and Permissions

About this article

Cite this article

Jaremko, J.L., MacMahon, P.J., Torriani, M. et al. Whole-body MRI in neurofibromatosis: incidental findings and prevalence of scoliosis. Skeletal Radiol 41, 917–923 (2012). https://doi.org/10.1007/s00256-011-1333-x

Download citation

  • Received:

  • Revised:

  • Accepted:

  • Published:

  • Issue Date:

  • DOI: https://doi.org/10.1007/s00256-011-1333-x

Keywords

  • Whole-body MRI (WBMRI)
  • Neurofibromatosis
  • Incidental findings
