Abstract
A new method is proposed for the discrimination of wood species by combining near-infrared reflectance spectroscopy (NIRS) and laser-induced breakdown spectroscopy (LIBS) and using chemometrics for data analysis. The method was applied to the analysis of 42 samples from six different species: Amburana cearensis, Copaifera lucens, Phyllocarpus riedelii, Cariniana legalis, Bowdichia virgilioides, and Aspidosperma pyricollum. The spectra from both techniques were merged on a single data matrix and pretreated by standard normal variate (SNV) and Savitzky–Golay first derivative with smoothing. Principal component analysis was applied to the exploratory data analysis and showed a clear formation of sample groups according to the wood species only when the data from both analytical techniques and the data pretreatment were used. Sample discrimination using partial least squares discriminant analysis was proved possible, but with an average misclassification of about 10%. Sample grouping and discrimination were shown to be probably related to different concentrations of iron, copper, zinc, and/or sodium (affecting the LIBS spectra) and lignin, water, cellulose, and/or hemicellulose (affecting the NIRS spectra).
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
References
Bächle H, Zimmer B, Wegener G (2012) Classification of thermally modified wood by FT-NIR spectroscopy and SIMCA. Wood Sci Technol 46:1181–1192. https://doi.org/10.1007/s00226-012-0481-z
Bouslamti MA, Irle MA, Belloncle C et al (2013) Classification of treated wood using Fourier transform near infrared spectroscopy and multivariate data analysis. Int Wood Prod J 4:116–121. https://doi.org/10.1179/2042645312Y.0000000026
Carballo-Meilan A, Goodman AM, Baron MG, Gonzalez-Rodriguez J (2014) A specific case in the classification of woods by FTIR and chemometric: discrimination of Fagales from Malpighiales. Cellulose 21:261–273. https://doi.org/10.1007/s10570-013-0093-2
Cui X, Wang Q, Zhao Y et al (2019) Laser-induced breakdown spectroscopy (LIBS) for classification of wood species integrated with artificial neural network (ANN). Appl Phys B 125:56. https://doi.org/10.1007/s00340-019-7166-3
Francisco-Fernández M, Tarrío-Saavedra J, Mallik A, Naya S (2012) A comprehensive classification of wood from thermogravimetric curves. Chemom Intell Lab Syst 118:159–172. https://doi.org/10.1016/j.chemolab.2012.07.003
Francisco-Fernández M, Tarrío-Saavedra J, Naya S et al (2015) Classification of wood using differential thermogravimetric analysis. J Therm Anal Calorim 120:541–551. https://doi.org/10.1007/s10973-014-4260-y
Francisco-Fernández M, Tarrío-Saavedra J, Naya S et al (2017) Statistical classification of early and late wood through the growth rings using thermogravimetric analysis. J Therm Anal Calorim 127:499–506. https://doi.org/10.1007/s10973-016-5917-5
Gonzaga FB, Rocha WFC, Correa DN (2015) Discrimination between authentic and false tax stamps from liquor bottles using laser-induced breakdown spectroscopy and chemometrics. Spectrochim Acta Part B At Spectrosc 109:24–30. https://doi.org/10.1016/j.sab.2015.04.011
Gonzaga FB, Braga LR, Sampaio AP et al (2017) A simple method for forward variable selection and calibration: evaluation for compact and low-cost laser-induced breakdown spectroscopy system. Anal Bioanal Chem 409:3017–3024. https://doi.org/10.1007/s00216-017-0247-4
Hayashi K, Tsuchikawa S, Inoue K, Noma J (2003) Application of near-infrared spectroscopy to wood discrimination. J Wood Sci 49:29–35. https://doi.org/10.1007/s100860300005
Horacek M, Jakusch M, Krehan H (2009) Control of origin of larch wood: discrimination between European (Austrian) and Siberian origin by stable isotope analysis. Rapid Commun Mass Spectrom 23:3688–3692. https://doi.org/10.1002/rcm.4309
Kalaw JM, Sevilla FB III (2018) Discrimination of wood species based on a carbon nanotube/polymer composite chemiresistor array. Holzforschung 72:215–223. https://doi.org/10.1515/hf-2017-0097
Kramida A, Ralchenko Y, Reader J, NIST ASD Team (2018) NIST: atomic spectra database (version 5.6.1). https://physics.nist.gov/asd. Accessed 2 Apr 2019
Kurata Y (2017) Nondestructive classification analysis of wood soaked in seawater by using near-infrared spectroscopy. For Prod J 67:63–68. https://doi.org/10.13073/FPJ-D-15-00049
Lavine BK, Davidson CE, Moores AJ, Griffiths PR (2001) Raman spectroscopy and genetic algorithms for the classification of wood types. Appl Spectrosc 55:960–966. https://doi.org/10.1366/0003702011953108
Lopez-Moreno C, Amponsah-Manager K, Smith BW et al (2005) Quantitative analysis of low-alloy steel by microchip laser induced breakdown spectroscopy. J Anal At Spectrom 20:552. https://doi.org/10.1039/b419173k
Nisgoski S, de Oliveira AA, de Muñiz GIB (2017) Artificial neural network and SIMCA classification in some wood discrimination based on near-infrared spectra. Wood Sci Technol 51:929–942. https://doi.org/10.1007/s00226-017-0915-8
Oliveira EM, Braga JWB, da Costa AF (2015) Discrimination between similar woods by molecular fluorescence and partial least squares. Quim Nova 5:5. https://doi.org/10.5935/0100-4042.20150127
Oliveira DM, Fontes LM, Pasquini C (2019) Comparing laser induced breakdown spectroscopy, near infrared spectroscopy, and their integration for simultaneous multi-elemental determination of micro- and macronutrients in vegetable samples. Anal Chim Acta 1062:28–36. https://doi.org/10.1016/j.aca.2019.02.043
Park S-Y, Kim J-C, Kim J-H et al (2017) Possibility of wood classification in Korean softwood species using near-infrared spectroscopy based on their chemical compositions. J Korean Wood Sci Technol 45:202–212. https://doi.org/10.5658/WOOD.2017.45.2.202
Piuri V, Scotti F (2010) Design of an automatic wood types classification system by using fluorescence spectra. IEEE Trans Syst Man Cybern Part C (Appl Rev) 40:358–366. https://doi.org/10.1109/tsmcc.2009.2039479
Ramalho FMG, Andrade JM, Hein PRG (2018) Rapid discrimination of wood species from native forest and plantations using near infrared spectroscopy. For Syst 27:e008. https://doi.org/10.5424/fs/2018272-12075
Savitzky A, Golay MJE (1964) Smoothing and differentiation of data by simplified least squares procedures. Anal Chem 36:1627–1639. https://doi.org/10.1021/ac60214a047
Schwanninger M, Rodrigues JC, Fackler K (2011) A review of band assignments in near infrared spectra of wood and wood components. J Near Infrared Spectrosc 19:287–308. https://doi.org/10.1255/jnirs.955
Shou G, Zhang W, Gu Y, Zhao D (2014) Application of near infrared spectroscopy for discrimination of similar rare woods in the Chinese market. J Near Infrared Spectrosc 22:423–432. https://doi.org/10.1255/jnirs.1136
Solo-Gabriele HM, Townsend TG, Hahn DW et al (2004) Evaluation of XRF and LIBS technologies for on-line sorting of CCA-treated wood waste. Waste Manag 24:413–424. https://doi.org/10.1016/j.wasman.2003.09.006
Zhang M, Zhao GJ, Liu B et al (2019) Wood discrimination analyses of Pterocarpus tinctorius and endangered Pterocarpus santalinus using DART-FTICR-MS coupled with multivariate statistics. IAWA J 40:58–74. https://doi.org/10.1163/22941932-40190224
Zhu M-Z, Wen B, Wu H et al (2019) The quality control of tea by near-infrared reflectance (NIR) spectroscopy and chemometrics. J Spectrosc 2019:1–11. https://doi.org/10.1155/2019/8129648
Acknowledgements
This work was supported by the National Council of Technological and Scientific Development (CNPq) [Grant Numbers 573894/2008-6 and 307771/2015-6] and the São Paulo Research Foundation (FAPESP) [Grant Number 2008/57808-1].
Author information
Authors and Affiliations
Corresponding author
Ethics declarations
Conflict of interest
The authors declare that they have no conflict of interest.
Additional information
Publisher's Note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Rights and permissions
About this article
Cite this article
Leandro, J.G.R., Gonzaga, F.B. & Latorraca, J.V.d. Discrimination of wood species using laser-induced breakdown spectroscopy and near-infrared reflectance spectroscopy. Wood Sci Technol 53, 1079–1091 (2019). https://doi.org/10.1007/s00226-019-01119-7
