Abstract
Near infrared diffuse reflectance was used for the determination of specific gravity in green Pinus taeda L. wood samples representing simulated increment cores obtained at breast height and merchantable green logs. The effects of using three pre-processing methods (second derivative, multiplicative scatter correction, and orthogonal signal correction) to reduce the scatter observed in the original spectra were evaluated. The effectiveness of each method was assessed in terms of the average predictive ability of the models and in terms of multivariate figures of merit derived from net analyte signal theory. Specific gravity was successfully modeled using green wood samples. No differences in predictive ability among models were found, although more parsimonious regressions were obtained using transformed spectra. The incorporation of figures of merit for the characterization of calibration models proved to be a valuable tool for understanding the effects of the pre-processing alternatives on the final results.
This is a preview of subscription content, log in via an institution to check access.
Similar content being viewed by others
References
Blanco M, Coello J, Iturriaga H, Maspoch S, de la Pezuela C (1997) Effect of data preprocessing methods in near-infrared diffuse reflectance spectroscopy for the determination of the active compound in a pharmaceutical preparation. Appl Spectrosc 51(2):240–246
Booksh KS, Kowalski BR (1994) Theory of analytical chemistry. Anal Chem 66(15):782A–791A
Bro R, Andersen CM (2003) Theory of net analyte signal vectors in inverse regression. J Chemometrics 17(12):646–652
Brown CD, Vega-Montoto L, Wentzell PD (2000) Derivative preprocessing and optimal corrections for baseline drift in multivariate calibration. Appl Spectrosc 54(7):1055–1068
Esbensen KH (2002) Multivariate data analysis in practice, 5th edn edn. CAMO Process AS, Oslo
Evans R (1994) Rapid measurement of the transverse dimensions of tracheids in radial wood sections from Pinus radiata. Holzforschung 48(2):168–172
Evans R, Stringer S, Kibblewhite RP (2000) Variation of microfibril angle, density and fibre orientation in twenty-nine Eucalyptus nitens trees. Appita J 53(6):450–457
Faber NM (1998) Efficient computation of net analyte signal vector in inverse multivariate calibration models. Anal Chem 70(23):5108–5110
Faber NM (1999) Multivariate sensitivity for the interpretation of the effect of spectral pretreatment methods on near-infrared calibration model predictions. Anal Chem 71(3):557–565
Geladi P, McDougall D, Martens H (1985) Linearization and scatter-correction for near-infrared reflectance spectra of meat. Appl Spectrosc 39(3):491–500
Lorber A (1986) Error propagation and figures of merit for quantification by solving matrix equations. Anal Chem 58(6):1167–1172
Lorber A, Faber K, Kowalski BR (1997) Net analyte signal calculation in multivariate calibration. Anal Chem 69(8):1620–1626
Martens H, Næs T (1989) Multivariate calibration. Wiley, Chichester
Mevik BH, Cederkvist HR (2004) Mean squared error of prediction (MSEP) estimates for principal component regression (PCR) and partial least squares regression (PLSR). J Chemometrics 18(9):422–429
Mevik BH, Wehrens R (2007) The pls package: principal component and partial least squares regression in R. J Stat Softw 18(2):23
Mora CR, Schimleck LR (2008) On the selection of samples for multivariate regression analysis: application to near infrared (NIR) calibration models for the prediction of pulp yield in Eucalyptus nitens. Can J For Res 38(10):2626–2634
Olivieri A, Faber NM, Ferré J, Boqué R, Kalivas JH, Mark H (2006) Uncertainty estimation and figures of merit for multivariate calibration. Pure Appl Chem 78(3):633–661
Reeves JB, Delwiche SR, Reeves VB (2006) Least squares means multiple comparison testing of reference versus predicted residuals for evaluation of partial least squares spectral calibrations. J Near Infrared Spectrosc 14(6):371–377
Schimleck LR, Workman JJ Jr (2004) Analysis of timber and paper. In: Roberts C, Workman JJ, Reeves J (eds) Near-infrared spectroscopy in agriculture. American Society of Agronomy, Crop Science Society of America and Soil Science Society of America, Madison, pp 635–646
Schimleck LR, Mora C, Daniels RF (2003) Estimation of the physical wood properties of green Pinus taeda radial samples by near infrared spectroscopy. Can J For Res 33(12):2297–2305
Schimleck LR, Mora C, Daniels RF (2004) Estimation of tracheid morphological characteristics of green Pinus taeda L. radial strips by near infrared spectroscopy. Wood Fiber Sci 36(4):527–535
Seasholtz MB, Kowalski B (1993) The parsimony principle applied to multivariate calibration. Anal Chim Acta 277(2):165–177
Shenk JS, Workman JJ Jr, Westerhaus MO (2008) Application of NIR spectroscopy to agricultural products. In: Burns DA, Ciurczak EW (eds) Handbook of near-infrared analysis, 2nd edn. CRC Press, Boca Raton, pp 347–386
Thygesen LG (1994) Determination of dry matter content and basic density of Norway spruce by near infrared reflectance and transmission spectroscopy. J Near Infrared Spectrosc 2(3):127–135
Tsuchikawa S (2007) A review of recent near infrared research for wood and paper. Appl Spectrosc Rev 42(1):43–71
Wentzell PD, Brown CD (2000) Signal processing in analytical chemistry. In: Meyer RA (ed) Encyclopedia of analytical chemistry. Wiley, Chichester, pp 9764–9800
Wiklund S, Nilsson D, Eriksson L, Sjöström M, Wold S, Faber K (2007) A randomization test for PLS component selection. J Chemometrics 21(10):427–439
Wold S, Antti H, Lindgren F, Öhman J (1998) Orthogonal signal correction of near-infrared spectra. Chemom Intell Lab Syst 44(1–2):175–185
Acknowledgments
The authors thank Dr. Lee Allen (NCSU and VT Forest Nutrition Cooperative) and Dr. Fikret Isik (NCSU Cooperative Tree Improvement Program) for the provision of samples for the wood strip data set and the green logs data set, respectively. The authors also thank Dr. Sandra Kays (Quality and Safety Assessment Research Unit, USDA Russell Agricultural Research Center) for providing access to their XDS spectrometer. The first author thanks Bioforest S.A. for the support to complete this work.
Author information
Authors and Affiliations
Corresponding author
Rights and permissions
About this article
Cite this article
Mora, C.R., Schimleck, L.R. Determination of specific gravity of green Pinus taeda samples by near infrared spectroscopy: comparison of pre-processing methods using multivariate figures of merit. Wood Sci Technol 43, 441–456 (2009). https://doi.org/10.1007/s00226-008-0235-0
