Analytical and Bioanalytical Chemistry

, Volume 407, Issue 25, pp 7733–7746 | Cite as

Identification of Ginkgo biloba supplements adulteration using high performance thin layer chromatography and ultra high performance liquid chromatography-diode array detector-quadrupole time of flight-mass spectrometry

  • Bharathi Avula
  • Satyanarayanaraju Sagi
  • Stefan Gafner
  • Roy Upton
  • Yan-Hong Wang
  • Mei Wang
  • Ikhlas A. KhanEmail author
Research Paper

Abstract

Ginkgo biloba is one of the most widely sold herbal supplements and medicines in the world. Its popularity stems from having a positive effect on memory and the circulatory system in clinical studies. As ginkgo popularity increased, non-proprietary extracts were introduced claiming to have a similar phytochemical profile as the clinically tested extracts. The standardized commercial extracts of G. biloba leaf used in ginkgo supplements contain not less than 6 % sesquiterpene lactones and 24 % flavonol glycosides. While sesquiterpene lactones are unique constituents of ginkgo leaf, the flavonol glycosides are found in many other botanical extracts. Being a high value botanical, low quality ginkgo extracts may be subjected to adulteration with flavonoids to meet the requirement of 24 % flavonol glycosides. Chemical analysis by ultra high performance liquid chromatography-mass spectrometry revealed that adulteration of ginkgo leaf extracts in many of these products is common, the naturally flavonol glycoside-rich extract being spiked with pure flavonoids or extracts made from another flavonoid-rich material, such as the fruit/flower of Japanese sophora (Styphnolobium japonicum), which also contains the isoflavone genistein. Recently, genistein has been proposed as an analytical marker for the detection of adulteration of ginkgo extracts with S. japonicum. This study confirms that botanically authenticated G. biloba leaf and extracts made therefrom do not contain genistein, and the presence of which even in trace amounts is suggestive of adulteration. In addition to the mass spectrometric approach, a high performance thin layer chromatography method was developed as a fast and economic method for chemical fingerprint analysis of ginkgo samples.

Keywords

Ginkgo biloba L. HPTLC UHPLC-DAD-QToF-MS Dietary supplements Styphnolobium japonicum (L.) Schott

Notes

Acknowledgments

This research is supported in part by “Science Based Authentication of Dietary Supplements” funded by the Food and Drug Administration grant number 1U01FD004246-04, the United States Department of Agriculture, Agricultural Research Service, Specific Cooperative Agreement No. 58-6408-1-603-04. The authors would like to thank Annette Ford for the extraction of samples.

Conflict of interest

The authors declare no conflicts of interest.

Supplementary material

216_2015_8938_MOESM1_ESM.docx (3.7 mb)
ESM 1 (DOCX 3.67 mb)

References

  1. 1.
    Janssen IM, Sturtz S, Skipka G, Zentner A, Velasco MG, Busse R (2010) Ginkgo biloba in Alzheimer’s disease: a systematic review. Wien Med Wochenschr 160:539–546CrossRefGoogle Scholar
  2. 2.
    Ahlemeyer B, Krieglstein J (2003) Pharmacological studies supporting the therapeutic use of Ginkgo biloba extract for Alzheimer’s disease. Pharmacopsychiatry 36:S8–S14CrossRefGoogle Scholar
  3. 3.
    Song J, Fang G, Zhang Y, Deng Q, Wang S (2010) Fingerprint analysis of Ginkgo biloba leaves and related health foods by high-performance liquid chromatography/electrospray ionization-mass spectrometry. J AOAC Int 93:1798–1805Google Scholar
  4. 4.
    Van Beek TA, Montoro P (2009) Chemical analysis and quality control of Ginkgo biloba leaves, extracts and phytopharmaceuticals. J Chromatogr A 1216:2002–2032CrossRefGoogle Scholar
  5. 5.
    Wang F, Jiang K, Li Z (2007) Purification and identification of genistein in Ginkgo biloba leaf extract. Chin J Chromatogr 25:509–513CrossRefGoogle Scholar
  6. 6.
    Pandey R, Chandra P, Arya KR, Kumar B (2014) Development and validation of an ultra-high performance liquid chromatography electrospray ionization tandem mass spectrometry method for the simultaneous determination of selected flavonoids in Ginkgo biloba. J Sep Sci 37:3610–3618CrossRefGoogle Scholar
  7. 7.
    Harnly JM, Luthria D, Chen P (2012) Detection of adulterated Ginkgo biloba supplements using chromatographic and spectral fingerprints. J AOAC Int 95:1579–1587CrossRefGoogle Scholar
  8. 8.
    Demirezer LO, Büyükkaya A, Uçaktürk E, Kuruüzüm-Uz A, Güvenalp Z, Palaska E (2014) Adulteration determining of pharmaceutical forms of Ginkgo biloba extracts from different international manufacturers. Rec Nat Prod 8:394–400Google Scholar
  9. 9.
    Chen P, Ozcan M, Harnly J (2007) Chromatographic fingerprint analysis for evaluation of Ginkgo biloba products. Anal Bioanal Chem 389:251–261CrossRefGoogle Scholar
  10. 10.
    Wohlmuth H, Savage K, Dowell A, Mouatt P (2014) Adulteration of Ginkgo biloba products and a simple method to improve its detection. Phytomedicine 21:912–918CrossRefGoogle Scholar
  11. 11.
    United States Pharmacopoeia and National Formulary (USP36-NF31) (2013) United States Pharmacopeial Convention, Rockville, MDGoogle Scholar
  12. 12.
    Chandra A, Li Y, Rana J, Persons K, Hyun C, Shen S, Mulder T (2011) Qualitative categorization of supplement grade Ginkgo biloba leaf extracts for authenticity. J Funct Foods 3:107–114CrossRefGoogle Scholar
  13. 13.
    Xie P, Chen S, Liang Y-Z, Wang X, Tian R, Upton R (2006) Chromatographic fingerprint analysis-a rational approach for quality assessment of traditional Chinese herbal medicine. J Chromatogr A 1112:171–180CrossRefGoogle Scholar
  14. 14.
    Champagne BA, Emmel VK (2011) Rapid screening test for adulteration in raw materials of dietary supplements. Vib Spectrosc 55:216–223CrossRefGoogle Scholar
  15. 15.
    Little DP (2014) Authentication of Ginkgo biloba herbal dietary supplements using DNA barcoding. Genome 57:1–4CrossRefGoogle Scholar
  16. 16.
    United States Pharmacopoeia and National Formulary (USP37-NF32) (2014) United States Pharmacopeial Convention, Rockville, MDGoogle Scholar
  17. 17.
    Second Supplement to United States Pharmacopoeia and National Formulary (USP37-NF32) (2014) United States Pharmacopeial Convention, Rockville, MDGoogle Scholar
  18. 18.
    Gray DE, Upton R, Chandra A, Porter A, Harris RK (2006) Quantitative analysis of flavonol glycosides in Ginkgo biloba: a comparison of two analytical methods. Phytochem Anal 17:56–62CrossRefGoogle Scholar
  19. 19.
    Calderón-Montaño JM, Burgos-Morón E, Pérez-Guerrero C, López-Lázaro M (2011) A review on the dietary flavonoid kaempferol. Mini Rev Med Chem 11:298–344CrossRefGoogle Scholar
  20. 20.
    Gevrenova R, Kitanov G, Ilieva D (2007) Ontogenetic and seasonal variation in the flavonoid composition of Sophora japonica cultivated in Bulgaria. Pharm Biol 45:149–155CrossRefGoogle Scholar
  21. 21.
    Chu Q, Fu L, Wu T, Ye J (2005) Simultaneous determination of phytoestrogens in different medicinal parts of Sophora japonica L. by capillary electrophoresis with electrochemical detection. Biomed Chromatogr 19:149–154CrossRefGoogle Scholar
  22. 22.
    Liu JS, Tiu CM, Huang MF (1980) Study on the active constituents of Sophora japonica L. Chin Trad Herb Drugs 11:145–146Google Scholar
  23. 23.
    Xie Z, Lam S, Wu J, Yang D, Xu X (2014) Chemical fingerprint and simultaneous determination of flavonoids in Flos Sophorae Immaturus by HPLC-DAD and HPLC-DAD-ESI-MS/MS combined with chemometrics analysis. Anal Methods 6:4328–4335CrossRefGoogle Scholar
  24. 24.
    Kite GC, Veitch NC, Boalch ME, Lewis GP, Leon CJ, Simmonds MSJ (2009) Flavonol tetraglycosides from fruits of Styphnolobium japonicum (Leguminosae) and the authentication of Fructus Sophorae and Flos Sophorae. Phytochemistry 70:785–794CrossRefGoogle Scholar
  25. 25.
    British Pharmacopoeia (2012) British Pharmacopoeia Commission. The Stationary Office, LondonGoogle Scholar

Copyright information

© Springer-Verlag Berlin Heidelberg 2015

Authors and Affiliations

  • Bharathi Avula
    • 1
  • Satyanarayanaraju Sagi
    • 1
  • Stefan Gafner
    • 2
  • Roy Upton
    • 3
  • Yan-Hong Wang
    • 1
  • Mei Wang
    • 1
  • Ikhlas A. Khan
    • 1
    • 4
    Email author
  1. 1.National Center for Natural Products Research, Research Institute of Pharmaceutical SciencesThe University of MississippiUniversityUSA
  2. 2.American Botanical CouncilAustinUSA
  3. 3.American Herbal PharmacopoeiaScotts ValleyUSA
  4. 4.Division of Pharmacognosy, Department of BioMolecular Sciences, School of PharmacyThe University of MississippiUniversityUSA
